NEFF U1442B0GB Safety guide
How to connect up,
build-in, set up, use and
look after your
U1442 oven
NEFF (UK) Ltd
2
Table of contents
Important Information . . . . . . . . . . 3
Packaging and old appliances . . . . . 3
Before installation . . . . . . . . . . . . . . 4
Safety information . . . . . . . . . . . . . . 4
Reasons for damage . . . . . . . . . . . . 5
Your new cooker . . . . . . . . . . . . . . 6
The control panel . . . . . . . . . . . . . . . 6
Function selector – main oven . . . . . 6
Temperature selector – main oven . . 7
Temperature selector – mini oven . . 7
Function selector – mini oven . . . . . 7
Press-down switches . . . . . . . . . . . 8
Shelf positions . . . . . . . . . . . . . . . . . 8
Accessories . . . . . . . . . . . . . . . . . . 9
Before using your Appliance
for the first time . . . . . . . . . . . . . . . 10
Preliminary cleaning . . . . . . . . . . . . . 10
Initial burn-in . . . . . . . . . . . . . . . . . . 10
Subsequent cleaning . . . . . . . . . . . . 10
Time of day . . . . . . . . . . . . . . . . . . . 10
Electronic clock . . . . . . . . . . . . . . . 11
The control panel . . . . . . . . . . . . . . . 11
Minute timer . . . . . . . . . . . . . . . . . . 11
Automatic timer . . . . . . . . . . . . . . . . 12
Special functions . . . . . . . . . . . . . . . 13
Description of Oven Features . . . . 14
Switching the oven ON and OFF . 16
Inhaltsverzeichnis
Baking – main oven . . . . . . . . . . . . 18
Cooking Tips and Helpful Hints . . . . 19
Roasting – main oven . . . . . . . . . . 20
Grilling – main oven . . . . . . . . . . . . 22
Circo-roasting . . . . . . . . . . . . . . . . . 23
Surface grilling . . . . . . . . . . . . . . . . . 23
Roasting – mini oven . . . . . . . . . . . 24
Grilling – mini oven . . . . . . . . . . . . 25
Surface grilling . . . . . . . . . . . . . . . . . 25
Defrosting and Cooking . . . . . . . . 26
Defrosting with circotherm . . . . . . . . 26
Cleaning and Care . . . . . . . . . . . . . 28
Important cleaning basics . . . . . . . . 28
Catalytic oven surface . . . . . . . . . . . 30
Oven Cleaning . . . . . . . . . . . . . . . . . 31
Removing/installing
the oven door . . . . . . . . . . . . . . . . . 32
Shelf supports . . . . . . . . . . . . . . . . . 33
Service and Repair information . . 34
Trouble-shooting Guide . . . . . . . . . 35
Assembly instructions
For the installer
and kitchen expert
Important installation notes . . . . . 37
Installation of the built-in oven . . . 38
3
Important information
Before using your new appliance, please read these
Instructions for Use carefully. They contain important
information concerning your Personal safety as well
as on use and care of the appliance.
The Instructions for Use apply to several versions of
this appliance. Accordingly, you may find
descriptions of individual features that do not apply
to your specific appliance.
Please keep the operating and installation
instructions in a safe place; this important
documentation may also be of use to a possible
subsequent owner.
Packaging and Your new appliance was protected by suitable
old appliances packaging while it was on its way to you. All materials
used for this purpose are environmentally friendly and
can be recycled. Please make a contribution to
protecting the environment by disposing of the
packaging appropriately.
Old appliances are not worthless rubbish.
Environmentally-conscious recycling can reclaim
valuable raw materials.
Before disposing of your old appliance, please make
sure that it is unusable, or label it with a sticker
stating „Caution, scrap”.
This appliance is labelled in accordance with
European Directive 2002/96/EG concerning used
electrical and electronic appliances (waste electrical
and electronic equipment – WEEE). The guideline
determines the framework for the return and
recycling of used appliances as applicable
throughout the EU.
