Manhattan 175586 User manual

SERIAL

PCI CARD

WITH 5 V

POWER OUTPUT

USER

MANUAL

Model 175586

MAN-175586-UM-0308-01

Thank you for purchasing this MANHATTAN

Serial PCI Card with 5 V

Power Output, Model 175586. The easy-to-follow instructions in this

manual help make installation of the card quick and simple, so you’ll

also soon be enjoying the benets of these features:

• Adds 4 independent RS-232 (16950 UART) DB9 serial ports to a

desktop computer

• Each port features an individually controlled 5 V DC power supply

• Supports data transfer rates up to 920 kbps

• Fits regular and low-prole PCI slots

• Lifetime Warranty

INSTALLATION

NOTE: After installing the driver, set the correct data rate using a frequency

of 14.745 MHz or by using the automatic frequency detection function.

5 V Jumper Setting for each RS-232 Port

• 5 V DC on Pin 9 of DB9 connector = 5 V short.

• Normal RI function on Pin 9 of DB9 connector = RI short.

Windows 9X/Me

1. Turn off the computer.

2. Insert the Serial PCI Card into an available PCI slot.

3. Turn the computer back on.

4. When the Install Wizard displays “Found New Hardware” message,

select “Specify the location of the driver (Advanced)”; insert the driver

CD in the CD-ROM drive; click “Next.”

5. Conrm that “Search for the best driver for your device (Recommended)”

and “Specify a location” are both selected. De-select any other options

and enter “E:\” (or whatever letter designates the drive); click “Browse.”

6. Specify a location; for example, “E:\PCI IO Host\OXmPCI\Windows.”

Click “OK”; click “Next.”

7. When the wizard indicates that it found a driver for the device, click

“Next.” Then click “Finish” to exit the wizard.

8. Repeat Steps 4–7.

9. Once the driver is installed, click “Yes” to restart the computer.

Windows 9X/Me Installation Verication & Frequency Setting

1. Right-click My Computer on the desktop, then select “Properties” and

click on the Device Manager tab.

2. Double-click “Multifunction adapters.” If no yellow exclamation point (!)

or question mark (?) appears in front of “OX16PCI954 PCI UARTs

(unique bars)” or “OX16PCI95x PCI bridge,” the driver has started

properly.

3. Double-click “Ports.” If no yellow exclamation point (!) or question

mark (?) appears in front of “PCI Communications Port (COM3)” —

or (COM4–6, as per Step 8 below) — the driver has started properly.

4. To view information about devices attached to the controller, right-

click “PCI Communications Port (COM3)” and click “Properties.”

5. Click on the Data Rate tab. On the Input Clock panel, enter “14.7456”

in the “Crystal Frequency” eld or select “Automatic Crystal Detection.”

6. In the Baud Rate Generation options panel, select “User Dened

Override Speed.”

7. In the Override Conguration panel, position the speed bar controller

to the correct baud rate.

8. Repeat Steps 4–7 to set COM4, COM5 and COM6.

Windows NT 4.0

1. Turn on the computer.

2. Insert the driver CD into the CD-ROM drive.

3. Browse the driver CD and specify a location; for example, “E:\PCI IO

Host\OXmPCI\Windowsexe\NT4_Serial.”

4. Double-click “Install_Serial.”

5. When “Windows NT4 Device Installer” displays, click “Next.”

6. When “OxSer.INF” displays, select “Install”; then click “Next” and “Yes.”

7. When “The operation was completed successfully and the driver has

been started” displays, click “Exit.”

Windows NT 4.0 Installation Verication & Frequency Setting

1. Right-click Start on the desktop, then select “Settings” and “Control

Panel.”

2. Double-click “Ports”; select a COM port (e.g., “COM3”). The driver has

started correctly.

Windows 2000/XP

1. Turn off the computer.

2. Insert the Serial PCI Card into an available PCI slot.

3. Turn the computer back on.

4. Insert the driver CD in the CD-ROM drive.

5. When the Install Wizard displays the window with a “Found New

Hardware” message, click “Next.”

6. Select “Search for a suitable driver for my device (Recommended)”;

click “Next.”

7. Conrm that “Specify a location” is the only option selected; click “Next.”

8. Enter “E:\” (or whatever letter designates the drive); click “Browse.”

9. Specify a location; e.g., “E:\PCI IO Host\OXmPCI\Windows.” Click “OK.”

10. When the wizard indicates that it found a driver for the device, click

“Next.” Then click “Finish” to exit the wizard.

11. Repeat Steps 5–10.

Windows 2000/XP Installation Verication & Frequency Setting

1. Right-click My Computer on the desktop, then select “Properties” and

click on the Hardware tab, then click “Device Manager.”

2. Double-click “Multifunction adapters.” If no yellow exclamation point (!)

or question mark (?) appears before “OX16PCI954 PCI UARTs (unique

bars)” or “OX16PCI95x PCI bridge,” the driver has started properly.

3. Double-click “Ports.” If no yellow exclamation point (!) or question

mark (?) appears in front of “PCI Communications Port (COM3)” —

or (COM4–6, as per Step 7 below) — the driver has started properly.

4. To view information about devices attached to the controller, right-

click “PCI Communications Port (COM3)” and click “Properties.”

5. Click on the Data Rate tab. On the Input Clock panel, enter “14.7456”

in the “Crystal Frequency” eld or select “Automatic Crystal Detection.”

6. In the Baud Rate Generation options panel, select “Use default baud

rate.”

7. Repeat Steps 4–6 to set COM4, COM5 and COM6.

SPECIFICATIONS

• 32-bit / 33 MHz fully complaint PCI host interface; PCI V3.0

• Superset and backward compatible with 16C550, 16C650, 16C750

and 16C850

• 128-Byte deep FIFO per transmitter and receiver

• 128Rx and 128Tx interrupt and 128 ow control thresholds

• 3.3 V / 5 V DC operation

• Compliant with PCI Specication, revision 3.0 and PCI Power

Management Specication 1.1

• Two brackets, cable, drivers and manual included

• Windows 98/Me/NT 4.0/2000/XP/Vista compatible

All products mentioned are trademarks or registered trademarks of their respective owners.

www.manhattan-products.com

MANHATTAN®offers a complete line

of PC Components, Peripherals, Cables and Accessories.

Ask your local computer dealer for more information

or visit us online at
