Molex 207129 Series User manual

Hand Crimp Tool For SATA Power Cable Crimp Receptacles

Doc No: ATS-638239900 Release Date: 02- - UNCONTROLLED COPY Page of 7

Revision: A Revision Date: 02- -

INSULATION CRIMP

HEIGHT

BRUSH

STRIP

LENGTH

BELL MOUTH

CONDUCTOR CRIMP HEIGHT

BEND

DOWN

BEND

ROLLING

LANCE HEIGHT

TWISTING

SEAM

CUT-OFF

TAB

HAND CRIMP

TOOL

Application Tooling

Sp cification Sh t Ord r No. 63823-9900

FEATURES

 A full cycle ratcheting hand tool ensures complete crimps

 Ergonomic soft grip handles for comfortable crimping

 A precision user-friendly terminal locator wire stop holds terminals in the proper crimping position

 Right and Left handed applications

 This tool is IPC/WHMA A-620 Class 2 compliant

 This tool is RoHS compliant, however RoHS compliant is not required

SCOPE

Products: SATA Power Cable Crimp Receptacles, 8-22 AWG.

T rminal

S ri s No.

T rminal Ord r No. Wir Siz and Typ

Insulation Diam t r Strip L ngth





R l AWG mm² mm In. mm In.

6758

6758 -0000

6758 -000

8-22 UL 007 .40-2.40

.055-.094

3.50 . 38

6758 -0002

6758 -0009

6758 -00 0

6758 -00

6758 -00 2

6758 -00 9

Customer to cut off terminal from reel: 0.50mm (.020”) maximum Cut-off Tab.

DEFINITION OF TERMS

TYPE 4D

Hand Crimp Tool For SATA Power Cable Crimp Receptacles

Doc No: ATS-638239900 Release Date: 02- - UNCONTROLLED COPY Page 2 of 7

Revision: A Revision Date: 02- -

The above terminal drawing is a generic terminal representation. It is not an image of a terminal listed in the

scope.

▲Insulation Crimp Not :

Due to the terminal’s insulation grip design

and/or insulation diameter range, this tool

uses “overlap” form geometry in the

insulation punch. This produces an overlap

insulation crimp (A620 – compliant). While

the insulation punch profile may appear

“lopsided”, this is a normal condition for this

tool. See figure to the right. (Some tools with

multiple crimp pockets may not have the

“overlap” profile on all pockets).

CONDITIONS:

After crimping, the conductor profiles should measure the following.

T rminal

S ri s No

Wir Siz Conductor Crimp Insulation Crimp Pull Forc

Minimum Profil

H ight Width (R f.) H ight Max.

Width (R f.)

AWG

mm2 mm In. mm In. mm In. mm In. N Lb. 18

6758

8 UL 007

. 5- .25

.045-.049

.55- .65

.06 -.065

3.50 . 38 2.90 . 4 88.20

9.8

20 UL 007

. 0- .20

.043-.047

.55- .65

.06 -.065

3.50 . 38 2.90 . 4 58.80

3.2

22 UL 007

.05- . 5

.04 -.045

.55- .65

.06 -.065

3.50 . 38 2.90 . 4 39.20

8.8 X

OPERATION

CAUTION: Install only Molex terminals listed above with this tool. Do not crimp hardened objects as damage can

occur to the tool or die.

Open the tool by squeezing the handles

together. At the end of the closing stroke, the

ratchet mechanism will release the handles

and the hand tool will spring open. See

Figure .

Crimping T rminals

. Select the desired terminal listed in the

preceding charts.

2. Make sure the center of the locator is in

the down position. With the locator

attached, push the locator button on the

back of the hand tool to bring the locator

forward through the tooling. See Figure

OVERLAP

INSULATION

CRIMP

OVERLAP FORM GEOMETRY

ANVIL

PUNCH

WIRE

LOCATOR

IN DOWN

POSTION

PUSH ON THE

LOCATOR BUTTON

Figur 2

SQUEEZE HANDLES

TOGETHER

HANDLE WILL

SPRING OPEN

Figur 1

Hand Crimp Tool For SATA Power Cable Crimp Receptacles

Doc No: ATS-638239900 Release Date: 02- - UNCONTROLLED COPY Page 3 of 7

Revision: A Revision Date: 02- -

RELEASE

LOCATOR BUTTON

TERMINAL

Figur 3

LOCATOR

PUSHED THRU

TOOLING

TERMINAL

LOCATOR

BUTTON

PUSHED IN

LOCATOR

3. While holding the locator button in, load the terminal into the proper nest opening in the locator based on the

wire gauge or terminal type markings on the hand tooling. See Figure 3.

4. Release the locator button, allowing the locator to return to the crimping position.

5. Close the tool handle until the first ratchet position engages. See Figure 4.

6. Insert the properly stripped wire through the terminal and against the wire stop. See Figure 5.

7. Crimp the terminal by squeezing the tool handles until the ratchet mechanism cycle has been completed.

Release the handles to open the jaws.

