Logia LOWSB510PB User manual
5-IN-1 WIRELESS
WEATHER STATION
WITH PC DATA SYNC
USER GUIDE
LOWSB510PB
2
Thank you for purchasing the Logia™5-in-1 Wireless Weather Station with PC Data Sync. This
User Guide is intended to provide you with guidelines to ensure that operation of this product is safe
and does not pose risk to the user. Any use that does not conform to the guidelines described in this
User Guide may void the limited warranty.
Please read all directions before using the product and retain this guide for reference. This product is
intended for household use only. It is not intended for commercial use.
This product is covered by a limited one-year warranty. Coverage is subject to limits and exclusions.
See warranty for details.
SAFETY PRECAUTIONS
PRODUCT FEATURES
PACKAGE CONTENTS
DISPLAY CONSOLE OVERVIEW
LCD DISPLAY OVERVIEW
WIRELESS WEATHER SENSOR OVERVIEW
WIRELESS WEATHER SENSOR SETUP
DISPLAY CONSOLE SETUP
CLOCK SET OPTIONS DISPLAY
OTHER DISPLAY CONSOLE SETTINGS
WEATHER FORECAST
BAROMETRIC PRESSURE
RAINFALL
HISTORY GRAPH
MAX/MIN DATA RECORD
WEATHER ALERT SETTINGS
POINTING THE WIRELESS WEATHER SENSOR TO SOUTH
DATA LOG
PC SOFTWARE
UNINSTALLING THE WEATHER TOOL SOFTWARE
CARE AND MAINTENANCE
SPECIFICATIONS
QUESTIONS?
3
4
5
6
7
8
10
13
16
17
23
24
24
25
27
28
29
30
31
32
32
33
37
TABLE OF CONTENTS
3
SAFETY PRECAUTIONS
1. Do not let children use or play with this device. It is not a toy.
2. Do not use any attachments not supplied or recommended by the manufacturer.
3. Do not place the appliance near open ames or heat sources. Fire, electric shock, product damage,
or injury might occur.
4. Do not mix old and new batteries in the display unit.
5. A low battery symbol will appear in the upper right corner of the LCD display when battery
power is low. Be sure to change the batteries promptly to ensure the proper operation of the
weather station.
6. Do not subject the display unit to excessive force or shock (do not throw the unit!), dust, extreme
high or low temperatures, or humidity/moisture. These can cause the unit to stop functioning as
well as present the risk of shock, re, or other hazards.
7. Do not cover the ventilation holes on the display with newspapers, curtains, or any other items.
8. Never immerse the display in water! If you spill any liquid on the display, dry it immediately with
a soft, lint-free cloth.
9. Do not use abrasive or corrosive materials to clean the display.
10. Do not tamper with the display or the weather vane’s internal components. This invalidates your
limited warranty.
11. Placing this product on certain types of wood may result in unintended damage to the nish,
for which Logia™will not be responsible. Consult your furniture manufacturer’s instructions for
information on wood care.
12. Do not dispose of old batteries as unsorted municipal waste. Make sure to dispose of them properly
according to your local guidelines.
13. The main display console is only intended for use indoors.
QUESTIONS OR PROBLEMS? CONTACT US!
www.logiaweatherstation.com
4
PRODUCT FEATURES
1. Wireless 5-in-1 weather sensor measures wind speed, wind direction, rainfall, temperature, and
humidity.
2. No calibration needed! The product is fully pre-calibrated and mostly assembled; all you need to do
is install it and sync with the included display console.
3. Provides precise weather and environmental information directly from your own backyard, instead
of relying on a national weather station.
4. Black and white LCD display screen with amber backlight.
5. Can alert you to excessively high/low indoor or outdoor temperatures or humidity, high wind speeds,
extreme drops in barometric pressure, high heat indexes, low wind chills, and high/low dew points.
6. Syncs with installed PC software to help you store and track weather data in your area. (Does not
work with non-Windows computers.)
5
PACKAGE CONTENTS
1. Wireless Weather
Sensor (1)
2. Mounting Pole (1)
Plastic Exterior
3. Mounting Clamp (1)
4. Mounting Base (1)
5. Large Mounting Screws (4)
6. Large Hexagonal Nuts (4)
7. Large Washers (4)
8. Small Screws (2)
9. Small Hexagonal Nuts (2)
10. Rubber Pads for Mounting
Clamp
11. Micro USB Cable (1)
12. Display Console (1)
13. User Guide
1
2
5
7
8
6
9
4
3
10
12 11
13
6
DISPLAY CONSOLE OVERVIEW
MAIN CONSOLE OVERVIEW
1. Snooze/Backlight button
2. LCD Display (see overview
on page 7)
3. Micro USB port
4. CH button
5. GRAPH/ button
6. HISTORY/ button
7. MAX/MIN button
8. BARO button
9. WIND button
10. RAIN button
11. INDEX button
12. Alert indicator
13. Wall mount notch
14. CLOCK SET button
15. SENSOR/SYNC button
16. °C/°F button
17. DATA button
18. TIME SYNC button
19. Battery compartment
20. Kickstand
21. ALARM button
22. ALERT button
23. RESET button
7
1
2
3
4
5
13
14
15
16
17
18
19
20
21
22
23
6
7
8
9
10
11
12
6
7
LCD DISPLAY OVERVIEW
1. a) Time, b) date, and c) moon phase
2. Weather forecast icons
3. Weather indexes (heat index, wind chill, Beaufort level, dew point)
4. Wind direction and wind speed
5. Temperature and humidity (outdoor)
6. Temperature and humidity (indoor)
7. Multi-function historical bar chart
8. Barometer and rainfall
9. Sunrise/sunset times
1a
2 7
1b
1c
3 8
4 9
5
6
8
WIRELESS WEATHER SENSOR OVERVIEW
MAIN DEVICE
1. Rain collector
2. Level
3. Antenna
4. Wind cups (anemometer)
5. Mounting pole
6. Sensor casing
7. Wind vane
8. Mounting base
9. Mounting clamp
10. Red LED indicator
11. RESET button
12. Battery compartment
13. Mounting clamp
screws
1
4
2
6
3
710
11
12
5
13
8
9
9
RAIN GAUGE
TEMPERATURE AND HUMIDITY SENSOR
WIND SENSOR
1. Rain collector
2. Tipping bucket
3. Rain sensor
4. Drain holes
1. Sensor shield
2. Temperature and
humidity sensor
1. Wind cups (anemometer)
2. Wind vane
1
1
1
2
2
2
3 4
10
WIRELESS WEATHER SENSOR SETUP
INSTALL BATTERIES
1. Unscrew the door to the battery compartment on the underside of the main sensor unit.
2. Insert three (3) new AA alkaline batteries, making sure the polarities match up with the markings
inside the compartment.
3. Replace the battery door, ensuring the watertight O-ring is properly aligned. This maintains the
water-resistant seal.
4. Replace the battery screw, making sure it is tightly fastened down. The red LED should begin
ashing every 12 seconds.
