Miele KM 6375 User manual
36” Flush-Mounted Induction Cooktop
KM 6375
8mieleusa.com Specification Sheets TRS 09282015
36” Flush-Mounted Induction Cooktop
KM 6375
FOREVER BETTER
KM 6375
Page 2 of 8
SPECIFICATIONS
KM 6375 Induction Cooktop Item 26637562USA
Product Dimensions 357/8” (911 mm) W x 43/4” (121 mm) H x
203/16” (512 mm) D
Cut-out Dimensions 35” (889 mm) W x 195/16” (490 mm) D
Minimum Back Spacing From Wall 2” (50 mm)
Minimum Countertop Thickness 11/8” (29 mm)
Maximum Countertop Thickness 19/16” (40 mm)
Minimum Recommended distance to
ventilation hood 24” (610 mm)
Electrical
Electrical Requirements 208V, 60Hz, 50 Amps, 10,000W
240V, 60Hz, 50 Amps, 11,500W
Power Cable 3’ 111/4” (1.2 m)
Shipping
Shipping Weight 65.35 lbs
Shipping Dimensions 405/16” W x 79/32” H x 2621/32” D
Support
Call 800.843.7231
Miele Website 8www.mieleusa.com
20/20 Link 82020technologies.com
Specification Sheets TRS 09282015
Features:
•5 cooking zones
(1) vario zone of 4-6"
(1) vario zone of 51/2-8"
(2) vario zones of 6-9"
(1) vario zone of 7-11"
•(1) PowerFlex zone — PowerFlex
technology combines two zones into
a unique large zone (9x15"), up to 7,7kW
•TwinBooster function
•Con@ctivity 2.0 — communication
between cooktop and hood
•Direct Selection Plus controls, default
power level 1-9, extended 1-12
•Stop&Go function
•Keeping Warm function
•Auto heat-up
•Pan size recognition
•Timer
•Overheating protection
•Child safety lock and safety switch-off
PRODUCT VIEWS
KM 6375
Page 3 of 8
Top View
36” Flush-Mounted Induction Cooktop
KM 6375
FOREVER BETTER
35 7/8” (911 mm)
20 3/16” (512 mm)
Specification Sheets TRS 09282015
36” Flush-Mounted Induction Cooktop
KM 6375
FOREVER BETTER
KM 6375
Page 4 of 8
INSTALLATION DIMENSIONS
This unit must only be ush mounted! Proud mounting of unit may damage the unit
and will void warranty.
Specification Sheets TRS 09282015
36” Flush-Mounted Induction Cooktop
KM 6375
FOREVER BETTER
INSTALLATION
SAFETY CLEARANCE
Front Side View Of Flush Mount
Installation With Granite, Marble,
Or Solid Surface Countertops
KM 6375
Page 5 of 8
Specification Sheets TRS 09282015
36” Flush-Mounted Induction Cooktop
KM 6375
FOREVER BETTER
INSTALLATION
SAFETY CLEARANCE
Front Side View Of Flush Mount
Installation for Solid Wood,Tiled, Or
Glass Countertops
KM 6375
Page 6 of 8
Specification Sheets TRS 07152015
36” Flush-Mounted Induction Cooktop
KM 6375
FOREVER BETTER
INSTALLATION
Ventilations
Back View Side View
Specification Sheets TRS 07152015
KM 6375
Page 7 of 8
KM 6375
Page 8 of 8
Specification Sheets TRS 07152015
Toekick Height
31/233/44 41/441/243/45 51/453/46
Countertop
Thickness
11/8OK OK NA NA NA NA NA NA NA NA
11/4OK OK NA NA NA NA NA NA NA NA
13/8OK OK OK NA NA NA NA NA NA NA
11/2OK OK OK NA NA NA NA NA NA NA
19/16 OK OK OK NA NA NA NA NA NA NA
Countertop Thickness vs. Toekick Height
Taken into consideration:
• 35” tall cabinetry
• 3/4”(exact) platform thickness under oven/above toekick
36” Flush-Mounted Induction Cooktop
KM 6375
FOREVER BETTER
KM 6375 INDUCTION COOKTOP INSTALLATION IN COMBINATION
WITH UNDERCOUNTER 30” MIELE OVEN H6x80BP
