Before driving
Introduction 2
Instrumentation 6
Controls and features 22
Seating and safety restraints 110
Starting and driving
Starting 148
Driving 152
Roadside emergencies 166
Servicing
Maintenance and care 186
Capacities and specifications 232
Customer assistance 237
Reporting safety defects 249
Index 250
All rights reserved. Reproduction by any means, electronic or mechanical including
photocopying, recording or by any information storage and retrieval system or translation
in whole or part is not permitted without written authorization from Ford Motor Company.
Ford may change the contents without notice and without incurring obligation.
Copyright © 2000 Ford Motor Company
Contents
1
The following warning may be required by California law:
CALIFORNIA Proposition 65 Warning
WARNING: Engine exhaust, some of its constituents, and
certain vehicle components contain or emit chemicals known to
the State of California to cause cancer and birth defects or other
reproductive harm. In addition, certain fluids contained in vehicles and
certain products of component wear contain or emit chemicals known
to the State of California to cause cancer and birth defects or other
reproductive harm.
ICONS
Indicates a safety alert. Read the
following section on Warnings.
Indicates vehicle information related
to recycling and other
environmental concerns will follow.
Correct vehicle usage and the
authorized disposal of waste
cleaning and lubrication materials are significant steps towards
protecting the environment.
Indicates a message regarding child
safety restraints. Refer to Seating
and safety restraints for more
information.
Indicates that this Owner Guide
contains information on this subject.
Please refer to the Index to locate
the appropriate section which will
provide you more information.
Introduction
2
WARNINGS
Warnings provide information which may reduce the risk of personal
injury and prevent possible damage to others, your vehicle and its
equipment.
BREAKING-IN YOUR VEHICLE
There are no particular breaking-in rules for your vehicle. During the
first 1 600 km (1 000 miles) of driving, vary speeds frequently. This is
recommended to give the moving parts a chance to break in.
INFORMATION ABOUT THIS GUIDE
The information found in this guide was in effect at the time of printing.
Ford may change the contents without notice and without incurring
obligation.
EMISSION WARRANTY
The New Vehicle Limited Warranty includes Bumper to Bumper
Coverage, Safety Restraint Coverage, Corrosion Coverage, and 7.3L
Power Stroke Diesel Engine Coverage. In addition, your vehicle is eligible
for Emissions Defect and Emissions Performance Warranties. For a
detailed description of what is covered and what is not covered, refer to
the Warranty Guide that is provided to you along with your Owner’s
Guide.
Introduction
3
These are some of the symbols you may see on your vehicle.
Vehicle Symbol Glossary
Safety Alert See Owner’s Guide
Fasten Safety Belt Air Bag-Front
Air Bag-Side Child Seat
Child Seat Installation
Warning
Child Seat Tether
Anchorage
Brake System Anti-Lock Brake System
Brake Fluid -
Non-Petroleum Based Traction Control
Master Lighting Switch Hazard Warning Flasher
Fog Lamps-Front Fuse Compartment
Fuel Pump Reset Windshield Wash/Wipe
Windshield
Defrost/Demist
Rear Window
Defrost/Demist
Power Windows
Front/Rear Power Window Lockout
Introduction
4
Vehicle Symbol Glossary
Child Safety Door
Lock/Unlock
Interior Luggage
Compartment Release
Symbol
Panic Alarm Engine Oil
Engine Coolant Engine Coolant
Temperature
Do Not Open When Hot Battery
Avoid Smoking, Flames,
or Sparks Battery Acid
Explosive Gas Fan Warning
Power Steering Fluid Maintain Correct Fluid
Level
MAX
MIN
Emission System Engine Air Filter
Passenger Compartment
Air Filter Jack
Check fuel cap
Introduction
5
OFF
AUTO
1
AUTO
2
PUSH INTERIOR
CANCEL
RES
ACCEL
COAST
SET
VOL
NEXT
VOL
DIM
km/h
10
20
30
40 50 60
70
80
90
100
MPH
TRIP A
RPM x 1000
20
40
60 80 100
120
140
160
0
1
2
345
6
7
8
F
H
CE
SERVICE
ENGINE
SOON
Headlamp control
(pg. 22)
Instrument panel
dimmer control
(pg. 22)
Instrument cluster
(pg. 8)
Anti-theft indicator light
(pg. 104)
Audio controls *
(pg. 86)
Driver air bag
(pg. 131)
Speed control
(pg. 82)
Foglamp control
(pg. 23)
Turn signal lever
(pg. 87)
Windshield
wiper/washer control
(pg. 88)
* if equipped
Instrumentation
6
OFF REAR 1 2 3 4
1
MAX
A/C
A/C
OFF
2
3
4
OVERDRIVE
OFF/ON
FF
REW
SIDE
1- 2
BASS TREB BAL FADE TAPE
AMS
AM
FM
CD
CLK
VOL - PUSH ON
SHUFFLECOMPCD
EJ
CD
SCAN
DISCS
TUNE
SEEK
321456
DC
12V
SECURITY
HAZARD
RR DEFOG
RR WIPER
RR WASH
Gearshift (including
overdrive button)
(pg. 157) Hazard flasher
(pg. 167)
Rear wiper/washer
(pg. 88)
Rear defroster
(pg. 42)
Auxiliary power point
(pg. 81)
Audio system
(pg. 42)
Climate control system
(pg. 24)
CD Changer*
(pg. 76)
Instrumentation
7
WARNING LIGHTS AND CHIMES
Standard analog instrument cluster
Optional electronic instrument cluster
Charging system
Illuminates when the ignition is
turned to the ON position and the
engine is off. The light also
illuminates when the battery is not
charging properly, requiring
electrical system service.
Air bag readiness
•Standard analog instrument
cluster
•Optional electronic instrument
cluster
km/h
0
10
20
30
40 50 60
70
80
90
100
MPH
TRIP A
RPM x 1000
20
40
60 80 100
120
140
160
0
1
2
345
6
7
8
F
H
CE
CRUISE SET
P
R
N
D
2
P
1
SERVICE
ENGINE
SOON
ABS
AIR
BAG
ABS O/D
OFF
OUTSIDE TEMP
INST ECONOMY
AVG. ECONOMY
TO EMPTY
PRND21
FUEL DOOR UNLEADED FUEL ONLY
CRUISE
MPH
km/h
km
F
E
H
C
1/2
N
O
R
M
A
L
0
1
2
345678
P!
BRAKE
X 1000
RPM
TRIP 1
TRIP 2
˚F ˚C
MILES/BAL
L/100 km
AIR
BAG
Instrumentation
8
Momentarily illuminates when the ignition is turned ON. If the light fails
to illuminate, continues to flash or remains on, have the system serviced
immediately.
Safety belt
Momentarily illuminates when the
ignition is turned to the ON position
to remind you to fasten your safety
belts. For more information, refer to
the Seating and safety restraints
chapter.
Brake system warning
•Standard analog instrument
cluster
•Optional electronic instrument
cluster
Momentarily illuminates when the ignition is turned to the ON position
to ensure the circuit is functional. Also illuminates if the parking brake is
engaged. If the brake warning lamp does not illuminate at these times,
seek service immediately. Illumination after releasing the parking brake
indicates low brake fluid level and the brake system should be inspected
immediately.
Engine oil pressure
Momentarily illuminates when the
ignition is turned to the ON position
and the engine is off. Illuminates
when the oil pressure falls below the
normal range. Stop the vehicle as
soon as safely possible and switch off the engine immediately. Check the
oil level and add oil if needed. Refer to Engine oil in the Maintenance
and care chapter.
!
BRAKE
P!
BRAKE
Instrumentation
9
