Mitsubishi Electric P-250F-E User manual

LOSSNAY HEAT RECOVERY VENTILATOR SYSTEM COMPONENT

Filter name MODEL

MODEL CODE

Applicable model Location to use

Replacement lter P-250F-E 5KB010

VL-250CZPVU-R-E/VL-250CZPVU-L-E

RA, OA

L Type

R Type

RA: Return Air

OA: Outdoor Air

SA: Supply Air

P-350F-E 5KB016

VL-350CZPVU-R-E/VL-350CZPVU-L-E

Standard lter P-250SF-E 5KB011

VL-250CZPVU-R-E/VL-250CZPVU-L-E

RA, OA

SA

P-350SF-E 5KB017

VL-350CZPVU-R-E/VL-350CZPVU-L-E

Medium e󰀩ciency lter P-250MF-E 5KB012

VL-250CZPVU-R-E/VL-250CZPVU-L-E

RA, OA

SA

P-350MF-E 5KB018

VL-350CZPVU-R-E/VL-350CZPVU-L-E

PM2.5 lter P-250PF-E 5KB013

VL-250CZPVU-R-E/VL-250CZPVU-L-E

RA, OA

SA

P-350PF-E 5KB019

VL-350CZPVU-R-E/VL-350CZPVU-L-E

NOx lter P-250NF-E 5KB014

VL-250CZPVU-R-E/VL-250CZPVU-L-E

SA

P-350NF-E 5KB020

VL-350CZPVU-R-E/VL-350CZPVU-L-E

* When a NOx lter and an optional dust catch lter (P-250/350SF-E, P-250/350MF-E, P-250/350PF-E) are used together, make sure

to install a NOx lter on the SA side and a dust catch lter on the OA side.

* Install any of the lters other than NOx lter on the OA and RA side to protect the product.

Instruction Manual For Customer

This lter is a part to replace the lter installed in Lossnay.

- Make sure to read this manual carefully before using the product.

Safety precautions

The types and levels of danger that may arise if the product

is handled improperly are described with the warning symbols

shown below.

WARNING

This applies to mishandling or misoperation of the product which may

lead to a fatal or serious injury.

Follow

instructions

Before replacement, make sure to turn o󰀨 the

controller and the distribution panel circuit breaker.

Electric shock and burns could result if power is owing.

CAUTION

This applies to mishandling or misoperation of the product, which will

lead to an injury or damage to your home, household e󰀨ects, etc.

Follow

instructions

Always wear gloves during replacement.

Injury could result.

Securely install the parts.

Injury could result if the product falls.

Do not use an unstable stand for replacement.

Injury could result from falling over.

Outline drawings and Materials

Unit: mm

MODEL A B

P-250F-E 302 178

P-250SF-E

P-250MF-E

P-250PF-E

P-250NF-E

306 177

P-350F-E 377 178

P-350SF-E

P-350MF-E

P-350PF-E

P-350NF-E

382 177

Materials are shown below, please dispose properly according to

the laws of each country.

MODEL Main material

P-250/350F-E PET, acrylic ber

P-250/350PF-E

P-250/350MF-E

P-250/350SF-E

Polypropylene, polyester

P-250/350NF-E Pulp

Filtration specication

MODEL ISO16890: 2016 EN779: 2012

P-250/350F-E Coarse 55% G3

P-250/350SF-E Coarse 90% G4

P-250/350MF-E ePM10 80% M6

P-250/350PF-E ePM2.5 50% M6

P-250/350NF-E: Exclusion rate of NO2is 90%.

* The ltration specications other than the specications of

P-250/350NF-E are results of tests conducted by third-party certication

bodies and are not a guaranteed value.

* The ltration specications of P-250/350NF-E are measured by the

manufacturer and are not a guaranteed value.

A

B

15

OA

SA

RA

RA

SA

OA

2011876H07701

Manufactured by:

TOKYO BLDG. 2-7-3, MARUNOUCHI, CHIYODA-KU, TOKYO, 100-8310 JAPAN

3. Install the lters.

Install the lter in the lter case in the reverse order of disassembly.

- When installing the lter in the lter case, insert the lter slowly

by widening the lter xing tab so that the lter is not deformed.

- Check that the lter is not stuck out of the lter case.

Reassembly and checking after replacement

CAUTION

After maintenance, install the parts securely.

Injuries could result if the product falls.

1. Install the removed lter case and lter cover on the unit.

2. After reassembling, press the ON/OFF button on the controller

and check the following.

- Check that the unit is not making any abnormal noises.

- Check that the unit is blowing the air correctly.

- Check that the air is not leaking from the installation part of

the lter case.

Note:

- Depending on the use environment, condensation water, snow,

and fog can adhere to the lters. These are not the problems of

product functions and quality.

- Do not forget to install the lters. (Dirt can clog on the surface of

the Heat exchanger, resulting in lowering the air volume.)

- Filters below are disposable and cannot be cleaned.

Replacement intervals are di󰀨erent depending on the conditions

of the air to use. Refer to the maintenance timing below to

replace with new lters.

Type Model name Maintenance timing

Standard lter P-250SF-E

P-350SF-E One year

Medium e󰀩ciency lter P-250MF-E

P-350MF-E One year

PM2.5 lter P-250PF-E

P-350PF-E

For SA installation: One year

For OA and RA installations: Six months

NOx lter P-250NF-E

P-350NF-E Six months

- Refer to the unit’s manual to learn about how to clean and replace

P-250F-E and P-350F-E, and how to use the lter maintenance

sign of the remote controller.

- For consultation on the handling and maintenance, contact your

dealer.

We recommend to enter the date of the start of use of lters

in the below table per replacement for the next replacement.

Filter name Installation location Date of start of use

OA SA RA

OA SA RA

OA SA RA

OA SA RA

OA SA RA

Filter case

Filter

Filter xing tab

Replacement method

1. Turn the power o󰀨

1) Turn the Lossnay o󰀨.

2) Shut o󰀨 circuit breakers.

2. Remove the lters.

* The gure shows VL-350CZPVU-R-E.

1) Remove the lter covers where the lters are replaced.

2) Pull out the lter cases slowly.

CAUTION

When removing lter cases, make sure to withdraw them

slowly by using both hands. Otherwise, condensed water

can drop from the inside.

3) Remove the lters from the lter cases.

* By factory default, a lter is not inserted in the supply air

lter case.

OFF

Breaker

Filter cover (outdoor air lter)

Filter cover (exhaust air lter)

Filter cover (supply air lter)

Filter case (outdoor air lter)

Filter case (exhaust air lter)

Filter case (supply air lter)

Filter case

Filter

Filter xing tab
