MSA TransAire User manual



Operating Manual

TransAire

5 & 10 Minute Escape Hood Respirators



OrderNo.:10008901/04

PrintSpec:10000005389(A)

CR:800000062938

MSAsafety.com

WARNING!

Theseinstructionsmustbeprovidedtousersbeforeuseoftheproductandretainedforreadyreferencebytheuser.Readthismanualcarefullybefore

usingormaintainingthedevice.Thedevicewillperformasdesignedonlyifitisusedandmaintainedinaccordancewiththemanufacturer's

instructions.Otherwise,itcouldfailtoperformasdesigned,andpersonswhorelyonthisdevicecouldsustainseriousinjuryordeath.



ThewarrantiesmadebyMSAwithrespecttotheproductarevoidediftheproductisnotinstalledandusedinaccordancewiththeinstructionsinthis

manual.Pleaseprotectyourselfandyouremployeesbyfollowingtheinstructions.

PleasereadandobservetheWARNINGSandCAUTIONSinside.Foradditionalinformationrelativetouseorrepair,call1-800-MSA-2222during

regularworkinghours.

MSAisaregisteredtrademarkofMSATechnology,LLCintheUS,EuropeandotherCountries.Forallothertrademarksvisit

https://us.msasafety.com/Trademarks.



1000CranberryWoodsDrive

USA

Phone1-800-MSA-2222

Fax1-800-967-0398

ForyourlocalMSAcontacts,pleasegotoourwebsitewww.MSAsafety.com

US 4

Contents

1 Introduction 5

1.1 NIOSHApprovalInformation 5

1.2 SpecialUserInstructions 5

2 General Description 5

3 Unpacking 6

4 Donning 6

4.1 DonningtheCylinderandCarrier 6

4.2 DonningtheApparatusHood 8

5 Removing the TransAire Escape Hood 8

6 Maintaining the Escape Hood 10

6.1 CleaningandDisinfecting 10

6.2 ComponentInspection(AfterCleaningandDisinfecting) 12

6.3 HoodPackingInstructionsforTransAireApparatus 14

6.4 ReassemblingtheEscapeHood 15

5 US

1 Introduction

Table 1 TransAire Configurations

Description P/N

5min.aluminum 10008292

10min.carbonfiber 10008293

10min.carbonfiber 10083327

5min.aluminumlessair 10067739

10min.aluminumlessair 10066740

1.1 NIOSH Approval Information

J-Failuretoproperlyuseandmaintainthisproductcouldresultininjuryordeath.

M-Allapprovedrespiratorsshallbeselected,fitted,usedandmaintainedinaccordancewithMSHA,OSHAandother

applicableregulations.

N-Neversubstitute,modify,addoromitparts.Useonlyexactreplacementpartsintheconfigurationasspecifiedbythe

manufacturer.

O-RefertoUsersInstructions,and/ormaintenancemanualsforinformationonuseandmaintenanceoftheserespirators.

S-SpecialorcriticalUsersInstructionsand/orspecificuselimitationsapply.Refertouserinstructionsbeforedonning.

1.2 Special User Instructions

1. Anadequaterespiratoryprotectionprogrammustincludeknowledgeofhazards,hazardassessment,selectionof

properrespiratoryprotectiveequipment,instructionandtrainingintheuseofequipment,inspectionand

maintenanceofequipment,andmedicalsurveillance.[SeeOSHAregulations,Title29CFR,Part1910.134]

2. Thisrespiratorwillperformasdesignedonlyifusedandmaintainedaccordingtothemanufacturer’sinstructions.

TheProgramAdministratorandtheusersmustreadandunderstandtheseinstructionsbeforetryingtouseor

servicethisproduct.Weencourageourcustomerstowriteorcallforinformationonthisproductbeforeusingit.

3. ThisrespiratormaybeusedonlyafterproperinstructionandtraininginitsuseasspecifiedinOSHAregulations[Title

29CFR,Part1910.134].

4. Thisrespiratormaybewornforescapeonlyfromatmosphereswhichareimmediatelydangeroustolifeorhealthas

definedinTitle42CFR,Part84,orfromwhichthewearercannotescapewithouttheaidofarespirator.Underno

circumstancesshouldtherespiratorbeusedasanunderwaterdevice.

5. Approvedforuseattemperaturesabove0°F.

6. TomaintainNIOSHapproval,theairusedinthecylindermustmeettherequirementsoftheCompressedGas

AssociationSpecificationG-7.1forqualityverificationlevel(grade)Dairorequivalentspecifications.Thecylinder

shallmeetapplicableDOTspecifications.

