MCZ WALL ANGLE AIR 8 M1 Technical specifications

Instructions in English

SEALED PELLET STOVE

WALL ANGLE AIR 8 M1

PART 1 - REGULATIONS AND ASSEMBLY

GBUSE AND INSTALLATION MANUAL

TABLE OF CONTENTS

TABLE OF CONTENTS .................................................................................................. II

INTRODUCTION ..........................................................................................................1

1WARNINGS AND WARRANTY CONDITIONS .................................................................2

2INSTALLATION.........................................................................................................8

3DRAWINGS AND TECHNICAL FEATURES....................................................................17

4UNPACKING...........................................................................................................19

5CLADDING ASSEMBLY.............................................................................................21

6OPENING THE DOORS .............................................................................................31

7USB SOCKET CONNECTION ......................................................................................34

8ELECTRICAL CONNECTION.......................................................................................35

9LOADING THE PELLETS ...........................................................................................36

INTRODUCTION

Dear Customer,

our products are designed and manufactured in compliance with European reference standards for construction products (EN13240 for

wood-burning stoves, EN14785 for pellet-burning appliances, EN13229 for replaces/wood-burning inserts and EN 12815 for wood-

burning range cookers), with high quality materials and extensive experience in transformation processes. The products also meet the

essential requirements of Directive 2006/95/EC (LowVoltage) and Directive 2004/108/EC (Electromagnetic Compatibility).

To get the best performance, we suggest you read the instructions in this manual carefully.

This installation guide is an integral part of the product: ensure that the manual is always supplied with the appliance, even if it changes

owner. If the manual is lost, you can request another copy from the local Technical Dept. or download it directly from the company’s

website.

All local regulations, including those referring to national and European standards, must be observed when installing the appliance.

In Italy, for the installation of systems with a biomass below 35KW, refer to the Ministerial Decree 37/08 and the qualied installation

technician with the suitable requirements must issue a certicate of compliance for the system installed. (By system we intend

Stove+Flue+Air vent).

REVISIONS TO THE PUBLICATION

The content of this manual is strictly technical and the property of MCZ Group Spa.

No part of this manual may be translated into other languages, adapted and/or reproduced, even in part in other mechanical and/or

electronic form or media, for photocopies, recordings or other, without the prior written authorisation from MCZ Group Spa.

The company reserves the right to make changes to the product at any time without prior notice. The proprietary company reserves its

rights according to law.

CARE OF THE MANUAL AND HOW TO CONSULT IT

• Take care of this manual and store it in an easily and quickly accessible place.

• Should this manual be lost or destroyed, request a copy from your retailer or directly from the authorised Technical assistance

department. It can also be downloaded from the company’s website.

• “Bold text”requires special attention.

• “Text in italics”is used to draw attention to other paragraphs in the manual or for any additional clarications.

• “Note”provides the reader with additional information.

SYMBOLS USED IN THE MANUAL

ATTENTION:

carefully read the corresponding message as failure to comply with the information provided may result

in serious damage to the product and danger to the persons who use it.

INFORMATION:

failure to comply with these provisions will compromise use of the product.

OPERATING SEQUENCES:

sequence of buttons to be pressed to access the menus or perform adjustments.

MANUAL

carefully read this manual or the relative instructions.

1-WARNINGS ANDWARRANTY CONDITIONS

SAFETY WARNINGS

• Installation, electrical connection, operating check and maintenance

must only be carried out by authorised and qualied personnel.

• Installthe product inaccordance withall local andnationallegislation

and regulations in force in the region or state.

• Only use the fuel recommended by the manufacturer. The product must not be

used as an incinerator.

• It is strictly forbidden to use alcohol, petrol, liquid fuel for lanterns, diesel, bio-

ethanol, uids for lighting charcoal or similar liquids to light/rekindle the ame

in these devices. Keep these ammable liquids well away from the appliance

when in use.

• Do not put any fuel other than wood pellets in the hopper.

• The instructions provided in this manual must always be complied with to

ensure the product and any electronic appliances connected to it are used

correctly and accidents are prevented.

• This appliance can be used by children aged 8 years and above and

persons with reduced physical, sensory or mental capabilities or lack

of experience and knowledge provided they are supervised or have

been given instructions regarding use of the appliance in a safe way

and understand the hazards involved. Children must not play with the

appliance. Cleaning and maintenance to be performed by the user

must not be carried out by children without supervision.

