Moxa Technologies NPort NWH650 User manual

Moxa Wireless Ethernet Client

User’s Manual

Second Edition, June 2008

www.moxa.com/product

Reproduction without permission is prohibited.

11Mbps Wireless Ethernet Client

FCC WARNING

This equipment has been tested and found to comply with the limits for a Class B Digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses, and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the user

is encouraged to try to correct the interference by one or more of the following measures:

ŸReorient or relocate the receiving antenna.

ŸIncrease the separation between the equipment and receiver.

ŸConnect the equipment to an outlet on a circuit different from that to which the receiver

is connected.

ŸConsult the dealer or an experienced radio/TV technician for help.

You are cautioned that changes or modifications not expressly approved by the party

responsible for compliance could void your authority to operate the equipment. This device

complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may

cause undesired operation.

FCC RF Radiation Exposure Statement

This equipment complies with FCC RF radiation exposure limits set forth for an

uncontrolled environment. This equipment should be installed and operated with a minimum

distance of 20 centimeters between the radiator and your body.

Moxa Wireless Ethernet Client

User’s Manual

The software described in this manual is furnished under a license agreement and may

be used only in accordance with the terms of that agreement.

Reproduction without permission is prohibited.

Trademarks

MOXA is a registered trademark of Moxa Inc.

All other trademarks or registered marks in this manual belong to their respective

manufacturers.

Disclaimer

Information in this document is subject to change without notice and does not

represent a commitment on the part of Moxa.

Moxa provides this document “as is,” without warranty of any kind, either expressed

or implied, including, but not limited to, its particular purpose. Moxa reserves the

right to make improvements and/or changes to this manual, or to the products and/or

the programs described in this manual, at any time.

Information provided in this manual is intended to be accurate and reliable. However,

Moxa assumes no responsibility for its use, or for any infringements on the rights of

third parties that may result from its use.

This product might include unintentional technical or typographical errors. Changes

are periodically made to the information herein to correct such errors, and these

changes are incorporated into new editions of the publication.

Technical Support Contact Information

www.moxa.com/support

Moxa Americas:

Toll-free: 1-888-669-2872

Tel: +1-714-528-6777

Fax: +1-714-528-6778

Moxa China (Shanghai office):

Toll-free: 800-820-5036

Tel: +86-21-5258-9955

Fax: +86-10-6872-3958

Moxa Europe:

Tel: +49-89-3 70 03 99-0

Fax: +49-89-3 70 03 99-99

Moxa Asia-Pacific:

Tel: +886-2-8919-1230

Fax: +886-2-8919-1231

11Mbps Wireless Ethernet Client

Table of Contents

1 INTRODUCTION..........................................................................................1

SYSTEM REQUIREMENTS ...................................................................................1

PLACEMENT GUIDELINES ..................................................................................1

HOW TO USE THIS GUIDE...................................................................................2

TERMINOLOGY USED IN THIS GUIDE ..................................................................2

APPLICATION SCENARIOS..................................................................................3

Infrastructure Network..................................................................................3

Ad Hoc Network ...........................................................................................4

2 HARDWARE DESCRIPTION......................................................................5

LED INDICATORS .............................................................................................6

3 WEC CONFIGURATION TOOL INSTALLATION ...................................7

4 USING THE WEC COMFIG TOOL.............................................................8

CONNECT..........................................................................................................8

PASSWORD .......................................................................................................9

SERVICE ...........................................................................................................9

General......................................................................................................10

Encryption..................................................................................................13

Ethernet......................................................................................................14

