OVEN/BASE
No. Part No. Description
Section:
Series Qty
1 74005772 PEDESTAL, SIDE 10 2
2 74003565 RUNNER, DRAWER 10 2
- 74005230 NUT, LOCK (8-32) 10 2
- 74004078 ROLLER, DRAWER 10 2
3 74002373 LEG, LEVELING 10 4
4 74007556 CORD, POWER 10 1
5 74004944 SENSOR, OVEN (SHORT) Note: SENSOR, OVEN 10 1
- 74001530 SCREW (8AB1/2-NI) Note: SCREW, SENSOR 10 2
6 74001757 RACK, OVEN Note: RACK, OVEN 10 2
7 7401P037-60 BLOCK, TERMINAL 10 1
8 74005564 BRACKET, ANTI-TIP 10 1
- 7101P352-60 SCREW Note: SCREW, BRACKET 10 2
9 74003388 HOUSING, BULB Note: HOUSING, BULB 10 1
10 7407P103-60 BULB, OVEN 10 1
11 74003391 RETAINER, BULB COVER Note: RETAINER, BULB COVER 10 1
12 74003389 COVER, BULB Note: COVER, BLUB 10 1
13 4020F001-80 PEDESTAL, FRONT/REAR Note: PEDESTAL, FRONT 10 1
14 74001530 SCREW (8AB1/2-NI) Note: SCREW, PEDESTAL 10 6
- 74001530 SCREW (8AB1/2-NI) Note: SCREW, SUPPORT 10 4
15 74007129 SUPPORT, VALVE REGULATOR 10 1
16 74009480 RETAINER, BOTTOM INSULATION 10 1
- 74001530 SCREW (8AB1/2-NI) Note: SCREW, RETAINER 10 4
17 74006574 SHIELD, HEAT POUCH 10 1
- 74001530 SCREW (8AB1/2-NI) Note: SCREW, SHIELD 10 2
- 74003503 INSULATION, OVEN 10 1
18 7002P140-60 INSULATION, DRAWER & SHIELD 10 1
- 74001530 SCREW (8AB1/2-NI) Note: SCREW, SHIELD 10 2
19 74006591 SHIELD, WARMING DRAWER 10 1
20 74004465 PAN, BAKE BURNER 10 1
- 74001530 SCREW (8AB1/2-NI) Note: SCREW, BAFFLE 10 2
21 74001219 BAFFLE, OVEN FRONT 10 1
22 74003387 RECEPTACLE, BULB Note: RECEPTACLE, BULB 10 1
- 71001394 SCREW 10 1
23 74009583 SUPPORT, SPARK MODULE 10 1
24 74005465 COVER, VALVE/REGULATOR 10 1
- 74001530 SCREW (8AB1/2-NI) Note: SCREW, COVER 10 2
25 74002376 BOTTOM, OVEN 10 1
- 3601F239-45 BAFFLE, OVEN BOTTOM 10 1
25 74011228 BOTTOM, OVEN (FIXED) 11 1
- 71001394 SCREW 10 2
- 74002377 CLIP, OVEN BOTTOM 10 2
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available