7. Wearimpermeableprotectiveclothingforexposuretogasesorvaporswhichcanpoisonbyskinabsorption.

8. Donotalter,modify,orsubstituteanycomponentswithouttheapprovalofthemanufacturer.Alterationswillvoidthe

NIOSHapproval.

9. Inspecttherespiratorregularlyandmaintainitaccordingtothemanufacturer’sinstructions.Repairsmustonlybe

madebyproperlytrainedpersonnel.

2 General Description

Tworespiratorsaredescribedinthismanual:

• TransAire5MinuteEscapeHoodRespirator

• TransAire10MinuteEscapeHoodRespirator

3 Unpacking

US 6

BothrespiratorsfromMSAareapprovedbytheNationalInstituteforOccupationalSafetyandHealth(NIOSH)foruseas

anescapedevicefromhazardousatmospheres,includingthosewhichareimmediatelydangeroustolifeorhealth(IDLH).

AnIDLHatmosphereisdefinedas:

“ ... conditions that pose an immediate threat to life or health or conditions that pose an immediate threat of severe

exposure to contaminants, such as radioactive materials, which are likely to have adverse cumulative or delayed effects on

health.” [Title 42 CFR, Part 84, Subpart A, par. 84.2 (q)].”

TransAireEscapeapparatusconsistofacarriercontainingaloose-fittinghood,aflow-controlregulatorandhose

assembly,andanaircylinderandvalveassembly.TheTransAire5MinuteEscapeHoodRespiratoraircylindercontainsa

5-minutesupplyofairatFULLpressure(2216psig).TheTransAire10MinuteEscapeHoodRespiratoraircylinder

containsa10-minutesupplyofairatFULLpressure(3000psig).

TherearesignificantdifferencesbetweenESCAPEapparatus(liketheTransAire)andself-containedbreathingapparatus

(SCBA).

Table 2 Comparison: TransAire Escape Apparatus vs Self-Contained Breathing Apparatus (SCBA)

5-Minute Escape Apparatus 10-Minute Escape Apparatus SCBA

Airflowsfromthecylindertothehood

constantlyuntilthecylinderisempty(5

minutes)

Airflowsfromthecylindertothehood

constantlyuntilthecylinderisempty

(10minutes)

Airflowsfromthecylindertothehood

followinguser'sbreathingrate(30

minutesto60minutes)

Noaudiblealarmwhenthecylinderis

nearlyempty

Noaudiblealarmwhenthecylinderis

nearlyempty

Audiblealarmwarnstheuserthatthe

cylinderisnearlyempty

Loose-fittinghood Loose-fittinghood Tight-fittingpressure-demand

facepiece.Servicetime:30to60

minutes(dependsonthemodel).

Theapparatuscanbewornonthechest,hiporwaist,andmaybecarriedintoorstoredinanareathatmaybepotentially

hazardous.Thehoodisdesignedtobeareservoirofbreathingair.Itisnotdesignedtoprovidesplashprotectionor

withstandexposuretodirectflameorhighheat.

3 Unpacking

Whenyoureceivetheapparatus,inspectittobesureithasnotbeendamagedinshipment.Inmaycases,youwillnotbe

thefirsttohandletheapparatus.So,checkthatitisassembledcorrectly.ChecktheaircylindertobesureitisFULL.The

pressuregaugeshouldread3000psiat70°Fforthe10-minuteunitand2216forthe5-minuteunit.

4 Donning

NOTE: Thecylindermaybewornthreeways:Chest-mounted,hip-mounted,orwaist-mounted.

4.1 Donning the Cylinder and Carrier



1. Chest-Mounted

a. CheckthatthestraphookisattachedtothebottomD-ring.

b. Adjustthecarrierstraptofitcomfortablyoveryourhead.

7 US

4 Donning

c. Slipthestrapoveryourheadsothatitrestsonthebackofyourneck.



2. Hip-Mounted

a. Adjustthecarrierstrapsothatitisfullyextended.

b. AttachthestraphooktotheD-ring.

c. Sliponearmintothestrap.Placethestrapoveryourheadandrestiton

yourshoulder.

 3. Waist-Mounted(usingtheoptionalshoulderstrap)

a. AttachtheshoulderstraptothetopD-rings.



b. RemovethecarrierstrapfromtheD-ringandadjustthestraptoitsfull

length.

c. Dontheshoulderstrap.Pulltheadjustingstrapforasnug,comfortablefit.

5 Removing the TransAire Escape Hood

US 8

d. AttachthecarrierstraphooktotheD-ringandadjustthestraptoyour

waistsize.