• The user, or whoever is operating the product, must read and fully understand

the contents of this installation guide before performing any operation. Errors or

incorrect settings may cause hazardous conditions and/or incorrect operation.

• Do not climb on or lean on the product.

1-WARNINGS ANDWARRANTY CONDITIONS

• Do not dry linen on the product. Any drying racks or the like must be kept at a

safe distance from the product. Fire hazard.

• All liability for improper use of the product is entirely borne by the user and relieves

the manufacturer of any civil and criminal liability.

• Any type of tampering or unauthorised replacement with non-original spare

parts may be hazardous for the operator’s safety and relieves the company of

any civil and criminal liability.

• Many surfaces of the product get very hot (door, handle, glass, smoke outlet

pipes, etc.). Avoid coming into contact with these parts without

adequate protective clothing or suitable equipment, such as gloves

with thermal protection or“cold handle”operating systems.

• It is forbidden to operate the product with the door open or the glass

broken.

• The doors/covers on the appliance must remain closed when it is not

being used.

• The product must be powered by an electrical system that is equipped with an

eective earthing device.

• Switch the product o in the event of a fault or malfunction.

• Accumulated unburnt pellets in the burner after each“failed ignition” must be

removed before lighting again. Check that the burner is clean and positioned

properly before lighting again.

• Do not wash the product with water. Water may penetrate inside the unit and

damage the electrical insulation and cause electric shocks.

• Do not stand for a long time in front of the product in operation. Do not overheat

the room you are in and where the product is installed. This may cause injuries

and health problems.

• Install the product in a location that does not present a re hazard and is

equipped with power and air supplies and smoke outlets.

• In the event of re in the chimney, turn o the device, disconnect it from the

mains and do not open the hatch. Then contact the competent authorities.

• The product and the cladding must be stored in a dry place and must not be

exposed to weathering.

1-WARNINGS ANDWARRANTY CONDITIONS

• It is recommended not to remove the feet that support the product in order

to ensure adequate insulation, especially if the ooring is made of ammable

materials.

• In the event of a malfunction of the ignition system, do not force it on by using

ammable materials.

• Special maintenance must only be performed by authorised and qualied

personnel.

• Assess the static conditions of the surface on which the weight of the product

will rest and provide suitable insulation if it is made of ammable material (e.g.

wood, tted carpet or plastic).

• Live electrical parts: only power the product once it has been fully assembled.

• Disconnect the product from the 230V power supply before performing any

maintenance operations.

• Improperuseorpoormaintenanceoftheproductcancausehazardoussituations

to arise.

• It is forbidden to manually load the fuel into the brazier. Failure to

follow this warning can lead to hazardous situations.

• Before the product is restarted, always remove any unburned pellets

building up in the brazier due to failed ignition, the emptying of the

hopper or any situation that may cause this condition.

1-WARNINGS ANDWARRANTY CONDITIONS

INFORMATION:

Please contact the retailer or qualied personnel authorised by the company to resolve a problem.

• Only use the fuel specied by the manufacturer.

• When the product is switched on for the rst time, it is normal for it to emit smoke due to the paint heating for the rst time.

Therefore make sure the room in which it is installed is well ventilated.

• Check and clean the smoke outlet pipes regularly (chimney tting).

• The product is not a cooking appliance.

• Always keep the cover of the fuel tank closed.

• Store this installation and user manual with care as it must accompany the product for the duration of its useful life. If the product is

sold or transferred to another user, always ensure the manual is also handed over.

INTENDED USE

The product only works with wood pellets and must be installed indoors.

PRODUCT PERFORMANCE CHECKS.

All our products undergo ITT TESTS carried out by a notied laboratory (system 3) and in accordance with (EU) Regulation number

305/2011“Construction products”, according to standard EN 14785:2006 (pellets) and“Machinery Directive”EN 303-5 (boilers).

In the case of tests for any market surveillance or inspections by third parties, please take the following warnings into account:

• to reach the declared performance levels, the product must perform an operating cycle of at least 15/20 hours beforehand

• use the average draught of the combustion smoke specied in the“product technical specications”table

• the type of pellets used must comply with current EN ISO 17225-2 regulations

• the amount of fuel may vary according to the length and caloric value of the fuel. This may require some adjustments to stay in

line with the hourly consumption specied in the“product technical specications”table. A1 pellets ensure an overall caloric value

within tight margins compared to the test pellets used. However, size considerably aects performance, therefore on average it must

not be less than 24 mm long and with a 6mm diameter

• in the case of a wood-burning product, check the correct residual moisture content of the fuel, which must not be less than 12% or

more than 20%. As the moisture increases, dierent combustion air settings are required. The settings are to be carried out via the

combustion air register, thereby modifying the mixture between primary and secondary air.

