Mount-It! MI-310 User manual

English

Installation Instruction

UNPACKING INSTRUCTIONS

IMPORTANT SAFETY INFORMATION

Carefully open the carton, remove contents and lay out on cardboard or other protective surface to avoid damage.

If you don't understand these directions or have any doubts about the safety of the installation.

Check package contents against the Supplied Parts List in the next page to assure that all components were

received undamaged. Do not use damaged or defective parts.

Carefully read all instructions before attempting installation.

Install and operate this device with care. Please read this instruction before beginning the installation, and carefully

follow all instructions contained herein. Use proper safety equipment during installation.

Do not use this product for any purpose or in any configuration not explicitly specified in this instruction. We hereby

disclaim any and all liability for injury or damage arising from incorrect assembly, incorrect mounting, or incorrect use

of this product.

If you are uncertain about the nature of your wall, consult a qualified installation contractor.

Please call a qualified installation contractor for help if you:

Tools Required

WARNING

This TV mount must be securely attached to the vertical wall. If the

mount is not properly installed it may fall, resulting in possible injury

and/or damage.

5/32"(4mm) Drill Bit

Phillips Screwdriver

3/8"(10mm) Masonry Bit

Stud Finder

Wrench or Socket Set

Carpenter's Level

Note: The mounting components and hardware supplied in this package are not designed for installations to walls with steel studs

or to cinder block walls. If the hardware you need for your installation is not included, please consult your local hardware store for

proper mounting hardware for the application.

CAUTION!

Supplied Parts List

Please install the Plastic Knob on the Monitor

Bracket as left diagram before you do the next

step. Please note the two knobs should be

installed in the opposite way on the two monitor

brackets.

(2)Plastic Knob

(4)M6 Washer-E

(4)M6x20 Bolt-J

(4)M8x45 Bolt-N

(4)M4 Spacer-A

(1)Wall Plate

(4)M8 Washer-F

(4)M6x35 Bolt-K

(6)Lag Bolt Washer-X

(8)5mm M6/M8

Spacer-B

(1)Left Monitor Bracket

(4)M4x12 Bolt-G

(4)M8x20 Bolt-L

(6)M8x90mm Lag Bolt-Y

(4)20mm M6/M8

Spacer-C

(1)Right Monitor Bracket

(4)M4x30 Bolt-H

(4)M8x35 Bolt-M

(6)M10x80mm

Concrete Anchor-Z

(4)M4 Washer-D

(1)Allen Key

Mounting the Wall Plate to the Wall

Step 1

80mm

90mm

10mm

Brick or Concrete Wall

Wood Studs Wall

90mm

4mm

1.1 1.2

1.1 1.3

1.2

Wall Plate

16"(406mm)

Wall Plate

Mounting the Monitor Brackets to a TV

Step 3 Attaching Monitor to Wall Plate and Adding the Safety Bolts

Step 4 Levelling Mount

Wall Plate Wall Plate

Monitor Brackets

Step 2

3.1 3.2

2.1G/H/J/K/L/M/N

2.2A/B/C

(Optional)

2.3

G to N

D to F

Monitor Bracket

A,B,C

(if necessary)

Safety Bolt

Wall Wall
