Mitsubishi Electric SD220U User manual

Energy savings considered throughout, including low-maintenance,

filter-free construction and cost-saving operation. Lamp life extended

to as long as 4,000hr when used in the “Low Lamp” mode.

*When used at the low lamp mode. Maximum lamp life at standard mode use is 3,000 hours.

Energy-saving, Cost-saving FeaturesEasy User Interface

Introducing the New Teacher’s Pet

It’s like giving a presentation in a suburban residential area in the

middle of the night! That’s the operating sound level promised by

the SD220U.

SD220U

Mobile SVGA

NEW

Simple, No-nonsense Operation

Quick Menu

Operation doesn’t get any easier than this.

The tool bar is broken down into seven

main menus and one custom menu.

Switch to sub-menus for setting more

specific operations.

The perfect projector for educational environments

Amazingly Quiet OperationUser-friendly Design

Easy Lamp Replacement

The projection lamp is located in the upper

part of the projector, so regardless of

where the unit is sitting—on a table or

suspended from the ceiling—replacement

is quick and easy.

Long-life 4,000hr* Lamp

Stand-by Mode of Less than 1W

Only 26dBA (in low mode)

MOBILE SVGA PROJECTOR

SD220U

Screen Size and Projection Distance

As seen from the side

SD220U

Height

Projection Distance (L)

SD220U

0.55" 1-Chip DMD

800 x 600 (Total 480,000 pixels)

2200lm

2000 : 1

30" - 300"

1.9 - 2.2

Model

Display Technology

Resolution

Brightness

Contrast Ratio

Picture Size

Throw Ratio

Specifications

PC Compatibility 640 x 480 - 1280 x 1024,

True : 800 x 600, Sync on Green available

NTSC / NTSC 4.43 / PAL

(

including PAL-M, N

)

/ SECAM / PAL-60

Component Video ; 480i/p (525i/p), 576i/p (625i/p),

720p (750p), 1080i (1125i 60Hz), 1080i (1125i 50Hz)

Video Compatibility

160W (Shut-off Time 4000hr)with Low Mode,

180W (Shut-off Time 3000hr)with Standard Mode

Source Lamp

RGB ; mini D-sub 15pin x 1

Video ; RCA x 1

Audio ; Stereo mini jack (ø3.5mm)x 1

Input Terminals

Communication Terminal

Audio Speaker

Dimensions (W x H x D)

Weight

Power Requirements

Optional Lamp

RS-232C; mini DIN 8pin x 1

2W Mono

320 x 104 x 236 mm / 12.6 x 4.1 x 9.3 inch

3.0kg / 6.6lbs

AC 100-240V, 50/60Hz

VLT-XD221LP

Screen

Diagonal Size Width (W)Max. Zoom Min. Zoom

Height (H)

inch

120

150

180

Distance from screen (L)Height projected

image (Hd)

inch

100

150

200

250

300

102

152

203

254

381

508

635

762

inch

120

160

200

240

122

163

203

305

406

508

610

122

152

229

305

381

457

inch

124

155

233

311

389

468

1.5

2.3

3.1

3.9

5.9

7.9

9.9

11.9

inch

103

138

173

260

347

434

1.7

2.6

3.5

4.4

6.6

8.8

11.0

inch

3.6

5.4

7.2

9.0

13.4

17.9

22.4

26.9

Screen size chart (4:3 aspect ratio)

The above numbers are approximate, and may be slightly different from the actual measurements.

Screen

Diagonal Size Width (W)Max. Zoom Min. Zoom

Height (H)

inch

123

147

Distance from screen (L)Height projected

image (Hd)

inch

100

150

200

250

300

102

152

203

254

381

508

635

762

inch

131

174

218

261

133

177

221

332

443

553

664

100

125

187

249

311

374

inch

100

135

169

254

339

424

509

1.7

2.6

3.4

4.3

6.4

8.6

10.8

12.9

inch

112

150

188

283

378

473

1.9

2.8

3.8

4.8

7.2

9.6

12.0

inch

7.2

10.8

14.3

17.9

26.9

35.9

44.8

53.8

114

137

Screen size chart (16:9 aspect ratio)

The above numbers are approximate, and may be slightly different from the actual measurements.

320

236

116 116

34.5

45.4

113.9135.5

213

14.3

30.6

214

64.5

60.2

Top View Bottom View

Front View Side View

• Compliance with ISO21118-2005

• All brand names and product names are trademarks, registered trademarks or trade names of their respective holders.

Unit:mm

Input and Output Terminals

Audio input

Video

PC/Component

Video input

Serial RS-232C

1 2 3 4

Brilliant

ColorTM

Color

Enhancer

Wall

Screen Splash

Screen

Low

Stand-by

Power

Low

Fan Noise

Top/Side

Lamp

Page

Up/Down

Instant

Shutdown

Long-life

Lamp

Password

Lock

Picture Performance

Presentation

User Friendly
