Migatronic OMEGA2 BASIC II User manual

QUICKGUIDE

OMEGA2BASIC II

50113770 I

Proces 1,0 mm 1,5 mm 2,0 mm 3,0 mm

Materiale Tråd Gas S

(m/min)

(V)

(m/min)

(V)

(m/min)

(V)

(m/min)

(V)

Fe 0,8 CO22,5 19,0 4,5 19,5 7,0 21,0 11,0 27,0

Fe 1,0 CO22,0 18,0 2,5 19,0 3,0 20,0 4,5 21,0

Fe 1,2 CO21,0 18,0 2,0 20,0 2,5 21,0 3,5 22,0

Fe 0,8 ArCO23,0 16,0 6,0 18,0 7,5 19,5 11,0 20,0

Fe 1,0 ArCO22,0 15,0 3,0 16,0 4,0 17,0 6,0 19,0

Fe 1,2 ArCO21,5 16,5 2,5 17,5 3,5 18,0 4,5 20,5

Fe 1,6 ArCO21,0 17,0 2,0 18,0 2,5 18,5

CrNi 1,0 ArCO23,0 15,0 4,0 16,0 6,0 17,0 8,5 20,0

CrNi 1,2 ArCO22,0 15,0 3,0 16,0 3,5 16,5 6,0 18,0

AI 1,0 Ar 4,0 14,5 6,0 15,0 7,5 16,0 9,0 19,0

AI 1,2 Ar 3,5 13,0 5,0 15,0 8,0 16,0 9,0 17,0

Proces 4,0 mm 6,0 mm 10,0 mm

Materiale Tråd Gas S

(m/min)

(V)

(m/min)

(V)

(m/min)

(V)

Fe 0,8 CO213,0 29,0 18,0 30,0 24,0 37,0

Fe 1,0 CO26,0 22,5 9,0 24,5 14,0 32,0

Fe 1,2 CO24,5 23,0 7,5 28,5 11,0 36,0

Fe 0,8 ArCO214,0 26,0 18,0 31,0 24,0 33,0

Fe 1,0 ArCO28,0 20,0 11,5 26,5 16,0 30,0

Fe 1,2 ArCO25,5 20,5 8,0 29,0 10,0 32,0

Fe 1,6 ArCO23,0 19,5 4,0 22,0 5,5 29,0

FeFlux 1,2 ArCO26,0 21,0 8,0 25,0 11,0 28,0

CrNi 1,0 ArCO29,0 25,0 10,0 27,0

CrNi 1,2 ArCO28,0 24,0 10,0 24,0 12,0 31,0

AI 1,0 Ar 11,0 22,0 13,0 25,0 15,0 27,0

AI 1,2 Ar 10,0 18,0 13,0 23,0 15,0 26,0

Svejsetabel (indstillet værdi) BASIC II - fabriksindstilling

Indstillingsmuligheder Område Trin Fabriksindstilling Enhed

2T/4T

Primære parametre:

1 Trådhastighed OMEGA2300 1,5 - 18,0 0,1 3,0 m/min

Trådhastighed OMEGA2400/550 1,5 - 27,0 0,1 3,0 m/min

2 Lysbuespænding OMEGA2300 13 - 32 0,1 18,0 V

Lysbuespænding OMEGA2400/550 13 - 37 0,1 18,0 V

Sekundære parametre:

1 Arc Adjust -5,0 - +5,0 0,1 0,0 -

2 Gasforstrømning 0,0 - 10,0 0,1 0,2 s

3 Krybestart Off / 1,5 - Max. 0,1 2,0 m/min

6 Burnback 1 - 30 1 5 ms

7 Gasefterstrømning 0,0 - 10,0 0,1 3,0 s

t Punkttid 0,0 - 50,0 0,1 0,0 s

G Gas Manuel 0,5 - 27,0 l

r Fjernkontrol 0 = intern

1 = brænderkontrol

2 = fjernkontrol

C Køling ON / Off

L Låsefunktion ON / OFF

QUICKGUIDE OMEGA2BASIC II

3 Drejeknap

Indstilling af lysbuespænding. Hvis

knappen for sekundære parametre er

aktiv, vil sekundære parametre kunne

trimmes.

