Netopia 45413 User manual

Version 2.2

DSL Equipment Installation Guide

Netopia45413 Router

Installation Guide for Customer Self Install, Windows 9x/ME/NT/2000/Mac Page 2

Table of Contents

Follow Steps 1 through 5 to complete the DSL Equipment Installation

Step 1: Verify Your System Requirements and Documents 3

Step 2: Verify the Contents of Your DSL Equipment Kit 4

Step 3: Install a Telephone Filter on Every Telephone Line 5

Step 4: Install the Netopia® DSL Router 7

Step 5: Configure Your Computer

Windows

95 and 98 Dynamic Configuration 8

Windows

95 and 98 Static Configuration 11

Windows

2000 Dynamic Configuration 15

Windows

2000 Static Configuration 17

Windows

NT Dynamic Configuration 19

Installing TCP/IP for Windows 22

Macintosh DHCP Configuration 26

Macintosh Static Configuration 29

Customer Support: 1-877-611-6342

IMPORTANT NOTE: This guide portrays the typical steps for the installation process. Please

follow the instructions. Some computer or network configurations may cause software windows

to appear that are not depicted in this guide. Please read and follow the instructions on those

screens to continue the installation process. Verify that you are installing your DSL equipment

AFTER the “Phone Company Commit Date” given to you when you ordered your DSL Internet

Service. MegaPath Networks Inc. and its affiliates have no responsibility for any personal injury

or property damage which may result from your installation of DSL Equipment as discussed in

this guide. MegaPath Networks and its affiliates specifically disclaim any liability for such injury or

damage. By proceeding with this installation, you assume all risk of personal injury or property

damage. Please consult the documentation provided by your PC vendor to identify any impact on

your warranty.

Installation Guide for Customer Self Install, Windows 9x/ME/NT/2000/Mac Page 3

Welcome to MegaPath DSL service. You will find everything you need to install your

DSL service in this kit. It is important to carefully and exactly follow the step-by-step

instructions for your operating system. Note: Do NOT use the instructions that came

with your Netopia.

Step 1: Verify Your System Requirements and Documents

This MegaPath DSL kit was designed for installation on computers operating with Microsoft

Windows

2000, Windows

ME, Windows98, Windows95, Windows

NT, and Macintosh computers with

operating system version 8.2 and higher.

PC System Requirements: You must also meet the requirements listed below in order to successfully

complete the installation of your MegaPath DSL kit.

o PC with a Pentium-class processor

o CD-ROM Drive

o 166 MHz

o 25 Mb free disk space

o 32 Mb RAM

o Built-in Network Interface Card; consult your system’s documentation for details. Please note:

Many systems already have a Network Interface Card installed. If your system already has

a card installed, and it is not currently in use, you DO NOT need to install an additional NIC

Card.

Macintosh System Requirements:

o System 8.2 or higher

You must install this kit AFTER the “Phone Company Commit Date” given to you when you ordered your

DSL Internet Service from MegaPath.

Installation Guide for Customer Self Install, Windows 9x/ME/NT/2000/Mac Page 4

Netopia Router

Step 2: Verify the Contents of Your DSL Equipment

1-2 way

Phone

litter 4-Phone Line

Filters

Power

Cord

1-Standard

Phone Cord

Ethernet/Data

Cable

Netopia

Router

Serial Port

Cable

Ethernet/Data

Cable

Serial Port

Cable

Phone

Cord

Installation Guide for Customer Self Install, Windows 9x/ME/NT/2000/Mac Page 5

Step 3: Install a Telephone Filter on Every Telephone Line

IMPORTANT: Install filters on every phone jack on your DSL line that

will be used for an analog device to prevent interference from the

digital signal provided by DSL service. A filter is required between all

phones, answering machines, fax machines, Caller ID units or analog

routers and the phone jack for the DSL line. Connect the phone line

connected to your router to the side of the filter labeled “ADSL HPN”

a. Desktop Phones and Analog Devices

Phone

Line

Jack

Phone Line

Filter

Phone Cord Phone or Analog

Equipment (Answering

Machine, Fax, Caller ID

Unit, etc.)

b. Wall Mounted Phones

Wall Mounted

Phone Jack Wall

Mounted

Phone Filter Wall

Mounted

Phone

*Some wall-mounted phones connect

directly to the filter and will not need

this cord.

