MHZ 11-8130 User manual
070055255
with side guide
Installation brackets with side guide
Installation brackets
Ceiling bracket Wall bracket
Clamp bracket Wall bracket
Clamp bracket
1
Subject to technical changes, Edition 09.2014
* With safety tensioner system for child safety (included in standard delivery), see p. 5
Please note: Be sure to fit in correct direction and to keep chain taut. Correct positioning of the safety tensioner system must be checked
regularly and in the case of doubt be re-adjusted.
*
*
Attention: When using tools (ladders, drilling machines, etc.) for installation and maintenance of our products, always follow safety instructions
of the manufacturer.
11-8130
Ceiling bracket Wall bracket
PLEATED BLINDS
Installation and Operating Instructions
Please observe the required minimum distances from
our sales documents. Especially in case of pleated
blinds with DUETTE Fixé fabrics.
®
1.
pre punch
2.
1. 2.
Clamp bracket
Glazing
bead/ceiling Frame/wall
1.
pre punch
Bracket installation
max. 130 cm
15 cm 15 cm
Operate
(hanging secured automatically)
4.
3.
4.
3.
2.
* With safety tensioner system for child safety (included in standard delivery), see p. 5
Please note: Be sure to fit in correct direction and to keep chain taut. Correct positioning of the safety tensioner system must be checked
regularly and in the case of doubt be re-adjusted.
*
Pleated blinds
Subject to technical changes, Edition 09.2014
22
Side guide installation
4.
3.
18 mm
3.
90°
5 mm pretension
*
Glazing
bead 1.
pre punch
2.
2.
ø 4 mm
15
18 mm
Glazing
bead
* With safety tensioner system for child safety (included in standard delivery), see p. 5
Please note: Be sure to fit in correct direction and to keep chain taut. Correct positioning of the safety tensioner system must be checked
regularly and in the case of doubt be re-adjusted.
Ordering measurement
6,5 mm
2.
1.
pre punch
anti rotation lock
90°
24,5
Glazing
bead
Ordering measurement
Subject to technical changes, Edition 09.2014
3
Pleated blinds
Side guide installation
Retension if
necessary
Tension is set by factory
4
Subject to technical changes, Edition 09.2014
1.
2.
Clamp
bracket
3.
aprox.
1 cm
4.
5.
1.
pre punch
6,5 mm
2.
90°
24,5 mm
Frame/
wall
Ordering measurement
Pleated blinds
Pleated blinds
Subject to technical changes, Edition 09.2014
5
Installation Child Safety System
ATTENTION
Please read the instructions carefully before mounting and using this device and fit accordingly. Children are at risk of
strangulation if the device is not mounted correctly. Please keep the instructions for future reference.
The implementation of additional safety systems can help to reduce the risk of strangulation, but cannot, however,
be seen as providing complete protection against misuse.
• Young children can be strangled by loops in pull cords, chains, tapes and inner cords that operate the product.
• To avoid strangulation and entanglement, keep cords out of the reach of young children. Cords may become
wrapped around a child’s neck.
• Move beds, cots and furniture away from window covering cords.
• Do not tie cords together. Make sure cords do not twist and create a loop.
Check the device if it is not in regular use and replace the device when it is damaged.
Warning notice in accordance with DIN EN 13120
Safety tensioner for operating chain
Lock washer
clipped in
Clip on lock washer
Mounting orientation
„UP“ = top
Marking "UP" (rear)
for window frame installation
for wall installation
Please note:
Be sure to fit in correct direction and
to keep chain taut. Correct positioning
of the safety tensioner system must be
checked regularly and in the case of
doubt be re-adjusted.
max.
Export department
MHZ Hachtel GmbH & Co. KG . P.O. Box 80 05 20 . D-70505 Stuttgart . Germany
Phone 0711/97 51-0 . Fax 0711/ 97 51-4 11 50 . www.mhz.de · export@mhz.de
