Morris W76326CAP User manual
W76326CAP
EN
3
Index
BEFORE USING THE APPLIANCE ................................. 5
General warnings...................................................................... 5
Old and out-of-order fridges...................................................... 9
Safety warnings ........................................................................ 9
Installing and operating your fridge.......................................... 10
Before Using your Fridge ..........................................................11
Information about New Generation Cooling Technology ..........11
THE PARTS OF THE APPLIANCE AND THE
COMPARTMENTS .......................................................... 13
Dimensions .............................................................................. 15
THE VARIOUS FUNCTION AND POSSIBILITIES ......... 16
Display and control panel ........................................................ 16
Operating your fridge ............................................................... 17
Super freeze mode .............................................................. 17
Super cool mode .................................................................. 17
Economy mode .................................................................... 17
Holiday mode ....................................................................... 18
Drink cool mode ................................................................... 18
Screen saver mode .............................................................. 19
Light cancelling mode .......................................................... 19
Function of Child lock .......................................................... 19
Cooler temperature settings ................................................ 20
Freezer temperature settings ............................................... 20
Warnings about temperature adjustments ............................... 21
Accessories ............................................................................. 22
Freezer box .......................................................................... 22
Chiller shelf .......................................................................... 22
Humidity controler ................................................................ 22
Adjustable door shelf ........................................................... 23
Adjustable glass shelf .......................................................... 23
Natural Ion Tech / Ionisier .................................................... 23
Maxi-fresh preserver ............................................................ 24
EN
4
CLEANING AND MAINTENANCE .................................. 25
Defrosting ................................................................................ 26
Replacing LED Lighting ........................................................... 26
ARRANGING FOOD IN THE APPLIANCE ..................... 27
Refrigerator compartment ........................................................ 27
Freezer compartment .............................................................. 29
TRANSPORTATION AND CHANGING OF INSTALLATION
POSITION ........................................................................ 33
Repositioning the door ............................................................. 33
BEFORE CALLING YOUR AFTER SALES SERVICE ... 34
TIPS FOR SAVING ENERGY .......................................... 38
TECHNICAL DATA .......................................................... 39
INFORMATION FOR TEST INSTITUTES ....................... 39
CUSTOMER CARE AND SERVICE ................................ 39
EN
5
BEFORE USING THE APPLIANCE
General warnings
This appliance is not intended to be used as a built-in
appliance.
WARNING: Keep ventilation openings, in the
appliance enclosure or in the built-in structure, clear of
obstruction.
WARNING: Do not use mechanical devices or other
means to accelerate the defrosting process, other than
those recommended by the manufacturer.
WARNING: Do not use electrical appliances inside
the food storage compartments of the appliance, unless
they are of the type recommended by the manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: When positioning the appliance, ensure
the supply cord is not trapped or damaged.
WARNING: Do not locate multiple portable socket-
outlets or portable power supplies at the rear of the
appliance.
WARNING: In order to avoid any hazards resulting
IURPWKHLQVWDELOLW\RIWKHDSSOLDQFHLWPXVWEH¿[HGLQ
accordance with the following instructions:
If your appliance uses R600a as a refrigerant (this
information will be provided on the label of the cooler)
you should take care during transportation and installation
to prevent the cooler elements from being damaged.
R600a is an environmentally friendly and natural gas,
but it is explosive. In the event of a leak due to damage
of the cooler elements, move your fridge away from open
ÀDPHVRUKHDWVRXUFHVDQGYHQWLODWHWKHURRPZKHUHWKH
EN
6BEFORE USING THE APPLIANCE
appliance is located for a few minutes.
While carrying and positioning the fridge, do not
damage the cooler gas circuit.
Do not store explosive substances such as aerosol
FDQVZLWKDÀDPPDEOHSURSHOODQWLQWKLVDSSOLDQFH
This appliance is intended to be used in household
and domestic applications such as:
- VWDႇNLWFKHQDUHDVLQVKRSVRႈFHVDQGRWKHUZRUNLQJ
environments.
- farm houses and by clients in hotels, motels and
other residential type environments.
- bed and breakfast type environments;
- catering and similar non-retail applications.
If the socket does not match the refrigerator plug,
it must be replaced by the manufacturer, a service
DJHQWRUVLPLODUO\TXDOL¿HGSHUVRQVLQRUGHUWRDYRLG
a hazard.
A specially grounded plug has been connected to the
power cable of your refrigerator. This plug should be
used with a specially grounded socket of 16 amperes.
