Montpelier MICL88 User manual

Integrated Larder Fridge - In Column

MICL88 - 88cm - Slider Fixings

Please read these instructions carefully before attempting to install or use this appliance.

We recommend that you keep these instructions in a safe place for future reference.

Installation and Operating Instructions

THE PERFECT BALANCE OF FUNCTION AND STYLE

LAUNDRY - DISHWASHING - COOKING - COOLING

EN - 2

Icon Type Meaning

WARNING Serious injury or death risk

RISK OF ELECTRIC SHOCK Dangerous voltage risk

FIRE Warning; Risk of re / ammable materials

CAUTION Injury or property damage risk

IMPORTANT Operating the system correctly

Thank you for choosing this Montpellier Integrated Larder Fridge.

Our refrigeration products have been designed to provide you with the best combination of style, reliability and

performance to give you years of trouble-free use.

You may be familiar with a similar product, but please take time to read these instructions carefully before installing

or using your Fridge to ensure you get the most from your purchase.

We recommend that you keep this manual in a safe place for future reference.

Your Integrated Larder Fridge is covered by a comprehensive 5 Year Parts &

Labour Guarantee. In the unlikely event that you experience a problem with

your Fridge, you can rest assured that you are fully protected against the cost

of repairs for the first 5 Years. Please note that any claim must be

accompanied by the model reference number, serial number and proof of

purchase.

To activate your guarantee, you will need your product serial number. This

can be found inside your appliance on the left hand wall on a small sticker.

There are two ways to register your Guarantee:

•Online: Visit the Support page on our website and complete the online Product

Registration form. www.montpellier-appliances.com

•By Post: Simply detach and ll in the form provided, attach a stamp and send

it in the post. Don’t forget to include your e-mail address so that we can send

conrmation through to you.

Welcome

Note: We are unable to take registrations over the phone.

ACROSS INTEGRATED COOLING

YEAR

GUARANTEE

PA R T S & L A B O U R

www.montpellier-appliances.com

EN - 3

CONTENTS

1 SAFETY INSTRUCTIONS ................................................................................. 4

1.1 General Safety Warnings ...............................................................................................4

1.2 Installation warnings.......................................................................................................7

1.3 Electrical information (For UK type plug)........................................................................7

1.4 During Usage..................................................................................................................8

2 DESCRIPTION OF THE APPLIANCE ............................................................... 9

3 USING THE APPLIANCE .................................................................................. 9

3.1 Thermostat Setting .........................................................................................................9

3.2 Temperature Settings Warnings .....................................................................................9

4 FOOD STORAGE ............................................................................................ 10

5 CLEANING AND MAINTENANCE .................................................................. 11

5.1 Defrosting .....................................................................................................................12

5.2 Replacing the Light Bulb...............................................................................................12

6 SHIPMENT AND REPOSITIONING................................................................. 13

6.1 Transportation and Changing Positioning ....................................................................13

7 BEFORE CALLING AFTER-SALES SERVICE............................................... 13

8 TIPS FOR SAVING ENERGY .......................................................................... 14

EN - 4

1 SAFETY INSTRUCTIONS

1.1 General Safety Warnings

Read this user manual carefully.

WARNING: Keep ventilation openings, in the

appliance enclosure or in the built-in structure, clear of

obstruction.

WARNING: Do not use mechanical devices or

other means to accelerate the defrosting process,

other than those recommended by the manufacturer.

WARNING: Do not use electrical appliances inside

the food storage compartments of the appliance,

unless they are of the type recommended by the

manufacturer.

WARNING: Do not damage the refrigerant circuit.

WARNING: When positioning the appliance,

ensure the supply cord is not trapped or damaged.

WARNING: Do not locate multiple portable socket-

outlets or portable power supplies at the rear of the

appliance.

WARNING: In order to avoid any hazards resulting

from the instability of the appliance, it must be xed in

accordance with the following instructions:

If your appliance uses R600a as a refrigerant (this

information will be provided on the label of the cooler)

you should take care during transportation and

installation to prevent the cooler elements from being

damaged. R600a is an environmentally friendly and

EN - 5

natural gas, but it is explosive. In the event of a leak

due to damage of the cooler elements, move your

fridge away from open ames or heat sources and

ventilate the room where the appliance is located for a

few minutes.

