CALIBRATION INSTRUCTIONS
The Magnum HD was factory calibrated, however, calibration should be checked occasionally to
assure optimum performance.
1. Pull the on/off lever to the “OFF” position.
Set the rate control plate to setting “B”. 3. Loosen the rate control knob and slide the rate
plate until the port is just opening. Loosen
pointer screw and move pointer until it aligns
with “A” on the rate plate. Retighten pointer
screw.
2. Flip on/off control lever to the “ON” position.
Check the port opening. It should be just open.
If adjustment is necessary, continue to step #3.
Rate Control Knob
Pointer
Rate Control Plate
Port is just open
Pointer Screw
VIEW IS
INSIDE OF
HOPPER
WARRANTY
Magnum Spreader warrants to Purchaser the following:
Magnum Spreader, warrants to the original purchaser for a period of two year’s from the date of purchase of Magnum Spreader brand spreader
products that they will be free from defects in materials or workmanship, with the exceptions stated below. No person is authorized to change this
warranty or to create any additional warranty on Magnum Spreader products.
Magnum Spreader will repair any product that proves to be defective in materials or workmanship. In the event repair is not possible or practical (as
determined by Magnum Spreader in its sole discretion), Magnum Spreader will either replace the product with a new product of similar model and
price, or refund the full purchase price, as determined by Magnum Spreader. Customer must keep the complete spreader system serviced/
maintained as recommended by Magnum Spreader.
This warranty does not cover:
• Problems caused by failure to follow the product instructions, or failure to maintain the product as described in the Operator’s Manual;
• Damage resulting from rust, corrosion
• Damage caused by usage that is not in accordance with product instructions (use of the spreader for any purpose other than spreading approved
material is considered misuse and abuse);
• Any spreader, or any part, component, or assembly thereof, which has been modified or altered;
• Problems caused by using accessories, parts, or components not supplied by Meyer Products;
• Cost of tax, freight, transportation or storage charges, environmental charges, solvents, sealants, lubricants or any other normal shop supplies.
• Problems caused by collision, fire, theft, vandalism, riot, explosion, lightning, earthquake, windstorm, hail, water, flood, or any other Acts of God;
• Liability for damage to property, or injury to, or death of any person arising out of the operation, maintenance or use of the covered product;
• Products with missing or altered serial numbers;
How To Get Service:
• It is the responsibility of the original purchaser to establish the warranty period by verifying the original delivery date. A bill of sale, cancelled
check or some other appropriate payment record may be kept for that purpose. It is recommended, but not required, that the consumer verify the
original delivery date by immediately returning the attached Warranty Registration Card.
How State Law Applies:
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
