National Instruments ELVIS RIO CM User manual
GETTING STARTED GUIDE
NI ELVIS RIO Control Module
This document describes how to begin using the NI ELVIS RIO Control Module.
Safety Guidelines
Operate the NI ELVIS RIO CM only as described in the user documentation.
Caution Do not operate the NI ELVIS RIO CM in a manner not specified in this
document. Product misuse can result in a hazard. You can compromise the safety
protection built into the product if the product is damaged in any way. If the product
is damaged, return it to NI for repair.
Electromagnetic Compatibility Guidelines
This product was tested and complies with the regulatory requirements and limits for
electromagnetic compatibility (EMC) stated in the product specifications. These requirements
and limits provide reasonable protection against harmful interference when the product is
operated in the intended operational electromagnetic environment.
This product is intended for use in industrial locations. However, harmful interference may
occur in some installations, when the product is connected to a peripheral device or test object,
or if the product is used in residential or commercial areas. To minimize interference with
radio and television reception and prevent unacceptable performance degradation, install and
use this product in strict accordance with the instructions in the product documentation.
Furthermore, any changes or modifications to the product not expressly approved by National
Instruments could void your authority to operate it under your local regulatory rules.
Caution To ensure the specified EMC performance, operate this product only with
shielded cables and accessories.
Caution To ensure the specified EMC performance, the length of the cable
connected to the USB device port must be no longer than 3m (10ft) and cable
connected to USB host port must be no longer than 30 m (100 ft).
Caution To ensure the specified EMC performance, only use direct board-to-board
connections to connect myRIO Expansion Port (MXP) connectors.
Preparing the Environment
Caution Clean the NI ELVIS RIO CM with a soft, nonmetallic brush. Make sure
that the device is completely dry and free from contaminants before returning it to
service.
Ensure that the environment in which you are using the NI ELVIS RIO CM meets the
following specifications.
Operating temperature 10 °C to 35 °C
Storage temperature
(IEC 60068-2-1, IEC 60068-2-2)
-20 °C to 70 °C
Operating humidity (IEC 60068-2-78) 10% RH to 90% RH, noncondensing
Storage humidity (IEC 60068-2-78) 10% RH to 90% RH, noncondensing
Maximum altitude 2,000 m
Pollution Degree (IEC 60664) 2
Indoor use only.
Note Refer to the NI ELVIS RIO Control Module Specifications on ni.com/manuals
for complete specifications.
Unpacking the Kit
Caution To prevent electrostatic discharge (ESD) from damaging the device,
ground yourself using a grounding strap or by holding a grounded object, such as
your computer chassis.
2| ni.com | NI ELVIS RIO CM Getting Started Guide
1. Touch the antistatic package to a metal part of the computer chassis.
2. Remove the device from the package and inspect the device for loose components or any
other sign of damage.
Caution Never touch the exposed pins of connectors.
Note Do not install a device if it appears damaged in any way.
3. Unpack any other items and documentation from the kit.
Store the device in the antistatic package when the device is not in use.
Verifying the Kit Contents
Verify that the following items are included in the NI ELVIS RIO CM kit.
Figure 1. NI ELVIS RIO CM Kit Contents
32 4 5
1
1. NI ELVIS RIO CM Device
2. NI LabVIEW 2016 ELVIS RIO Control Software
Bundle
3. Getting Started Guide
4. M4 Mounting Screw (x4)
5. USB 2.0 A-to-B (Angled) Cable
Installing the NI ELVIS RIO CM
What to Use
• Hardware
– NI ELVIS II Series Workstation
– NI ELVIS II Series AC/DC power supply
– USB 2.0 A-to-B (Angled) Cable
– M4 mounting screws
– Computer
• Software
– NI LabVIEW 2016 ELVIS RIO Control Software Bundle
• Tools
– Screwdriver, Phillips #1
NI ELVIS RIO CM Getting Started Guide | © National Instruments | 3
What to Do
Note Refer to the NI ELVIS RIO Control Module User Manual and the NI ELVIS II
Series User Manual on ni.com/manuals to identify ports and connectors.
1. Position the NI ELVIS RIO CM on the NI ELVIS II Series Workstation.
2. Slide the Workstation Interface Connector of the NI ELVIS RIO CM into the Prototyping
Board Connector on the workstation and ease it into place.
3. Secure the NI ELVIS RIO CM to the workstation using two M4 mounting screws.
4| ni.com | NI ELVIS RIO CM Getting Started Guide
Powering Up the NI ELVIS RIO CM
1. Install required software from the NI LabVIEW 2016 ELVIS RIO Control Software
Bundle DVD.
