Motorola ADVISOR Gold User manual

1801 Main

Kansas City, MO 64108-1932

phone: 816•221•2720

fax: 816•556•9119

email: [email protected]

website: www.mobilfone.com

User’s Guide

Advisor®

Advisor ® Gold FLX

Find us on the web.

Contents

Page

ADVISOR Gold or ADVISOR Gold FLX Pager............1

Exciting FLEXTechnology by Motorola.......................1

Getting the Most fromYour Pager ...............................1

Display Symbols .........................................................2

Controls ......................................................................2

Pager Symbols............................................................3

TurningYour Pager On................................................4

TurningYour Pager Off................................................4

Receiving and ReadingYour Messages......................5

Using the Function Menu............................................6

Backlighting.................................................................6

Locking and Unlocking Messages ..............................6

Setting theTime and Date ..........................................7

Setting the Alarm ........................................................8

Setting the Message Alarm.........................................9

Setting the Alert Mode ..............................................10

Setting the Alert Pattern............................................10

Turning the Maildrop Alert On and Off ......................11

Deleting Messages from Memory.............................11

Moving Messages toYour Notebooks.......................12

Deleting Messages FromYour Notebooks................13

Setting Auto On/Off...................................................13

Other Features..........................................................14

Battery Information ...................................................15

Care ofYour Pager....................................................16

CleaningYour Pager..................................................16

Repair and Maintenance...........................................17

Patent Information.....................................................17

27b05toc.fr5 Page ii Thursday, December 5, 1996 08:21

ADVISOR Gold or ADVISOR Gold FLX Pager

Congratulations on purchasing either an ADVISOR

Gold or ADVISOR Gold FLX pager by Motorola

.Your

new pager provides exciting capabilities in messaging

and can become a vital part of your business and per-

sonal life.The pager’s four-line display and expanded

functionality incorporate many of the most advanced

electronic, communication, and wireless technologies

available. It is reliable, convenient, and designed for

easy operation.

These operating instructions explain how to use your

pager and provide helpful suggestions for ﬁrst-time

and experienced users.

Exciting FLEXTechnology by Motorola

The ADVISOR Gold FLX pager uses the latest in

paging—

FLEX



TECHNOLOGY

This technological

advance extends battery life up to ﬁve times longer

than ordinary pagers, saving you time and money.As

a Motorola FLEX

pager user, you can feel more

conﬁdent in receiving your pages because FLEX

tech-

nology improves the ability to receive pages. FLEX

technology has been developed by Motorola, the

leader in paging innovation and quality.

Along with FLEX

technology, this compact pager uses

many advances in electronic and wireless technology

which allow you to receive text and numeric messages

instantly and affordably.

Getting the Most fromYour Pager

• Spend a few minutes learning all of the functions

and messaging capabilities of your pager.

• Give your pager number to your business associ-

ates, friends, family, children’s school, and the baby-

sitter so you can always be reached in an emer-

gency.

• Include your pager number on business cards and

on your answering machine message.

1027b05text.fr5 Page 1 Thursday, December 5, 1996 08:19

Display Symbols

Controls

ESCAPE

È Ñ å É ó ò ï ñ í Ö ¶

Set

Auto

On/Off

AddTo

Note-

book

Set

Message

Alarm

Choose

Alert

Set

Audible/

Silent

Alert

Turn

Pager

Off

Escape

(tostatus

screen)

Delete All

Messages

Lock/

Unlock

Message

SetTime

and Alarm

Delete

Message

Left/Right

Directional

Buttons

Function/

Select Button Read/

Escape/

Power On

Button

Up/Down

Directional

Buttons

1027b05text.fr5 Page 2 Thursday, December 5, 1996 08:19

Pager Symbols

Pager Status Symbols: (Left column)

Power On

Audible Alert Mode

Auto On/Off

Alarm

Message Status Symbols:(Top two rows of display)

Locked Message

Maildrop Indicator (Alert Enabled)

Maildrop Indicator (Alert Disabled)

Message In Memory Indicator

Memory Full Indicator

Alarmed Message

Function Menu Symbols: (Bottom row of display)

