Maestro MR070 User manual

Модель/Model: MR070

Сerticated in Ukraine

Виріб сертифіковано в Україні

091

Owners manual. Electric kettle

Bedienungsanleitung. Wasserkocher

Instrukcji obsługi. Сzajnik elektryczny

Manualul proprietarului. Ceainic electric

Руководство по эксплуатации. Электрический чайник

Керівництво з експлуатації. Електричний чайник

Pictures/ Bilder/Rysunki/ Figuri/ Рисунки/ Малюнки 1

Description of the appliance___________________________________________4

Gerät_______________________________________________________________11

Konstrukcja urządzenia_______________________________________________22

Structura produsului____________________________________________________31

Устройство прибора____________________________________________________40

Склад приладу________________________________________________________49

Dear customer, we thank you for purchase of goods

Functionality, design and conformity to the quality standards

guarantee to you reliability and convenience in use of this device.

Please read and comply with these original instructions prior to the

initial operation of your appliance and store them for later use of

subsequent owners.

The kettle is designed only for warming and boiling water

for home use.

Under condition of observance of user regulations and a special-

purpose designation, a parts of appliance do not contain unhealthy

substances.

Technical specications

Model: MR070

Capacity: 1,5 L

Electrical supply:

Alternating current- AC;

Rated voltage 220-240V;

Rated frequency 50Hz;

Power consumption 1200W

Protective class I

Protection class IPX0

Description of the appliance

Picture1 (page 2)

A- Cover;

В- Handle for cover opening;

C- Switch button with indicator light;

Position «0» - OFF

Position «I» - ON

D- Handle;

E- Kettle case;

F- Base.

Safety instructions

When using your appliance, basic safety precautions should

always be followed,

including the following:

SPECIAL INSTRUCTIONS

ATTENTION!

- Do not allow the ingress of water and moisture on the support and

internal electric parts of the device located outside the container for

water.

- Always remove the kettle from the support to ll it with water or to

clean.

- Do not touch the water in the kettle when it is on the support.

Failure to observe these rules may result in electric shock!

Only plug the appliance into an outlet with an earthed (ground)

contact.

- DO NOT let children or untrained persons use the appliance

without supervision.

- DO NOT leave the appliance unnecessarily plugged in.

Disconnect the plug from the mains when the appliance is

not being used.

- DO NOT use the power cord or the appliance in order to pull the

plug out of the socket.

- DO NOT leave the appliance exposed to the weather (rain, sun,

etc. ).

- DO NOT leave the appliance without supervision when it is

connected to the power supply.

- Close supervision is necessary when the appliance is used near

children.

- Always use the appliance on a dry, level surface.

- Do not put on and take off the kettle from the support when it is

switched on. First, turn it off with a switch.

- Always unplug from the plug socket when not in use and before

cleaning.

- Do not operate the appliance if damaged, after an appliance

malfunctions or it has been damaged in any manner, return to at

authorized service engineer for repair.

- In the interest of safety, regular periodic close checks should be

carried out on the supply cord to ensure no damage is evident.

Should there be any signs that the cord is damaged in the slightest

degree, the entire appliance should be returned be authorized

service engineer.

- Do not let the cord hang over the edge of a table or counter or

touch hot surfaces. Allow unit to cool before storage.

- Do not touch any hot surfaces, do not store or cover the appliance

until it has full cooled down.

- Do not use harsh abrasives, caustic cleaners or oven cleaners

when cleaning this appliance.

- This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities, or

lack of experience and knowledge, unless they have been given

supervision or instruction concerning use of the appliance by a

person responsible for their safety.

- Children should be supervised to ensure that they do not play with

the appliance.

- Do not leave the kettle switched on if the temperature in the room

may fall below zero. When the temperature is below zero, the

thermostat of the device may spontaneously turn on and switch on

the device.

ATTENTION!

- The surface of the device becomes very hot during operation.

Be careful because you may burn yourself greatly by touching the

surfaces of the cover, case, water of vapor.

- Do not open the cover of the kettle during boiling.

- Do not lift the kettle by its cover.

- Take and lift the kettle only keeping it for the handle, touch only the

buttons of the device.

- Do not ll the kettle with the water level higher than the mark

«MAX».

- Place the kettle only on a dry, stable, even, slip-resistant surface.

- Lift the kettle full with hot water with special care!

In case of failure to observe the above mentioned rules there

arises the danger of burning!

- To avoid possible damages by vapor turn the kettle nose away

from walls and furniture when it is boiling. Use the support to save

the sensitive cover of furniture from damages.

- Do not place the kettle and its support on heating devices.

- Do not close the opening for the exit of vapor near the switch.

- Do not use the kettle without a cover.

- Do not switch the kettle on without water or when the water

level is below the mark «MIN». If the kettle is empty or there

is not enough water in it, it is automatically turned off by safety

device. In such case, disconnect the device from the mains, let it

cool down and then ll it with water again and turn it on; the kettle

will begin to boil water and after the end of this process it will turn

off in the regular regime.

