GQM1885C1H240GB01_ (0603, C0G, 24pF, 50Vdc)

_: packaging code Reference Sheet

1.Scope

2.MURATA Part NO. System

(Ex.)

3. Type & Dimensions

(Unit:mm)

4.Rated value

5.Package

Product specifications in this catalog are as of Jan.25,2013,and are subject to change or obsolescence without notice.

Please consult the approval sheet before ordering.

Please read rating and !Cautions first.

RF HIGH FREQUENCY CHIP MONOLITHIC CERAMIC CAPACITOR

0.2 to 0.5

24 pF

Temp. Range

(Ref.Temp.)

(8) Packaging

mark

(4)

DC Rated

Voltage

Packaging Unit

±2 %

-55 to 125 °C

0±30 ppm/°C

25 to 125 °C

(25 °C)

(3) Temperature Characteristics

(Public STD Code):C0G(EIA)

Specifications and Test

Methods

(Operationg

Temp. Range)

Temp. coeff

or　Cap. Change

(5) Nominal

Capacitance

(6)

Capacitance

Tolerance

50 Vdc

0.5 min.

(2) T

0.8±0.1

This product specification is applied to RF High Frequency Chip Monolithic Ceramic Capacitor used for RF High frequency

Electronic equipment.

(1)-1 L

1.6±0.1

(1)-2 W

0.8±0.1

f180mm Reel

PAPER W8P4

4000 pcs./Reel

f330mm Reel

PAPER W8P4

10000 pcs./Reel

(1)L/W

Dimensions

(2)T

Dimensions

(3)Temperature

Characteristics

(4)DC Rated

Voltage

(5)Nominal

Capacitance

(6)Capacitance

Tolerance

(8)Packaging

Code

(7)Murata’s

Control Code

GQM 18 85C 1H 240 G B01 D

GQM1885C1H240GB01-01 1

No Item Test Method

1Operating Temperature 5C : -55℃to 125℃

2Rated Voltage See the previous pages. The rated voltage is defined as the maximum voltage which may be

applied continuously to the capacitor.

When AC voltage is superimposed on DC voltage, VP-P or VO-P,

whichever is larger, should be maintained within the rated

voltage range.

3Appearance No defects or abnormalities. Visual inspection.

4Dimension Within the specified dimensions. Using calipers.

5Dielectric Strength No defects or abnormalities. No failure should be observed when 300% of the rated

voltage is applied between the terminations for 1 to 5

seconds, provided the charge/discharge current is less

than 50mA.

6Insulation More than 10,000MΩor 500Ω・F . The insulation resistance should be measured with a DC

Resistance (Ｗhichever is smaller) voltage not exceeding the rated voltage at 25℃

and 75%RH max. and within 2 minutes of charging.

7Capacitance Within the specified tolerance. The capacitance/Q should be measured at 25℃

at the frequency and voltage shown in the table.

8Q30pFmin. : Q≧1400

30pFmax.: Q≧800+20C

C:NominalCapacitance (pF)

9Capacitance Capacitance Within the specified tolerance.(Table A-1) The temperature coefficient is determind using the

Temperature

Change capacitance measured in step 3 as a reference.

Characteristics

When cycling the temperature sequentially from step 1

through 5 the capacitance should be within the specified

tolerance for the temperature coefficient and capacitance

Temperature Within the specified tolerance.(Table A-1) change as Table A-1.

Coefficent The capacitance drift is caluculated by dividing the

differences betweeen the maximum and minimum measured

values in the step 1,3 and 5 by the cap. value in step 3.

Capacitance Within ±0.2% or ±0.05pF

Drift (Whichever is larger.)

10 Adhesive Strength of No removal of the terminations or other defect should occur. Solder the capacitor on the test jig (glass epoxy

Termination board)shown in Fig.3 using an eutectic solder. Then apply

10N* force in parallel with the test jig for 10+/-1sec.

The soldering should be done either with an iron or using the

reflow method and should be conducted with care so that the

soldering is uniform and free of defects such as heat shock.

*5N（GQM188)

11 Vibration  Appearance No defects or abnormalities. Solder the capacitor on the test jig (glass epoxy board) in the

Resistance same manner and under the same conditions as (10).

Capacitance Within the specified tolerance. The capacitor should be subjected to a simple harmonic

motion having a total amplitude of 1.5mm, the frequency

Q30pFmin. : Q≧1400 being varied uniformly between the approximate limits of 10

30pFmax.: Q≧800+20C and 55Hz. The frequency range, from 10 to 55Hz and return

to 10Hz, should be traversed in approximately 1 minute. This

C:NominalCapacitance (pF) motion should be applied for a period of 2 hours in each 3

mutually perpendicular directions(total of 6 hours).

