Midea MCH295W User manual
Chest Freezer
USER MANUAL
MCH295W
CONTENTS
1
Safety information ........................................ 2-3
Identifying parts of the freezer ........................................ 4
Transporting ........................................ 5
Installation ........................................ 5
Operating instructions ........................................ 6
Defrosting ........................................ 7
Cleaning & Maintenance ........................................ 8
Energy saving tips ........................................ 9
Disconnection of the appliance ........................................ 9
Troubleshooting Guide ........................................ 10
Repairs, Service & Warranty ........................................ 11
Specifications ........................................ 12
SAFETY INFORMATION
CAUTION
WARNING
Congratulations on your new eezer. This manual contains important information on the Midea fr
installation, use and care of your appliance. Please read this manual carefully before use. Follow
instructions and keep the manual for future reference.
The appliance is specifically constructed for domestic use and is therefore suitable for the storage of
frozen food and the production of ice-cubes. The appliance has not been designed or manufactured for
professional use. Midea declines all responsibility for damage deriving from improper use of the
appliance. The freezer has undergone the necessary tests on the tightness of the refrigeration circuit
and complies with the safety regulations.
WARNING
The WARNING symbol indicates information that concerns your personal safety
CAUTION
The CAUTION symbol indicates information on avoiding damage to the appliance
R600a
R600a WARNING LABEL
·This appliance contains a small quantity of flammable, non-synthetic R600a refrigerant.
·Ensure that the tubing of the refrigerant circuit is not damaged during transportation and
installation.
·Ensure careful installing, handling and disposing to avoid safety hazards. If accidental
damage occurs, keep the appliance away from open fires or devices that produce sparks,
unplug the appliance and call an authorised service agent. Thoroughly ventilate the room in
which the appliance is situated for several minutes.
·Leaking refrigerant may cause eye injuries or could ignite.
·Hydrocarbon refrigerants have excellent refrigerant properties, minimal global warming
potential and no ozone depletion potential.
·Hydrocarbon refrigerants cannot be ‘retrofitted’ to an appliance that has not been designed
and approved to use that type of refrigerant.
3
·The room for installing the appliance must be at least 1m per 8g of refrigerant. The amount
of refrigerant in the appliance can be found on the rating plate attached to the appliance.
R600a Refrigerant Warning
2
R600a
SAFETY INFORMATION
3
·Young children should be supervised to ensure that they do not play with the appliance.
·Packing (e.g. plastic wraps, polystyrene etc.) can be dangerous for children. There is a
risk of suffocation. Keep packaging materials away from children.
Most of the packing material used is recyclable. Please separate the plastic and cardboard and dispose
through your local recycling depot or place in appropriate recycling collection bins.
If disposing of this appliance, please contact your local authority for safe disposal. Incorrect disposal
may cause injury to the user or flammable gases may cause environmental damage. Remove the lid,
cut off the main cable, break or remove spring or bolt catches to prevent children from getting trapped
or harming themselves.
WARNING
Safety of children
-The freezer is designed to operate on a single phase power supply within a voltage range of 220-
240V/50Hz.
-Do not allow any sharp objects to come in contact with the refrigerant system to avoid damage to the
refrigerant circuit.
-This product is for indoor use only.
-Do not place electrical items or cooking equipment nearby. Keep away from substances which could
cause ignition and ensure good ventilation is always available.
-Do not electrical appliances inside the place or operate any freezer.
-Do not place objects on top of the appliance which are magnetic, heavy or filled with water.
-If the supply cord is damaged, it must be replaced by authorised Midea service personal, service
agent or similarly qualified persons in order to avoid a hazard.
-Do not store flammable, explosive, volatile and highly corrosive materials in the freezer. Containers
with flammable gases or liquids can leak at low temperature. There is a risk of explosion or fire.
-Do not splash water on the appliance. It may cause malfunction or electric shock.
-Always switch off and unplug the appliance before cleaning.
-This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
Safety Precautions
Information on disposal
IDENTIFYING PARTS OF THE FREEZER
4
Wire basket
Light indicator
Drainage plug
Temperature control dial
Lid
1
2
3
1
2
3
4
4
5
5
TRANSPORTING
Remove all packaging material before using new . This and adhesive tape your freezer
includes the foam base and all adhesive tape holding the accessories inside and freezer
outside.
Clean both the inside and outside of the with a cloth lukewarm soapy freezer soft and
water.
Keep the upright and avoid squeezing or vibration during freezer
transport. Avoid a slanting angle over 45 degrees during handling.
Do not lift or pull the lid when moving, otherwise it may become
deformed.
5
Positioning your freezer
Place your in a well ventilated area away from a heat source and direct sunlight. freezer
Do not install the in a damp or wet location as this may cause damage to the freezer
insulation and result in leakage. Condensation may also build up on the outer cabinet
causing rust.
Allow 200mm of airspace between the back and sides of the freezer to allow for
adequate air circulation. Ensure at least a 700mm clearance above the unit for the lid to
fully open.
CAUTION
Allow for adequate ventilation around your freezer
INSTALLATION
Do not connect your freezer to the power supply immediately after it is placed
vertically. You should keep it standing for at least 2 hours before connection to let
it settle.
6
OPERATING INSTRUCTIONS
The temperature of the freezer can be
controlled manually by adjusting the
temperature dial located on the front lower
right hand corner (item 4 on page 4). The
range of the temperature control is from
position “1” the warmest to “6” the coldest.
Adjust the temperature control to the setting
that best suits your needs.
Controlling the temperature
Position “4” is for normal use.
The “OFF” position stops the cooling cycle but does not shut off the power to the freezer.
