Nexgrill 810-0018 User manual

OUTDOOR CHARCOAL GRILL

MODEL #810-0018

•This instruction manual contains important information necessary for the proper

assembly and safe use of the appliance.

•Read and follow all warnings and instructions before assembling and using the

appliance.

•Keep this manual for future reference.

Questions, problems, missing parts? Before returning to your retailer, call our customer service

department at UK:02392-322880, 8 a.m.-5 p.m. Monday - Friday.

SERIAL # ____________________ MFG. DATE _____________ PURCHASE DATE: ____________

19000401A0

WARNING

Do not burn more than 10lbs of charcoal in this unit at one time.

Keep a fire extinguisher nearby at all times.

This grill is for outdoor use only, in well-ventilated areas.

The use of alcohol, prescription or non-prescription drugs may impair the user’s ability

to properly assemble and safely operate this unit.

Use caution when lifting and moving the unit to avoid back strain or back injury. Two

people are recommended to lift or move the unit. Do not move the unit while it is in use.

DO NOT operate the unit near or under flammable or combustible materials such as

decks, porches or carports. A minimum clearance of 36 in. (92cm) is required from all

combustible materials. DO NOT operate the unit under overhead construction or

combustible materials. 2

Table of Contents

Assembly Instructions . . . . . . . . . . . . . . . . . .

Lighting instruction . . . . . . . . . . . . . .. . . . . .

Operating and cooking instructions. . . . . . . .

Proper care & maintenance . . .. . . . . . . . . . .

Ordering parts . . . . . . . . . . . . . . . . . . .

Limited warranty . . . . . . . . . . . . . . . .

10-21

23-24

Safety Instruction . . . . . . . . . . . . . . . . . . . . .

Hardware Contents . . . . . . . . . . . . . . . . .

Preparation . . . . . . . . . . . . . . . . . . . .

Packaging Contents ………………………..

Exploded View . . . . . . . . . . . . . . . . . . . . . . . .

Part List . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2-3

5-6

8-9

Safety Instruction

ATTENTION: This barbecue will

become very hot while in use. Do not

move it during operation.

Do not use indoors.

CAUTION: Do not use spirit, petrol or

comparable fluids for lighting or re-lighting!

WARNING: Keep children and pets away.

WARNING

This product is not to be used as a heater.

Operate the unit on a stable, level, non-flammable surface such as asphalt, concrete or

solid ground. DO NOT operate the unit on flammable material such as carpet or a wood

deck.

Use caution when assembling and operating this unit to avoid cuts and scrapes from

edges.

DO NOT use this product in a manner other than its intended purpose. It is NOT

intended for commercial use. It is not intended to be installed or used in or on a

recreational vehicle and/or boats.

DO NOT Store this unit near gasoline or other combustible liquids or where other

combustible vapors may be present.

DO NOT store or operate this product in an area accessible to children or pets. Store

this unit in a dry, protected location.

DO NOT leave the unit unattended while in use.

DO NOT leave hot ashes unattended until the grill cools completely.

DO NOT move the unit while in use or while ashes are still hot. Allow the unit to cool

completely before moving or storing.

NEVER use gasoline or other highly volatile fluids as a starter.

Always wait for any charcoal flames to subside before placing food on cooking grid.

Dispose of cold ashes by wrapping them in a heavy-duty aluminum foil and placing in a

noncombustible container. Make sure that there are no other combustible materials in

or near the container.

Allow the unit to cool completely before conducting any routine cleaning or

maintenance.

Safety Instruction

Failure to comply with these instructions could result in a fire or explosion that

could cause serious bodily injury, death, or property damage.

Combustion by products produced when using this product contain chemicals

known to the States of California to cause cancer, birth defects, or other reproductive

harm.

Your grill will be very hot. Never lean over the cooking area while using your grill.

Do not touch cooking surfaces, grill housing, lid or any other grill parts while the grill

is in operation, or until the gas grill has cooled down after use.

Preparation

Before beginning assembly, make sure all parts are present. Compare parts with package contents list and

diagram above. If any part is missing or damaged, do not attempt to assemble the product. Contact customer

service for replacement parts.

•Tools required for assembly (not included).

-Phillips Screwdriver

-Wrench

• Note: The grill right and left sides are on your right and left as you face the front of the grill.