4 Trådhastighed og Lysbuelængde

Tryk på knappen og drej på dreje-

knapperne, indtil den ønskede

trådhastighed og lysbuelængde opnås.

5 Sekundære parametre

Tryk på knappen indtil den ønskede

parameter vises i displayet. Afslut med

et kort tryk på knap 4

Låsefunktion

(under sekundære parametre)

Sekundære parametre kan låses/låses op

ved at holde knap 1 og knap 4 inde

samtidigt.

ASvejsespænding

B Advarsel - Overophedning

BASIC II BETJENINGSPANEL

I. Tænd maskinen

II. Indstil trådhastighed

III. Indstil lysbuespænding

1 Valg af tastemetode

Skift mellem 2-takt (indikator slukket)

og 4-takt (indikator lyser).

2-takt: Svejseforløbet begynder, når

brændertasten aktiveres og afsluttes,

når brændertasten slippes.

4-takt: S

vejseforløbet begynder, når

brændertasten aktiveres og slippes.

Afsluttes når brændertasten atter

aktiveres.

2 Drejeknap

Indstilling af trådhastighed samt ranger-

hastighed når der rangeres.

Arc Adjust (elektronisk drossel)

GAS

Fjernkontrol

Køling 4-takt tast (1) skal holdes inde for at

aktivere/deaktivere kølingen via drejeknap 3

(kun Omega2400/550)

Låsefunktion

Indstillet svejsestrøm (A)

Krybestart

(m/min.)

Gasfor-

strømning (t) Burnback

Gasefter-

strømning (t)

Punkttid (s)

QUICKGUIDE

OMEGA2BASIC II

50113770 I

Process 1.0 mm 1.5 mm 2.0 mm 3.0 mm

Material Wire Gas S

(m/min)

(V)

(m/min)

(V)

(m/min)

(V)

(m/min)

(V)

Fe 0.8 CO22.5 19.0 4.5 19.5 7.0 21.0 11.0 27.0

Fe 1.0 CO22.0 18.0 2.5 19.0 3.0 20.0 4.5 21.0

Fe 1.2 CO21.0 18.0 2.0 20.0 2.5 21.0 3.5 22.0

Fe 0.8 ArCO23.0 16.0 6.0 18.0 7.5 19.5 11.0 20.0

Fe 1.0 ArCO22.0 15.0 3.0 16.0 4.0 17.0 6.0 19.0

Fe 1.2 ArCO21.5 16.5 2.5 17.5 3.5 18.0 4.5 20.5

Fe 1.6 ArCO21.0 17.0 2.0 18.0 2.5 18.5

CrNi 1.0 ArCO23.0 15.0 4.0 16.0 6.0 17.0 8.5 20.0

CrNi 1.2 ArCO22.0 15.0 3.0 16.0 3.5 16.5 6.0 18.0

AI 1.0 Ar 4.0 14.5 6.0 15.0 7.5 16.0 9.0 19.0

AI 1.2 Ar 3.5 13.0 5.0 15.0 8.0 16.0 9.0 17.0

Process 4.0 mm 6.0 mm 10.0 mm

Material Wire Gas S

(m/min)

(V)

(m/min)

(V)

(m/min)

(V)

Fe 0.8 CO213.0 29.0 18.0 30.0 24.0 37.0

Fe 1.0 CO26.0 22.5 9.0 24.5 14.0 32.0

Fe 1.2 CO24.5 23.0 7.5 28.5 11.0 36.0

Fe 0.8 ArCO214.0 26.0 18.0 31.0 24.0 33.0

Fe 1.0 ArCO28.0 20.0 11.5 26.5 16.0 30.0

Fe 1.2 ArCO25.5 20.5 8.0 29.0 10.0 32.0

Fe 1.6 ArCO23.0 19.5 4.0 22.0 5.5 29.0

FeFlux 1.2 ArCO26.0 21.0 8.0 25.0 11.0 28.0

CrNi 1.0 ArCO29.0 25.0 10.0 27.0

CrNi 1.2 ArCO28.0 24.0 10.0 24.0 12.0 31.0

AI 1.0 Ar 11.0 22.0 13.0 25.0 15.0 27.0

AI 1.2 Ar 10.0 18.0 13.0 23.0 15.0 26.0

Welding table (set value) BASIC II - Factory setting

Setting possibilities Area Step Factory setting Unit

2T/4T

Primary parameters:

