Magic Chef MCBR445B2 User manual

REFRIGERATOR

INSTRUCTION MANUAL

Model No.: MCBR445W2

MCBR445B2

MCBR445S2

To ensure proper use of this appliance and your safety, please read the following

instructions completely before operating this appliance.

TABLE OF CO TE TS

Before Putting Into Use………………………………………………………………….. 2

Tips For Energ Savings………………………………………………………………….. 2

Important Safet Instructions……………………………………………………………. 3

Name Of The Parts……………………………………………………………………….. 4

Specifications……………………………………………………………………………… 4

How To Operate:

Starting Your New Refrigerator………………………………………………….. 5

Temperature Control………………………………………………………………. 5

How To Defrost…………………………………………………………………….. 5

How To Clean……………………………………………………………………….……… 6

How To Install………………………………………………………………………….…… 6

Care And Maintenance

What To Do……………………………………………………………………….… 7

Changing The Reversible Doors………………………………………………….……… 8-9

Refrigerator Warrant ……………………………………………………………………… 10

Before Putting Into Use

Before connecting the appliance to the power suppl , let the unit stand upright for 4 hours,

which will reduce the possibilit of the cooling s stem malfunctioning due to improper

handling.

Clean our unit thoroughl before putting into use. (See How to Clean)

Use the parts diagram on page 4 to insure proper positioning of internal components.

Tips for Energy Savings

Keep the refrigerator and freezer doors closed as much as possible, particularl in warm /

humid conditions.

Maintain adequate ventilation around the back and sides of the unit.

Maintain a thermostat setting of between “3” and “5” under normal use.

Allow warm food to cool to room temperature before placing in the refrigerator or freezer.

Excessive ice build up will increase energ consumption. Defrost the unit when ice / frost

is1/4” thick.

Important Safety Instructions

DA GER: Risk of child entrapment. Before ou throw awa our old refrigerator or freezer:

Take off the doors.

Leave the shelves in place so that children ma not easil climb inside the unit.

The appliance must be correctl connected to the power suppl . (See: “HOW TO INSTALL”).

Do not use an extension cord as this can negativel affect the performance of the unit.

Do not touch the cooled surfaces while the appliance operates, especiall not with wet

hands, because the skin ma stick to the cold surfaces.

Do not freeze bottled liquids such as carbonated soft drink, beer, wine, etc. Doing so can

cause glass bottles and aluminum cans to rupture.

If the unit fails to cool properl , dispose of spoiled food as needed.

All repairs should be made b a qualified service technician. Repairs made b

non-qualified personnel will void the warrant .

Do not defrost the appliance with other electric devices (hair dr er, etc.) and never scrape

the ice or frost la er with sharp tools.

The rating plate is inside the appliance or outside on the rear wall.

AME OF THE PARTS

Model No.: MCBR445W2 / MCBR445B2 / MCBR445S2

⑴ Evaporator

⑵ Drain Pan

⑶ Temperature Control Box

⑷ Shelves

⑸ Door Liner

⑹ Ice Cube Tra

⑺ Rack

⑻ Bottle Rack

⑼ Crisper

⑽ Can Dispenser

⑾ Temperature Control Dial

⑿ Defrost Button

SPECIFICATIO S

Product Description Magic Chef Refrigerator with Glass Shelves

Model No. MCBR445W2 / MCBR445B2 / MCBR445S2

Capacit 4.4 Cu. Ft.

Width Height Depth Unit Dimensions

( inches ) 18.89” 32.91” 21.1”

Net Weight ( lbs ) 57.3 ( lbs )

HOW TO OPERATE

Starting Your ew Refrigerator

1. Clean the refrigerator thoroughl . Wipe the outside with a soft dr cloth, the interior with a

clean moist cloth.

2. Insert the power suppl cord into the socket.

3. Turn the thermostat dial to “7”. Close the doors and let the refrigerator operate for 15-20

minutes.

4. Reduce the thermostat to a mid-range setting between “3” and “5” on the thermostat control.

Temperature Control

To control the internal temperature, adjust

the thermostat dial. “1” is the warmest

setting. “7” is the coldest.

The Dial ma be set an place on the scale.

It does not have to be set exactl on a

number. To make ice cubes in the freezer

compartment, adjust the thermostat to the

coldest setting.

ote: Wait 3-5 minutes before restarting if ou unplug the refrigerator. The unit ma fail to

operate properl if restarted too quickl .

How To Defrost

Defrost the refrigerator when the frost accumulated on the evaporator is about 1/4” thick.