If there is no such socket in your house, please have
one installed by an authorised electrician.
This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without
supervision.
EN
7
Children aged from 3 to 8 years are allowed to load
and unload refrigerating appliances. Children are not
expected to perform cleaning or user maintenance
of the appliance, very young children (0-3 years old)
are not expected to use appliances, young children
(3-8 years old) are not expected to use appliances
safely unless continuous supervision is given, older
children (8-14 years old) and vulnerable people can
use appliances safely after they have been given
appropriate supervision or instruction concerning
use of the appliance. Very vulnerable people are not
expected to use appliances safely unless continuous
supervision is given.
If the supply cord is damaged, it must be replaced
by the manufacturer, an authorised service agent or
VLPLODUTXDOL¿HGSHUVRQVLQRUGHUWRDYRLGDKD]DUG
This appliance is not intended for use at altitudes
exceeding 2000 m.
To avoid contamination of food, please respect the
following instructions:
Opening the door for long periods can cause
D VLJQL¿FDQW LQFUHDVH RI WKH WHPSHUDWXUH LQ WKH
compartments of the appliance.
Clean regularly surfaces that can come in contact
with food and accessible drainage systems
6WRUHUDZPHDWDQG¿VKLQVXLWDEOHFRQWDLQHUVLQWKH
refrigerator, so that it is not in contact with or drip
onto other food.
Two-star frozen-food compartments are suitable for
storing pre-frozen food, storing or making ice cream
and making ice cubes.
BEFORE USING THE APPLIANCE
EN
8
One-, two- and three-star compartments are not
suitable for the freezing of fresh food.
If the refrigerating appliance is left empty for long
SHULRGVVZLWFKRႇGHIURVWFOHDQGU\DQGOHDYHWKH
door open to prevent mould developing within the
appliance.
BEFORE USING THE APPLIANCE
EN
9
BEFORE USING THE APPLIANCE
Old and out-of-order fridges
If your old fridge has a lock, break or remove the lock before
discarding it, because children may get trapped inside it and may
cause an accident.
Old fridges and freezers may contain isolation material and
refrigerant with CFC or HFC. Therefore, take care not to harm
environment when you are discarding your old fridges.
Please ask your municipal authority about the disposal of the WEEE
reuse, recycle and recovery purposes.
Notes:
Please read the instruction manual carefully before installing and
using your appliance. We are not responsible for the damage
occurred due to misuse.
Follow all instructions on your appliance and instruction manual,
and keep this manual in a safe place to resolve the problems that
may occur in the future.
This appliance is produced to be used in homes and it can only be
XVHGLQGRPHVWLFHQYLURQPHQWVDQGIRUWKHVSHFL¿HGSXUSRVHV
It is not suitable for commercial or common use. Such use will
cause the guarantee of the appliance to be cancelled and our
company will not be responsible for losses incurred.
This appliance is produced to be used in houses and it is only
suitable for cooling / storing food. It is not suitable for commercial
or common use and/or for storing substances except for food.
Our company is not responsible for losses to be incurred in the
contrary case.
Safety warnings
Do not connect your Fridge Freezer to the mains electricity
supply using an extension lead.
Do not plug in damaged, torn or old plugs.
Do not pull, bend or damage the cord.
This appliance is designed for use by adults, do not allow children
WRSOD\ZLWKWKHDSSOLDQFHRUOHWWKHPKDQJRႇWKHGRRU
Never touch the power cord/plug with wet hands as this could
cause a short circuit or electric shock.
Do not place glass bottles or beverage cans in the ice-making
compartment as they can burst as the contents freeze.
EN
10 BEFORE USING THE APPLIANCE
'R QRW SODFH H[SORVLYH RU ÀDPPDEOH PDWHULDO LQ \RXU IULGJH
Place drinks with high alcohol content vertically in the fridge
compartment and make sure that their tops are tightly closed.
When removing ice from the ice-making compartment, do not
touch it. Ice may cause frost burns and/or cuts.
Do not touch frozen goods with wet hands. Do not eat ice-cream
or ice cubes immediately after you have taken them out of the
ice-making compartment.
Do not re-freeze frozen goods after they have melted. This may
cause health issues such as food poisoning.
'RQRWFRYHUWKHERG\RUWRSRIIULGJHZLWKODFH7KLVDႇHFWVWKH
performance of your fridge.
Secure any accessories in the fridge during transportation to
prevent damage to the accessories.
