MaxiCosi Mara XT User manual

Mara XT

Ultra Compact Stroller

50 lb (22.7 kg)

4358-8155C 5.19.21

KEEP INSTRUCTIONS FOR FUTURE USE.

Read all instructions before using this stroller.

WARNING:

Safety Information

FOR THE SAFETY OF YOUR CHILD, PLEASE READ THE FOLLOWING WARNINGS AND

INSTRUCTIONS AND KEEP FOR FUTURE REFERENCE.

• Adult assembly required.

• NEVER LEAVE CHILD UNATTENDED. ALWAYS keep child in view when in stroller.

• AVOID SERIOUS INJURY from falling or sliding out. ALWAYS use the harness system.

Check frequently to make sure it is secure.

• ALWAYS keep fingers away from moving parts, when folding, unfolding or adjusting stroller to

prevent finger entrapment.

• ALWAYS make sure stroller is fully open and locked before using.

• ALWAYS use the brakes when stroller is stopped.

• ALWAYS remove protective material and poly bags and dispose before assembly.

• NEVER put hot liquids in the cup holder.

• NEVER use stroller on stairs or escalators.

• NEVER rollerblade with stroller.

• NEVER allow children to play with or hang onto the stroller.

• NEVER allow children to climb into the stroller unassisted. Stroller may tip over and injure child.

• NEVER place or hang parcels, bags, or accessories on the handle or canopy. The stroller may

tip over or the canopy may collapse.

• This product will become unstable if a parcel bag or rack is used when there is no provision for

one.

• This product may become unstable if a parcel bag, other than the one recommended by the

manufacturer is used.

• This product will become unstable if the manufacturer’s recommended load is exceeded.

• Care must be taken when folding and unfolding the stroller to prevent finger entrapment.

• DO NOT carry additional children, goods, or accessories in or on this product except as

recommended in the manufacturer’s instructions.

• NEVER place more than 2 lbs (.9 kg) in the cup holder.

• NEVER place more than 1 lb (.5 kg) in the storage pocket.

• NEVER place more than 10 lb (4.5 kg) in the storage basket. If weight is exceeded, hazardous

unstable conditions may exist.

• STROLLER is only for use with children up to 50 lb (22.7 kg), AND WHEN SEATED, the mid-

point of your child’s head is at or below the top of the stroller seat.

• ONLY use this stroller with ONE child at a time.

• STROLLER is for use with children who can sit up unassisted and is NOT recommended for

newborns.

• Failure to follow the steps and warnings on the labels and in the instruction manual can result

in serious injury or death to your child.

Contents

Parts of Stroller........................................ 1

Installing & Removing Front Wheels........... 2

Unfolding Stroller Frame........................... 3

Using Parking Brake &

Locking Swivel Wheels ............................. 4

Canopy Use ............................................ 5

Attaching Car Seat to Stroller Frame ......... 6

Removing Car Seat from Stroller Frame..... 7

Reclining Stroller Seat .............................. 8

Adjusting Footrest.................................... 8

Storage Basket & Pocket Use.................... 9

Adjusting Stroller Seat Harness Straps....... 10

Securing Child in Stroller Seat................... 12

Folding Stroller ........................................ 13

Accessory Use & Care.............................. 14

Wash & Care of Stroller Parts.................... 14

Dorel Juvenile Group Information .............. 15

Replacement Parts................................... 15

Warranty ................................................. 15

Parts of Stroller

Lay out and identify all of the

parts.

If any parts are missing, do not

return this product to the

place of purchase.

Please contact Consumer Care

via:

• Phone: 1-800-951-4113

• Text: 1-812-652-2525

• Chat: www.maxicosi.com

You will need to know the model

number and manufacture date.

It is located on a label on the

stroller frame.

Stroller

Frame

Car Seat Adapters

Front Wheels

Cup Holder

Stroller

Seat

Harness

Straps

Stroller Seat

Pad Insert

Harness

Covers

Buckle

Cover

Installing & Removing Front Wheels

Attach the front wheels as shown. Finished!

NOTE: Pull out on the wheels to

make sure they are secured.

Installing Front Wheels

click!

1 2

Removing Front Wheels

Press the release button on the

stroller frame and hold it in.

Remove the front wheels.

Inside of leg frame

Unfolding Stroller Frame

Push in on the stroller frame and

then pull the stroller frame latch

away from the stroller.

Continue to lift up and then push

the crossbar forward until the

stroller locks into place.

Hold the stroller frame as

shown and lift up.

Finished!

Stroller Frame Latch

click!

ALWAYS keep fingers away

from moving parts, when folding,

unfolding, or adjusting stroller

to prevent finger entrapment.

WARNING:

To Lock Parking Brake

Push down.

To Release Parking Brake

Lift up.

Using Parking Brake & Locking Swivel Wheels

Parking Brake

(locks both rear wheels)

To Lock Swivel Wheels To Unlock Swivel WheelsFront Swivel Wheels

click!

• The wheels must face forward

as shown.

• Firmly push the lock tab down.

• Locked swivel wheels are best

for traveling over rocky or

uneven surfaces.

• Firmly pull the lock tab up.

• Unlocked swivel wheels are

best for everyday strolling.

Rear Wheels

Front Wheels

Canopy Use

Lift the fabric to access the

Peek-a-Boo window.

Pull the canopy forward

to extend.

Locate the zipper and unzip to extend the canopy farther.

Air Flow

Windows

Attaching Car Seat to Stroller Frame

Attach the car seat to the car seat adapters.

ONLY install the car seat rear-facing.

Pull up on the car seat either at

the carry handle or handle hubs to

check if it is securely attached.

click!

Illustrations show a generic car seat icon.

Match the colored dots on the adapters with the

colored dots on the attachments.

Slide the car seat adapters onto the attachments.

Car Seat Adapters

2 3

Locate the car seat adapter

attachments on the stroller frame.

click!