• While carrying and positioning the fridge, do not

damage the cooler gas circuit.

• Do not store explosive substances such as aerosol

cans with a ammable propellant in this appliance.

• This appliance is intended to be used in household

and domestic applications such as:

–staff kitchen areas in shops, ofces and other

working environments.

–farm houses and by clients in hotels, motels and

other residential type environments.

–bed and breakfast type environments;

–catering and similar non-retail applications.

• If the socket does not match the refrigerator plug,

it must be replaced by the manufacturer, a service

agent or similarly qualied persons in order to avoid

a hazard.

• A specially grounded plug has been connected

to the power cable of your refrigerator. This plug

should be used with a specially grounded socket

of 13 amperes. If there is no such socket in your

house, please have one installed by an authorised

electrician.

EN - 6

• This appliance can be used by children aged from

8 years and above and persons with reduced

physical, sensory or mental capabilities or lack of

experience and knowledge if they have been given

supervision or instruction concerning use of the

appliance in a safe way and understand the hazards

involved. Children shall not play with the appliance.

Cleaning and user maintenance shall not be made

by children without supervision.

• Children aged from 3 to 8 years are allowed to load

and unload refrigerating appliances. Children are not

expected to perform cleaning or user maintenance

of the appliance, very young children (0-3 years old)

are not expected to use appliances, young children

(3-8 years old) are not expected to use appliances

safely unless continuous supervision is given, older

children (8-14 years old) and vulnerable people can

use appliances safely after they have been given

appropriate supervision or instruction concerning

use of the appliance. Very vulnerable people are

not expected to use appliances safely unless

continuous supervision is given.

• If the supply cord is damaged, it must be replaced

by the manufacturer, an authorised service agent or

similar qualied persons, in order to avoid a hazard.

• This appliance is not intended for use at altitudes

exceeding 2000 m.

EN - 7

1.2 Installation warnings

Before using your fridge for the rst time,

please pay attention to the following points:

• The operating voltage for your fridge is

220-240 V at 50Hz.

• The plug must be accessible after

installation.

• Your fridge may have an odour when it is

operated for the rst time. This is normal

and the odour will fade when your fridge

starts to cool.

• Before connecting your fridge, ensure

that the information on the data plate

(voltage and connected load) matches

that of the mains electricity supply. If in

doubt, consult a qualied electrician.

• Insert the plug into a socket with an

efcient ground connection. If the socket

has no ground contact or the plug does

not match, we recommend you consult a

qualied electrician for assistance.

• The appliance must be connected

with a properly installed fused socket.

The power supply (AC) and voltage at

the operating point must match with

the details on the name plate of the

appliance (the name plate is located on

the inside left of the appliance).

• We do not accept responsibility for any

damages that occur due to ungrounded

usage.

• Place your fridge where it will not be

exposed to direct sunlight.

• Your fridge must never be used outdoors

or exposed to rain.

• Your appliance must be at least 50 cm

away from stoves, gas ovens and heater

cores, and at least 5 cm away from

electrical ovens.

• If your fridge is placed next to a deep

freezer, there must be at least 2 cm

between them to prevent humidity

forming on the outer surface.

• Do not cover the body or top of fridge

with lace. This will affect the performance

of your fridge.

• Clearance of at least 150 mm is required

at the top of your appliance. Do not place

anything on top of your appliance.

• Do not place heavy items on the

appliance.

• Clean the appliance thoroughly before

use (see Cleaning and Maintenance).

• Before using your fridge, wipe all parts

with a solution of warm water and a

teaspoon of sodium bicarbonate. Then,

rinse with clean water and dry. Return all

parts to the fridge after cleaning.

• The installation procedure into a kitchen

unit is given in the installation manual.

This product is intended to be used in

proper kitchen units only.

1.3 Electrical information (For UK type

plug)

Warning! This appliance must be

earthed.

The mains lead of this appliance has been

tted with a specially earthed plug.