Choose Alert

SetTime and Alarm

Set Auto On/Off

Set Audible Alert

Set Silent Alert

Turn Pager Off

Escape (to status screen)

Delete Message

Delete All Messages

Lock Message

Unlock Message

Maildrop Indicator (Alert Enabled)

Maildrop Indicator (Alert Disabled)

Set Message Alarm

Add to Notebook

1027b05text.fr5 Page 3 Thursday, December 5, 1996 08:19

Other Symbols:

Enter Auto On/Off Menu and Auto On/Off

Enabled

Auto On/Off Disabled

24 HourTime

AMTime

PMTime

Disable Alarm

Enable Alarm

No Message Alert (On Choose Alert Menu)

Chirping Alert (On Choose Alert Menu)

(

Full Battery Gauge

Low Battery Gauge

Out of Range

Message Continuation

Truncated Message

<..> Alphanumeric Missing Fragment Indicator*

- - - - -

Long Numeric Missing Fragment Indicator*

Errored Data Indicator

These symbols apply to ADVISOR Gold FLX only.

TurningYour Pager On

Press

Your pager alerts and shows

in the left column of

the display.The time and date are shown at the bottom

of the display.

TurningYour Pager Off

➊

Press

to display the function menu.

➋

Press

to move the cursor to

➌

Press

twice to turn the pager off.

1027b05text.fr5 Page 4 Thursday, December 5, 1996 08:19

Receiving and ReadingYour Messages

When a message is received, your pager alerts and

displays a ﬂashing

symbol.

➊

Press any button to stop the alert.

➋

Press

to display your message.

The pager automatically stores the message and the

time and date it is received.

A ﬂashing arrow

at the bottom right corner of the

screen indicates the message you are reading contin-

ues beyond the four lines of the display.

Press

to advance to the next screen of the mes-

sage.

Press to read your message line by line.

Press and hold

to rapidly scroll through your mes-

sage, screen by screen.

If more than one message exists, press

select the message you want to read.The symbol

indicates the location of the message. Press

display your message.While reading your messages,

you can press

to view the previous or next

message.

A ﬂashing

symbol indicates you have a message

that has not been read.The pager alerts at predeter-

mined intervals to remind you of any unread mes-

sages.

ADVISOR Gold and ADVISOR Gold FLX pagers store

up to 19 personal messages in memory.

1027b05text.fr5 Page 5 Thursday, December 5, 1996 08:19

Using the Function Menu

Press

to display the function menu.

The function menu gives you access to the many features

of your pager through a series of symbols and prompts.

For example, when the function menu screen is ﬁrst dis-

played, the

symbol ﬂashes, indicating the present

position of the cursor.You can now press

move the cursor within the function menu.

NOTE:

To exit from any menu without making changes,

press

Backlighting

The pager’s backlight illuminates in low-light condi-

tions when any button is pressed.You can manually

activate or deactivate the backlight at any time by

pressing and holding

for two seconds. If no other

buttons are pressed, the backlight automatically turns

off when the pager returns to the standby mode.

Locking and Unlocking Messages

Up to 10 messages can be locked in memory, preventing

them from being replaced when memory is full (indicated

by the ésymbol).

➊Press Ë.

➋Press äor ãto select the message to lock.

➌Press Áto display the function menu.

➍Press ãto move the cursor to lock (í) or unlock

(ì).

➎Press Áto lock or unlock the message.

➏The symbol íor ìis displayed, indicating the status

of the message in memory.

1027b05text.fr5 Page 6 Thursday, December 5, 1996 08:19

Setting theTime and Date

➊Press Áto display the function menu.

➋Press äto move the cursor to Ñ.

➌Press Áto display the set-time screen.

➍Press ãto move the cursor to the hour digit.

➎Press or to adjust the hour.

➏Press ãto move the cursor to the minute digit.

➐Press or to adjust the minute.

➑Repeat the process for each set of digits: AM/PM/

24 hr., month/day/year.

➒Press Áto activate the time and date change.

If you move the cursor past the last symbol in the row

(far right), it automatically wraps around and displays

at the ﬁrst symbol in the beginning of the same row (far

left).

