Lowrance Endura Out&Back User manual

Endura Quick Start Guide

Power — The Power key is located on the left side of

the unit. To turn Endura On or Off, press and hold the

Power key for three seconds.

Mark & Arrow keys — The Mark key is used to

save your present position as a waypoint or to select

highlighted menu items. The Arrow keys move the cursor

on the map, select map items and highlight menu items.

Zoom out/Zoom in — Used to change the map scale.

Press both keys together for device lock/unlock.

Using the touch screen

Endura features touch screen controls to select menu items, scroll lists

and move the cursor to different parts of the map. To select an item, just

tap the screen. To pan the map or scroll a list, touch and drag.

Pages Key

Main Menu

Menu Key

Map

Satellite

Trip

Computer*

Elevation

Nav Status

Compass*

Page Sequence

* These pages are optional for Out&Back

*988-0160-55A*

Marking present position as a waypoint

Press and hold the1. MARK key for three

seconds. To personalize the waypoint,

touch the Name or Icon elds.

Touch the2. Back tab to return to the previous

page.

Find menu

Used to search for items ranging from waypoints and

geocaches to trails and routes. To access the Find menu,

press MENU and touch Find.

Selecting a destination

Press1. MENU and touch Find.

Touch the desired category on the Find menu.2.

Select the desired destination from the list. The3.

Goto tab will appear in the upper right corner.

Touch the4. Goto tab.

Press5. PAGES to select the Map or Nav Status page.

Map page

Pan Map — drag nger across screen to pan map

Return to present position — touch Back

Zoom — touch +/- keys to change map scale

Select items — touch desired onscreen map item,

or use ARROW KEYS and MARK to review

Nav Status

To navigate — follow the navigation arrow

Navigation arrow

Distance to destination or next point in your trip