- THIS APPLIANCE IS FOR HOUSEHOLD USE ONLY. DO NOT

USE THE APPLIANCE FOR ANYTHING OTHER THAN INTENDED

USE.

Purchase industrial devices for commercial use.

Actions in extreme situations:

- If a device tumbled into water, immediately, unplug the device, not

touching to the device or water.

- In case of appearance from appliance of smoke, sparkling, strong

smell of a burn isolation, immediately stop use the device, unplug

the device, appeal to the nearest service center.

Operation

Before the rst use:

- Remove packing and advertising materials and stickers.

- Inspect the kettle and make sure that there are no damages to the

kettle, power line cord, plug and support.

- Unwind the power line cord completely.

- Place the support on a dry, even, stable surface.

CAUTION! Is required on surfaces where heat may cause a

problem – an insulated heat pad is recommended.

- Connect the plug to the mains.

- Remove the kettle from the support.

- Open the cover, ll the kettle with cold water up to the mark

«MAX» (the water level scale with «MIN» and «MAX» marks is

inside). Close the cover.

- Place the kettle on the support.

- Turn the switch (C/ Fig.1) to the position «I». The indicator will

light signaling that the device has turned on, and the kettle shall

begin warming the water.

- When the water begins to boil, the switch will be turned to

the position «О» (off), the light will fade and the kettle will be

automatically turned off.

- You must pour out the rst portion of water and repeat the boiling

procedure again.

- Now the kettle is ready for use.

ATTENTION! Do not ll the kettle with cold water until cools down;

let it get cool before lling with cold water.

Failure to observe this rule may result in the damage to the

ceramic case.

Further boil water as specied above.

The level of water in the kettle must be somewhere between the

marks «MIN» and «MAX».

The process of warming the water can be interrupted at any

moment by pressing on the switch.

ATTENTION! If your kettle switches off before the water begins to

boil, you should clean it of scale (see cleaning and maintenance).

The kettle can continue operation if its cover is open.

Cleaning and maintenance

Regular cleaning improves the performance of the device.

The quantity and the speed of forming the scale, and consequently,

the necessity of cleaning depend on the water hardness in your

region and the intensity of the device usage. All over fur of scale in

your kettle is not allowed!

It is recommended to clean the kettle at least 2 times a year

but however until the appearance of all over scale.

ATTENTION!

- Never clean a kettle connected to mains.

- Before cleaning, disconnect the kettle and let it cool down.

- Do not use abrasive and aggressive detergents.

- Never submerge the kettle, its support, power line cord and plug in

water or other liquids.

Cleaning the kettle from scale

Clean the kettle from scale with special agents sold in the open

market. Cleaning from scale can be also performed by the methods

described below:

METHOD 1

- Fill the kettle to maximal level with a mixture consisting of 1 part

of usual vinegar and 2 parts of water. Switch on the kettle and let is

boil and automatically switch off.

- Let the mixture settle during 10-12 hours and pour it out.

- Fill the kettle with fresh water up to maximal level and boil it again.

Pour out this water too to remove the smell of vinegar.

-Wash the internal part of the device with clean water, wipe it and

dry the kettle.

METHOD 2

- Fill the kettle with the above mentioned mixture of water and

vinegar and boil it 2 or 3 times running. Rinse it with water and rub

it dry.

- For usual cleaning wipe the kettle case from the inside and outside

with a soft wet sponge or cloth. Soapy water can be used.

- Rinse the kettle and wipe it dry.

- Let the device get fully dry before using.

- Any other kinds of maintenance should be performed by qualied

personnel in a servicing center.

Storage

- Switch off the kettle and let it completely cool before storage.

- Wipe and dry the kettle before storage.

- Do not wind the power line cord around the kettle until it is

completely cooled down.

- Store the kettle in a cool, dry and clean place beyond the assess

of children and people with limited physical and mental abilities.

Environmental protection

Old appliances contain valuable materials that can be recycled.

Please arrange for the proper recycling of old appliances. Please

dispose your old appliances using appropriate collection systems.

Subject to technical modications!

This manual suits for next models

Table of contents

Languages:

Popular Kettle manuals by other brands

IKEA

IKEA UPPHETTA manual

Krups

Krups BW500B55 manual

Clas Ohlson

Clas Ohlson KE7086-BH instruction manual

Brock

Brock WK 0902 GR manual

inventum

inventum CBW010 instruction manual

Westfalia

Westfalia Retro 81 48 86 instruction manual

Ovente

Ovente KS88 Series Faqs

HUSLOG

HUSLOG AK-0832 user manual

Saturn

Saturn ST-EK840 manual

Wilfa

Wilfa TK-1200B operating instructions

HOME ELEMENT

HOME ELEMENT HE-KT150 user manual

Breville

Breville Crystal Clear BKE290 Instruction booklet

ECG

ECG RK 1745 instruction manual

cecotec

cecotec THERMOSENSE 600 TOUCH BLACK instruction manual

Kalorik

Kalorik JK 39825 operating instructions

tomado

tomado TM-1971 instruction manual

Cosori

Cosori CS108-NK user manual

Electrolux

Electrolux E7K1-6BP user manual