• it is required to check the operation of devices that can aect performance (for example air fans or electrical safety devices) in case

of damage due to handling.

• maximum performance can be achieved at the maximum ame and ventilation power.

• strictly comply with the withdrawal points required by regulations both in terms of emissions and temperature.

WARRANTY CONDITIONS

The company guarantees the product, with the exception of parts subject to normal wear (listed on the following page), for a

period of 2 (two) years from the date of purchase attested by:

• a document to serve as proof of purchase (invoice and/or receipt) that shows the name of the vendor and the date on which the

purchase was made;

• forwarding of the completed warranty certicate within 8 days of purchase.

Furthermore, in order for the warranty to be valid, the device must be installed and calibrated by qualied personnel, and where necessary,

the user must be issued with a declaration of conformity and correct functioning of the product.

We recommend testing the product before completion with the relative nishes (claddings, painting of walls, etc.).

Installations that do not meet the current standards, improper use and lack of maintenance as expected by the manufacturer, void the

product warranty.

The warranty is valid on the condition that the instructions and warnings contained in the user and maintenance manual are observed,

1-WARNINGS ANDWARRANTY CONDITIONS

and therefore the product is used correctly.

Replacement of the entire system or repair of one of its components does not extend the warranty period, and the original expiry date

remains unchanged.

The warranty covers the replacement or free repair of parts recognised as being faulty at source due to manufacturing defects.

In the event of a fault, to benet from the warranty, the customer must keep the warranty certicate and provide it along with the

document given at the time of purchase to the Technical Service Centre.

EXCLUSIONS

The warranty does not cover malfunctions and/or damage to the appliance that arise due to the following causes:

• Damage caused during transport and/or handling

• all parts that develop faults due to negligence or improper use, incorrect maintenance, installation that does not comply with the

manufacturer’s instructions (always refer to the installation guide provided with the appliance)

• incorrect sizing with regard to the use or faults in the installation or failure to implement the necessary measures to ensure proper

execution

• improper overheating of the equipment, i.e. the use of fuels not conforming to the types and quantities indicated in the instructions

provided

• further damage caused by incorrect user operations in an attempt to x the initial fault

• worsening of the damage caused by the user continuing to operate the appliance even after the fault has been detected

• in the presence of a boiler, any corrosion, deposits or breakage caused by water ow, condensation, hardness or acidity of the water,

improperly performed descaling treatments, lack of water, mud or limescale deposits

• ineciency of chimneys, ues or parts of the system aecting the appliance

• damage caused by tampering with the appliance, atmospheric agents, natural disasters, vandalism, electrical discharges, res, faults

in the electric and/or hydraulic system.

• Failure to have yearly stove maintenance performed by an authorised technician or qualied personnel shall render the warranty

void.

The following are also excluded from this warranty:

• parts subject to normal wear such as gaskets, glass, cladding and cast iron grilles, painted, chrome-plated or gilded parts, handles

and electric cables, bulbs, indicator lights, knobs, all parts which can be removed from the rebox.

• Variations in colour of the painted or ceramic/serpentine parts and crazed ceramics as they are natural characteristics of the material

and product use.

• masonry work

• system parts (if present) not supplied by the manufacturer

Any technical operations on the product to remove the aforementioned defects and consequent damage must be agreed upon with the

Technical Service Centre, who reserves the right to accept the relative appointment or not. However, said operations shall not be carried

out under warranty but as technical support to be granted as part of any potentially and specically agreed conditions and in accordance

with the fees in force for the work to be carried out.

The user will also be charged for any costs incurred to remedy the incorrect technical operations, tampering or damage to the appliance,

not attributable to original faults.

Without prejudice to the legal or regulatory limits, the warranty does not cover the containment of atmospheric and acoustic pollution.

The company declines all liability for any damage which may be caused, directly or indirectly, to persons, animals or objects as

a consequence of non compliance with any provision specied in the manual, especially warnings regarding installation, use

and maintenance of the appliance.

