MadgeTech Titan S8 Specification sheet

Product User Guide

TITAN S8

Portable Data Acquisition Logger

www. .com information@itm.com1.800.561.8187

Product User Guide

General Features ...................................................... 3

User Interface .......................................................... 8

Logging, Viewing and Managing Data ................... 22

Settings, Preferences and Support........................ 39

Technical Specifications ........................................ 42

Table of Contents

www. .com information@itm.com1.800.561.8187

Product User Guide

Device Overview

The MadgeTech Titan S8 is a portable, multi-use industrial data logger with eight channels and a user-friendly touchscreen interface. This versatile logger

measures and records temperature, current, voltage and pulse simultaneously and displays data in real time. The Titan S8 is compatible for use with

many thermocouple, RTD or thermistor probes as well as a number of voltage output sensors, current switches, transmitters and transducers.

Versatility makes Titan S8 the perfect companion for industrial engineers, quality assurance professionals, compliance oicers or automotive

technicians. The Titan S8 is very easy to use and configure via the built in capacitive touchscreen graphic display.

The Titan S8 is a powerful, independent tool. Unlike many other data loggers, the Titan S8 delivers an all-in-one data collection and monitoring solution

that does not require a PC or any downloaded soware for operation.

Chapter 1: General

External Features

Front Side Back

Home Button

Power Button

LCD Touchscreen

Tabletop Kickstand

Mounting Keyholes

USB Port

Power InputInput Ports

»Power Button: To power on and power o the device, hold down the Power button for 3 seconds.

»Home Button: The Home button will return the user to the home screen.

»Input Ports: The Titan S8 features 8 sensor channel inputs plus one alarm port and a ground (details on pages 5-6).

»LCD Touchscreen: 5 inch LCD capacitive touchscreen.

»USB Port: The Titan S8 has a built-in USB port for downloading data to a flash drive.

»Power Input: Charging port.

www. .com information@itm.com1.800.561.8187

Product User Guide

The Titan S8 display can rotate 180 degrees depending on the desired orientation of the device. This option is available from the Settings menu under

the Display section. Please note: Power restart required in order to apply screen rotation

Tabletop Orientation

The Titan S8 features a built in kickstand on the back of the device for use on a flat surfaces.

Device Orientation

Desktop Orientation

For handheld and tabletop use, the inputs will be on the top.

Wall Mount Orientation

For wall mount use the unit will be rotated so that the inputs will be

on the bottom.

www. .com information@itm.com1.800.561.8187

Product User Guide

The Titan S8 features 10 ports. Please refer to the image below for the port number as it relates to device orientation.

Device Inputs

1Input:

Input: 10

Channels and Functions

Ports 1 thru 8 are sensor input channels (Temperature, Current or Voltage)

Port 9 serves as an alarm output

Port 10 serves as a ground for the device

Frequency or Pulse Counter

Can only be used on port 1

3-Wire and 4-Wire PT100 RTD Sensors

Use ports 1-2, 3-4, 5-6, or 7-8

2-Wire PT100 RTD Sensors

Can be used on ports 1-8

www. .com information@itm.com1.800.561.8187

Product User Guide

Each of the 8 input channels can be individually configured for the following types and sensor ranges.

Sensor Types & Measurement Ranges

Parameter Input Type Range

»Current Current input 0 mA - 24 mA

»Frequency (port 1 only) Frequency input 20 to 4000 Hz

»Pulse / Counter (port 1 only) Pulse input 0 to 4,000,000,000 Pulses

»Voltage Volt input 0 V - 12 V

»Voltage Millivolt input 0 mV - 99mV

»Temperature Thermistor NTC-1 (2252) -25 °C to +150 °C

»Temperature Thermistor NTC-2 (10K) -25 °C to +150 °C

»Temperature PT100 RTD 2-Wire -200 °C to +400 °C

»Temperature PT100 RTD 3-Wire -200 °C to +400 °C

»Temperature PT100 RTD 4-Wire -200 °C to +400 °C

»Temperature Thermocouple J -210 °C to +760 °C

»Temperature Thermocouple K -270 °C to +1370 °C

»Temperature Thermocouple T -270 °C to +400 °C

»Temperature Thermocouple E -270 °C to +980 °C

»Temperature Thermocouple R -50 °C to +1760 °C

»Temperature Thermocouple S -50 °C to +1760 °C

»Temperature Thermocouple N -270 °C to +1300 °C

»Temperature Thermocouple B +50 °C to +1820 °C

www. .com information@itm.com1.800.561.8187

Product User Guide

Powering, Charging and Downloading Data

Power Button

(On/O)

USB-C Charging Port

(Cable Included)

USB Port

(For oloading data files and

updating device soware)

www. .com information@itm.com1.800.561.8187

Product User Guide

Stop Logging

Chapter 2: User Interface

Top Menu Bar

The top bar of the Titan S8 Interface features status icons and useful information to refer to while using the device.

Logging Session Indicator

Charging Indicator

Battery Level

Current Time

Home Screen

The Home screen will display the following options when the Home button is selected.

Stop Logging Icon

The Start Logging icon will

change to "Stop Logging"

when device is recording.

»Channel Configuration: Configure parameters and options for each channel

»Real-Time: Quickly view Real-Time data for all active channels

»Start Logging: Start logging using current settings (Stop logging if device is active)

»Current Session: View data from the current logging session as graph, tabular or real-time

»Data Storage: View and oload logged sessions

»Settings: Access device preferences and options Home Button

Actively Logging

Inactive

Delayed Start Configured

External Memory

Alarm Set

Internal Memory

90% - 97% Full

97% - 100% Full

www. .com information@itm.com1.800.561.8187

Product User Guide

Start Up Steps

Follow these steps for first use or when the device is powered up.

»Power Button: Press and hold the Power Button for 3 seconds to power up the device.

»Screen Ready: Wait for the device to iniate, you will see the MadgeTech logo when complete.

»Local Time: Enter the local time to be used by the device and click Next.

»Home: When the device presents the Home screen it is ready to use.

www. .com information@itm.com1.800.561.8187

Product User Guide

Channel Configuration

When the Channel Configuration icon is selected, the device will display the screen shown below

»Channel 1-8: Configure the type of channel input, units, engineering units (if applicable), alarms and user calibration adjustments.

»Apply: Applies the current channel configuration to make the device ready to start logging.

»Save: The user has the ability to save the current channel configuration so it may be loaded and used later.

»Load: The Load button will load previously saved channel configurations.

»Disable All: Clears the configuration of all channels, returning them to the default disabled status.

Select Channel Configuration
