My Child IM-151122-V3 User manual
Unicorn Walker
Instruction manual
En 2-11
Fr 13-22
IMPORTANT! READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
This product is intended only for a child who can sit up by itself and until
it is able to walk by itself or weighs more than 12 kg.
BS EN 1273:2020.
IMPORTANT ! LIRE ATTENTIVEMENT ET CONSERVER POUR REFERENCE FUTURE
Ce produit est uniquement destiné aux enfants pouvant s’asseoir par
eux même et jusqu’à ce qu’ils soient en mesure de marcher seul, ou s’ils
pèsent plus de 12kg.
Ce produit a été testé pour répondre à la norme BS EN 1273:2020.
IM-151122-V3
page 2
Safety instructions
Battery disposal
Battery warnings
Only use the recommended batteries observing correct voltage and size.
Always take care to insert your batteries correctly, observing the plus and minus marks
on the battery and appliance.
Do not mix new and used batteries.
Do not mix different types of batteries.
Always remove batteries (whether they are dead or not) if you are not going to use the
product for long periods (as batteries may leak and cause damage).
Never attempt to re-charge ordinary (non-rechargeable) batteries.
Remove rechargeable batteries before attempting to charge them.
Do not short-circuit the supply terminals
Batteries should always be changed by an adult.
Keep batteries out of reach of children.
Children can choke on batteries. If swallowed seek medical advice immediately.
The crossed out wheelie bin symbol indicates that the product
must not be disposed of with other household waste.
Do not treat batteries (old or new) as household waste.
Never dispose of batteries in a re this may cause them to
explode.
Batteries (old or new) should be disposed of by taking them to
a designated collection point or recycling facility.
• Prevent collisions with glass in doors, windows and furniture.
• This product is intended only for a child who can sit up by itself and until it is
able to walk by itself or weighs more than 12 kg.
• This baby walking frame should be used only for short periods of time (e.g. 20
min).
• Do not use the product if any components are broken or missing.
• Do not use accessories or replacement parts other than those approved by
the manufacturer.
• Never use the baby walking frame without the supplied anti-fall blocks
attached.
• Never use the baby walking frame without the supplied wheels attached.
WARNING:
• Never leave the child unattended.
• The child will be able to reach further and move rapidly
when in the baby walking frame:
• Prevent access to stairs, steps and uneven surfaces.
• Guard all res, heating and cooking appliances.
• Remove hot liquids, electrical cables and other potential
hazards from reach.
page 3
Your 3 year warranty
Whilst we make and test our products to the highest standards of durability there’s
always a small chance of a hiccup! Our promise is to repair, replace or refund a MyChild
product that has an identied manufacturing defect from the date of purchase for a full
3 years thereafter at no extra cost.
However, you must register within 28 days of the date of purchase to receive the full 3
years guarantee!
To receive your full guarantee you can register your product by:
visiting https://mychild.co.uk/pages/warranty and complete the warranty form,
or by telephone on 0161 335 2508.
Care and maintenance
• To prolong the life of your nursery product keep it clean and do not leave it in direct
sunlight for extended periods of time.
• Removable fabric covers and trims may be cleaned using warm water with a
household soap or a mild detergent. Allow it to dry fully, preferably away from direct
sunlight.
• If the wheels squeak - use a silicon based spray ensuring it penetrates the wheel and
axle assembly.
• Do not dry clean, or use bleach.
• Do not machine wash, tumble or spin dry, unless the care labelling on the product
permits these methods.
• Non removable fabric covers and trims may be cleaned using a damp sponge with
soap or mild detergent. Allow it to dry completely before folding or storing it away.
• In some climates the covers and trims may be affected by mould and mildew. To
help prevent this occurring, do not fold or store the product if it is damp or wet.
Always store the product in a well ventilated area.
• Always check parts regularly for tightness of screws, nuts and other fasteners - tighten
if required. If any parts are bent, torn, worn or broken please contact Customer
Service.
page 4
Parts checklist
Welcome
Thank you for purchasing the MyChild Unicorn Walker.
Please read the instructions and warnings carefully before use to ensure safe and
satisfactory operation of this product.
Your child’s safety is your responsibility. If you have a query with this product or require
replacement parts, please contact the MyChild Helpline on 0161 335 2508.
Lay out the parts on a soft level surface and compare to the part/xings checklist
below. Do not discard any packaging until you are sure that you have all the parts.
WARNING! Assembly by an adult. Keep away from children until fully assembled. Keep
children clear during assembly as pack contains small parts which may present a
choking hazard.
