Motorola FOCUS86 User manual

USER’S GUIDE

Focus TAG

Works with FOCUS86 Wi-Fi® Home Video Camera

The features described in this guide are subject to modifications without prior notice.

This User’s Guide has all the information you need to make the most out of your

product.

Please read the Safety Instructions on page 4 before you install the unit.

Inside the Box

• 1 x Focus TAG with pre-installed CR2032 battery

• 1 x Focus TAG Opener

• 1 x Quick Start Guide

Welcome...

to your new Motorola Focus TAG!

Thank you for purchasing your new Motorola Focus TAG.

Focus TAG is a BLE device that works as a motion sensor and a presence detector.

It is designed as an external sensor for FOCUS86 Wi-Fi®Home Video Camera. If

you have always wondered what happens when you are away, wonder no more.

Now you can monitor your children, pets or property with this easy to use device.

You can install Focus TAG from your iPhone®/iPad®or Android™ devices and

receive alerts from your PC or Notebook, as well as from your iPhone®/iPad®or

Android™ devices.

Please keep your original dated sales receipt for your records. For warranty

service of your Motorola product, you will need to provide a copy of your dated

sales receipt to confirm warranty status. Registration is not required for warranty

coverage.

For product related questions, please call:

US and Canada 1-888-331-3383

E-mail: support@motorolahome.com

On the Web: www.motorolahome.com/support

Some of the contents in this manual may differ from your device depending

on the region, service provider, model specifications, or device’s software.

Content (high quality content) that requires high CPU and RAM usage will

affect the overall performance of the device. Apps related to the content may

not work properly depending on the device’s specifications and the

environment that it is used in.

ENGLISH

Table of contents

1. Safety Instructions .................................................................................... 4

2. How it works ............................................................................................. 5

3. Overview of Focus TAG........................................................................... 5

4. Getting Started ......................................................................................... 6

4.1 Remove Plastic Strip to Power On............................................................. 6

4.2 Change Battery .......................................................................................... 6

5. Add Focus TAG as a Motion Sensor ........................................................ 8

5.1 Add another Focus TAG ............................................................................ 8

6. Add Focus TAG as a Presence Detector ................................................. 9

6.1 Add another Focus TAG ............................................................................9

7. Using Focus TAG .................................................................................... 10

8. Unpair Focus TAG with your Android™ or iOS Device........................ 10

9. Reset Focus TAG.................................................................................... 10

10. General Information ............................................................................... 11

11. Technical Specifications ......................................................................... 17

4Safety Instructions

1. Safety Instructions

WARNING

This product is compliant with all relevant electromagnetic field standards and

is, when handled as described in the User’s Guide, safe to use. Therefore,

always read the instructions in this User’s Guide carefully before using the

device.

• Adult assembly is required due to small parts. Keep all small parts away from

children.

• This product is not a toy. Do not allow children to play with it.

• This product is not a substitute for responsible adult supervision.

• Keep this User’s Guide for future reference.

• Test the product and all its functions so that you are familiar with it prior to

use.

• Do not install the product near a heat source.

• Only use a battery of the same type. This product uses a replaceable battery

(CR2032).

• Do not touch the battery contacts with sharp or metal objects.

CAUTION

There is danger of explosion if the battery is replaced by an incorrect type.

Dispose of used batteries according to their instructions.

Important guidelines for installing your Focus TAG

• Use of other 2.4 GHz products, such as other wireless networks, Bluetooth®

systems or microwave ovens may cause interference with this product. Keep

the Focus TAG away from these types of products, or turn them off if they

appear to be causing interference.

• Always ensure that you have a good Wi-Fi®connection available.

How it works 5

ENGLISH

2. How it works

As a motion detector

Stick Focus TAG on a door or window. When the door or window moves,

Focus TAG will send an alert to FOCUS86, which will then send an alert to your

Android™ or iOS device.

As a presence sensor

Place Focus TAG inside an object, such as a school bag. When your child leaves

home with the school bag, FOCUS86 will stop to receive signals from Focus

TAG. After about 1 minute, FOCUS86 will send an alert to your Android™ or iOS

device notifying you that your child has left home.

When your child returns home with the school bag, FOCUS86 will start to

receive signals from Focus TAG. You will then receive an alert from FOCUS86

notifying you that your child has reached home.

3. Overview of Focus TAG

PAIR button • Press and hold for 5 seconds to pair Focus TAG

with your Android™ or iOS device.

LED light • Flashes in blue when Focus TAG is in

registration mode.

LED light

PAIR button

Minimum Requirement: Smartphones/

Tablets: iOS7, Android 4.4, Bluetooth 4.0

(iPhone 4S or above)

6Getting Started

4. Getting Started

4.1 Remove Plastic Strip to Power On

The device uses a replaceable battery (CR2032).