12 Deflection Appearance No marking defects. Solder the capacitor on the test jig (glass epoxy board)

shown in Fig.1 using an eutectic solder. Then apply a force

Capacitance Within ±5％or ±0.5pF in the direction shown in Fig 2. The soldering

Change (Whichever is larger) should be done by the reflow method and should be

conducted with care so that the soldering is uniform and free

of defects such as heat shock.

13 Solderability 75% of the terminations is to be soldered evenly Immerse the capacitor in a solution of ethanol (JIS-K-8101)

of Termination and continuously. and rosin (JIS-K-5902) (25% rosin in weight propotion) .

Preheat at 80 to 120℃for 10 to 30 seconds.

After preheating, immerse in an eutectic solder solution for

2+/-0.5 seconds at 230+/-5℃or Sn-3.0Ag-0.5Cu solder

solution for 2+/-0.5 seconds at 245+/-5℃

■SPECIFICATIONS AND TEST METHODS

Specification

Char.

Item

(1000pF and below)

Frequency

10.1MHz

Voltage

0.5 to 5Vrms

Step

Temperature(C)

252

-553

252

1253

252

JEMCNS-0003Ｆ 2

No Item Test Method

14 Resistance to

The measured and observed characteristics shall satisfy

Preheat the capacitor at 120 to 150℃for 1 minute.

Soldering Heat

the specifications in the following table. Immerse the capacitor in an eutectic solder solution or

Appearance No defects or abnormalities. Sn-3.0Ag-0.5Cu solder solution at 270+/-5℃for

10+/-0.5 seconds. Let sit at room temperature for 24+/-2

Capacitance Within ±2.5% or ±0.25 pF hours.

Change (Whichever is larger)

Q30pFmin.:Q≧1400

30pFmax.:Q≧800+20C

C:NominalCapacitance (pF)

I.R.

More than 10,000MΩor 500Ω•F

(Whichever is smaller)

Dielectric No defects.

Strength

15 Temperature

The measured and observed characteristics shall satisfy

Fix the capacitor to the supporting jig in the same

Cycle the specifications in the following table. manner and under the same conditions as (10).

Appearance No defects or abnormalities. Perform the five cycles according to the four heat

treatments listed in the following table.

Capacitance Within ±2.5% or ±0.25pF Let sit for 24+/-2 hours at room temperature, then measure.

Change (Whichever is larger)

Q30pFmin. : Q≧1400

30pFmax.: Q≧800+20C

C:NominalCapacitance (pF)

I.R.

More than 10,000MΩor 500Ω•F

(Whichever is smaller)

Dielectric No defects.

Strength

16 Humidity

The measured and observed characteristics shall satisfy

Sit the capacitor at 40±2℃and 90 to 95% humiduty for

Steady State the specifications in the following table. 500±12 hours.

Appearance No defects or abnormalities. Remove and let sit for 24±2 hours (temperature compensating type)

at room temperature, then measure.

Capacitance Within ±5％or ±0.5pF

Change (Whichever is larger)

Q30pF and over : Q≧350

10pF and over, 30pF and below : Q≧275+5C/2

C:Nominal Capacitance(pF)

I.R.

More than 1,000MΩor 50Ω •F (Whichever is smaller)

The measured and observed characteristics shall satisfy

Apply the rated voltage at 40±2℃and 90 to 95% humidity

the specifications in the following table. for 500±12 hours.

Appearance No defects or abnormalities. Remove and let sit for 24±2 hours at room temprature then

muasure. The charge/discharge current is less than 50mA.

Capacitance Within ±7.5% or ±0.75pF

Change (Whichever is larger)

Q30pF and over : Q≧200

30pF and below : Q≧100+10C/3

I.R. More than 500MΩor 25Ω •F (Whichever is smaller)

The measured and observed characteristics shall satisfy

Apply 200% of the rated voltage for 1000±12 hours at the

Load the specifications in the following table. maximun operating temperature±3℃.

Appearance No defects or abnormalities. Let sit for 24±2 hours (temperature compensating type) aｔ

room temperature, then measure.

Capacitance Within ±3% or ±0.3pF The charge/discharge current is less than 50mA

Change (Whichever is larger)

Q30pF and over : Q≧350

10pF and over, 30pF and below : Q≧275+5C/2

C:Nominal Capacitance(pF)

I.R.