Note: The tamper proof ratchet action will not release the tool until it has been fully closed.

8. Remove the crimped terminal from the terminal

locator by pulling on the wire.

9. Visually inspect the crimped terminal for proper

crimp location.

TERMINAL

Figur 6

WIRE

WIRE STOP

PARTIALLY

CLOSE HANDLE

TOOLING

PARTIALLY

CLOSED

Figur 4

FIRST RATCHET

POSITION

OPEN

POSITION

PRE-STRIPPED WIRE

TERMINAL

WIRE AGAINST THE

WIRE STOP

Figur 5 TERMINAL

WIRE

WIRE STOP

IS PART

OF THE

LOCATOR

Hand Crimp Tool For SATA Power Cable Crimp Receptacles

Doc No: ATS-638239900 Release Date: 02- - UNCONTROLLED COPY Page 4 of 7

Revision: A Revision Date: 02- -

Figur 8

PUSH ON

HANDLE

JAWS OPEN

PULL OPEN

TOOLING TOOLING

M3 BHCS

MATCH

UP MARKS

FRONT BACK

Figur 9

0. On some large O.D. wires, it may not be

possible to insert the wire with the tool partially

closed. Those wires should be inserted with the

hand tool in the open position. Insert the wire

above the terminal in the punch and against the

wire stop then close the tool. See Figure 6.

Not :

A crimp height chart is provided with this manual as

Reference Only. Due to the wide range of wires,

strands, insulation diameters, and durometers

available, actual crimp height measurements may

very slightly. An occasional, destructive, pull force

test should be performed to check hand tool crimp.

Pull Force value Must exceed the Minimum pull force

specifications listed.

Locator R plac m nt

See the parts list on the last page of this document for

the proper locator order number. Follow the steps

below to replace the locator.

. Open the crimp hand tool.

2. Squeeze gently on the lower area shown in Figure

7A with your thumb and index finger. The lower

tabs of the locator should disengage from the hand

tool.

3. Lift and pull away from the hand tool. The top

locator hooks should slip out of the top slots easily.

See Figure 7A.

4. To reinstall the new locator, make sure the hand

tool is in the open position.

5. Press the red insert down as far as it will go as shown in Figure 7B.

6. Holding onto the lower part of the locator with your thumb and index finger, insert the locators top hooks (2)

into the hand tool top slots.

7. Rotate the locator down and press the lower tabs

into the two bottom slots of the hand tool. To secure

the locator into place, the lower tabs must snap into

place on the hand tool frame.

Right or L ft Hand Op ration

This hand tool has an added feature that can be

converted from a right handed application to a left

handed application. It is necessary to reverse the tooling if using the left handed application along with the locator.

Follow the steps below:

SQUEEZE

HERE

SQUEEZE

HERE

LOCATOR

Figur 7A

TOP HOOKS

TOP SLOTS OF

HANDTOOL

LOWER TABS

MAKE SURE

CENTER OF LOCATOR

IS IN THE

DOWN POSITION

Figur 7B

Hand Crimp Tool For SATA Power Cable Crimp Receptacles

Doc No: ATS-638239900 Release Date: 02- - UNCONTROLLED COPY Page 5 of 7

Revision: A Revision Date: 02- -

Figur 12

SQUEEZE

THE LINK IN

THE HANDLE

HOLD THE HAND

TOOL IN POSITION

SETTING

WHEEL

RATCHET

RELEASE LEVER

. The locator must be removed before reversing the tooling.

2. Remove the M3 BHCS which is holding the upper tooling.

3. Flip the upper tooling to the opposite side and replace the M3 BHCS. Make

sure the small markings on the front and back of the hand tool frame match

up and are on the outside of the hand tool frame. See Figure 8 and 9.

4. Do the same thing with the lower tooling and tighten the M3 screws. Be

sure the small markings line up.

5. Reinstall the locator by following the Instructions in the locator replacement

section.

Maint nanc

It is recommended that each operator of the tool be made aware of, and

responsible for, the following maintenance steps:

. Remove dust, moisture, and other contaminants with a clean brush, or soft, lint free cloth.

2. Do not use any abrasive materials that could damage the tool.

3. Make certain all pins; pivot points and bearing surfaces are protected with

a thin coat of high quality machine oil. Do not oil excessively. The tool

was engineered for durability but like any other equipment it needs

cleaning and lubrication for a maximum service life of trouble free crimping.

Light oil (such as 30 weight automotive oil) used at the oil points, every

5,000 crimps or 3 months, will significantly enhance the tool life.

4. Wipe excess oil from hand tool, particularly from crimping area. Oil

transferred from the crimping area onto certain terminations may affect the

electrical characteristics of an application.

