NetComm NP2008HS User manual

networking

Build or extend your network with ease

Build or extend a local Ethernet network with this Plug & Play network switch

for Windows®95/98/2000/ME/XP, Linux and Mac S 8/9/X

Automatically detects and sets the optimum data rate

Store & Forward technology ensures high-performance and error-free transfers

8-Port SmartSwitch

8 x 10/100Mbps

Ethernet Ports

10/100Mbps AUTO-NEGOTIATION ETHERNET SWITCH

NP2008HS

NETC MM LIMITED ABN 85 002 490 486 • 2-6 Orion Road, L NE COVE, NSW, 2066 • phone 02 9424 2070 • fax 02 9424 2010 • email [email protected]

www.netcomm.com.au

• 8 x 10/100Mbps Auto-Negotiation Ethernet ports

• Simple Plug & Play

• Automatically detects and sets optimum data rate

• Store & Forward switching method

• Windows® 95/98/2000/Me/XP, Linux, Mac S

8/9/X

• Supports Auto-MDI/MDI-X

• Full/half duplex transfer mode for each port

• Wire speed reception and transmission

• Integrated address Look-Up Engine, supports 1K

absolute MAC addresses

• Physical layer port Polarity Detection and

Correction function

• Comprehensive front-panel diagnostic LEDs

• IEEE 802.3x flow control for full-duplex

• Back pressure flow control for half-duplex

KEY FEATURES

8-Port SmartSwitch

NP2008HS

8-Port SmartSwitch

Trademarks and registered trademarks are the property of NetComm Limited or their respective owners. Specifications are subject to change without notice. Images shown may vary slightly from the product.

Technical Specifications

Package Contents

Your Netcomm dealer: NetComm is Australia’s dynamic data communications and

networking solutions provider. For more information on this and

other NetComm products, please visit www.netcomm.com.au

NetComm Limited BN 85 002 490 486

PO Box 1200, Lane Cove NSW 2066 ustralia.

HONE (02) 9424 2070 • FAX (02) 9424 2010

www.netcomm.com.au • EMAIL [email protected]

Trademarks and registered trademarks are the property of NetComm

Limited or their respective owners. Specifications are subject to change

without notice. Images shown may vary slightly from the product.

SPECIFICATIONS

Filtering Address Table 1K entries per device

ower Adaptor 7.5VDC/1

ower Consumption 2.8 watts (max.)

Dimensions 125 ( ) x70 (d) x 30 (h)

Temperature

OPER TING: 0~ 40C

STOR GE: -10 ~ 70C

Humidity

OPER TING: 10% ~ 90% RH

STOR GE: 5% ~ 90% RH

Emission

FCC Class B, CE mark Class B, VCCI-B. C-Tick (N367)

SPECIFICATIONS

Standard

IEEE 802.3 10B SE-T

IEEE 802.3u 100B SE-TX

Network Media

ETHERNET: UTP Cat. 3,4,5

E ST ETHERNET: UTP Cat. 5

rotocol CSM /CD

Topology Star

Number of orts

8 x 10/100Mbps uto-MDIX with RJ-45 connector

Network Data Transfer Rate

ETHERNET:10Mbps (H LF-DUPLEX)

20Mbps (FULL-DUPLEX)

F ST ETHERNET:100Mbps (H LF-DUPLEX)

200Mbps (FULL-DUPLEX)

Diagnostic LEDs

PER UNIT: Power(1Green LED)

PER PORT: Link/ ctivity

SPEED:(100Mbps) NetComm NP2008HS 8-Port SmartSwitch

Power Pack N367

PACKAGE CONTENTS

1YEAR

WARRANT Y

C NDITI NS APPLY
