Master Forge RT2417S User manual
1
Master Forge & M Design®is a registered
trademark of LF, LLC. All rights reserved.
Lowes.com/masterforge
ATTACH YOUR RECEIPT HERE
Serial Number _________________________ Purchase Date _________________________
Questions, problems, missing parts? Before returning to your retailer, call our
customer service department at 1-800-963-0211, 8 a.m. - 6 p.m., EST,
Monday - Thursday, 8 a.m. - 5 p.m., EST, Friday.
ITEM #0503231
3-BURNER STAINLESS STEEL GRILL
MODEL #RT2417S
Español p. 39
AB13577
WARNING
Improper installation,
adjustment, alteration, service
or maintenance can cause
injury or property damage.
Read this instruction manual
thoroughly before installing or
servicing this equipment.
WARNING
1. Do not store or use gasoline or
other ammable vapors and
liquids in the vicinity of this or
any other appliance.
2. An LP tank not connected for
use should not be stored in the
vicinity of this or any other
appliance.
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open ames.
3. Open the lid.
4. If the odor continues, keep
away from the appliance and
immediately call your gas
supplier or re department.
WARNING
For Outdoor Use Only
GAS-FIRED
C US
MH 10297
2Lowes.com/masterforge
TABLE OF CONTENTS
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Hardware Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Assembly Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Natural Gas Conversion Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Cooking with Gas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Replacement Parts List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
3Lowes.com/masterforge
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, operate
or install the product. If you have any questions regarding the product, please call
customer service at 1-800-963-0211, 8:00 am to 6:00 pm, EST, Monday- Thursday, 8:00
a.m. to 5:00 p.m., EST, Friday.
1. The installation of this appliance must conform with local codes or, in the absence of local
codes, with either the National Fuel Gas Code, ANSI Z223.1/NFPA 54, or Natural Gas
and Propane Installation Code, CSA/CGA-B149.1.
2. This grill is intended for use outdoors and should not be used in a building, garage or any
other enclosed or covered area.
3. This outdoor grill is not intended for installation in or on recreational vehicles and/or boats.
4. A minimum clearance of 36 in. from combustible constructions to the sides of the grill and
36 in. from the back of the grill to combustible constructions must be maintained. This
outdoor cooking gas appliance must not be placed under overhead combustible
construction.
5. The use of an electrical source requires that when installed, the grill must be electrically
grounded in accordance with local codes or, in the absence of local codes, with
ANSI/NFPA 70, or the Canadian Electrical Code, CSA C22.1. Keep electrical supply cords
and the fuel supply hose away from heated surfaces.
6. Inspect the hoses before each use for excessive abrasion or wear, or cuts that may affect
safe operation of the grill. If there is evidence of excessive abrasion or wear, or the hose is
cut, it must be replaced prior to the grill being put into operation. The replacement hose
assembly must be those specied by the manufacturer.
7. Keep your grill in an area clear and free from combustible materials, gasoline and other
ammable vapors and liquids.
8. DO NOT obstruct the ow of combustion and ventilation air to this appliance.
9. Keep the ventilation openings of the tank enclosure free and clear from debris.
10. Check all gas connections for leaks with a soapy water solution and brush. Never use an
open ame to check for leaks.
11. Never use charcoal in the grill.
12. Never use the grill in windy areas.
13. Only a 20 lb. LP-gas cylinder is allowed. The cylinder must be
constructed and marked in accordance with the Specications for
LP Gas Cylinders of the U.S. Department of Transportation (D.O.T.)
or the National Standard of Canada, CAN/CSA-B339, Cylinders,
Spheres and Tubes for Transportation of Dangerous Goods; and
Commission. A 20 lb LP-Gas cylinder’s dimensions are:
14. Never use the grill without the drip tray installed and pushed completely into the back of
the grill. Without the drip tray, hot grease and debris could leak downward and produce a
re hazard.
18 in
13.9 in
8 in
12.2 in
4Lowes.com/masterforge
SAFETY INFORMATION
15. The pressure regulator for LP-gas grill is set for 11-in. water column (WC). Natural gas
grill provides a hose assembly which includes a quick-disconnect device, but no pressure
regulator. The LP pressure regulator or the natural gas hose assembly must be used.
Replacement pressure regulators and hose assemblies must be those specied in the
parts list.
