Moulinex 043-2214-8 User manual
12-CUP FOOD PROCESSOR
043-2214-8
ROBOT CULINAIRE DE 12 TASSES
www.moulinex.ca
EN FR
USER GUIDE
GUIDE DE L’UTILISATEUR
If you have any questions or concerns please call our Moulinex
toll-free number at 1-888-670-6681.
Si vous avez des questions ou des préoccupations, veuillez
appeler notre numéro sans frais Moulinex au 1-888-670-6681.
contents
important safeguards
product diagram
operating your food processor
care and cleaning
recipes
04
06
09
17
19
importantes mises en garde
pièces et caractéristiques
fonctionnement du robot culinaire
entretien et nettoyage
recettes
24
26
29
37
39
contenu
4
EN
When using electrical appliances, basic safety precautions
should always be followed, including the following:
1. Read all instructions.
2. To protect against risk of electrical shock, DO NOT put base, cord,
or plug in water or other liquid.
3. Close supervision is necessary when any appliance is used by or
near children.
4. Turn unit off and unplug from outlet when not in use, before put
ting on or taking off parts, and before cleaning. To disconnect,
turn unit off, grasp plug, and pull out from wall outlet.
Never yank on cord.
5. Avoid contact with moving parts.
6. DO NOT operate any appliance with a damaged cord or plug or
after the appliance malfunctions or has been damaged in any
manner. Return the appliance to an authorized service facility for
examination, repair, or electrical/mechanical adjustment.
7. The use of attachments not recommended or sold by the appliance
manufacturer may cause fire, electric shock, or injury.
8. DO NOT use outdoors.
9. DO NOT let cord hang over the edge of a table or counter or touch
hot surfaces.
10. Keep hands and utensils away from moving blades or Discs while
the unit is processing food, to prevent the possibility of severe
personal injury or damage to the food processor. A scraper may be
used but must be used only when the food processor is not
IMPORTANT SAFEGUARDS
5
EN
running.
11. Blades are sharp. Handle carefully.
12. Be sure to insert or remove Multipurpose/Chopping blade and
Slice/Shred Disc by using hubs to avoid injury.
13. To avoid injury, never place Multipurpose/Chopping blade or Slice/
Shred Disc on Base without first putting Bowl properly in place.
Make sure motor, Disc, and/or Multipurpose/Chopping blade have
stopped completely before removing cover.
14. Be certain cover is securely locked in place before operating
appliance.
15. Never feed food into chute by hand. Always use Food Pusher.
16. DO NOT operate this appliance in the presence of explosive and/or
flammable fumes.
17. DO NOT attempt to defeat the cover interlock mechanism.
18. DO NOT use the food processor to process hot liquids
19. DO NOT leave the appliance unattended while it is running.
20. Keep fingers out of discharge opening.
21. This appliance has Overload Protection. When working for too
long, the motor will stop working automatically, protecting the
appliance from overheating by cooling it down. The appliance
will work again when the motor cools down for about 5 minutes.
22. This appliance is for Household Use Only.
Toll free number for Moulinex: 1-888-670-6681
6
EN PRODUCT DIAGRAM
Food chute
Small food pusher
Big food pusher
Bowl cover
Bowl
Base
1. Big food pusher
2. Small food pusher
3. Disc Stem
4. Thin Slice/Shred
5. Multipurpose/Chopping blade
6. Dough Blade
7. Spatula
1 2 3
4
5 6 7
7
EN
Control Panel
1. Pulse
2. On
3. Off
Pulse
Pulse button must be pressed and held for unit to
operate. When released, unit will stop. Use PULSE for short
processing tasks, such as chopping nuts, raw meats, or vegetables.
This lets you check processed results and control the size.
On
When this button is pressed, unit runs continuously until
OFF button is pressed.
Off
Processor should always be left in OFF position when unit is
not in use.
PREPARING TO USE YOUR FOOD PROCESSOR
BEFORE FIRST USE
•Whenunpackingtheproductandremovingpackingmaterial,
handle the Multipurpose/Chopping blade, and Slice/Shred Disc
carefully; they are very sharp.
•WashallpartsexcepttheBaseinhot,soapywater.Rinsethem
dry. These parts can also be placed in the dishwasher. Be sure
Pulse On Off
8
EN
to read this Use & Care Book, paying special attention to the
sections on “How to Use” and “Care and Cleaning” to learn the
correct methods for taking the unit apart and cleaning.
Note: DO NOT attempt to chop ice in this food processor; it will
damage container and dull the Multipurpose/Chopping blade. This
unit will not whip cream, beat egg whites to a desirable volume,
grind coffee beans or spices with high oil content, or slice or
shred hard-cooked eggs, marshmallows, or soft cheeses.
Important: For your protection, this unit has an interlock system.
The processor won’t operate unless the bowl is properly locked
onto base and cover is properly locked onto the bowl. Be sure to
attach the bowl to the base before attaching the food chute Lid
on the bowl. Lid should be in the lock position. DO NOT attempt
to operate the unit without the bowl lid, bowl and food chute Lid
being correctly in place. Be sure base is on a flat, dry and clean
surface before you begin processing.
9
EN
OPERATING YOUR FOOD PROCESSOR
HOW TO ASSEMBLE THE BOWL
Align the base and bowl as illustrated in Fig.
1, then turn the bowl counterclockwise until it
clicks into the base.
Note: There is only one position for the bowl to
lock onto the base. The food processor will not
operate unless the bowl is securely locked onto
the base.
HOW TO LOCK THE COVER
Open the food chute lid (see “How to open food
chute lid”). Place the cover onto the bowl, align
the mark on the cover, twist the cover counter-
clockwise towards until it clicks into the bowl,
as illustrated in the Fig. 2.
Note: When cover is locked into position, the
safety mechanism on the cover and bowl will
align. The food processor will not operate unless
the cover is securely locked onto the bowl.
Fig.1
Fig.2
Bowl
Base
Cover
Bowl
10
EN
THE IMPORTANCE OF BIG FOOD PUSHER
Put the big food pusher into the food chute. As
illustrated in Fig. 3.
Fig.3
When processing large food, the big food pusher
has to be pushed into the food chute. As
illustrated in Fig. 4.
Note: The food processor will not operate unless
the big food pusher is latched onto the food
chute.
Fig.4
When processing long and thin food, the big
food pusher has to be completely pushed into
the food chute before putting foods into food
chute. As illustrated in Fig. 5.
Note: The food processor will not operate unless
the big food pusher is latched onto the food
chute.
Fig.5