PERFORM WEC SELF DIAGNOSTIC TEST..........................................................15

UPGRADE WEC FIRMWARE.............................................................................15

RESET WEC CONFIGURATION.........................................................................16

5 CONNECTING AN ETHERNET DEVICE................................................17

6 FREQUENTLY ASKED QUESTIONS........................................................18

7 SPECIFICATIONS......................................................................................19

8 APPENDIX...................................................................................................21

9 INDEX..........................................................................................................22

11Mbps Wireless Ethernet Client

List of Figures

FIGURE 1. INFRASTRUCTURE NETWORK...............................................................3

FIGURE 2. AD HOC NETWORK .............................................................................4

FIGURE 3. REAR PANEL.......................................................................................5

FIGURE 4. FRONT PANEL .....................................................................................5

FIGURE 5. CONNECT............................................................................................8

FIGURE 6. PASSWORD .........................................................................................9

FIGURE 7. SERVICE .............................................................................................9

FIGURE 8. CONFIGURATION/GENERAL ...............................................................10

FIGURE 9. CONFIGURATION/ENCRYPTION ..........................................................13

FIGURE 10. CONFIGURATION/ETHERNET..............................................................14

FIGURE 11. HARDWARE DIAGNOSIS.....................................................................15

FIGURE 12. UPGRADE FIRMWARE........................................................................16

FIGURE 13. RESET CONFIGURATION ....................................................................16

Package Checklist

The package should contain the following items:

•Wireless Ethernet Client With Power Adapter

•RS-232 Cable

•Cross-over Ethernet Cable

•Software CD

11Mbps Wireless Ethernet Client 1

Introduction

Congratulations on choosing Wireless Ethernet Client (WEC). This guide gives

instructions on installing WEC and using the configuration program.

WEC provides a wireless connection to the Internet or to shared resources for an

Ethernet-enabled device. Once WEC has been set up, all that is required is a cross-

over Ethernet cable to WEC to another device, such as a notebook computer. Ad

hoc mode provides Ethernet-enabled devices with the ability to communication

wirelessly between two WEC units.

System Requirements

You will need the following equipment to install and operate WEC:

•An Ethernet adapter.

•A PC running Windows 95/98/Me/NT4.0/2000/XP (only required when

you need to configure WEC’s network properties).

Placement Guidelines

The following tips are particularly significant for radio wave communications

systems:

1. Radio waves reflect or refract from buildings, walls, metal furniture, and other

objects. This could result in a degradation of performance due to the

fluctuations in the received signal.

2. Microwave ovens use the 2.45 GHz frequency bandwidth. WEC also operates

in the 2.4 –2.5 GHz bandwidth, and therefore shares some of the bandwidth

used by microwave ovens. This means that when a nearby microwave oven is

in use, it may interfere with signals emanating from a WEC unit, resulting in a

degradation of the wireless network’s performance.

To achieve the best performance, follow the guidelines given below when placing a

WEC unit:

•Place the unit as high as possible, and in as open an area as is possible

•Avoid placing the WEC (especially the antenna) close to metal objects (such

as file cabinets, metal cubicles, etc.).

•Keep WEC units as far away as possible from microwave ovens (a minimum

of 10 meters is recommended).

211Mbps Wireless Ethernet Client

How to Use this Guide

The Installation Guide gives complete instructions for installing Wireless Ethernet

Client (WEC).

Use the WEC COMFig tool—see page 8— to change the default WEC settings.

The WEC COMFig tool permits basic WEC offline configuration from a PC via an

RS-232 cable/COM port connection.

Terminology Used in this Guide

Domain Name/SSID

A “Domain” is most commonly used to refer to a group of computers with

hostnames that share a common suffix. The domain is usually defined by the

network administrator as a segment/subnet of a large network, and may comprise

overlapping wireless cells. Wireless nodes can roam freely within the same domain

without disconnecting from the network.

Regulatory Domain

WEC products use the unlicensed ISM (Industrial, Scientific, Medical) band to

communicate through radio waves. Different countries offer different radio

frequencies to be used as the ISM band. There are four frequency bands defined by

IEEE 802.11: Japan (2.471 GHz –2.497 GHz), USA, Extended Japan, Canada, and

Europe (2.4 GHz –2.4835 GHz), Spain (2.445 GHz –2.475 GHz), and France

(2.4465 GHz –2.4835 GHz). To use WEC in a country not listed above, check

with your government’s regulatory agency to determine the correct frequency band

to use. All WEC products are supplied preset to the country of sale’s frequency

band.

WEP

WEP stands for Wired Equivalent Privacy. It is an encryption scheme that provides

secure wireless data communication. WEP uses a 40-bit or 128-bit key to encrypt

data. Each wireless client on the network must use identical keys to decode a data

transmission.