1-WARNINGS ANDWARRANTY CONDITIONS

SPARE PARTS

In the event of a malfunction, consult the retailer who shall forward the call to the Technical Assistance Department.

Only use original spare parts. The retailer or service centre can provide all necessary information regarding spare parts.

We do not recommend waiting for the parts to get worn out before having them replaced. It is crucial to perform regular maintenance

checks.

The company declines all liability if the product and any other accessory is used improperly or modied without

authorisation.

All parts must be replaced with original spare parts.

Information for management of waste electrical and electronic equipment containing batteries and

accumulators

This symbol appears on the product, on the batteries, on the accumulators or on their packaging or on their documentation; it indicates

that the product and the batteries or the accumulators included must not be collected, recycled or disposed of with household waste at

the end of their service life.

Improper management of waste electrical and electronic equipment, batteries or accumulators can cause the hazardous substances

contained within to leak out. In order to avoid harming the environment or health, the user is required to separate this equipment, and/

or the batteries or accumulators included, from other types of waste and deliver them to the local collection centre. The distributor can

be asked to collect the waste electrical and electronic equipment under the conditions and according to the procedures laid down by

Legislative Decree 49/2014.

Separate collection and correct treatment of waste electrical and electronic equipment, batteries and accumulators contribute to

conserving natural resources, respect for the environment and ensure the protection of health.

For more information on collection centres for waste electrical and electronic equipment, batteries and accumulators, contact the

competent public Authorities for issue of the authorisations.

WHY SEALED

Products constructed with a perfectly sealed structure do not consume the room’s oxygen but draw all the air from the outer environment

(if suitably ducted) and may therefore be installed in all houses that require a high degree of insulation such as “passive”or “high energy

eciency”houses. Thanks to this technology there is no risk of smoke emissions in the room, hence no air inlets and relevant ventilation

grilles are required on the installation premises.

Consequently, there will be no more draughts of cold air in the room, which make it less comfortable and reduces the overall eciency of

the system.The sealed stove may even be installed in the presence of forced ventilation or in premises that might have negative pressure

with respect to the outside.

2-INSTALLATION

The instructions in this chapter refer explicitly to the Italian installation regulation UNI 10683. In any case,

always observe the regulations in force in the country of installation.

PELLETS

Wood pellets are manufactured by extruding sawdust which is produced during the processing of natural dried wood (without paint).

The compactness of the material is guaranteed by the lignin contained in the wood itself and allows the pellets to be produced without

glue or binders.

The market oers dierent types of pellets with characteristics that vary according to the wood mixtures used.The most common diameter

on the market is 6 mm (although 8 mm diameter is also available) with a length, on average, between 3 and 40 mm. A good quality pellet

has a density of between 600 and 750 or more kg/cubic metres and a moisture content that accounts for 5 to 8% of its weight.

Pellets have technical advantages besides being an ecological fuel, as the wood residue is used completely, thereby achieving cleaner

combustion than that of fossil fuels.

While good-quality wood has a caloric value of 4.4 kW/kg (15% moisture, after about 18 months of seasoning), that of pellets is around

4.9 kW/kg. To ensure good combustion, the pellets must be stored in a dry place and protected from dirt. Pellets are usually supplied in 15

kg bags, therefore, storing them is very convenient

Good quality pellets guarantee good combustion, thereby decreasing harmful emissions into the atmosphere.

The poorer the quality of the fuel, the more often the internal parts of the brazier and combustion chamber must

be cleaned.

The main quality certications for pellets currently available on the European market guarantee that the fuel complies with class A1/A2

according to ISO 17225-2 (ex EN 14961). These certications include, for example, ENPlus, DINplus, Ö-Norm M7135, and specically

assure that the following characteristics are complied with:

• caloric value: 4.6 ÷ 5.3 kWh/kg.

• Water content: ≤ 10% of the weight.

• Percentage of ash: max 1.2% of the weight (A1 less than 0.7%).

• Diameter: 6±1/8±1 mm.

• Length: 3÷40 mm.

• Content: 100% untreated wood without the addition of binding agents (max 5% bark).

• Packaging: in sacks made from ecologically compatible or biologically decomposing material.

The company strongly recommends using certied fuel for its products (ENplus, DINplus, Ö-Norm M7135).

Poor quality pellets or others that do not comply with the characteristics specied previously may compromise the

operation of your product and can therefore make the warranty and product liability invalid

15 Kg BAG OF PELLETS