To defrost, simpl push the defrost button. Be sure to keep the drain pan in place. Defrosting

usuall takes a few hours. The refrigerator will restart automaticall when defrosting ends. Empt

water from the drain pan after defrosting.

ever use a knife or other sharp metal instrument to scrape ice / frost from the inside of the

unit.

Defrost Button

HOW TO CLEA

Cleaners: Never use harsh, abrasive cleaners, heav -dut cleaners, or solvents on an surface.

Exterior: Wipe with damp, suds cloth, rinse and dr . For stubborn stains and for periodic waxing,

use silicon wax.

Freezer: When refrigerator needs defrosting press defrost button. Do not use sharp

instruments to scrape off ice/frost.

Refrigeration Section: Wash shelves and other removable parts in warm suds water, rinse and

dr . Wash interior with baking soda solution (3 tablespoons to I liter of water) or warm

suds water, rinse and dr .

Magnetic Door Seals: Wash with warm suds water.

The Finishing Touch: Replace all parts and return thermostat dial to desired setting.

HOW TO I STALL

Install the refrigerator in a convenient

location awa from extreme heat and

cold. Allow sufficient clearance between

the refrigerator and side wall so the

door(s) will open without obstruction.

Refrigerator is not designed for recessed

installation.

Select a space with strong level floor.

Allow 5 inches of space between the

refrigerator’s side and the wall.

The appliance must be correctl

connected to the power suppl .

POWER CORD REPLACEME T

If the refrigerator’s power cord is damaged, have it replaced b a qualified repair agent.

CARE A D MAI TE A CE

WHAT TO DO …

When the fridge is not in use for a prolonged period:

Remove the plug from the outlet.

Remove all contents from the fridge.

Dr the interior and leave the door open for a few da s.

When you wish to move the fridge:

Secure all movable parts and contents. (Package them separatel if necessar .)

Transport the fridge onl in an upright position. In an other position ou ma damage the

compressor.

Before calling service, please follow the checklist below.

This ma save ou an expensive service call.

If the refrigerator is not cooling properly:

Check to see that the door is closing properl and the door seal is not damaged.

Check that the interior circulation is not obstructed b having too man goods stored. (The

fridge is overloaded)

Did ou store an thing hot, without first cooling it to room temperature?

Is there sufficient clearance around all sides and above the fridge?

If the fridge starts making any unusual noises:

Is it wobbling? Re-level the unit and check if it now operates normall .

Have an objects fallen behind the fridge? If so, remove them and check if operation is now

normal.

Are an containers inside the fridge vibrating or resonating? If so, rearrange them then

check to see if operation has returned to normal.

WAR I G – Improper use of the grounding plug can result in a risk of electric shock. If it is

necessar to use an extension cord, use onl a 3-wire extension cord that has a 3-blade

grounding plug and a 3-slot receptacle that will accept the plug on the appliance. The marked

rating of the extension cord should be AC 115-120V, 10A, or more. If a grounding adapter is

used, make sure the receptacle box is full grounded.

CHA GI G THE REVERSIBLE DOORS

CAUTION: To avoid personal injury to yourself and/or property, we recommend

someone assist you during the door reversal process.

This refrigerator has been built with the door hinges on the right. If ou wish to change the opening direction, follow

the instruction below:

Unplug the refrigerator from its electrical outlet.

Empt ever thing in the refrigerator, including shelves, food, etc.

1. Remove the hinge cover on the right top of the cabinet.

2. Remove the two screws (using a ratchet tool with a

7/16” socket) that hold the top hinge to the cabinet.

Keep these screws for later use.

3. Lift the top hinge straight up to free the pin from the

socket on the top of the door.

4. Lift the door and place it on a padded surface to

prevent scratching it.

5. Remove the plug buttons from the upper left holes as

illustrated and transfer them to the uncovered holes at

the right side. Be sure to press the plug buttons firml

into the holes.

6. La the cabinet on its side down on the floor. Remove

the three screws that hold the bottom hinge to the

cabinet using a 7/16” socket. Keep these screws and

washer for later use.

7. Insert the bottom hinge at the left side using the two

screws previousl removed in step 6.

NOTE: Do not tighten screws.

8. Stand the cabinet.

9. Replace the door making sure the bottom socket

enters the bottom hinge pin. Be sure washer is in

place.

10. While holding the door in the closed position, secure

the top hinge at the left side using the two screws

previousl removed at the beginning in step 2. Do not

tighten the screws until the top of the door is leveled

with the top cabinet.

11. Replace the hinge cover.

12. Replace plugs.

13. Tools Required:

- 7/16” socket-ratchet.

- Putt knife or thin-blade screwdriver.