2. Connect the NI ELVIS RIO CM to the NI ELVIS II Series Workstation. Refer to the
Installing the NI ELVIS RIO CM section for more information.
3. Connect the USB Device Port on the NI ELVIS RIO CM to the computer with the USB
cable.
4. Turn on the Workstation Power Switch to power up the NI ELVIS II Series Workstation.
NI ELVIS RIO CM Getting Started Guide | © National Instruments | 5
5. Turn on the Prototyping Board Power Switch to power up the NI ELVIS RIO CM.
6. Launch the Getting Started Wizard from the USB Monitor.
Note The Getting Started Wizard can also be launched through the LabVIEW
Getting Started Window or LabVIEW Project right-click menu.
Tip The USB Monitor pop-up window appears once the NI ELVIS RIO CM is
connected to the computer and powered up.
7. Test the onboard devices with the test panel at the end of the Getting Started Wizard.
Connecting MXP Plants to the NI ELVIS RIO CM
Caution To prevent damage to the MXP plant and MXP connectors, secure the
NI ELVIS RIO CM to the NI ELVIS II Series Workstation using two M4 mounting
screws.
Caution To prevent damage to the NI ELVIS RIO CM and MXP plant, ensure that
the NI ELVIS RIO CM power is turned off before connecting the MXP plant.
1. Position the opening in the MXP plant over the prototyping board mounting bracket on
the NI ELVIS II Series Workstation.
Note For smaller MXP plants that are clear of the prototyping board mounting
bracket, position the MXP plant so that the MXP connectors are aligned.
2. Slide the MXP plant into the MXP connectors on the NI ELVIS RIO CM.
3. Secure the MXP plant to the NI ELVIS RIO CM using two M4 mounting screws.
6| ni.com | NI ELVIS RIO CM Getting Started Guide
Where to Go Next
*This item is also installed with the NI ELVIS RIO Control Toolkit
EXPLORE LEARN CREATE
DISCOVER
Located online at ni.com/manuals
Learn LabVIEW Basics
the application development
environment (ADE)
for your application.
about hardware features
or review device
specifications.
custom applications with
an application programming
interface (API).
NI ELVIS RIO Control
Module User Manual
NI ELVIS RIO Control
Module Specifications
NI ELVIS RIO Control
Module Setup*
NI ELVIS RIO Control
Toolkit Tutorial*
NI ELVIS RIO Control
Module Examples*
Located using the NI Example Finder
Located in the hardware kit
more about your products through ni.com.
Services
ni.com/services
NI Community
ni.com/community
Support
ni.com/support
Software Support
ni.com/info ex8g43
Worldwide Support and Services
The NI website is your complete resource for technical support. At ni.com/support, you have
access to everything from troubleshooting and application development self-help resources to
email and phone assistance from NI Application Engineers.
Visit ni.com/services for NI Factory Installation Services, repairs, extended warranty, and
other services.
Visit ni.com/register to register your NI product. Product registration facilitates technical
support and ensures that you receive important information updates from NI.
NI corporate headquarters is located at 11500 North Mopac Expressway, Austin, Texas,
78759-3504. NI also has offices located around the world. For telephone support in the United
States, create your service request at ni.com/support or dial 1 866 ASK MYNI (275 6964). For
telephone support outside the United States, visit the Worldwide Offices section of ni.com/
niglobal to access the branch office websites, which provide up-to-date contact information,
support phone numbers, email addresses, and current events.
8| ni.com | NI ELVIS RIO CM Getting Started Guide
Refer to the NI Trademarks and Logo Guidelines at ni.com/trademarks for information on NI trademarks. Other product and
company names mentioned herein are trademarks or trade names of their respective companies. For patents covering NI
products/technology, refer to the appropriate location: Help»Patents in your software, the patents.txt file on your media, or the
National Instruments Patent Notice at ni.com/patents. You can find information about end-user license agreements (EULAs)
and third-party legal notices in the readme file for your NI product. Refer to the Export Compliance Information at ni.com/
legal/export-compliance for the NI global trade compliance policy and how to obtain relevant HTS codes, ECCNs, and other
import/export data. NI MAKES NO EXPRESS OR IMPLIED WARRANTIES AS TO THE ACCURACY OF THE INFORMATION
CONTAINED HEREIN AND SHALL NOT BE LIABLE FOR ANY ERRORS. U.S. Government Customers: The data contained in
this manual was developed at private expense and is subject to the applicable limited rights and restricted data rights as set forth
in FAR 52.227-14, DFAR 252.227-7014, and DFAR 252.227-7015.
© 2016 National Instruments. All rights reserved.
378012B-01 Sep16