More than 1,000MΩor 50Ω •F (Whichever is smaller)

　　　Table A-1

　　　Note１：Nominal values denote the temperature coefficient within a range of 25℃to 125℃(for 5C)

■SPECIFICATIONS AND TEST METHODS

Specification

10pF and below : Q≧200+10C

C:Nominal Capacitance(pF)

10pF and below : Q≧200+10C

High Temperature

Humidity Load

Step

Temp.(C)

Time (min)

Min.

Operating Temp.+0/-3

30±3

Room Temp

2 to 3

Max.

Operating Temp.+3/-0

30±3

Room Temp

2 to 3

Char.

Nominal Values

(ppm/C) Note 1

Capacitance Change from 25C (%)

-55

-30

-10

Max.

Min.

Max.

Min.

Max.

Min.

030

0.58

-0.24

0.40

-0.17

0.25

-0.11

JEMCNS-0003Ｆ 3

Test method : Deflection

・Test substrate ・Test substrate

Material : Copper-clad laminated sheets for PCBs Material : Copper-clad laminated sheets for PCBs

　　　　　　　　 (Glass fabric base, epoxy resin) (Glass fabric base, epoxy resin)

Thickness : 1.6mm(GQM18/21: t:0.8mm) Thickness : 1.6mm(GQM18/21: t:0.8mm)

Copper foil thickness : 0.035mm Copper foil thickness : 0.035mm

Gray colored part of Fig.1: Solder resist

（Coat with heat resistant resin for solder）

Fig.1 (in:mm) Fig.3 (in:mm)

Fig.2 (in:mm)

■SPECIFICATIONS AND TEST METHODS

＊2

4.0±0.1

8.0±0.3

3.5±0.05

0.05以下

＊1

φ1.5

+0.1

-0

Ａ

*1,2：2.0±0.05

1.75±0.1

Ｂ

100

Land

f4.5

＊2

4.0±0.1

8.0±0.3

3.5±0.05

0.05以下

＊1

φ1.5

+0.1

-0

Ａ

*1,2：2.0±0.05

1.75±0.1

Ｂ

ﾗﾝﾄﾞ

f4.5

Glass epoxy board

Solder resist

Baked electrode or

copper foil

R230

Flexure:≦1

Capacitance meter

Pressurizing

speed

1.0mm/sec.

Support

Capacitor

Pressurize

Type

GQM18

1.0

3.0

1.2

GQM21

1.2

4.0

1.65

Type

GQM18

1.0

3.0

1.2

GQM21

1.2

4.0

1.65

JEMCNS-0003Ｆ 4

1.Tape Carrier Packaging(Packaging Code:D/E/L/J/F/K)

1.1 Minimum Quantity(pcs./reel)

φ180mm reel φ330mm reel

Paper Tape Plastic Tape Paper Tape Plastic Tape

Code:D/E Code:L Code:J/ F Code:K

GQM18 4000 10000

GQM2

4000 10000

GQM2

1000 4000

1.2 Dimensions of Tape

　(1)GQM18/21 (in mm)

Code GQM18 GQM21

A 1.05±0.1 1.55±0.15

B 1.85±0.1 2.3±0.15

　(2)GQM22

Code GQM22

A 2.8*

B 3.5* *Nominal Value

PACKAGING

GQM Type

Type

4.0±0.1

2.0±0.05

φ1.5

+0.1

-0

1.75±0.1

8.0±0.3

3.5±0.05

1.1 max.

Ａ

Ｂ

8.0±0.3

4.0±0.1

3.5±0.05

1.75±0.1

Ａ

Ｂ

2.5 max.

2.0±0.1

φ1.5

+0.1

-0

4.0±0.1

0.25±0.1

JEMCNP-01900 5

PACKAGING

GQM Type

図

ﾁｯﾌﾟ詰め状態

(

単位：

mm)

φ21±0.8

10±1.5

16.5 max.

Top Tape : Thickness 0.06

Feeding Hole :As specified in 1.2.

Hole for Chip : As specified in 1.2.

Base Tape : As specified in 1.2.

Bottom Tape :Thickness 0.05

(Only a bottom tape existence )

φ180+0/-3.0

φ330±2.0

φ50 min.

φ13±0.5

2.0±0.5

Chip

(in mm)

Fig.1 Package Chips

Fig.2 Dimensions of Reel

Fig.3 Taping Diagram

JEMCNP-01900 6

1.3 Tapes for capacitors are wound clockwise shown in Fig.3.

(The sprocket holes are to the right as the tape is pulled toward the user.)