Contained in your carton are:
NoPart Qty
1 Walker body 1
2 Seat unit 1
3 Musical play tray* 1
4 Footrest pad 1
5 Front wheels 2
6 Rear wheels 2
7 Anti-fall blocks 6
8 Lollipop toy 1
9 Ice cream cone toy 1
10 Spinning toy 1
11 Spinning toy base 1
*Actual style may vary
You will require one Phillips screwdriver
(not supplied).
1 2
3 4
7
9
5 6
108 11
page 5
Opening and closing the baby walker
1. To open: hold either side of the upper
part of the walker and pull upwards to
one of the three height positions. Ensure
the upper part of the walker clicks into
position.
Note: There is a click for each of the three
height positions. The walker is fully open
when you hear the 3rd click.
2. To close: Hold the front of the walker
and at the same time, turn and pull the
locking mechanism forward and lower
the upper part of the walker all the way
down.
3. To adjust the height: The simplest method to adjust the height is to lower the upper
part of the walker all the way down (as above, in step 2) then pull the upper part of
the walker back up so that it clicks into one of the three height positions.
WARNING! NEVER adjust the height when your child is in the walker. DO NOT place your
child in until you have adjusted the height and made sure it is locked in place.
click
page 6
2. Attaching the rear wheels:
With the baby walker still upside down
and fully folded down, insert both rear
wheels into the two round holes on either
corner at the rear of the walker.
Note: Ensure the thin pin (A) goes into the
smaller of the two holes and that the wide
pin (B) goes into the larger hole.
1. Attaching the front wheels:
With the baby walker still upside down
and fully folded down, insert both front
wheels fully into each round hole on
either corner at the front of the walker.
1. Attaching the anti-fall blocks: With
the baby walker upside down and fully
folded down, place the anti-fall blocks
around the walker as shown, inserting the
two plastic stems on each block into the
holes on the walker’s underside.
WARNING! DO NOT USE THE WALKER
WITHOUT THE ANTI-FALL BLOCKS
ATTACHED.
Attaching the walker’s anti-fall blocks
Attaching the walker’s front and rear wheels
A
B
page 7
1. Lower the walker all the way down, place the walker on a at level surface then
place the seat unit in to the centre of the baby walker.
2. Attach all plastic clips on the seat unit
to the walker body in the following order:
A. (See Fig 1) Starting with the seat unit’s
arm rests, insert clips through the holes (1)
and (2) in the seat unit fabric then insert
the clips into holes (A1) and (A2) on the
walker body.
B. Next, attach the seat unit’s backrest by
pushing the plastic clips into holes (B1),
(B2), (B3) and (B4). Start from one side
and work your way around. Grip the back
of the seat unit as low down as possible
(Fig 2), feeling for the head of the clip
and ensuring the clip is lined up with it’s
hole, push the clip in (Fig 2a).
Note: If a clip is not protruding from the
seat unit you may need to locate it and
pull it through the hole in the seat cover.
C. Finally insert the pins at the front of the
seat unit into keyhole slots (C1), (C2) and
(C3). (Fig 3)
WARNING: Ensure all pins and clips are
properly attached before placing your
child in the seat.
Fig 1
Fig 3
Fig 2a
Walker
body
Seat
fabric
Fig 2
12
C1 C2 C3
B1 B2 B3 B4
A2A1
Fitting the seat unit
page 8
The footpad
1. The footpad must be tted in the rocker
mode, and when you don’t want your
child to move about in the walker mode.
Attach using the six clips on the footpad
and hook over the side bars on either side
of the base.
1. Working on one side at a time, pull up
both locking knobs (A).
ATTENTION: Ensure the footpad is tted whilst in the rocker mode
A
Using walker and rocker modes
page 9
1. Align the lollipop toy (A) and ice cream
cone toy (B) with the mounting points on
the walker body and “click” them into
place.
2. Whilst pulling up on both locking knobs,
turn the base 90 degrees upwards into
the rocker mode. Repeat on the opposite
side and check that both sides of the
base are locked in position.
To convert back: Pull both locking
knobs (A) and turn the base 90 degrees
downwards into the walker mode.
Repeat on the opposite side and check
that both sides of the base are locked in
position.
WARNING! DO NOT convert from rocker
to walker or vice-versa whilst your child is
seated in the walker.
Using walker and rocker modes (continued)
Attaching the toys
A
B
A
page 10
1. Insert the toy base (A) into the recess
on the musical toy tray (B), turning the
base clockwise to lock in place.
Push the end of the spinning toy (C) into
the hole in the centre of the toy base (A).
Assembling the musical play tray
A
B
C
Musical play tray
1. Using a Phillips screwdriver, unscrew
the battery cover on the underside of the
musical play tray.
Insert 2 x 1.5V AA batteries (not supplied)
ensuring the correct battery orientation is
observed and then reattach the cover,
replacing the screw, making certain it is
not over-tightened.