1 Wire feed speed OMEGA2300 1.5 - 18.0 0.1 3.0 m/min

Wire feed speed OMEGA2400/550 1.5 - 27.0 0.1 3.0 m/min

2 Arc voltage OMEGA2300 13 - 32 0.1 18.0 V

Arc voltage OMEGA2400/550 13 - 37 0.1 18.0 V

Secondary parameters:

1 Inductance -5.0 - +5.0 0.1 0.0 -

2 Gas pre ﬂow 0.0 - 10.0 0.1 0.2 s

3 Soft start Off / 1.5 - Max. 0.1 2.0 m/min

6 Burnback 1 - 30 1 5 ms

7 Gas post ﬂow 0.0 - 10.0 0.1 3.0 s

t Spot time 0.0 - 50.0 0.1 0.0 s

G Gas Manual 0.5 - 27 l

r Remote control 0 = internal

1 = torch control

2 = remote control

C Cooling ON / OFF

L Lock function ON / OFF

QUICKGUIDE OMEGA2BASIC II

3 Control knob

Setting the arc voltage. If the key

for secondary parameters is active,

it is possible to trim the secondary

parameters.

4 Wire feed speed and arc length

Press the key and turn the control knobs

until the desired wire feed speed and arc

length are achieved.

5 Secondary parameters

Press the key until the desired

parameter is shown on the display.

Press key 4brieﬂy to ﬁnish.

Lock function

(under secondary parameters)

Lock/unlock secondary parameters

by pressing keys 1 and 4

simultaneously.

AWelding voltage

B Warning – overheating

BASIC II CONTROL PANEL

I. Switch on the machine

II. Set wire feed speed

III. Set arc voltage

1 Selecting trigger mode

Change between 2-stroke (indicator off)

and 4-stroke (indicator on).

2-stroke: The welding process starts

when the torch trigger is activated and

ends when the torch trigger is released.

4-stroke: The welding process starts

when the torch trigger is activated

and released, and ends when the torch

trigger is activated again.

2 Control knob

Setting the wire feed speed and inching

speed during wire inching.

Arc adjust (electronic choke)

GAS

Remote control

Cooling Press and hold down 4-stroke key (1)

to activate/deactivate cooling using control

knob 3 (Omega2400/550 only)

Lock funktion

Set welding current (A)

Soft start

(m/min.)

Gas

pre ﬂow (t) Burnback

Gas post

ﬂow (t)

Spot time (s)

QUICKGUIDE

OMEGA2BASIC II

50113770 I

Verfahren 1,0 mm 1,5 mm 2,0 mm 3,0 mm

Material Draht Gas S

(m/min)

(V)

(m/min)

(V)

(m/min)

(V)

(m/min)

(V)

Fe 0,8 CO22,5 19,0 4,5 19,5 7,0 21,0 11,0 27,0

Fe 1,0 CO22,0 18,0 2,5 19,0 3,0 20,0 4,5 21,0

Fe 1,2 CO21,0 18,0 2,0 20,0 2,5 21,0 3,5 22,0

Fe 0,8 ArCO23,0 16,0 6,0 18,0 7,5 19,5 11,0 20,0

Fe 1,0 ArCO22,0 15,0 3,0 16,0 4,0 17,0 6,0 19,0

Fe 1,2 ArCO21,5 16,5 2,5 17,5 3,5 18,0 4,5 20,5

Fe 1,6 ArCO21,0 17,0 2,0 18,0 2,5 18,5

CrNi 1,0 ArCO23,0 15,0 4,0 16,0 6,0 17,0 8,5 20,0

CrNi 1,2 ArCO22,0 15,0 3,0 16,0 3,5 16,5 6,0 18,0

AI 1,0 Ar 4,0 14,5 6,0 15,0 7,5 16,0 9,0 19,0

AI 1,2 Ar 3,5 13,0 5,0 15,0 8,0 16,0 9,0 17,0

Verfahren 4,0 mm 6,0 mm 10,0 mm

Material Draht Gas S

(m/min)