1.4 Part of the leader and part of the vacant section are attached as follows. (in mm)

1.5 Accumulate pitch : 10 of sprocket holes pitch = 40±0.3mm

1.6 Chip in the tape is enclosed by top tape and bottom tape as shown in Fig.1.

1.7 The top tape and base tape are not attached at the end of the tape for a minimum of 5 pitches.

1.8 There are no jointing for top tape and bottom tape.

1.9 There are no fuzz in the cavity.

1.10 Break down force of top tape : 5N min.

Break down force of bottom tape : 5N min. (Only a bottom tape existence )

1.11 Reel is made by resin and appeaser and dimension is shown in Fig 1.

There are possibly to change the material and dimension due to some impairment.

1.12 Peeling off force : 0.1N to 0.6N in the direction as shown below.

1.13 Label that show the customer part number, our part number, our company name, inspection

number and quantity, will be put in outside of reel.

PACKAGING

GQM Type

図

ﾁｯﾌﾟ詰め状態

(

単位：

mm)

Tail vacant Section

Chip-mounting Unit

Leader vacant Section

Leader Unit

(Top Tape only)

Direction

of Feed

160 min.

190 min.

210 min.

図

ﾁｯﾌﾟ詰め状態

(

単位：

mm)

165～180°

Top tape

JEMCNP-01900 7

Caution

■Limitation of use

Please contact our sales representatives or product engineers before using our products for the applications

listed below which require of our products for other applications than specified in this product.

　①Aircraft equipment ②Aerospace equipment ③Undersea equipment ④Power plant control equipment

　⑤Medical equipment ⑥Transportation equipment(vehicles,trains,ships,etc.) ⑦Traffic signal equipment

　⑧Disaster prevention / crime prevention equipment ⑨Data-processing equipment

　⑩Application of similar complexity and/or requirements to the applications listed in the above

■Storage and Operation condition

1. The performance of chip monolithic ceramic capacitors may be affected by the storage conditions.

1-1. Store capacitors in the following conditions: Temperature of +5℃to +40℃and a Relative Humidity

of 20% to 70%.

(1) Sunlight, dust, rapid temperature changes, corrosive gas atmosphere or high temperature and humidity

conditions during storage may affect the solderability and the packaging performance

Please use product within six months of receipt.

(2) Please confirm solderability before using after six months.

Store the capacitors without opening the original bag.

Even if the storage period is short, do not exceed the specified atmospheric conditions.

1-2. Corrosive gas can react with the termination (external) electrodes or lead wires of capacitors, and result

in poor solderability. Do not store the capacitors in an atmosphere consisting of corrosive gas (e.g.,

hydrogen sulfide, sulfur dioxide, chlorine, ammonia gas etc.).

1-3. Due to moisture condensation caused by rapid humidity changes, or the photochemical change caused

by direct sunlight on the terminal electrodes and/or the resin/epoxy coatings, the solderability and

electrical performance may deteriorate. Do not store capacitors under direct sunlight or in high huimidity

conditions

JEMCNC-0012L 8

■Rating

1.Temperature Dependent Characteristics

1. The electrical characteristics of the capacitor can change with temperature.

1-1. For capacitors having larger temperature dependency, the capacitance may change with temperature changes.

The following actions are recommended in order to insure suitable capacitance values.

(1) Select a suitable capacitance for the operating temperature range.

(2) The capacitance may change within the rated temperature.

When you use a high dielectric constant type capacitors in a circuit that needs a tight (narrow) capacitance

tolerance.

Example: a time constant circuit., please carefully consider the characteristics of these capacitors,

such as their aging, voltage, and temperature characteristics.

And check capacitors using your actual appliances at the intended environment and operating conditions.

□Typical temperature characteristics Char.R6 (X5R)

□Typical temperature characteristics Char.R7 (X7R)

□Typical temperature characteristics Char.F5 (Y5V)

2.Measurement of Capacitance

1. Measure capacitance with the voltage and the frequency specified in the product specifications.

1-1. The output voltage of the measuring equipment may decrease when capacitance is high occasionally.

Please confirm whether a prescribed measured voltage is impressed to the capacitor.

1-2. The capacitance values of high dielectric constant type capacitors change depending on the AC voltage

applied.

Please consider the AC voltage characteristics when selecting a capacitor to be used in a AC circuit.