Installing and operating your fridge
Before using your fridge, you should pay attention to the following
points:
The operating voltage for your fridge is 220-240 V at 50Hz.
We do not accept responsibility for any damages that occur due
to ungrounded usage.
Place your fridge where it will not be exposed to direct sunlight.
Your appliance should be at least 50 cm away from stoves, gas
ovens and heater cores, and at least 5 cm away from electrical
ovens.
Your fridge should never be used outdoors or exposed to rain.
When your fridge is placed next to a deep freezer, there should
be at least 2 cm between them to prevent humidity forming on
the outer surface.
Do not place anything on your fridge, and install your fridge in
a suitable place so that at least 15 cm of free space is available
above it.
Do not place heavy items on the appliance.
Use the adjustable front legs to make sure your appliance is
level and stable. You can adjust the legs by turning them in either
direction. This should be done before placing food in the fridge.
Before using your fridge, wipe all parts with a solution of warm
water and a teaspoon of sodium bicarbonate, then rinse with
clean water and dry. Place all parts in the fridge after cleaning.
Install the plastic distance guide (the part with black vanes at
WKHUHDUE\WXUQLQJLWDVVKRZQLQWKH¿JXUHWRSUHYHQWWKH
condenser from touching the wall.
The refrigerator should be placed against a wall with a free space
not exceeding 75 mm.
EN
11
BEFORE USING THE APPLIANCE
Before Using your Fridge
:KHQXVLQJ\RXUIULGJHIRUWKH¿UVWWLPHRUDIWHUWUDQVSRUWDWLRQ
keep it in an upright position for at least 3 hours before plugging
LQWR WKH PDLQV 7KLV DOORZV HႈFLHQW RSHUDWLRQ DQG SUHYHQWV
damage to the compressor.
<RXUIULGJHPD\KDYHDVPHOOZKHQLWLVRSHUDWHGIRUWKH¿UVWWLPH
This is normal and the smell will fade away when your fridge
starts to cool.
Information about New Generation Cooling
Technology
)ULGJHV ZLWK QHZ JHQHUDWLRQ FRROLQJ WHFKQRORJ\ KDYH D GLႇHUHQW
working system than static fridges. In normal fridges, humid air that
enters into fridge and the water vapor that comes out from the foods,
accumulates frost formation in freezer compartment. In order to melt
this frost, in other words defrost, the fridge has to be stopped. During
the stopping period, to keep the foods cold, user has to extract the
food to outside of fridge and user has to clear the ice during this
period.
In the fridges with new generation cooling technology, situation in
WKHIUHH]HUFRPSDUWPHQWLVFRPSOHWHO\GLႇHUHQW:LWKWKHDLGRIIDQ
cold and dry air is blown out through many points into the freezer
compartment. As a result of the homogenously blown cold air, even in
the spaces between shelves, foods are frozen equally and correctly.
On the other hand there will be no frost formation.
,QWKHUHIULJHUDWRUFRPSDUWPHQWWKHUHZLOOEHQHDUO\VDPHFRQ¿JXUDWLRQ
with freezer compartment. Air, that is emitted with the fan, located at
the top of refrigerator compartment, is cooled while passing through
the gap behind the air duct. At the same time, air is blown out through
the holes on the air duct so that cooling process is successfully
completed in the refrigerator compartment. Holes on the air duct are
designed such that the air distribution becomes homogenous in this
compartment.
As there is no air passage between freezer and refrigerator
compartment, there will be no odor mixing.
As a result of these, your fridge with new generation cooling
technology, gives you, ease of use beside the huge volume and
esthetic appearance.
Table of contents
Other Morris Refrigerator manuals
Morris
Morris T71525D User manual
Morris
Morris S70148SP User manual
Morris
Morris T71360CAP User manual
Morris
Morris W71366CAP/3 User manual
Morris
Morris KSTRC44CW User manual
Morris
Morris S7449SDL User manual
Morris
Morris W70305DAP User manual
Morris
Morris W7258GD User manual
Morris
Morris W71411NFD User manual
Morris
Morris GRB-409 User manual
Morris
Morris W72121SD User manual
Morris
Morris W7148SD User manual
Morris
Morris S71350NFL User manual
Morris
Morris B72212ETL User manual
Morris
Morris S71410NFD User manual
Morris
Morris B7556CAP User manual
Morris
Morris RETRO MRS-31320R User manual
Morris
Morris T70747DH User manual
Morris
Morris W71297CAP User manual
Morris
Morris B7222SP User manual