Installation Guide for Customer Self Install, Windows 9x/ME/NT/2000/Mac Page 6

c. DSL Router and Analog Device on the Same Jack

1. 1. Connect the filter to

your phone jack.

2. A filter is required

between all phones,

answering machines,

fax machines, Caller ID

units or analog routers

and the phone jack for

the DSL line.

3. Connect the phone

line connecter to your

router to the side of

the filter labeled “ADSL

HPN”.

d. DSL Router Running Directly from the Wall Jack with No Shared Devices

1. Connect the router to

your phone jack.

2. No filter is required if

the Netopia does not

share the line with an

analog device.

e. A NIC (Ethernet) card is required to complete this installation. If you do not have an available NIC

card, contact your computer vendor or authorized technician to arrange for installation.

NOTE: The NIC card must be properly installed before beginning the installation of the DSL kit

components.

Warnings and Cautions:

Refer to your PC manual for instructions on opening your PC to install

new hardware. Follow all safety warnings and precautions as specified

by your PC manufacturer.

In Addition:

• Back up any important files on your hard drive.

• Turn off your PC and unplug the power cord.

• Unplug all cables connecting your PC to the peripheral devices.

Note the port location of each device so you can easily reconnect

the cables later.

Installation Guide for Customer Self Install, Windows 9x/ME/NT/2000/Mac Page 7

Step 4: Install the Netopia45413 DSL Router

Insert the connector

from the power

adapter to the power

port, and plug the

other end into an

electrical outlet.

Connect one end of the

phone cord to the jack

labeled “DSL” on your

router, and the other

end to the side of the

filter labeled “ADSL

HPN”. This is not

necessary if the router

does not share the jack

with another analog

device such as a phone,

answering machine, fax

machine, etc. Use Serial Port cable to transfer

data between your Router and the

PC if you wish to reconfigure the

Router. (This step is not needed

for normal installation. Call

MegaPath Networks at 1-877-

611-6342 before you start to

reconfigure the Router.)

Plug one end

of the Ethernet

cable into one

of the empty

ports labeled

Ethernet.

Connect the other end of the Ethernet cable to the

Ethernet port on your computer.

Installation Guide for Customer Self Install, Windows 9x/ME/NT/2000/Mac Page 8

PC Environment

Step 5: Configuring Your Computer

Windows® 95 and Windows® 98 Dynamic Configuration (Recommended)

Before you use your new DSL connection, you must have TCP/IP set up on your computer. If you

do not see TCP/IP listed in your Network Components, go to page 22 and follow the instructions

for installing TCP/IP.

Windows95 and Windows98 Dynamic Configuration (Recommended)

1. Find the Network Neighborhood icon on your desktop. Right click on Network Neighborhood and select

Properties. Once highlighted, left click once on your mouse.

2. Highlight TCP/IP and click Properties. If you do not see TCP/IP in the list, go to the section in this guide titled

Installing TCP/IP.

Installation Guide for Customer Self Install, Windows 9x/ME/NT/2000/Mac Page 9

3. Select the IP Address tab. Click Obtain an IP Address automatically.

4. Click on the Gateway tab. If the box under Installed Gateways contains any IP addresses, highlight the IP

addresses and click Remove.

Installation Guide for Customer Self Install, Windows 9x/ME/NT/2000/Mac Page 10

5. Click on the DNS Configuration tab. Click Disable DNS. Click OK.

6. When prompted, reboot the computer. Click OK.

7. To check the success of your setup, open a web browser and visit www.megapath.net.While there, you will find

more information about additional services as well as setup and other support information.