Important: Do not use the

appliance without the fuse cover in position.

Should the fuse need to be replaced, it

must be replaced with a 13A fuse, ASTA

approved to BS1362.

The plug must be used with a specially

earthed socket of 13 amperes. If there is

no such socket in your house, please have

one installed by an authorised electrician.

The mains lead of this appliance has been

tted with a BS 1363A 13A fused plug. To

change a fuse in this type of plug, follow

the steps below:

EN - 8

1. Remove the fuse cover and fuse.

2. Fit replacement 13A fuse, ASTA

approved to BS 1362 type, into the fuse

cover.

3. Replace fuse cover.

1.4 During Usage

• Do not connect your fridge to the mains

electricity supply using an extension lead.

• Do not use damaged, torn or old plugs.

• Do not pull, bend or damage the cord.

• Do not use plug adapter.

• This appliance is designed for use by

adults. Do not allow children to play with

the appliance or hang off the door.

• Never touch the power cord/plug with wet

hands. This may cause a short circuit or

electric shock.

• Do not place explosive or ammable

material in your fridge. Place drinks with

high alcohol content vertically in the

fridge compartment and make sure their

tops are tightly closed.

Old and Out-of-order Fridges

• If your old fridge or freezer has a

lock, break or remove the lock before

discarding it, because children may

get trapped inside it and may cause an

accident.

• Old fridges and freezers contain

isolation material and refrigerant with

CFC. Therefore, take care not to harm

environment when you are discarding

your old fridges.

CE Declaration of conformity

We declare that our products meet the

applicable European Directives, Decisions

and Regulations and the requirements

listed in the standards referenced.

Disposal of your old appliance

The symbol on the product or on

its packaging indicates that this

product may not be treated as

household waste. Instead it shall

be handed over to the applicable

collection point for the recycling of electrical

and electronic equipment. By ensuring

this product is disposed of correctly,

you will help prevent potential negative

consequences for the environment and

human health, which could otherwise be

caused by inappropriate waste handling

of this product. For more detailed

information about recycling of this product,

please contact your local city ofce, your

household waste disposal service or the

shop where you purchased the product.

Packaging and the Environment

Packaging materials protect

your machine from damage that

may occur during transportation.

The packaging materials are

environmentally friendly as they are

recyclable. The use of recycled material

reduces raw material consumption and

therefore decreases waste production.

Notes:

• Please read the instruction manual

carefully before installing and using your

appliance. We are not responsible for the

damage occurred due to misuse.

• Follow all instructions on your appliance

and instruction manual, and keep this

manual in a safe place to resolve the

problems that may occur in the future.

• This appliance is produced to be used

in homes and it can only be used in

domestic environments and for the

specied purposes. It is not suitable for

commercial or common use. Such use

will cause the guarantee of the appliance

to be cancelled and our company will

not be responsible for the losses to be

occurred.

• This appliance is produced to be used in

houses and it is only suitable for cooling

/ storing foods. It is not suitable for

commercial or common use and/or for

storing substances except for food. Our

company is not responsible for the losses

to be occurred in the contrary case.

EN - 9

2 DESCRIPTION OF THE

APPLIANCE

This presentation is only for

information about the parts of the

appliance. Parts may vary according to the

appliance model.

1) Thermostat box

2) Refrigerator shelves

3) Crisper cover

4) Crispers

5) Bottle shelf

6) Door shelves

7) Egg holder

3 USING THE APPLIANCE

3.1 Thermostat Setting

The fridge thermostat automatically

regulates the temperature of the

compartment. Fridge temperatures can

be obtained by rotating the knob to higher

numbers, 1 to 5.

Important note: Do not try to rotate

the knob beyond position 1, it will stop

your appliance from working.

Lamp cover

Thermostat knob

Thermostat Settings

• Set the knob to a low/medium position,

up to 3, for short-term storage of food in

the appliance.

• Set the knob to a medium position, 3 or

4, for long-term storage of food in the

appliance.

• For long-term storage of food in the

refrigerator, you can set knop maximum

position (4 - 5).

