Motorola MC92N0-G User manual

MC92N0-G

http://www.motorolasolutions.com/mc92n0-g

Indicator LED Bar

Power

Trigger

Strap Lanyard

Microphone

Headphone

Jack

Display

Scan Button

Keypad

Stylus

Stored in handle

Data

Power

BATTERY INSERTION

QUICK START

GUIDE

See User Guide for more information

Stylus Removal

CHARGING INSTRUCTIONS

SNAP-ON ACCESSORY INSTALLATION

Cable Adapter Module

Four Slot Cradles

Charge-Only Cradle and Ethernet Cradle

Single Slot Serial/USB CradleFour Slot Spare Battery Charger

Battery Removal

Front View

SNAP-ON ACCESSORY INSTALLATION

= LED Indicator Location Slow Flash = Normal Charge Solid Amber = Full Charge Fast Flash = Charging Error= LED Indicator Location Slow Flash = Normal Charge Solid Amber = Full Charge Fast Flash = Charging Error

POST IN WORK AREA

MC92N0-G

Motorola Solutions, Inc.

http://www.motorolasolutions.com/mc92n0-g

OPTIMUM IMAGING AND SCANNING POSITIONS

OPTIMUM UPRIGHT BODY POSTURE

OPTIMUM BODY POSTURE

Taking breaks and

task rotation recommended

High Scanning

Use a ladder

Low Scanning

Alternate left and right knees

Laser Scanning

AVOID EXTREME

WRIST ANGLES

AVOID BENDING

AVOID REACHING

Alternate left and right hands

AVOID EXTREME WRIST ANGLES

Recommended Usage Guide

POST IN WORK AREAPOST IN WORK AREA

TAKING BREAKS AND TASK ROTATION RECOMMENDEDTAKING BREAKS AND TASK ROTATION RECOMMENDED

ALTERNATE LEFT AND RIGHT HANDSALTERNATE LEFT AND RIGHT HANDS

Long Range ImagingStandard Range Imaging

1301 E. Algonquin Rd. Scahumburg, IL 60196-1078, U.S.A.

MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M Logo are trademarks or

registered trademarks of Motorola Trademark Holdings, LLC and are used under license.

All other trademarks are the property of their respective owners.

72-161751-01 Rev A – July 2012