Up-to-date information on how to dispose of your
old appliance and the packaging from the new one
can be obtained from your retailer or local authority.
4
Before installation
Transport damage Check the appliance after unpacking it. Do not
connect the appliance if it has been damaged in
transport.
Electrical connection The cooker may only be connected by an approved
specialist. Losses resulting from damage caused by
incorrect connection will invalidate warranty claimes.
Safety information This appliance is intended for domestic use only.
Only use the cooker for food preparation.
Hot oven Open the oven door carefully. Hot steam may escape.
Never touch the internal surfaces of the oven or the
heating elements. There is a risk of burning.
Children must be kept at a safe distance from the
appliance.
Never store combustible items in the oven.
Risk of fire. Never place flammable objects onto the
hot plates. Fire hazard!
Never place cables of electronic devices onto the hot
plates.
Never clamp leads of electrical appliances in the hot
oven door. The insulation on the leads could melt.
There is a risk of short-circuiting.
Remove all packaging remnants, e.g. polystyrene
parts, from the oven.
Repairs Incorrectly done repairs are dangerous. There is a
risk of electrocution.
Repairs may only be carried out by after-sales
service technicians who have been fully trained by
BSH.
If there is a fault, switch off the oven fuse at the fuse
box.
Call the after-sales service.
5
Reasons for
damage
Baking tray, aluminium foil Do not place the baking tray on the oven floor.
or dishes on the oven floor Do not cover it with aluminium foil.
Do not place dishes on the oven floor.
This will cause heat accumulation. The baking and
roasting times will no longer be correct and the
enamel will be damaged.
Slide-in accessories To avoid damage, insert slide-in accessories
carefully.
Baking paper If using hot air functions *, do not place
greaseproof paper loosely in the oven (e.g. when
heating the oven).
The hot-air fan could draw in the paper which may
damage the heater and fan.
Water in the oven Never pour water directly into a hot oven.
This could damage the enamel.
Fruit juice When baking very moist fruit cakes, do not put too
much on the baking sheet. Fruit juice dripping from
the baking sheet leaves stains that cannot be
removed.
It is recommended that you use the deeper universal
pan.
Cooling with the oven door Only leave the oven to cool with the door closed. Do
not allow anything to become trapped in the oven
door. Even if you only leave the oven door open
slightly, the fronts of adjacent units may become
damaged over time.
Very dirty oven seal If the oven seal is very dirty, the oven door will no
longer close properly when the oven is in use.
The fronts of adjacent units could be damaged.
Keep the oven seal clean.
Using the oven door as a Do not stand or sit on the oven door.
seat
Care and cleaning Do not use high-pressure cleaners or steam jets.
Electronic timer controls
6
Your new cooker
Here you will learn more about your new oven. The
control panel and its switches and indicators are
explained here. The heating modes and the
accessories included with your oven will be
explained here.
The control panel
Main oven
Function selector
Settings
*
Circotherm
/
Top/bottom heat (conventional heating system)
(
Surface grilling, large area grill
)
Surface grilling, small area grill
,
Circo-roasting
&
Circotherm intensive
.
Bottom heat
e
Defrost
$
Oven light
Mini ovenMain oven
Temperature selector
with control lamp
Temperature selector
with control lamp
Function selector
7
Mini oven
Temperature selector
Settings
50 –275
Temperature in °C.
}Oven Cleaning
Function selector Use the function selector to select the type of
heating for the oven.
Settings
$
Oven light
/
Top/bottom heat
(conventional heating system)
(
Large area grill
)
Small area grill
Temperature selector
Settings
50 –275
Temperature in °C.
}Oven Cleaning
8
Press-down To engage and disengage, depress the switch,
switches making sure that it is in OFF position.
Shelf positions
Mini oven Your oven features 2 shelf positions.
The shelf positions are counted from bottom to top.
The numbers are marked in the oven.
Main oven Your oven features 4 shelf positions. The shelf
positions are counted from bottom to top.
The numbers are marked in the oven.