5. When tool is not in use, keep the handles closed to prevent objects from

becoming lodged in the crimping dies, and store the tool in a clean, dry

area.

Miscrimps or Jams

Should this tool ever become stuck or

jammed in a partially closed position, Do

Not force the handles open or closed. The

tool will open easily by pressing up on the

ratchet release lever in the movable

handle. See Figure .

How to Adjust Tool Pr load (S

Figur 12)

This hand tool is factory preset to 25-45

LBS. preload. It may be necessary over

the life of the tool to adjust tool handle

preload force. Listed below are the steps

required to adjust the crimping force of the hand tool to obtain proper crimp conditions:

LUBRICATION POINTS

(BOTH SIDES) LIGHT OIL

(EVERY 3 MONTHS OR

5,000 CRIMPS)

Figur 10

RATCHET RELEASE

LEVER

Figur 11

Hand Crimp Tool For SATA Power Cable Crimp Receptacles

Doc No: ATS-638239900 Release Date: 02- - UNCONTROLLED COPY Page 6 of 7

Revision: A Revision Date: 02- -

. Hold the hand tool in the palm of your hand as shown in Figure 2. Using the index finger squeeze the link

towards the top of the hand tool frame. This will release the preload adjustment wheel.

2. Rotate the setting wheel counter-clockwise (CCW) to increase handle force. The numbers will display higher.

To decrease handle force rotate the setting wheel clockwise (CW).

3. Release the link to lock the setting wheel in place.

4. Check the crimp specifications or conduct a pull test after tool handle preload force is adjusted.

Warranty

This tool is for electrical terminal crimping purposes only. This tool is made of the best quality materials. All vital

components are long life tested. All tools are warranted to be free of manufacturing defects for a period of 30

days. Should such a defect occur, we will repair or exchange the tool free of charge. This repair or exchange will

not be applicable to altered, misused, or damaged tools. This tool is designed for hand use only. Any clamping,

fixturing, or use of handle extensions voids this warranty.

CAUTION: Molex crimp specifications are valid only when used with Molex terminals and tooling.

CAUTIONS:

. Manually powered hand tools are intended for low volume or field repair. This tool is NOT intended for

production use. Repetitive use of this tool should be avoided.

2. Insulated rubber handles are not protection against electrical shock.

3. Wear eye protection at all times.

4. Use only the Molex terminals specified for crimping with this tool.

C rtification

Molex does not certify or re-certify hand tools but rather supplies the following guidelines for customers to re-certify

hand tools.

% This tool is qualified to pull force only. See the Molex web site for the Quality Crimp Handbook for more

information on pull testing.

% If the tool does not meet minimum pull force values, handle preload should be increased and the pull test

rerun, (See How to Adjust Preload).

% When the hand tool is no longer capable of achieving minimum pull force, it should be taken out of service and

replaced.

Hand Crimp Tool For SATA Power Cable Crimp Receptacles

Doc No: ATS-638239900 Release Date: 02- - UNCONTROLLED COPY Page 7 of 7

Revision: A Revision Date: 02- -

Figur 13

PARTS LIST

It m Numb r Ord r Numb r D scription Quantity

REF 63823-9900 Hand Crimp Tool Figure 3

63823-9975 Locator Assembly

2 638 0-0 04 Spring, Return

3 638 0-0 05 Spring, Ratchet

http://www.molex.com

Other manuals for 207129 Series

100

This manual suits for next models

Table of contents

Popular Crimping Tools manuals by other brands

Panduit

Panduit CT-1000 Operation & instruction manual

JST

JST CS 10 instruction manual

Danfoss

Danfoss ET4200 Operator's manual

Tyco Electronics

Tyco Electronics PRO-CRIMPER III instruction sheet

TE Connectivity

TE Connectivity 2063528-1 instruction sheet

Tyco Electronics

Tyco Electronics 69156-1 instruction sheet

CRH

CRH CRL CBLHCT1 instruction manual

Emerson

Emerson Klauke ES 105CFM manual

KIMBALL MIDWEST

KIMBALL MIDWEST 27-798 Operating instructions manual

Danfoss

Danfoss ET4350 Operator's manual

Milwaukee

Milwaukee M18 Operator's manual

HOGERT

HOGERT HT1P169 user manual

Textron

Textron ESG105L instruction manual

Tyco Electronics

Tyco Electronics 90035-3 instruction sheet

Emerson

Emerson Klauke ES 20RMCCFB manual

Continental Refrigerator

Continental Refrigerator PC150HD quick start guide

TE Connectivity

TE Connectivity ERGOCRIMP 1-1579001-3 instruction sheet

Tyco Electronics

Tyco Electronics CERTI-CRIMP 90418-1 instruction sheet

molex 207129 Series User manual

Popular Crimping Tools manuals by other brands
