Miia MWT-843G User manual
MIIA
Windows
TAB 8” 3G
ENG
MIIA MWT-843G
User Manual
INTRODUCTION
Thank you for your choosing the new Tablet PC.
This guide serves to enable users to get to know and familiar with our product as
soon as possible. Here we have made a brief introduction to the key layout and
definitions in figures and words.
4
I. Precautions before Use......................................................................................... 4
II. Key Layout and Denitions................................................................................... 5
III. Introduction to Desktop....................................................................................... 6
1. Windows 8.1 Start Screen.................................................................................... 6
2. Image Slide Application........................................................................................ 7
3. apps Introduction ................................................................................................. 8
4. Barra di accesso .................................................................................................. 9
5. Double Screen Application................................................................................. 11
IV. Basic Operations ............................................................................................... 12
1. Dormancy, Restart, and Power off ..................................................................... 12
2. Security Management ........................................................................................ 12
V. Iplay8 & Android operation system instructions................................................. 13
1. Notice illustration................................................................................................ 13
2. Wake or turn on the tablet under screen lock .................................................... 14
3. Home screen ...................................................................................................... 14
4. Applications screen............................................................................................ 15
5. Setting ................................................................................................................ 15
CONTENTS
5
I. PRECAUTIONS BEFORE USE
This production is suitable for use in non-tropic areas below 2,000 meters, and the
mark in the nameplate indicates the product is suitable for use in non-tropic
areas.
2. Prevent the Tablet PC from falling to the ground or being strongly impacted
otherwise.
3. Do not use it in the long term in any environment where the air is too cold, too hot
(<35°C), too humid or with too much dust. Do not expose the Tablet PC to sunlight.
4. Avoid using it in the strong magnetic and strong static environment as much as
possible.
5. Once any water or other liquid splashes onto the Tablet PC, close it immediately
and do not use it until it dries out.
6. Do not clean the Tablet PC with any detergent containing chemical element or
other liquid to avoid causing damage due to corrosion and becoming damp. If
cleaning is really necessary, clean it with dry soft cloth tissue paper.
7. Our company shall not bear any and all responsibilities for loss or deletion of
material inside the machine caused due to abnormal software and hardware
operation, maintenance or any other accident.
8. Please back up your important material at any time to avoid loss.
9. Please do not disassemble the Tablet PC by yourself; otherwise you will lose the
right to warranty.
10. This product supports the overwhelming majority of mainstream brands of 3G
DONGLE network cards. The cases for 3G Dongle may be different. It is suggested
that you test it to make sure it is OK before buying it.
11. This user manual will give instructions for iwork8 &iplay8 separately.Before
using the product,please carefuly read the operating instructions.The iwork8 runs
windows8.1 OS,while the iplay8 runs Android OS.
6
II. KEY LAYOUT AND DEFINITIONS
1Windows key/Power key: Press this button to return to the Start screen.
2Sound-/sound+: Lower/raise volume.
3Front CCD camera: take photos, and record pictures.
4Indicator light.
5Back CCD camera: take photos, and record pictures.
6
Press it down to start or close the touch screen panel. You can also let the
computer to enter dormancy through this button or wake from the
dormancy mode
8Headphone jack.
9
USB Port/
Mini HDMI Interface:
High-Definition Multimedia Interface.
Micro SD card slot:
The built-in storage card reader slot supports Micro SD.
DC port:
Charge device through this DC port DC-5V/2A.
7
SIM
7
1. Windows 8.1 start image
On the start screen, you can see many programs fixed in the image. These application
programs are displayed in the form of “magnet”. As long as you click them, you can
easily visit them.
You need to log on your Microsoft account before the application program completely
runs.
III. INTRODUCTION TO DESKTOP
8
2. Image slide applications
Slide to right
Reduce
Slide upward
Slide to left
Enlarge
Slide to the right from the left side
of the screen to start the application
program in running.
On the touch screen, narrow two fingers
to reduce the image.
In the start screen, slide upward from
the bottom of the screen to visit all
application program (APPS) interfaces.
Slide to the left from the right
side of the screen to start Charm menu
column.
On the touch screen, widen two
fingers to enlarge the image.
9
3. Introduction to app Interface
Besides the application programs already fixed on the start screen, you can also
start other application programs in all application programs, such as other software
application programs attached to the Tablet PC.
If you want to fix more application programs on the start interface, see the operation
in the figure below, (1) lightly touch, press and hold the application program magnet
for about one second and then let go, and select (2) to fix to the start screen.
10
Conversely, if you want to cancel or delete a certain application in the start screen, (1)
lightly touch, press and hold the application program magnet for about one second
and then let it go and run, and select (2) attribute column to cancel the programs
such as fixation and deletion and then it can be completed.
4. Charm menu column
Slide it to the left from the right side of the screen to start Charm menu column,
including: Start, Device, Setup, Share, and Search Program.