(V)

(m/min)

(V)

(m/min)

(V)

Fe 0,8 CO213,0 29,0 18,0 30,0 24,0 37,0

Fe 1,0 CO26,0 22,5 9,0 24,5 14,0 32,0

Fe 1,2 CO24,5 23,0 7,5 28,5 11,0 36,0

Fe 0,8 ArCO214,0 26,0 18,0 31,0 24,0 33,0

Fe 1,0 ArCO28,0 20,0 11,5 26,5 16,0 30,0

Fe 1,2 ArCO25,5 20,5 8,0 29,0 10,0 32,0

Fe 1,6 ArCO23,0 19,5 4,0 22,0 5,5 29,0

FeFlux 1,2 ArCO26,0 21,0 8,0 25,0 11,0 28,0

CrNi 1,0 ArCO29,0 25,0 10,0 27,0

CrNi 1,2 ArCO28,0 24,0 10,0 24,0 12,0 31,0

AI 1,0 Ar 11,0 22,0 13,0 25,0 15,0 27,0

AI 1,2 Ar 10,0 18,0 13,0 23,0 15,0 26,0

Schweißtabelle (eingestellter Wert) BASIC II – werkseitige Einstellungen

Einstellmöglichkeiten Bereich Abstufung Werkseitige

Einstellung

Einheit

2T/4T

Primärparameter:

1 Drahtfördergeschwindigkeit OMEGA 300 1,5 - 18,0 0,1 3,0 m/min

Drahtfördergeschwindigkeit OMEGA 400/550 1,5 - 27,0 0,1 3,0 m/min

2 Lichtbogenspannung OMEGA 300 13 - 32 0,1 18,0 V

Lichtbogenspannung OMEGA 400/550 13 - 37 0,1 18,0 V

Sekundärparameter:

1 Drossel -5,0 - +5,0 0,1 0,0 -

2 Gasvorströmung 0,0 - 10,0 0,1 0,2 s

3 Einschleichstart Off / 1,5 - Max. 0,1 2,0 m/min

6 Drahtrückbrand 1 - 30 1 5 ms

7 Gasnachströmung 0,0 - 10,0 0,1 3,0 s

t Punktschweißzeit 0,0 - 50,0 0,1 0,0 s

G Gas Manuell 0,5 - 27,0 l

r Fernregelung 0 = intern

1 = Brennerregelung

2 = Fernregelung

C Kühlung Ein/Aus

L Schlossfunktion Ein/Aus

QUICKGUIDE OMEGA2BASIC II

3 Drehregler

Einstellung der Lichtbogenspannung.

Wenn die Taste für Sekundärparameter

aktiv ist, können die Sekundär-

parameter eingestellt werden.

4 Drahtgeschwindigkeit und

Lichtbogenlänge

Die Taste drücken und die Drehregler

drehen, bis die gewünschten Draht-

geschwindigkeit und Lichtbogenlänge

erreicht sind.

5 Sekundärparameter

Taste gedrückt halten, bis der

gewünschte Parameter im Display

angezeigt wird.

Untermenü, Sekundärparameter:

Verlassen erfolgt durch kurzen

Tastendruck auf 4

Schlossfunktion

(unter Sekundärparameter)

Zum Sperren/Entsperren der Sekundär-

parameter die Taste 1 und die Taste 4

gleichzeitig drücken.