16. The cylinder used must include a collar to protect the cylinder valve.
17. Do not store a spare LP-gas cylinder under or near this appliance.
18. Never ll the cylinder beyond 80 percent full.
19. If the information in “17” and “18” is not followed exactly, a re
causing death or serious injury may occur.
20. The natural gas grill and its individual shutoff valve must be disconnected from the gas
supply piping system during any pressure testing of that system at test pressures in
excess of 0.5 PSI (3.5 kPa).
21. The outdoor cooking gas appliance must be isolated from the gas supply piping system
by closing its individual manual shutoff valve during any pressure testing of the gas supply
system at test pressures equal to or less than 1/2 PSI (3.5 kPa).
22. CALIFORNIA PROPOSITION 65 WARNING: The burning of gas cooking fuel generates
some byproducts which are on the list of substances known by the state of California to
cause cancer, reproductive harm, or other birth defects. To reduce exposure to these
substances, always operate this unit according to the use and care manual, ensuring you
provide good ventilation when cooking with gas.
IMPORTANT: We urge you to read this manual carefully and follow the recommendations
enclosed. This will ensure you receive the most enjoyable and trouble-free operation of your
new gas grill. We also advise you retain this manual for future reference.
WARNING: Your grill has been designed to operate using only the gas specied by the
manufacturer on the rating plate. Do not attempt to operate your grill with other gases. Failure
to follow this warning could lead to a re hazard and bodily harm and will void your warranty.
WARNING: Make certain your LP (propane) tank is lled by a reputable propane dealer. An
incorrectly lled or an overlled LP tank can be dangerous. The overlled condition combined
with the warming of the LP tank (a hot summer day, tank left in the sun, etc.) can cause LP
gas to be released by the pressure relief valve on the tank since the temperature increase
causes the propane to expand. LP gas released from the tank is ammable and can be
explosive. Refer to your Owner’s Manual for more information concerning lling your LP tank.
This unit contains one or more patents pending:
61/163,753
61/215,319
11/495,104
11/268,051
5Lowes.com/masterforge
SAFETY TIPS
●Never pull your grill. Always push it.
●Never move your grill while it is in operation or still hot.
●Always use a protected hand when cleaning the grid surface after the post-heating period an
when closing the propane tank valve.
●Use a covered hand during the grilling period.
●Wait until the burner box has completely cooled before reaching under to turn off the gas
●Using an uncovered hand to turn off the LP tank valve without allowing the grill to cool down
could result in severe burns.
●Never operate your grill under overhangs, awnings or any covered or enclosed area.
● Never spray liquid on the grid area to control are ups.
● To guard against possible grease res getting out of control, never leave a grill unattended.
● Grease res can be severe and cause grill damage, property damage and bodily harm.
● Always turn off the control knob rst, then the propane gas supply tank.
●Never cover your grill while it is still warm.
●Position your portable grill away from direct wind.
● Do not store or use gasoline or other ammable substances in the vicinity of your gas grill.
●Never store a propane tank (whether full or empty) inside your home or living area.
●Before storing your tank, make sure that it has been turned to the “OFF” position.
●Should you store your grill indoors, be sure to close the tank valve, disconnect the hose from
the tank, remove the tank from the grill and store the tank outdoors.
●Make sure the grill hood is completely open before lighting your grill.
● When connecting or replacing any gas ttings, all joints must be sealed with an approved,
leak-proof sealing compound.
● Never use an open ame to test for gas leaks.
●When your grill is not in use, it is recommended that for child safety, you remove the control
knobs and store them indoors.
●Keep children away from the grill at all times.
● Never drill out any orice or make any eld alterations to your grill without receiving approval
from the manufacturer.
● Do not store ammable materials in any of the cabinets beneath the grill burner box or in the
vicinity of your grill.
●Be careful while handling any parts during assembly. It is strongly recommended that you
protect your hands with a pair of work gloves.
●At high temperatures, some stainless grids may discolor over time. When the grill is cool,
wiping with a towel and vegetable oil may remove and treat some of this effect. Some
discoloration is normal.