Battery Life

The average battery life is up to 6 months.You will receive alerts via Hubble App

when the battery is low.

4.2 Change Battery

1. Remove the battery cover using the supplied opener.

2. Slip the opener into the slot on the back of Focus TAG.

3. Gently twist the opener to pop open the cover. Once the cover starts to

open, work your way carefully around the cover until it pops off.

Getting Started 7

ENGLISH

4. Insert the battery (model: CR2032) with positive pole (+) facing upwards

into the battery compartment.

5. Position the back cover over the battery compartment and press down

around the edges until you hear it click into its place.

6. Focus TAG powers on automatically when the battery is installed correctly.

back cover

8Add Focus TAG as a Motion Sensor

5. Add Focus TAG as a Motion Sensor

1. Make sure that you have correctly installed the battery on Focus TAG. (see

“Remove Plastic Strip to Power On” on page 6)

2. Run Hubble for Motorola Monitors App on your Android™ or iOS device.

3. Press and hold the PAIR button on Focus TAG for 5 seconds to begin

pairing it with your Android™ or iOS device. (see “Overview of Focus

TAG” on page 5 for the location of the PAIR button)

4. Select your FOCUS86 Camera.

5. Tap to select Door motion sensor.

6. Enter a name for Focus TAG, such as Front Door, Backyard Door, Bedroom

Window, and tap Continue.

7. Stick Focus TAG to the door.

Ensure that the door is closed and the distance between the door and

FOCUS86 Camera is not more than 91 metres.

8. Continue appears at the bottom of the screen and you must click

Continue to move on.

9. It will take a few minutes to check if motion sensing by Focus TAG can be

read by your FOCUS86 Camera.

A green tick appears when set up completes successfully.

10. If setup fails, tap Retry and repeat the steps starting from step 1.

11. To activate motion sensing, tap ACTIVATE NOW.

Note

The coverage area for movement detection is approximately 300 feet (91 meters)

between FOCUS86 Camera and Focus TAG.

There is a 30-second cool off period after a movement is detected.

There are 5 sensitivity options for movement detection, where “High” is the

most sensitive and “Low” is the least sensitive.

5.1 Add another Focus TAG

You can pair up to 5 Focus TAGs with your FOCUS86 Camera in your Hubble

Account.

To add another Focus TAG, repeat the steps in 5. “Add Focus TAG as a Motion

Sensor”.

Add Focus TAG as a Presence Detector 9

ENGLISH

6. Add Focus TAG as a Presence Detector

1. Make sure that you have correctly installed the battery on Focus TAG. (see

“Remove Plastic Strip to Power On” on page 6)

2. Run Hubble for Motorola Monitors App on your Android™ or iOS device.

3. Press and hold the pair button on Focus TAG for 5 seconds to begin pairing

it with your Android™ or iOS device.

4. Select your FOCUS86 Camera.

5. Tap to select Presence detection.

6. Put Focus TAG inside the object that you wish to track. Ensure that the

distance between the object and FOCUS86 Camera is not more than 300

feet (91 meters).

7. Enter a name for Focus TAG, such as Amy’s school bag and tap Continue.

8. Wait for about 10 seconds for Focus TAG to complete setup.

9. It will take a few minutes to check if presence detection by Focus TAG can

be read by your FOCUS86 Camera.

A green tick appears when set up completes successfully.

10. If setup fails, tap Retry and repeat the steps starting from step 1.

11. To activate presence detection, tap ACTIVATE NOW.

Note

The coverage area for presence detection is approximately 300 feet (91 meters)

between FOCUS86 Camera and Focus TAG.

There is a 1 minute delay before a notification will be sent to you when the target

object moves out or returns to the coverage area.

6.1 Add another Focus TAG

You can pair up to 5 Focus TAGs with your FOCUS86 Camera in your Hubble

Account. To add another Focus TAG, repeat the steps in 6. “Add Focus TAG as

a Presence Detector”.

10 Using Focus TAG

7. Using Focus TAG

8. Unpair Focus TAG with your Android™

or iOS Device

1. Run Hubble App on your Android™ or iOS® device.

2. If you have more than one camera installed, select a camera from the

camera list.

3. Tap to display a list of Focus TAG currently paired with your Android™

or iOS® device.

4. Select the Focus TAG that you wish to remove and tap .

9. Reset Focus TAG

To reset Focus TAG, simply remove the battery and insert it back again. See 4.1

“Remove Plastic Strip to Power On”.

Presence

detection

You will receive alerts on your Android™ or

iOS device when the object in which you have

placed Focus TAG leaves your house or

returns.

Motion sensor You will receive alerts on your Android™ or iOS

device when the door or window on which you

have fixed Focus TAG moves.
