AS001G

EN Cordless Dust Blower INSTRUCTION MANUAL 9

PL Akumulatorowa Dmuchawa

do Kurzu INSTRUKCJA OBSŁUGI 23

HU Akkumulátoros porfúvó HASZNÁLATI KÉZIKÖNYV 38

SK Akumulátorové prachové

dúchadlo NÁVOD NA OBSLUHU 52

CS Akumulátorový fukar na

prach NÁVOD K OBSLUZE 66

UK Акумуляторна повітродувка ІНСТРУКЦІЯ З

ЕКСПЛУАТАЦІЇ 80

RO Suantă de praf fără r MANUAL DE INSTRUCŢIUNI 95

DE Akku Gebläse BETRIEBSANLEITUNG 109

2

1

1

2

2

3

Fig.1

2

1

Fig.2

1

2

Fig.3

1

2

3

4

Fig.4

2

4

31

Fig.5

1

2

3

Fig.6

12

Fig.7

3

12

Fig.8

12

3

4

5

6

Fig.9

2

1

3

4

5

Fig.10

1 1

2

3

Fig.11

1

2

3

4

Fig.12

1

4

5

3

2

Fig.13

1

2

3

4

Fig.14

4

2

4

31

Fig.15

1

1

2

3

Fig.16

1

2

Fig.17

1

2

1

2

34

Fig.18

1

Fig.19

1

2

Fig.20

1

2

3

4

5

Fig.21

5

1

2

3

Fig.22

1

2

Fig.23

1

2

3

3

1

2

Fig.24

Fig.25

Fig.26

Fig.27

1

2

Fig.28

Fig.29

6

Fig.30

Fig.31

Fig.32

11

2

3

4

5

4

Fig.33

Fig.34

Fig.35

Fig.36

1

Fig.37

7

Fig.38

Fig.39

Fig.40

1

2

3

4

Fig.41

1

Fig.42

1

Fig.43

Fig.44

Fig.45

8

1

Fig.46

2

4

31

Fig.47

9ENGLISH

ENGLISH (Original instructions)

SPECIFICATIONS

Model: AS001G

Air speed (average) *2 *3 163 m/s

Air speed (max.) *2 *3 200 m/s

Maximum air volume *1 *2 1.1 m3/min

Maximum blowing force *1 *2 4: Max 2.8 N (0.29 kgf)

3: High 2.3 N (0.23 kgf)

2: Medium 1.7 N (0.17 kgf)

1: Low 1.1 N (0.11 kgf)

Continuous use *1 *2 4: Max 13 min

3: High 17 min

2: Medium 25 min

1: Low 50 min

Maximum air pressure *2 *3 29.7 kPa

Dimensions (L x W x H) *1 *2 180 mm x 94 mm x 300 mm

Rated voltage D.C. 36 V - 40 V max

Net weight 1.5 - 2.9 kg

*1 Without nozzles

*2 With battery model BL4025

*3 With nozzle 7

• Duetoourcontinuingprogramofresearchanddevelopment,thespecicationshereinaresubjecttochange

without notice.

• Specicationsmaydi󰀨erfromcountrytocountry.

• Theweightmaydi󰀨erdependingontheattachment(s),includingthebatterycartridge.Thelightestandheavi-

est combinations, according to EPTA-Procedure 01/2014, are shown in the table.

Applicable battery cartridge and charger

Battery cartridge BL4020* / BL4025* / BL4040* / BL4050F / BL4080F

* : Recommended battery

Charger DC40RA / DC40RB / DC40RC

• Some of the battery cartridges and chargers listed above may not be available depending on your region of

residence.

WARNING: Only use the battery cartridges and chargers listed above. Use of any other battery cartridges

andchargersmaycauseinjuryand/orre.

10 ENGLISH

Applicable nozzles and attachments

Nozzles and attachments Applications and purposes Diameters

Nozzle 3 Blowingairintoconnedspaces,corners,andspacesbythewallsto

dusto󰀨.

ø3.0 mm

Nozzle 7 Dustingo󰀨lters. ø7.0 mm

Nozzle 13 Using as blower

Cleaning work surfaces and blowing dust in general.

Anchor hole cleaning with optional long nozzles.

Functioningasajointbetweenlongnozzlesandbloweroutletofthetool.

Using as inator

Inatinglargeinatablepoolsorairmattresses.

Using as deator

Deatinglargeinatablepoolsorairmattresses.

Functioningasajointbetweenairventhosecompleteandrubber

attachments.

ø13 mm

Wide range nozzle Blowing air over dirt and liquid on desktop and wide-open area.

Blowing range: 120° with 5 holes

ø6.0 mm

* As a single hole

diameter

Pinch valve nozzle Inating/deatingbeachtoys,pillows,andsimilarplasticinatables.

*Deatingoperationcanbecarriedoutwithoptionalairventhose

complete.

ø7.0 mm

Flexible nozzle 6 Blowing dust out of any hard-to-reach spots, PCs and similar devices. ø6.0 mm x 800 mm