4.2 Donning the Apparatus Hood

1. Openthecylindervalvealltheway.



2. Pullthehook-and-loopstripandpullthepouchcoveroutawayfromthecarrier.

Graspthehoodfromthepouchandlistenforthesoundofairrushinginsidethe

hood.

3. Stretchtheneckbandwithbothhandsandpullthehoodoveryourheadsothat

theregulatorhoseisatthefront.

4. Makesurethereisnothing(suchasclothingorhair)betweentheneckbandand

yournecktopreventagoodseal.

5. Exittoasafeatmosphere—Immediately!

WARNING!

Thisapparatusisdesignedtosupplyairfornomorethan5or10minutes.Donotremaininthehazardousatmosphere.

Leaveimmediatelyandreturntoasafeatmosphere.Removethehoodwhenairflowstops.Therushingsoundwillstop,

andthehoodwillbegintocollapsearoundyourhead.

Failure to follow this warning can result in serious personal injury or death by suffocation.

5 Removing the TransAire Escape Hood

1. Stretchtheneckbandwithbothhandsandpullthehoodupoveryourhead.

2. Closethecylindervalve.

9 US

5 Removing the TransAire Escape Hood

3. Removetheshoulderstrap(andwaiststrapifused).



4. Hip-Mounted

a. Adjustthecarrierstrapsothatitisfullyextended.

b. AttachthestraphooktotheD-ring.

c. Sliponearmintothestrap.Placethestrapoveryourheadandrestiton

yourshoulder.

 5. Waist-Mounted(usingtheoptionalshoulderstrap)

a. AttachtheshoulderstraptothetopD-rings.



b. RemovethecarrierstrapfromtheD-ringandadjustthestraptoitsfull

length.

c. Dontheshoulderstrap.Pulltheadjustingstrapforasnug,comfortablefit.

6 Maintaining the Escape Hood

US 10

d. AttachthecarrierstraphooktotheD-ringandadjustthestraptoyour

waistsize.

6 Maintaining the Escape Hood

OSHAregulations(29CFR,Part1910.134)requirethattheuserestablishamaintenanceprogram.Thisprogrammust

includecleaninganddisinfecting,componentinspection,andreplacementofwornordamagedparts.

6.1 Cleaning and Disinfecting

WARNING!

Inspecttheapparatusafterithasbeencleanedanddisinfected.Becarefulthatyoudonotbreatheortouchthe

contaminantinhandlingtheapparatusoritsparts.Useequipmentdesignedtoprotectyoufromthespecificcontaminant.

Failure to follow this warning can result in exposure to the contaminant, and cause serious personal injury or

death.

Dependingonthecleaningpolicyadopted,eitheradesignatedpersonortheusershouldcleantheapparatus.ANSI

suggeststhatusersshouldbetrainedinthecleaningprocedure.Preparetheapparatusforcleaningandsanitizingas

follows:

1. Makesurethatthecylindervalveisfullyclosed.

2. Removetheexcesscontaminantfromtheapparatus.

3. Unscrewthehosenutandpullthehosefittingoutofthehoodinlet.

 4. Removethemufflerfromthehood.

11 US

6 Maintaining the Escape Hood

5. Unscrewandremovethepressureregulatorfromthecylindervalve.



6. Untietheretainingcordtoopenthecylindercarrierandremovetheaircylinder.

7. AddoneounceofConfidencePlusGermicidalCleaneroramildcleaning

solutiontoagallonofwarmwater(maximumtemperature110°F).

8. Submergethehoodandcarrierinthecleaningsolutionandscrubgentlyuntil

theyareclean.

9. Rinsebothhoodandcarrierthoroughlyinplain,warmwater(maximum

temperature110°F),thenairdry.Ifnotrinsedthoroughly,ConfidencePlus

GermicidalCleanermayirritateyourskin.

CAUTION!

Donotforce-drywithheat.Temperaturesabove110°Fmaydistortordamagepartsofthisapparatus.Thehoodisplastic

andmaybescratchedifrubbedwithcoarsedryclothorpapertowels.

Failure to follow this caution can result in minor or moderate injury.



10.UseadampclothorspongesaturatedinConfidencePlusGermicidalCleanerto

cleanthemuffler,mufflercover,diffuser,hoodhose,pressureregulator,cylinder

valveandaircylinderclean.

NOTE: Whentheyhavedried,reinstallthemuffler,diffuser,andmufflercoverin

thehood.

11.Ensurethatthemufflercoverisinstalledandpointedupatapproximately45

degreesleftorrightofcenter.
