Motorline MX92 Instruction Manual
V2.0
REV. 06/2017
MX92
2016-04-12
1 2 3 4 5 6 7 8
Mo Tu We Th Fr Sa Su
1
3
5
2
4
6
7
8
9
10 11
12 13
14
EN
1Week days
2Current date
3Current hour
4Signal transmission
5Programming modes
6Channel
7Up
8Confirm/Stop
9Down
10 Return
11 Advance
12 Time
13 Select
14 Battery
DESCRIPTION:
man • manual Su • Sunday
auto • automatic Mo • Monday
• random Tu • Tuesday
We • Wednesday
Th • Thursday
Fr • Friday
Sa • Saturday
Technical characteristics
• Power Supply 3V(CR2430)
• Working temperature -20 to 55°C
• Transmission frequency 433MHz
•Range 40m
• Number of channels 8 channels and 3 groups
• Code type Rolling Code
• Dimensions 45x130x12mm
PRE-PROGRAMMING
• When a battery is placed on the transmitter, this turns on all the characters on the display for
2 seconds. After this time stay in normal working.
• If more than 10 seconds passes without pressing any key, the remote control automatically
exits programming and returns to standby mode, without record any change.
• Factory values:
• the display shows initially: wednesday, 2014-01-01, 00:00h.
• manual mode active.
• Group 1 has the channels 1, 3, 5 and 7 memorized.
• Group 2 has the channels 2, 4, 6 and 8 memorized.
USER/INSTALLER MANUAL
Correct disposal of this product
(Electrical and electronic equip-
ment waste).
TRANSMISSION SIGNAL
Each time you press , the display will show in dynamic mode, indicating the signal
sending. The signal goes off when you stop pressing the button.
2. Press for 3 seconds to enter the selected group. Use - and + to select channels. To set
a channel in the group, press once. To remove if from the group, press once. When the
number is flashing, it means that does not yet belong to the group. When the number is fixed, it
belongs to the group.
In automatic or random
mode, use - and + to se-
lect the group 1 or
group
SET CURRENT DATE AND TIME
PROGRAMMING TIMER
REMOVE TIMERS
CHOOSE CHANNEL/GROUP
1 • Press M until the
remote control is in
manual mode.
1 • Select the channel
you want using the
buttons - and .
2 • Press for 3
seconds and the year
will flash.
2 • Press M until if
you put in automatic
mode (auto).
5 • Press to now set
the time and
use to change it.
NOTE • When you end the ascent and descent programming, the system automatically advances
to the next day. If you want to quit programming press for seconds.
Select the channel you want and insert for the opening and closing times.
Timers can only be deleted individually (channel by channel).
6 • Press again to set
the minutes and
use to change
them.
3 • Use the - and to
scroll through the va-
rious values that defi-
ne the date / time and
the and keys to
change each value.
3 • Press for se-
conds. The Su will flash
and the zone of the
time will appear empty.
4 • In the end, press
the button to
confirm.
4 • Using , se-
lect the day you want
to program.
The display always shows what the channel functions.
When you press an order will be transmitted by the indicated channel at the bottom of
the display.
Will be defining the ascent.
Will be defining the descent.
• MX92 was developed to function with MC4SP, MC4SPI, MC70, MC16 and MC18 control
boards. When using other control boards may be working imcompatibilities.
• The V lithium battery (CR) should be replaced once a year to ensure the
correct operation of the transmitter;
• To replace the dead battery remove the plastic cover, remove the battery out and
insert the new one, respecting the polarity shown on the container;
• The used battery must be placed in containers intended for this purpose.
Group 1 and 2 doesn't work with timer.
The minimum programmable time is minutes.
•AUTOMATIC
CONTROL (auto)
With timer function.
•MANUAL CONTROL
(man)
No timer function.
•RANDOM
CONTROL ( )
With random timing
function. The random
remote control is im-
plemented in accor-
dance with Standard ti-
ming (approx. 15 min.).
CONTROL OPTIONS
•Use Mto scroll
through the different
controls.
