LIVARNO LUX 102618 Technical specifications
IAN 102618
LED GLASS SHELF LIGHTING
LED-GLASBODENBELEUCHTUNG
Montage-, Bedienungs- und Sicherheitshinweise
LED-GLASHYLDEBELYSNING
Monterings-, betjenings- og sikkerhedshenvisninger
LED-BELYSNING FÖR
GLASHYLLPLAN
Monterings-, bruks- och säkerhetsanvisningar
LED GLASS SHELF LIGHTING
Assembly, operating and safety instructions
LED-VALO LASIHYLLYIHIN
Asennus-, käyttö- ja turvallisuusohjeet
ÉCLAIRAGE LED POUR
FOND EN VERRE
Instructions de montage, d‘utilisation et
consignes de sécurité
LED-GLASPLAATVERLICHTING
Montage-, bedienings- en veiligheidsinstructies
GB/IE Assembly, operating and safety instructions Page 3
FI Asennus-, käyttö- ja turvallisuusohjeet Sivu 16
SE Monterings-, bruks- och säkerhetsanvisningar Sidan 30
DK Monterings-, betjenings- og sikkerhedshenvisninger Side 43
FR/BE Instructions de montage, d‘utilisation et
consignes de sécurité Page 56
NL/BE Montage-, bedienings- en veiligheidsinstructies Pagina 70
DE/AT/CH Montage-, Bedienungs- und Sicherheitshinweise Seite 84
3GB/IE
Intended use......................................................Page 4
Parts description ............................................Page 4
Technical data...................................................Page 5
Scope of delivery...........................................Page 6
Safety notes.......................................................Page 6
Safety notice concerning batteries..........................Page 8
Safety advice for installation...................................Page 9
Before initial use
Mounting ..................................................................Page 10
Preparing the product for use
Switching the lamp on/off......................................Page 11
Controlling the light effects with the
remote control ..........................................................Page 11
Changing the battery.................................Page 13
Cleaning and Care........................................Page 13
Disposal.................................................................Page 13
Warranty..............................................................Page 15
4 GB/IE
LED Glass shelf lighting
Intended use
This product is suitable for providing decorative illumination
in indoor use. It is indended for clipping onto glass shelfs with
a thickness approx. 5–8mm. This product is intended for use
in private, domestic environments only and not for commercial
purposes.
Not suitable for ordinary lighting in household
room illumination.
Parts description
1LED driver
2Plug-in mains adapter with connection lead
3Double-sided adhesive tape
4Connector box
5Metal clip with LEDs
6Remote control
7Screw
5GB/IE
8Battery (type: CR 2025, 3 V )
9Battery drawer
Technical data
LED Glass shelf lighting
Operating voltage: 12V , 4x max. 0.5 W
Nominal capacity: max. 0.5W per clip (Note: The
bulbs cannot be replaced.)
Protection category:
TÜV/GS tested
Mains adapter
Primary rated voltage: 220–240V∼, 50 Hz
Secondary rated voltage: 12V , 0.5A
Protection category:
Model No. SBA-RCRGB120518
Remote control
Battery: 3V , type CR 2025
Max. range: ca. 6–8m
6 GB/IE
Scope of delivery
4 Metal clips with LEDs
1 LED driver with connector box
1 Plug-in mains adapter
1 Remote control
1 Battery (already installed)
2 Screws
2 Pieces of double-sided adhesive tape
1 Set of operating instructions
Safety notes
Before using the product, please familiarise yourself with all of
the safety information and instructions for use. When passing
this product on to others, please also include all the documents.
RISK OF FATAL INJURY!
During installation keep children away from the
area in which you are working. A large number
of screws and other small parts are included with delivery.
These may prove life-threatening if swallowed or inhaled.
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
7GB/IE
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appli-
ance. Cleaning and user maintenance shall not be made
by children without supervision.
WARNING: The extremely high speed of the light
change during the colour change effect can under cer-
tain circumstances result in visual impairment of children or
predisposed persons (e.g. by mental illness).
Avoid the danger of death
from electric shock:
Before use, ensure that the available mains voltage is the
same as the required operating voltage for the device
(220–240V∼, 50Hz).
Always check the product for damage before connecting
it to the power supply.
Never use the product if you find it damaged in any way.
This product does not contain any parts that can be ser-
viced by the user. The LEDs cannot be replaced.
Protect the product from sharp edges, mechanical stress
and hot surfaces.
8 GB/IE
Safety notice concerning
batteries
DANGER TO LIFE!
Batteries are not intended for children. If accidentally
swallowed seek immediate medical attention.
CAUTION!
EXPLOSION HAZARD!
Never recharge non-rechargeable batteries and do not
short-circuit and/ or open any batteries.
Never throw batteries into fire or water.
Do not exert mechanical loads to batteries.
If you do not observe these instructions, the battery could
be discharged beyond the cut-off voltage. This will then
pose a risk of leaking. If a battery has leaked, please
remove it instantly from the appliance to avoid damage.
Avoid contact with the skin, eyes and mucous membranes.
In the event of contact with battery acid, thoroughly flush
the affected area with clean water and seek immediate
medical attention.
Avoid extreme conditions and temperatures which may
impact batteries, e.g. on radiators.
9GB/IE
Remove the battery from the device if it is not going to be
used for a prolonged period.
Use only the recommended battery type!
When inserting the battery ensure the correct polarity!
This is shown in the battery compartment.
If necessary, clean the batteries and device contacts
before inserting batteries.
Promptly remove drained batteries from the product.
Safety advice for installation
Do not use any sharp and/or pointed objects, such as
wire, nails or clamps, to fasten the product in place.
The plug must be plugged into an easily accessible
socket, to ensure the plug can be unplugged easily in an
emergency.
The luminaire is not suitable for mounting on tubular
material.
10 GB/IE
Before initial use
Mounting
First install all the separate components of the light as
shown in Figure A.
Note: You can fit the LED driver 1of the light for glass
edge lighting using either the screws 7or using the
double-sided adhesive tape 3.
If you choose installation using double-sided adhesive
tape, please remove the protective foil from the back first
and stick it to the intended area, pressing firmly.
Make sure that the surface is clean, dry, smooth and free
of grease.
Insert the short edge of the metal clip with LED 5under
the glass and twist it to slip it onto the glass (see Fig. B).
Carefully move the metal clip with LED all the way onto
the glass.
Note: Always make sure that the LED touches the edge
of the glass, this might otherwise affect the lighting
effects.
The battery of the remote control 6is already inserted.
Remove the insulating stripes from the battery compart-
ment before first use.
