Miele DA 3190 User guide
NOTE: Drawing is not to scale.
SPECIFICATION SHEETS 150103
22 1/8" - 22 3/8" or
33 15/16 - 34 5/16"
19 11/16 "
Product and Cut-out Dimensions
Built-in Ventilation System
DA3190
23 5/8"- 35 7/16"
11 5/8" - 16 3/4"
E -
O -
5 foot - 120 Volt - 15 Amp 3-wire
molded plug power supply connects
right rear top.
Standard 110 Volt outlet
Location Codes
35 1/4"
10 3/16"
16 3/4"
9 7/8"
13 3/4"
6 1/2"
6 1/2"
E
Notes
• The following minimum spacing must be
maintained between hood and:
Electric cooktops: 18 inches
Gas cooktops: 26 inches
Open electric grill: 26 inches
• All installations must be done in
accordance with local codes.
○○○ ○ ○○○○
Ø 6"
3 3/8"
Duct
Centerline
Side Perspective
1 1/8"
10 13/16"
User
Supplied
Fascia
O
IMPORTANT INFORMATION
Unit must be installed through
the front of the cabinet.
Cabinet should not be
designed with lower rail.
Unit may be installed
in cabinets with the
following widths:
24" , 36", 60cm, 90cm