NOTE:To exit from any menu without making changes,

press Ë.

●Ñ22:23ô05/06/96●

Ã0:00ô--/--/--

SET TIME

Example of Set-Time Screen

1027b05text.fr5 Page 7 Thursday, December 5, 1996 08:19

Setting the Alarm

The alarm on your pager can be set for a speciﬁc time

and date, or it can be used as a daily alarm.

To set the alarm for a speciﬁc time and date:

➊Press Áto display the function menu.

➋Press äto move the cursor to Ñ.

➌Press Áto display the set-time-and-alarm screen.

➍Press to move the cursor to Ö.

The alarm symbol deﬁnes the alarm status—either

alarm enabled (c) or alarm disabled (Ã).

➎Press ãto move the cursor to Ö.

➏Press or to enable or disable the alarm.

➐Press ãto move the cursor to the hour digit.

➑Repeat the process for each entry (minute, AM/PM,

and date).

➒Press Áto activate your selection.The Ösymbol

is shown on the display.

At the selected time, your pager emits a 12-second

audible alert even if the pager is in the silent mode.

To set the alarm to alert daily:

Follow the steps previously described, except when

setting the date, press for the date entries until you

see a blank month, day, and year (--/--/--).The alarm is

now set to alert every day at this speciﬁed time.

NOTE: If the alarm expires without being acknowl-

edged, the Ösymbol ﬂashes until any button is

pressed.

NOTE:To exit from any menu without making changes,

press Ë.

Ñ22:23ô05/06/96

●Ã0:00ô--/--/--●

SET ALARM

Example of Set-Time-and-Alarm Screen

1027b05text.fr5 Page 8 Thursday, December 5, 1996 08:19

Other manuals for ADVISOR Gold

This manual suits for next models

Table of contents

Other Motorola Pager manuals

Motorola

Motorola TimePort PF1500 User manual

Motorola

Motorola Bravo classic User manual

Motorola

Motorola Ultra Express 6881023B75-A(X) User manual

Motorola

Motorola A03DXS5862AA User manual

Motorola

Motorola 9501 User manual

Motorola

Motorola Advisor Graphix CP1250 User manual

Motorola

Motorola TALKABOUT T10 User manual

Motorola

Motorola PAGE WRITER 2000X User manual

Motorola

Motorola TalkAbout T340 User manual

Motorola

Motorola ADVISOR User manual

Motorola

Motorola ULTRA Express ULTRA Express FLX Pager User manual

Motorola

Motorola Talkabout T900 User manual

Motorola

Motorola ULTRA Express FLX User manual

Motorola

Motorola BRAVO Encore User manual

Motorola

Motorola LX2 plus User manual

Motorola

Motorola Jazz User manual

Motorola

Motorola GoldLine User manual

Motorola

Motorola LS750 User manual

Motorola

Motorola PageOne Scriptor F User manual

Motorola

Motorola 6881012B23-D User manual

Motorola

Motorola LS550 User manual

Motorola

Motorola LS350 User manual

Motorola

Motorola Lifesyle Plus User manual

Motorola

Motorola WORD LINE FLX User manual

Popular Pager manuals by other brands

Alpha

Alpha Elite user guide

LRS

LRS RX-E467 user manual

Bellman & Symfon

Bellman & Symfon Visit BE1470 user manual

unication

unication E3 user manual

Infostream

Infostream X5 User's reference manual

ACE TELECOM

ACE TELECOM ACE-2040 user manual

Intek

Intek Allure owner's manual

Pocsag

Pocsag PG-2092P user manual

Alert Systems

Alert Systems HyperGuard MP10D manual

Radio Shack

Radio Shack 17-7040 owner's manual

PageOne

PageOne Advisor Graphix instruction manual

Syscall

Syscall Nttworks GP-210RT user manual

unication

unication G4 Configuring

GE LBI-31482 Maintenance manual

Gold Apollo

Gold Apollo AL-A27 user manual

Diva Telecom

Diva Telecom profile user manual

scope

scope GEO40A user manual

ISE

ISE ISP-5900 user manual
