To avoid continuing static corrections caused by the dog’s defiance or inability to
understand the training, the receiver will also return to standby status after three
continuous training sessions.
Note:
As the system uses satellite communication, the collar must NOT be worn inside
or in a covered area. Always test this if you are unsure of signal reception.
Set Up Guide
1. Turn on the receiver and the screen displays “20” and flashes. Repeat pressing Up
or Down button to set the distance value you want, which displays on screen and
flashes.
2. Press L button and hold for 3 seconds, it will display 00 and still flash. Now it starts
searching for the satellites and locating the initial point. Please don’t move the
receiver until it has successfully set the location. While the screen displays “00”
without any flashing, it means the locating process is completed and the set value
of radius is stored into memory.
Notice: Your location must be outdoors away from overhead obstructions,
otherwise the receiver will not be able to communicate with the satellites and
locate the initial point.
3. Repeatedly press S button to select the proper intensity of static shock (or vibration)
according to your dog’s size and weight.
Test the System
To verify the receiver is working as you want, you should test the boundary:
Step 1: Turn on the receiver and the screen displays the set distance and flashes.
Step 2: Press L button and hold for 3 seconds, it will display 00 and flash fast. Please
don’t move the receiver until it displays 00 without flashing.
Step 3: Walk from this initial point, and the screen will display the distance value when
L button is pushed. When you go outside the pre-set range, the receiver will start
beeping immediately, and then static shock or vibration. Its intensity will
increase as you move out further. This means the system is working properly.
Step 4: Go back towards the initial point and make sure the distance is showing
correctly. If the receiver stops beeping and static shock, it means the receiver is
working properly. Thus, the fence system is working well.
For static shock mode, put the LED test light over the two metal prongs of the
receiver and the LED will turn on when the static shock function is working.
