Malibu Boats LT10 User manual

LÁMPARA TIPO ANTORCHA

CON PANTALLA

INSTRUCCIONES DE MONTAJE Y DE INSTALACION

LAMPE ABAT-JOUR BALISE

INSTRUCTIONS D’INSTALLATION/DE MONTAGE

SHADED FLARE LIGHT

ASSEMBLY/INSTALLATION INSTRUCTIONS

MISE EN GARDE: La(les) lampe(s)

doi(ven)t être installée(s) conformément à tous

les codes et règlements locaux. Ne pas

installer à moins de 10 pieds d’une piscine,

spa ou fontaine.

AVISO: La(s) lámpara(s) deberá(n) ser

instalada(s) de acuerdo a los códigos y

regulaciones locales. No la(s) instale a menos

de 10 pies de distancia de una alberca,

jacuzzi o fuente.

CAUTION: Fixture(s) must be installed in

accordance with all local codes and

ordinances. Do not install within 10 feet of a

pool, spa or fountain.

Instructions de

montage de la lampe.

Instrucciones de montaje

de la lámpara.

Fixture Assembly

Instructions.

Screw pipe sections together.

Una los tubos por la

parte roscada.

Vissez les sections des

fourreaux ensemble.

Screw ground stake

into bottom of pipe.

Enrosque el soporte de

fijación al suelo en la

rosca de la parte inferior

del tubo.

Vissez le piquet de terre

à la base du fourreau.

Remove fixture from

plastic wrap.

Saque la lámpara del

envoltorio de papel.

Retirez la lampe de

l’emballage plastique.

LV528

RIGHT WAY

CORRECTO

CORRECT

WRONG WAY

INCORRECTO

INCORRECT

Lens-to-shade

assembly

4. Montaje del lente

a la pantalla Assemblage de la

lentille à l’abat-jour

Install bulb.

Instale la bombilla.

Installez l’ampoule.

Install lens at top

of fixture. Turn

clockwise to lock.

Instale la lente en la

parte superior de la

lámpara, haciéndola

girar hacia la derecha

hasta que se trabe.

Installez la lentille sur

la lampe. Tournez la

dans le sens des

aiguilles d’une montre

pour la verrouiller.

LT10

Snap lens down, into shade clips

Encajar el lente sobre los sujetadores

Emboîter la lentille sur les attaches

Do not place lens under shade clips

No colocar el lente por debajo de los

sujetadores de la pantalla

Ne pas placer la lentille au dessous

des attaches de l’abat-jour