ASchweißspannung

B Warnung – Überhitzung

BASIC II BEDIENFELD

I Maschine einschalten

II Drahtfördergeschwindigkeit einstellen

III Lichtbogenspannung einstellen

1 Trigger-Modus

Wechseln Sie zwischen 2-Takt (Indikator

aus) und 4-Takt (Indikator ein).

2-Takt: Der Schweißvorgang beginnt,

wenn der Trigger gedrückt wird und

endet, wenn er wieder losgelassen wird.

4-Takt: Der Schweißvorgang beginnt,

wenn der Trigger gedrückt und

losgelassen wird und endet, wenn er

wiederum gedrückt wird.

2 Drehregler

Einstellung der Drahtgeschwindigkeit

und Drahtfördergeschwindigkeit

während der Drahtförderung.

Arc adjust (elektronische Drossel)

GAS

Fernregelung

Kühlung Die 4-Takt-Taste (1) gedrückt halten

um Kühlung mittels Drehregler 3 zu

aktivieren/deaktivieren (nur Omega2400/550)

Schlossfunktion

Eingestellter Schweißstrom (A)

Einschleichstart (m/Min.)

Gasvor-

strömung (t) Drahtrückbrand

Gasnach-

strömung (t)

Punktschweißzeit (s)

GUIDE RAPIDE

OMEGA2BASIC II

50113770 I

Procédé 1,0 mm 1,5 mm 2,0 mm 3,0 mm

Matériau Fil Gaz S

(m/min)

(V)

(m/min)

(V)

(m/min)

(V)

(m/min)

(V)

Fe 0.8 CO22.5 19.0 4.5 19.5 7.0 21.0 11.0 27.0

Fe 1.0 CO22.0 18.0 2.5 19.0 3.0 20.0 4.5 21.0

Fe 1.2 CO21.0 18.0 2.0 20.0 2.5 21.0 3.5 22.0

Fe 0.8 ArCO23.0 16.0 6.0 18.0 7.5 19.5 11.0 20.0

Fe 1.0 ArCO22.0 15.0 3.0 16.0 4.0 17.0 6.0 19.0

Fe 1.2 ArCO21.5 16.5 2.5 17.5 3.5 18.0 4.5 20.5

Fe 1.6 ArCO21.0 17.0 2.0 18.0 2.5 18.5

CrNi 1.0 ArCO23.0 15.0 4.0 16.0 6.0 17.0 8.5 20.0

CrNi 1.2 ArCO22.0 15.0 3.0 16.0 3.5 16.5 6.0 18.0

AI 1.0 Ar 4.0 14.5 6.0 15.0 7.5 16.0 9.0 19.0

AI 1.2 Ar 3.5 13.0 5.0 15.0 8.0 16.0 9.0 17.0

Procédé 4,0 mm 6,0 mm 10,0 mm

Matériau Fil Gaz S

(m/min)

(V)

(m/min)

(V)

(m/min)

(V)

Fe 0.8 CO213.0 29.0 18.0 30.0 24.0 37.0

Fe 1.0 CO26.0 22.5 9.0 24.5 14.0 32.0

Fe 1.2 CO24.5 23.0 7.5 28.5 11.0 36.0

Fe 0.8 ArCO214.0 26.0 18.0 31.0 24.0 33.0

Fe 1.0 ArCO28.0 20.0 11.5 26.5 16.0 30.0

Fe 1.2 ArCO25.5 20.5 8.0 29.0 10.0 32.0

Fe 1.6 ArCO23.0 19.5 4.0 22.0 5.5 29.0

FeFlux 1.2 ArCO26.0 21.0 8.0 25.0 11.0 28.0

CrNi 1.0 ArCO29.0 25.0 10.0 27.0

CrNi 1.2 ArCO28.0 24.0 10.0 24.0 12.0 31.0

AI 1.0 Ar 11.0 22.0 13.0 25.0 15.0 27.0

AI 1.2 Ar 10.0 18.0 13.0 23.0 15.0 26.0

Tableau de soudage (consigne) BASIC II - Valeur usine

Possibilités de réglage Plage de réglage Précision Valeur usine Unité

2T/4T

Paramètres principaux :