11Mbps Wireless Ethernet Client 3

Application Scenarios

Infrastructure Network

An Infrastructure Network is formed by several stations and one or more Access

Points (APs), in which the stations are within a set distance from the AP. Figure 1

depicts the topology for a typical Infrastructure Network.

Figure 1. Infrastructure Network

Print Server

Ethernet

Ready

Computer

Computer with

Wireless LAN

Card

Hub

Access

Point

WEC

411Mbps Wireless Ethernet Client

Ad Hoc Network

An Ad Hoc Network is formed by a number of wireless stations (without an

Access Point) that communicate via radio waves. The shared resources on the

wireless network appear to users exactly as they would on a regular wired network.

The wireless operation of the network is totally transparent. Figure 2depicts a

typical Ad Hoc Network scenario.

Figure 2. Ad Hoc Network

Server

WEC

Ethernet

Ready

Computer

with

Wireless

LAN

Card

WEC

Table of contents

Other Moxa Technologies Wireless Access Point manuals

Moxa Technologies

Moxa Technologies AWK-4121 User manual

Moxa Technologies

Moxa Technologies AirWorks AWK-3131A User manual

Moxa Technologies

Moxa Technologies AirWorks AWK-6222 User manual

Moxa Technologies

Moxa Technologies AWK-3131A-M12-RTG-EU-T User manual

Moxa Technologies

Moxa Technologies AirWorks AWK-5222 User manual

Moxa Technologies

Moxa Technologies AirWorksAWK-6232-M12 Manual

Moxa Technologies

Moxa Technologies AWK-4121 User manual

Moxa Technologies

Moxa Technologies AWK-3121-SSC-RTG User manual

Moxa Technologies

Moxa Technologies AirWorks AWK-3131A User manual

Moxa Technologies

Moxa Technologies AirWorks AWK-6222 User manual

Moxa Technologies

Moxa Technologies airworks awk-5232 User manual

Moxa Technologies

Moxa Technologies AWK-3131A-RTG Series User manual

Moxa Technologies

Moxa Technologies AirWorks AWK-1127 User manual

Moxa Technologies

Moxa Technologies AWK-3131 User manual

Moxa Technologies

Moxa Technologies AWK-6232 User manual

Moxa Technologies

Moxa Technologies AirWorks WK-1137C-EU-T User manual

Moxa Technologies

Moxa Technologies AirWorks AWK-3131A User manual

Moxa Technologies

Moxa Technologies AirWorks AWK-5232-M12-RCC User manual

Moxa Technologies

Moxa Technologies WAC-1001 Series User manual

Moxa Technologies

Moxa Technologies TAP-6226 User manual

Moxa Technologies

Moxa Technologies airworks awk-5232 User manual

Moxa Technologies

Moxa Technologies AWK-4121 User manual

Moxa Technologies

Moxa Technologies AirWorks AWK-5222 User manual

Moxa Technologies

Moxa Technologies AirWorks AWK-3121 User manual

Popular Wireless Access Point manuals by other brands

D-Link

D-Link DWL-2100AP - AirPlus Xtreme G Quick installation guide

Ubiquiti

Ubiquiti NanoStation NSM2 quick start guide

Cisco

Cisco Aironet 1550 Series Getting started guide

Aruba

Aruba IAP-335 user guide

Advantek Networks

Advantek Networks AWN-AP-54MR user manual

IP-COM

IP-COM AP355 user guide

Buffalo

Buffalo AirStation WLA-L11G user manual

EnGenius

EnGenius EnStationACv2 user manual

D-Link

D-Link DAP-3662 Quick installation guide

xG Technology

xG Technology xMax CN1300 installation guide

Widelink

Widelink ezWave WAP-1100 Series user guide

Edimax

Edimax CAP1200 user manual

Ubiquiti

Ubiquiti LBE-5AC-Gen2 quick start guide

Aruba

Aruba AP-203R installation guide

LuXout Shades

LuXout Shades LUXSHADE MOTION manual

CreatComm

CreatComm TB5F user manual

SineDigital

SineDigital MW-1500AP(H) installation guide

TP-Link

TP-Link AP9650 V1 Quick installation guide