3.2 Temperature Settings Warnings

• The ambient temperature, temperature of

the freshly stored food and how often the

door is opened affects the temperature

in the fridge. If required, change the

temperature setting.

• It is not recommended that you operate

your fridge in environments colder than

10°C in terms of its efciency.

• When setting the thermostat, take into

consideration how often the appliance

door is opened and closed, how much

food is stored in the refrigerator, and the

environment in which the refrigerator is

located.

EN - 10

• When the appliance is rst switched on,

allow it to run for 24 hours in order to

reach operating temperature. During this

time, do not open the door and do not

keep a large quantity of food inside.

• Unplug your appliance during a power cut

to prevent damage to the compressor.

Once power is restored, delay plugging

in your appliance for 5 to 10 minutes.

This will help prevent damage to the

appliance's components.

• Your appliance is designed to operate in

the ambient temperature ranges stated

in the standards, according to the climate

class stated in the information label. It

is not recommended that your fridge is

operated in the environments which are

outside of the stated temperature ranges.

This will reduce the cooling efciency of

the appliance.

• Your appliance is designed to operate in

the ambient temperature (T/N = 16°C -

43°C) intervals stated in the standards,

according to the climate class displayed

on the information label. We do not

recommend operating your appliance out

of the stated temperature limits in terms

of cooling effectiveness.

Climate

Class Ambient Temperature oC

TBetween 16 and 43 (°C)

ST Between 16 and 38 (°C)

NBetween 16 and 32 (°C)

SN Between 10 and 32 (°C)

4 FOOD STORAGE

• To reduce humidity and avoid the

consequent formation of frost, always

store liquids in sealed containers in the

refrigerator. Frost tends to concentrate in

the coldest parts of the evaporating liquid

and, in time, your appliance will require

more frequent defrosting.

• Never place warm food in the

refrigerator. Warm food should be

allowed to cool at room temperature

and should be arranged to ensure

adequate air circulation in the refrigerator

compartment.

• Make sure no items are in direct contact

with the rear wall of the appliance as

frost will develop and packaging will stick

to it. Do not open the refrigerator door

frequently.

• We recommend that meat and clean sh

are loosely wrapped and stored on the

glass shelf just above the vegetable bin

where the air is cooler, as this provides

the best storage conditions.

• Store loose fruit and vegetable items in

the crisper containers.

• Store loose fruit and vegetables in the

crisper.

• Storing fruit and vegetables separately

helps prevent ethylene-sensitive

vegetables (green leaves, broccoli,

carrot, etc.) being affected by ethylene-

releaser fruits (banana, peach, apricot,

g etc.).

• Do not put wet vegetables into the

refrigerator.

• Storage time for all food products

depends on the initial quality of the food

and an uninterrupted refrigeration cycle

before refrigerator storage.

• To avoid cross-contamination do not

store meat products with fruit and

vegetables. Water leaking from meat

may contaminate other products in the

refrigerator. You should package meat

products and clean any leakages on the

shelves.

Table of contents

Other Montpelier Refrigerator manuals

Montpelier

Montpelier MLF176W User manual

Popular Refrigerator manuals by other brands

Bonnet Neve

Bonnet Neve SKYVIEW PLUS User instructions

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Instruction book

Sharp

Sharp SJ-BA31IEXW2-EU user manual

CORBERO

CORBERO CC2300MCW Instruction booklet

KitchenAid

KitchenAid 2205264 Use and care guide

Stengel

Stengel KU 1101 A++ user manual

NEFF

NEFF KI181 Series user manual

Hoshizaki

Hoshizaki Reach-In instruction manual

Amana

Amana ASD2524VES00 User instructions

BOMANN

BOMANN KGC 213 instruction manual

Danby

Danby DAR044A1SLDD Owner's use and care guide

Samsung

Samsung RF323TE user manual

Beko

Beko CSA31022 Instructions for use

IKEA

IKEA FROSTIG C 185 E manual

Electrolux

Electrolux ER 6821 D Instruction book

True

True TS-28 Specifications

Frigidaire

Frigidaire FSC23R5DW9 installation guide

Beko

Beko LSP4579W Instructions for use