1 Vitesse ﬁl OMEGA2300 1.5 - 18.0 0.1 3.0 m/min

Vitesse ﬁl OMEGA2400/550 1.5 - 27.0 0.1 3.0 m/min

2 Tension d’arc OMEGA2300 13 - 32 0.1 18.0 V

Tension d’arc OMEGA2400/550 13 - 37 0.1 18.0 V

Paramètres secondaires :

1 Réglage self (dureté d’arc) -5.0 - +5.0 0.1 0.0 -

2 Pré-Gaz 0.0 - 10.0 0.1 0.2 s

3 Dévidage ﬁl froid Off / 1.5 - Max. 0.1 2.0 m/min

6 Burnback 1 - 30 1 5 ms

7 Post-Gaz 0.0 - 10.0 0.1 3.0 s

t Pointage (tempo) 0.0 - 50.0 0.1 0.0 s

G Gaz Manuel 0.5 - 27.0 l

r Commande à distance 0 = interne

1 = réglage à la torche

2 = commande à distance

C Cooling (Refroidissement) ON / OFF

L Fonction de verrouillage ON / OFF

GUIDE RAPIDE OMEGA2BASIC II

2 Encodeur de réglage

Cet encodeur permet de régler la vitesse

de ﬁl et la vitesse de dévidage du ﬁl à

froid.

3 Encodeur de réglage

Cet encodeur permet de régler la

tension d’arc. L’activation de la touche

des paramètres secondaires vous permet

de régler les paramètres correspondants.

4 Vitesse de dévidage et

longueur de l’arc

Appuyer sur la touche et tourner les

boutons de commande jusqu’à ce que la

vitesse du ﬁl d’ alimentation souhaitée

et la longueur d’ arc sont atteints.

5 Paramètres secondaires

Appuyez sur cette touche jusqu’à ce que

le paramètre souhaité s’afﬁche à l’écran.

Appuyez brièvement sur la touche 4

pour terminer.

Fonction de verrouillage

(dans les paramètres secondaires)

Verrouiller / déverrouiller les paramètres

secondaires en appuyant sur les touches

1 et 4 simultanément.

APrésence Arc

B Alerte surchauffe

PANNEAU DE COMMANDE BASIC II

I. Démarrer la machine

II. Régler la vitesse de ﬁl

III. Régler la tension d’arc

1 Sélection du mode gâchette

Possibilité de choisir entre le mode

2temps (LED éteinte) et mode 4 temps

(LED allumée).

2-temps: Le cycle de soudage commence

quand on appui sur la gâchette et

s’arrête quand on relâche la gâchette.

4-temps: le procédé de soudage

démarre lorsque la gâchette de la

torche est activée puis relâchée,

et s’arrête lorsque la gâchette est

réactivée.

Réglage self (dureté de l’arc)

GAZ

Commande à distance

Cooling (Refroidissement) Appuyez sur

la touche à 4 temps (1) et maintenez-

la enfoncée pour activer/désactiver le

refroidissement à l’aide du bouton de

commande 3 (Omega2400/550 uniquement)

Fonction de verrouillage

Courant de soudage (A)

Dévidage ﬁl froid (m/min.)

Pré-Gaz (t)

Burnback

Post-Gaz (t)

Pointage (tempo) (s)

GUIDA RAPIDA

OMEGA2BASIC II

50113770 I

Processo 1.0 mm 1.5 mm 2.0 mm 3.0 mm

Materiale Filo Gas S

(m/min)

(V)

(m/min)

(V)

(m/min)

(V)

(m/min)

(V)