Caution

-20

-15

-10

-5

-75 -50 -25 025 50 75 100

Capacitance Change (%)

Temperature (℃)

-100

-80

-60

-40

-20

-50 -25 025 50 75 100

Capacitance Change (%)

Temperature (℃)

-20

-15

-10

-5

-75 -50 -25 025 50 75 100 125 150

Capacitance Change (%)

Temperature (℃)

JEMCNC-0012L 9

3.Applied Voltage

1. Do not apply a voltage to the capacitor that exceeds the rated voltage as called-out in the specifications.

1-1. Applied voltage between the terminals of a capacitor shall be less than or equal to the rated voltage.

(1) When AC voltage is superimposed on DC voltage, the zero-to-peak voltage shall not exceed the

rated DC voltage.

When AC voltage or pulse voltage is applied, the peak-to-peak voltage shall not exceed the

rated DC voltage.

(2) Abnormal voltages (surge voltage, static electricity, pulse voltage, etc.) shall not exceed the

rated DC voltage.

Typical voltage applied to the DC capacitor

DC voltage DC voltage+AC AC voltage Pulse voltage

（E：Maximum possible applied voltage.）

1-2. Influence of overvoltage

Overvoltage that is applied to the capacitor may result in an electrical short circuit caused by the

breakdown of the internal dielectric layers .

The time duration until breakdown depends on the applied voltage and the ambient temperature.

4. Applied Voltage and Self-heating Temperature

1. When the capacitor is used in a high-frequency voltage, pulse voltage, application,

be sure to take into account self-heating may be caused by resistant factors of the capacitor.

1-1. The load should be contained to the level such that when measuring at atomospheric temperature of 25℃,

　　　 the product's self-heating remains below 20℃and surface temperature of the capacitor in the actual circuit

remains wiyhin the maximum operating temperature.

Caution

E E E E

0 0

JEMCNC-0012L 10

This manual suits for next models

Table of contents

Other Murata Industrial Electrical manuals

Murata

Murata GRM0335C1E8R2CA01 Series User manual

Murata

Murata GRM0335C1H8R7CA01 Series User manual

Murata

Murata GRT31CR61A476ME13 Series User manual

Murata

Murata GRM0225C1E9R5BA03 Series User manual

Murata

Murata GJM1555C1H3R2BB01 Series User manual

Murata

Murata GRM033R61A104KE15 Series User manual

Murata

Murata GRT155R60J225KE01 Series User manual

Murata

Murata GRT188R61C475ME13 Series User manual

Murata

Murata GQM2195C2E620GB12 Series User manual

Murata

Murata GRM022R60J473ME15 Series User manual

Murata

Murata GRM219R61H105KA73 Series User manual

Murata

Murata GJM0335C1E8R6CB01 Series User manual

Murata

Murata GRT31CR61C106KE01 Series User manual

Murata

Murata GRM31CE70G476ME15 Series User manual

Murata

Murata GRM1555C2A7R0DA01 Series User manual

Murata

Murata GRT155C81E224ME01 Series User manual

Murata

Murata GRM32ER71K475ME14 Series User manual

Murata

Murata GRM0225C1E5R7DA03 Series User manual

Murata

Murata GJM1555C1H5R1WB01 Series User manual

Murata

Murata GQM2195C2E750JB12 Series User manual

Murata

Murata GQM1885C1H120GB01 Series User manual

Murata

Murata GRM21BC81C226ME44 Series User manual

Murata

Murata GRM188R71H471KA01 Series User manual

Murata

Murata GRM216R71H102KA01 Series User manual

Popular Industrial Electrical manuals by other brands

Rexroth Indramat

Rexroth Indramat DURADRIVE SYSTEM200 Project planning manual

Abtech

Abtech HVJB Series Installation, operation & maintenance instructions

SAF-HOLLAND

SAF-HOLLAND CBX 5415.5 Installation and operation manual

Eaton

Eaton Ulusoy HMH24-04 user manual

Newlong

Newlong NP-7H NSTRUCTION MANUAL/PARTS LIST

Stahl

Stahl 8575/12 operating instructions

SI Pegasus installation instructions

Cooper Power Systems

Cooper Power Systems VXE15 Installation and operation instructions

S&C

S&C Vista SD manual

Siemens

Siemens 3VA9988-0BM10 operating instructions

Siemens

Siemens SITRANS LVS100 operating instructions

Siemens

Siemens SENTRON SUPERSWITCH 3KL82 Series manual

Rockwell Automation

Rockwell Automation Allen-Bradley MP-Series installation instructions

Phasemation

Phasemation DG-100 owner's manual

Eaton

Eaton 10250T/E34 Instructional Leaflet

Bticino

Bticino LN4572 manual

ABB

ABB System pro E power Instruction handbook

WPI

WPI STX2-PLUS instruction manual