When using hot air function, do not use shelf
position »2«, in order not to block air circulation.
9
Accessories Your appliance is supplied with:
Universal pan with wire shelf 3 Wire shelves
Additional accessories can be obtained from a specialist dealer.
Before ordering, please check the Neff sales literature to
confirm which of the following items are available in the UK: Order no.
Note:
The baking tray or universal pan may distort while the oven is operating. This is
caused by major temperature differences on the utensil. These differences may occur
if only one part of the utensil was covered or if deep-frozen food, e.g. pizza, was
placed on the utensil.
The distortion will subside again during baking, roasting or grilling.
Universal pan, non-stick
Soufflé pan
Baking tray, aluminium
Baking tray, enamelled
Baking tray, non-stick
Wire shelf, high/low
Wire shelf, close mesh
Upgrade set Clou, 3 pieces for main oven
Upgrade set Clou, 4 pieces for main oven
Pizza stone
Universal pan Z 1232 X0
Z 1233 X0
Glass pan Z 1262 X0
Z 1272 X0
Z 1332 X0
Z 1342 X0
Z 1343 X0
Pizza tray Z 1352 X0
Z 1432 X0
Z 1442 X0
Z 1742 X0
Z 1752 X0
System steam cooker N 8642 X0 EU
Z 1912 X0
Universal oval roaster enamelled Z 9930 X0
10
Before using your appliance
for the first time
Preliminary Ta ke the accessories out of the oven.
cleaning Remove all packaging remnants, e.g. polystyrene
parts, from the oven.
1. Clean the appliance exterior with a soft
moistened cloth.
2. Remove the shelf supports from the oven.
3. Clean the oven and the accessories with a hot
detergent solution.
Please observe the operating instructions
furnished with the hob.
Initial burn-in Before using the appliance for the first time, you
must set the time on the electronic clock.
Preheat the empty oven for about 30 minutes.
Select heat for the main and mini oven at a setting of
190 °C.
Subsequent cleaning Clean the oven with a hot detergent solution.
Install the shelf supports.
Time of day After connecting to the mains, or after a power
Setting the time failure, the display 0:00 will blink.
Press the >button and set the current time with
the rotary knob (e.g. 15:00 hours).
To correct the time, press the >button until the
symbol flashes.
Then set the time.
Note: The time cannot be corrected if an automatic
function has been set (see Electronic clock for
cancelling automatic function).
This manual suits for next models
4
Table of contents
Other NEFF Oven manuals
NEFF
NEFF B 1624 Series User manual
NEFF
NEFF B57VS26.0B Operating and maintenance instructions
NEFF
NEFF B57VS26N0B User manual
NEFF
NEFF B45M42.5 User manual
NEFF
NEFF B 1544 Series User manual
NEFF
NEFF U12M42N0GB - annexe 2 User manual
NEFF
NEFF B2ACH7H 0 Series User manual
NEFF
NEFF U14M42W3GB User manual
NEFF
NEFF B95M42N0MK User manual
NEFF
NEFF B1422B0GB Safety guide
NEFF
NEFF U17M52 3GB Series User manual
NEFF
NEFF B1421B2GB Safety guide
NEFF
NEFF B4780N0 User manual
NEFF
NEFF B57CR22G0B User manual
NEFF
NEFF U15M42 0GB Series User manual
NEFF
NEFF B54CR31 0B Series User manual
NEFF
NEFF C28CT26 0B Series User manual
NEFF
NEFF B6ACH7A 0A Series User manual
NEFF
NEFF B57VR22N0B User manual
NEFF
NEFF B48FT74 0B Series User manual
Popular Oven manuals by other brands
Bosch
Bosch HVA531NS0 instruction manual
Electrolux
Electrolux EOF6P46X user manual
Combi
Combi BLODGETT BC142GDS Specifications
AEG
AEG COMPETENCE 311704300 Installation and operating instructions
Falcon
Falcon DOMINATOR PLUS G3106 Series Servicing instructions
Rational
Rational SCC WE 61G installation manual