Fe 0.8 CO22.5 19.0 4.5 19.5 7.0 21.0 11.0 27.0

Fe 1.0 CO22.0 18.0 2.5 19.0 3.0 20.0 4.5 21.0

Fe 1.2 CO21.0 18.0 2.0 20.0 2.5 21.0 3.5 22.0

Fe 0.8 ArCO23.0 16.0 6.0 18.0 7.5 19.5 11.0 20.0

Fe 1.0 ArCO22.0 15.0 3.0 16.0 4.0 17.0 6.0 19.0

Fe 1.2 ArCO21.5 16.5 2.5 17.5 3.5 18.0 4.5 20.5

Fe 1.6 ArCO21.0 17.0 2.0 18.0 2.5 18.5

CrNi 1.0 ArCO23.0 15.0 4.0 16.0 6.0 17.0 8.5 20.0

CrNi 1.2 ArCO22.0 15.0 3.0 16.0 3.5 16.5 6.0 18.0

AI 1.0 Ar 4.0 14.5 6.0 15.0 7.5 16.0 9.0 19.0

AI 1.2 Ar 3.5 13.0 5.0 15.0 8.0 16.0 9.0 17.0

Processo 4.0 mm 6.0 mm 10.0 mm

Materiale Filo Gas S

(m/min)

(V)

(m/min)

(V)

(m/min)

(V)

Fe 0.8 CO213.0 29.0 18.0 30.0 24.0 37.0

Fe 1.0 CO26.0 22.5 9.0 24.5 14.0 32.0

Fe 1.2 CO24.5 23.0 7.5 28.5 11.0 36.0

Fe 0.8 ArCO214.0 26.0 18.0 31.0 24.0 33.0

Fe 1.0 ArCO28.0 20.0 11.5 26.5 16.0 30.0

Fe 1.2 ArCO25.5 20.5 8.0 29.0 10.0 32.0

Fe 1.6 ArCO23.0 19.5 4.0 22.0 5.5 29.0

FeFlux 1.2 ArCO26.0 21.0 8.0 25.0 11.0 28.0

CrNi 1.0 ArCO29.0 25.0 10.0 27.0

CrNi 1.2 ArCO28.0 24.0 10.0 24.0 12.0 31.0

AI 1.0 Ar 11.0 22.0 13.0 25.0 15.0 27.0

AI 1.2 Ar 10.0 18.0 13.0 23.0 15.0 26.0

Tabella parametri di saldatura Regolazioni di fabbrica BASIC II

Possibilità di regolazione Campo Incrementi Regolazioni

di fabbrica

Unità di

misura

2/4 tempi

Parametri principali :

1 Velocità ﬁlo OMEGA2300 1.5 - 18.0 0.1 3.0 m/min

Velocità ﬁlo OMEGA2400/550 1.5 - 27.0 0.1 3.0 m/min

2 Tensione d’arco OMEGA2300 13 - 32 0.1 18.0 V

Tensione d’arco OMEGA2400/550 13 - 37 0.1 18.0 V

Parametri secondari :

1 Reattanza -5.0 - +5.0 0.1 0.0 -

2 Pregas 0.0 - 10.0 0.1 0.2 s

3 Soft Start Off / 1.5 - Max. 0.1 2.0 m/min

6 Burnback 1 - 30 1 5 ms

7 Postgas 0.0 - 10.0 0.1 3.0 s

t Tempo puntatura 0.0 - 50.0 0.1 0.0 s

G Gas Manuale 0.5 - 27.0 l

r Controllo a distanza 0 = interno

1 = torcia

2 = comando a distanza

C Raffreddamento ON / OFF

L Blocco ON / OFF

GUIDA RAPIDA OMEGA2BASIC II

3 Manopola di regolazione

Girare la manopola per regolare la

tensione d’arco. Se è selezionato un

parametro secondario, ne permette la

regolazione.

4 Velocità ﬁlo e lunghezza d’arco

Schiacciare il pulsante e girare la

manopola ﬁno ad impostare velocità

ﬁlo e lunghezza d’arco desiderate.

5 Parametri secondari

Premere il tasto ﬁno a visualizzare sul

display il parametro desiderato.

Premere brevemente 4per ﬁnire.

Blocco (parametri secondari)

Blocco/sblocco dei parametri

secondary premendo i tasti 1 e 4

simultaneamente.