Lights
Green POWER light: Will always be on when the appliance is connected to the mains
and switched on.
Red RUN light: Will be on when the compressor is working.
Red ALARM light: Will be on when the inside temperature is too high.
Note:
·The first time you turn the unit on, set the temperature dial to your desired position and
allow the unit to cool down for 2~3 hours before placing food in the freezer.
·If you choose to change the temperature setting, adjust the dial by one numerical
increment at a time. Allow several hours for the temperature to stabilise between
adjustments.
1
2
3
4
5
0
FF
Power AlarmRun
6
Heavy frost will effect the freezing process or internal temperature of the appliance and
increase power consumption. Thus, defrosting is required if the frost is >5mm thick.
Defrosting is a manual process. Please follow these steps:
Turn the temperature dial to “OFF” (green light out) and disconnect the appliance.
Remove the frozen food from the freezer and place it in a cool area to protect the
food. Remove the wire basket(s).
Open the lid and wait for the ice to defrost. During defrosting, the ice melts into the
cabinet.
Remove the drain plug on the inside floor of the freezer by rotating it and pulling it
out.
Place a shallow pan outside the drain outlet for the defrosted water to drain out into.
Check the pan occasionally so that the water does not overflow.
When defrosting, a plastic scraper or plastic utensil may be used. Never use metal
instruments or electrical appliances to defrost the freezer.
When defrosting is complete, wipe down the inside of the freezer.
Replace the plug on inside floor.
Reset the temperature to the desired setting and power on the freezer.
Allow the cabinet to cool for at least one hour.
Return basket(s) and food to freezer.
1.
2.
3.
4.
5.
6.
7.
DEFROSTING
8.
9.
10.
11.
12.
7
HELPFUL HINT: Defrosting usually takes a few hours. Leaving the lid open will help
speed the process. Also pouring warm water (not boiling) on the ice will help speed
melting. If you must use a scraper - please use caution - it is very easy to damage the
freezer compartment and void your warranty.
CLEANING & MAINTENANCE
Please check the points below after maintenance:
(1) Is there any damage to the power lead?
(2) Can the power plug be inserted into the power socket correctly?
(3) Is the power plug and/or lead heating up?
8
Never use hot water, solvents, commercial kitchen cleaners, aerosol cleaners,
metal polishers, caustic or abrasive cleaners or scourers to clean the appliance
as they will damage it. Many commercially available cleaning products and
detergents contain solvents that will damage your . When cleaning, freezer
using only a soft cloth and lukewarm soapy water.
CAUTION
Lid seal
Take care to keep the lid seal clean. Sticky food and drink can cause the seal to stick to
the cabinet and tear when you open the lid. Wash the seal with a mild detergent and
warm water. Rinse thoroughly and dry.
Cleaning the appliance
Interior
Clean the freezer interior regularly. Turn power off. Wipe the interior with a soft cloth and
lukewarm soapy water. Wipe away any food spills thoroughly. Dry all surfaces and
removable parts. If you have taken out any removable parts, replace them and switch on
the power before re-stocking the freezer.
Exterior
Clean the freezer with only lukewarm soapy water and a soft cloth. Rinse with clean
water and then wipe the surface with a soft clean cloth to remove any soap residue.
Avoid getting water on the freezer controls.
WARNING
Before cleaning: Turn appliance off at the power point, then remove the power
cord from the outlet. This will make sure there is no chance of electric shock.
It is recommended that the freezer be cleaned each time it is defrosted to help keep the
unit odour free and running efficiently.
9
Reduce opening the frequently. This will increase the appliance efficien and lid cy
reduce power consumption.
Be sure to wrap food properly, and wipe containers dry before placing them in the
freezer. This cuts down on frost build-up inside the freezer.
There should always be some space between food items for proper air circulation.
Hot food should be cooled down before placing into the appliance, otherwise the
interior temperature and power consumption will increase.
Adjust the temperature control to a setting that is acceptable for the storage of the
food. This will reduce the power consumption.
1.
2.
3.
ENERGY SAVING TIPS
DISCONNECTION OF THE APPLIANCE
During a power failure, do not put additional food in the appliance and reduce opening
the lid.
Leave the freezer operating during short vacations.
If the freezer will not be used for several months or it is to be placed in storage, remove
all food and unplug the power cord. Clean and dry the interior thoroughly. To prevent
odour and mould growth, leave the lid open slightly: wedging it open if necessary or have
the lid removed.
Use extreme caution in the case of children. The unit should not be accessible to child’s
play.
If unplugging the appliance from the power outlet, please leave at least 5
minutes before re-connection.
CAUTION
4.
5.
Table of contents
Other Midea Freezer manuals
Midea
Midea MDRC282FZ Series User manual
Midea
Midea Mru21F2AWW User manual
Midea
Midea MRC07M5AWW User manual
Midea
Midea JHSD172 User manual
Midea
Midea UR-BD100-DQ User manual
Midea
Midea UR-BD143-DQ User manual
Midea
Midea MU53DSWBR1RCM User manual
Midea
Midea WF130 User manual
Midea
Midea UR-BD240WE-ST User manual
Midea
Midea MRC05M4AWW User manual
Midea
Midea FZ.411.SS User manual
Midea
Midea MRC09M4AWW User manual
Midea
Midea 353545 Wiring diagram
Midea
Midea HS-185CN User manual
Midea
Midea MRU17F6AWW User manual
Midea
Midea UR-BD295-DQ User manual
Midea
Midea MDRC152FE User manual
Midea
Midea 355418 Wiring diagram
Midea
Midea CHEST FREEZER Series User manual
Midea
Midea MRC05M3AWW User manual