Phillips Screwdriver Wrench

Hardware Contents

101

Chimney lid springHH

514

Flat washer for utensil hooks

514

ST4.2 x 10-mm Self-tapping screws

Item Description Size Extra hardware Quantity

AA 1/4-in. x 15-mm Truss head screws with locking

washers 28 2 30

5/32-in. x 10-mm Truss head screws with locking

washers 16 2 18

1/4 –in. nuts 51 6

DD 1/4- in. x 15-mm stage screws 41 5

5/32-in. x 10-mm Flat Head Screws

415

FF ¼-in. Flat washers 25 227

Package Contents

A. Bottom panel-1 pc B. Right cart leg, front-1pc C. Right cart leg, back--

---1 pc D. Left cart leg, front--1

E. Left Cart leg, back-1 pc F. Door iron piece-1 pc G. Swivel caster-1 pc H. Swivel caster

with brake-1 pc

I. Stationary caster-2 pcs J. Side panel, left -1 pc K. Side panel, right -1 pc L. Back panel - 2 pcs

M. Cart frame - 1 pc N. Cart central panel – 1 pc O. Cart top panel – 1 pc P. Door, left – 1 pc

Q. Door, right – 1 pc R. Door hinge plate, left-

1pc

S. Door hinge plate, right

–1pc T. Charcoal ash tray- 1

Package Contents

V. Side shelf support

bracket A -2pcs W. Side shelf support

bracket B -2pcs X. Side shelf trim piece,

left-1 pc

Y. Side shelf trim piece,

right-1 pc Z. Side shelf hook-4pcs AB. Side shelf, left-1 pc AC. Side shelf, right-1 pc

AD. Charcoal Chimney -1 pc AE. Chimney lid -1 pc AF. Warming rack -1 pc AG. Charcoal pan

control knob -1 pc

AH. Cooking grid with hole -

3 pcs AI. Cooking grid lifter -1 pc AJ. Firebox assembly ----

---1 pc

U. Charcoal ash tray

handle assembly– 1 pc

Explode view

02 03

09 10

12 13

20 19

39 27

2829

53 52

37 55

Part List

No. Part (Description) Warranty

coverage QTY No. Part (Description) Warranty

coverage QTY

1 Main lid 1 1 27 Side shelf support bracket B 1 2

2 Main lid hinge 1 2 28 Side shelf stage screw 1 8

3 Chimney lid 1 1 29 Side shelf hook 1 4

4Charcoal Chimney 1130Side shelf, left 1 1

5 Temperature gauge 1 1 31 Charcoal pan 1 1

6Temperature gauge

housing 1132

Charcoal pan support

bracket 12

7Charcoal ash tray handle

assembly 1 1 33 Charcoal pan support 1 2

8 Main lid handle seat, left 1 1 34 Charcoal pan control knob

pin assembly 12

9 Main lid handle tube 1 1 35 Charcoal pan adjustment

assembly 11

10 Main lid handle seat, right 1 1 36 Charcoal ash tray 1 1

11 Warming rack 1 1 37 Door handle assembly 1 2

12 Cooking grid lifter 1 1 38 Back panel 1 2

13 Cooking grid with hole 1 3 39 Cart top panel 1 1

14 Charcoal pan support

bracket with pin 1 2 40 Swivel caster with brake 1 1

15 Side shelf trim piece, right 1 1 41 Swivel caster 1 1

16 Side shelf, right 1 1 42 Bottom panel 1 1

17 Charcoal bowl assembly Non-

replaceable 1 43 Left cart leg, back 1 1

18 Main control panel 1 1 44 Side panel, left 1 1

19 Ventilation adjustment

bracket 1 1 45 Left cart leg, front 1 1

20 Ventilation door screw pin

assembly 1246

Right cart leg, back 11

21 Logo 1 1 47 Side panel, right 1 1

22 Ventilation door control

knob 1 1 48 Right cart leg, front 1 1

23 Ventilation panel 1 1 49 Door magnet 1 2

24 Charcoal pan control knob 1 1 50 Cart frame 1 1

25 Side shelf support bracket

A1 2 51 Cart central panel 1 1

26 Side shelf trim piece, left 1 1 52 Stationary caster 1 2

Part List

11Grill cover11Door hinge plate, left56

No. Part (Description) Warranty

coverage QTY No. Part (Description) Warranty

coverage QTY

53 Door, left 1 1 57 Door iron piece 11

54 Door, right 11 KD assembly hardware pack 1 1

55 Door hinge plate, right 1 1 Manual 1 1

Assembly Instructions

Fig.1

16x AA

Fig. 2

Step 2. L shape bracket assembly

a). Loosen, but do not remove the screws that are

pre-assembled on the bottom panel (A), align

the holes on the bottom panel (A), then attach

the L shape bracket (F) onto the bottom panel

(A) by aligning the holes.

b). Tighten the two screws that were

loosened above. As shown in Fig. 2.

Step 3. Cart leg assembly

Note: The back legs are the two that have 4 side

screws on the inside of each leg and the front legs

have two screws the face to the back of the grill

for attaching the side panels.

a). Loosen, but do not remove the 4 screws that

are pre-assembled on the bottom panel (A),

align the holes on the left cart leg, front (D) and

left cart leg, back (E), then place the cart legs

onto the bottom panel by aligning the screws

that were loosened in the bottom panel (A) as

shown in Fig. 3.

b). Tighten the screws that were loosened above.

Fig. 3

Tool Required: Philips Screwdriver

1. Caster Assembly

a). Mount the casters onto the bottom panel (A) using

sixteen 1/4-in. x 15-mm truss head screws with

locking washers (AA) and sixteen ¼-in flat washers

(FF).

b). The swivel caster with brake (H) should be

positioned under the left rear of the cart bottom

and the swivel caster (G) should be positioned

under left front as shown in Fig. 1.

d). The two stationary casters (I) should be positioned

under the right side.

e). Turn over the bottom panel for assembling casters.

16x FF
