NEUTRIK EtherCON TOP User manual

Cut cable end approx. 45°.

Slide the bushing over the cable.

To ease the boot assembly apply some

cable pulling lubricant to the cable ends.

ASSEMBLY INSTRUCTION

etherCON

TOP NE8MX-TOP

, IP65 and UL50ERuggedized RJ 45 Data Connector

Page 1BDA 547 V2

45°

1STANDARD CABLE ASSEMBLY

13& STANDARD ASSEMBLY OF etherCON CONNECTOR

2CABLE & BOOT ASSEMBLY WITH INSERTION TOOL

Position Insertion Tool ontothe the

cable.

Wet the tip with mounting fluid.

23& WITH ASSESSORIES:

CABLE & BOOT ASSEMBLY WITH INSERTION TOOL.

ITX-TOP: Cable insertion tool to guide the cable into the boot.

PIP65 RATED AND UL50E APPROVED.

MOUNTING VERSIONS

Slide the cable with the tool throught the

boot.

Remove the tool.

Assembl the RJ45 plug on the cable.e

Cut off release tab of RJ45 plug.the

Put chuck onto the cable.the

Align the opening with the contact side.

Position the RJ45 in the chuck.

Attention:

RJ45 must be straight.

Special versions must engage in the

inner recess of the chuck.

Page 2

STANDARD

VERSION

SPECIAL

VERSION

etherCON NE8MX-TOP

3ASSEMBLY RJ45 PLUG AND CONNECTOR

BDA 547 V2

Position bushing onto chuck.the the

Slide boot to thethe unit (insert and ) in

housing and tighten the bushing.

Attention:

Screw the bushing to the end of the thread.

CAUTION:

There is no overlap allowed.

www.neutrik.com

NEUTRIK AG T: F:LI +423 / 237 24 24 +423 232 53 93/

NEUTRIK USA Inc. T: F:USA +1 704 / 972 3050 +1 704 438 9202/

NEUTRIK UK Ltd.

() T: F:UK +44 1983 / 811441 +44 1983 811 439/

NEUTRIK Vertriebs GmbH T: F:DE/NL/AT/DK +49 8131 / 280 890 +49 8131 280 830/

NEUTRIK France FR T: F:+33 1 4131 6750 +33 1 4131 0511//

NEUTRIK Tokyo Ltd. JP T: F:+81 3 3663 4733 +81 3 3663 4796//

NEUTRIK Hong Kong Ltd. T: F:HK +852 2687 6055 +852 2687 6052//

NEUTRIK India Pvt. Ltd. IND T: F:+ +91 22 26163 54091/982 05 43 424 /

II ©® ®

Page 3

etherCON NE8MX-TOP

0.0 mm

Find more etherCON®

details on

www.neutrik.com.

STANDARD

VERSION

SPECIAL

VERSION

PFINISHED etherCON®

ITX-TOP TOOL:

Find more details on

www.neutrik.com/product/

itx-top
