Motorola T215 User manual
Quick Start Guide
motorola T215
1
congratulations
The Motorola T215 Bluetooth® Car Kit Speakerphone
delivers a satisfying in-vehicle handsfree conversation
experience in a sleek design. Perfect for receiving and
making calls wirelessly from your phone.
• Goodbye earpieces and wires
—drive safely
with wireless control of your phone calls using
intuitive push buttons on your speakerphone.
•Stayconnected
—allows for over 36 hours of
talk time in one charge; battery indicator prompts
your next charge.
• Clear conversations always
—as good as
placing the phone next to your ear.
your speakerphone
2
your speakerphone
Take a moment to familiarize yourself with your new
T215 speakerphone.
Mute
Button
Speaker
Battery
Indicator
Light
Volume
Down
Button
Volume
Up
Button
Bluetooth
Indicator
Light
Call
Button
Microphone
Power
Switch
Charging
Port
charge it
3
charge it
You’ll need to charge your speakerphone before you can
use it. While charging, the battery indicator light is red. It
turns green when the battery is fully charged.
Note:
Speakerphone is functional while charging.
Note:
Your battery is designed to last the life of your
product. It should only be removed by a recycling facility.
Any attempt to remove or replace your battery will
damage your speakerphone.
pair & connect
4
pair & connect
Let’s get your speakerphone paired and connected to
your Bluetooth phone.
initial pair & connect
1
Turn off any Bluetooth devices previously paired with
your speakerphone.
2
Turn on the Bluetooth feature on your phone.
3
Turn on your speakerphone (see page 7 for help).
The Bluetooth and Battery indicator lights alternately
flash to indicate the speakerphone is in discoverable
mode.
4
Set your phone to search for Bluetooth devices.
5
Select
Motorola T215
from the search results on
your phone.
6
Select
Ok
or
Ye s
to pair your speakerphone with
your phone.
Note:
When prompted for the passkey, enter
0000
.
The Bluetooth indicator light changes to solid blue for
1 minute to indicate successful pairing and connection.
pair & connect
5
test your connection
To test connection to your phone:
1
Slide the speakerphone onto your visor (see “install
in car” on page 6 for help).
2
On your phone, dial the number you want to call and
press the
Call/Send
key.
If your phone and speakerphone are successfully
connected, you hear ringing on the speakerphone.
For daily use, make sure your speakerphone is turned on,
and your phone’s Bluetooth feature is on. Your
speakerphone and phone will connect automatically.
Note:
For additional help with pairing and connecting
your speakerphone with specific phones, see
www.motorola.pairxusa.com
.
install in car
6
install in car
Slide the speakerphone onto your sun visor, as shown.
turn on & off
7
turn on & off
turn on
Slide
ë
switch to
ON
position. The Bluetooth indicator
light is pulsing (if connected with a device) or flashing
along with the Battery indicator light (if ready to be
paired).
turn off
Slide
ë
switch to
OFF
position. The indicator lights turn
off to indicate the speakerphone is off.
Battery
Indicator
Light
Bluetooth
Indicator
Light
Power
Switch
volume
8
volume
Tap th e
9
or
Ï
buttons to adjust the volume on your
speakerphone.
You’ll hear a tone as you increase or decrease volume.
When you reach maximum or minimum volume, you
hear two tones.
Volume
Down
Button
Volume
Up
Button