ATensione di saldatura

B Allarme – surriscaldamento

Pannello di controllo BASIC II

I. Accendere la macchina

II. Regolare la velocità del ﬁlo

III. Regolare la tensione d’arco

1 2/4 tempi

Permette di cambiare da 2 tempi (LED

spento) a 4 tempi (LED acceso).

2 tempi : Il processo di saldatura inizia

quando viene premuto il pulsante torcia

e si interrompe quando questo viene

rilasciato.

4 tempi : Il processo di saldatura inizia

quando il pulsante torcia viene premuto

rilasciato

e si interrompe quando

questo viene premuto nuovamente.

2 Manopola di regolazione

Regola la velocità del ﬁlo in saldatura e

nel cambio bobina.

Reattanza elettronica

GAS

Controllo a distanza

Raffreddamento Schiacciare e tenere

premuto il pulsante 4 tempi (1) per

attivare/disattivare l’unità di raffreddamento

usando la manopola 3 (solo Omega2400/550)

Blocco

Corrente di saldatura (A)

Soft start (m/min.)

Pregas (t)

Burnback

Postgas (t)

Tempo puntatura (s)

Table of contents

Languages:

Other Migatronic Welding System manuals

Migatronic

Migatronic OMEGA3 YARD 300 User manual

Migatronic

Migatronic PI 500 ROBO User manual

Migatronic

Migatronic PILOT 200 HP User manual

Migatronic

Migatronic PILOT 161 AC/DC User manual

Migatronic

Migatronic AUTOMIG 2 User manual

Migatronic

Migatronic SIGMA GALAXY Product guide

Migatronic

Migatronic SIGMA GALAXY 300 COMPACT/S User manual

Migatronic

Migatronic MIG 385 MK III User manual

Migatronic

Migatronic PI 320 DC User manual

Migatronic

Migatronic MIG 385 MK III User manual

Migatronic

Migatronic FOCUS 200 AC/DC PFC User manual

Migatronic

Migatronic RALLY MIG 161i User manual

Migatronic

Migatronic SIGMA 300 Compact User manual

Migatronic

Migatronic OMEGA 220 User manual

Migatronic

Migatronic MIG 385x S User manual

Migatronic

Migatronic MIGMAN 385 User manual

Migatronic

Migatronic FLEX 3000C User manual

Migatronic

Migatronic MWF 552 YARD User manual

Migatronic

Migatronic SIGMA SELECT ROBO User manual

Migatronic

Migatronic Focus Tig 200 AC/DC User manual

Migatronic

Migatronic LTE 200 User manual

Migatronic

Migatronic OMEGA 270 MINI User manual

Migatronic

Migatronic SIGMA2 300 STBOFF SHORE User manual

Migatronic

Migatronic Delta 200 DC HP PFC User manual

Popular Welding System manuals by other brands

Berner

Berner PLASMACUT 54 instruction manual

Pro Spot

Pro Spot PR-155 Assembly instructions

Forney

Forney 210 operating manual

Thermal Arc

Thermal Arc 400S operating manual

Lincoln Electric

Lincoln Electric HANDYMIG 170I Operator's manual

GYS

GYS PROTIG 201 AC/DC Original instructions

TAFA

TAFA 30*8B35 owner's manual

Lincoln Electric

Lincoln Electric INVERTEC V350-PRO CE Technical specifications

ESAB

ESAB Buddy Arc 145 instruction manual

CIGWELD

CIGWELD 636804 use instructions

Red-D-Arc

Red-D-Arc DC-400 Operator's manual

Hobart Welding Products

Hobart Welding Products Spool Gun DP 3035-10 owner's manual

Elettro

Elettro HI-MIG 3000 SYNERGIC instruction manual

WIA

WIA Weldmatic 270 CP132-2 Operator's manual

Sonics

Sonics H520T instruction manual

Miller

Miller Big Blue 400D owner's manual

NewArc

NewArc RT2000 Operational manual

Hypertherm

Hypertherm powermax1000 Operator's manual
