Miele DA 3160 User guide

NOTE: Drawing is not to scale.

SPECIFICATION SHEETS 150103

22 1/8" - 22 3/8"

19 11/16 "

Product and Cut-out Dimensions

Built-in Ventilation System

DA3160

23 5/8" minimum

11 5/8" - 16 3/4"

E -

O -

5 foot - 120 Volt - 15 Amp 3-wire

molded plug power supply connects

right rear top.

Standard 110 Volt outlet

Location Codes

23 7/16"

10 3/16"

16 3/4"

9 7/8"

13 3/4"

6 1/2"

6 1/2"

E

Notes

• The following minimum spacing must be

maintained between hood and:

Electric cooktops: 18 inches

Gas cooktops: 26 inches

Open electric grill: 26 inches

• All installations must be done in

accordance with local codes.

○○○ ○ ○○○○

Ø 6"

3 3/8"

Duct

Centerline

Side Perspective

1 1/8"

10 13/16"

User

Supplied

Fascia

O

IMPORTANT INFORMATION

Unit must be installed through

the front of the cabinet.

Cabinet should not be

designed with lower rail.