6Lowes.com/masterforge
PACKAGE CONTENTS
A
H
G
I J K L
M
N
O
PQ
R
S
T
U
B C D
E
F
7Lowes.com/masterforge
PACKAGE CONTENTS
PART DESCRIPTION QUANTITY
A Burner Box 1
BHeat Tent 3
CMain Grid 2
DWarming Rack 1
ERight Side Shelf
Bracket 2
FRight Side Shelf 1
G Left Side Shelf 1
HLeft Side Shelf
Bracket 2
IDrip Tray Support 1
JSafety Tank Ring 1
K Tank Ring Bracket 1
PART DESCRIPTION QUANTITY
L Rear Panel 1
MIgniter 1
NRight Panel 1
ODrip Tray 1
PBottom Panel 1
QLocking Caster 2
R Caster 2
S Door 1
T Left Panel 1
U Front Beam 1
8Lowes.com/masterforge
HARDWARE CONTENTS
AA BB CC
3/16-24 x 1/2 in.
Screw
qty. 49
1/4-20 x 5/8 in.
Screw
qty. 2
AA Battery
qty. 1
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts
with package contents list and hardware contents list. If any part is missing or damaged,
do not attempt to assemble the product.
Estimated Assembly Time: 30 minutes by 2 people
Tools Required for Assembly: Phillips screwdriver (sold separately)
9Lowes.com/masterforge
ASSEMBLY INSTRUCTIONS
WARNING: The grill should be assembled and placed on a at, level suface.
Compare the parts and hardware with the list and diagrams. Do not attempt assembly if
any part is missing or damaged.
1. Attach the locking casters (Q) and the
casters (R) to the bottom panel (P)
using 12 screws (AA). When this process
is completed, turn the bottom panel over.
The two locking casters (Q) should be
at the back of the grill.
2. Align the holes in the rear panel (L)
with the holes in the bottom panel (P)
and insert screws (AA) into the aligned
holes.
Note: Do not tighten the screws
completely. Leave at least one full turn
on each. After all the screws have been
installed, go back and tighten them fully.
Hardware Used
Hardware Used
AA 3/16-24 x 1/2 in.
Screw x 12
AA
AA
3/16-24 x 1/2 in.
Screw x 3
1
AA
Q
P
R
2
P
L
10 Lowes.com/masterforge
ASSEMBLY INSTRUCTIONS
3. Attach the left panel (T) and right panel (N) to
the bottom panel (P). For both the left and
right panels, there are three screws for the
rear panel (L) and four for the bottom panel.
Insert the four bottom panel screws rst.
Hardware Used
AA 3/16-24 x 1/2 in.
Screw x 14
4. Attach the front beam (U) to the left panel (T)
and the right panel (N) with 2 screws (AA)
on each side as shown.
Hardware Used
AA 3/16-24 x 1/2 in.
Screw x 4
3
AA
L
N
P
T
AA
U
4
Other manuals for RT2417S
1
This manual suits for next models
1
Table of contents
Other Master Forge Grill manuals
Master Forge
Master Forge GD4215S User manual
Master Forge
Master Forge GGP-2501 User manual
Master Forge
Master Forge TG2036701-MF-01 User manual
Master Forge
Master Forge BG179A User manual
Master Forge
Master Forge CBT1227L User manual
Master Forge
Master Forge 1010037 User manual
Master Forge
Master Forge 332738 User manual
Master Forge
Master Forge CG2053401-MF User manual
Master Forge
Master Forge CBC835L User manual
Master Forge
Master Forge GBC22491L User manual
Master Forge
Master Forge B10LG25 User manual
Master Forge
Master Forge MFX784BDP User manual
Master Forge
Master Forge RT2417S Mounting instructions
Master Forge
Master Forge CBC23023L User manual
Master Forge
Master Forge 820-0033 User manual
Master Forge
Master Forge BG2724B-L User manual
Master Forge
Master Forge MFA350CNP User manual
Master Forge
Master Forge GBT13039L User manual
Master Forge
Master Forge 3618ST User manual
Master Forge
Master Forge CBC23043L User manual
Popular Grill manuals by other brands
Kenmore
Kenmore 415.16123800 Use and care guide
Camp Chef
Camp Chef PG24CLAU Warning & instruction booklet
Tucker Barbecues
Tucker Barbecues GTR Series Assembly, installation and operating instructions
Monogram
Monogram ZGG540NCP1SS owner's manual
Equipex
Equipex Sodir Savoy Operation manual
Gaggenau
Gaggenau VR 414 610 use and care manual
