Linksys WRT54GS Operation manual

Model No.

Product Data

Wireless

WRT54GS

The Wireless-G Networking Solution with

SpeedBooster Performance Enhancement

Internet-sharing

Router, 4-port Switch,

and performance

enhanced Wireless-G

(802.11g) Access

Point

High security: Industry-

leading Parental Control

capability, 128-bit wireless

encryption, powerful SPI

firewall

Shares a single Internet

connection and other

resources with Ethernet

wired, Wireless-G, -B,

and SpeedBooster

devices

New SpeedBooster

technology increases

wireless network per-

formance by up to

35%

The Wireless-G Broadband Router with SpeedBooster is

really three devices in one box. First, there's the Wireless

Access Point, which lets you connect Wireless-G, Wireless-B,

and other performance-enhanced SpeedBooster devices

to the network. There's also a built-in 4-port full-duplex 10/

100 Switch to connect your wired-Ethernet devices

together. Finally, the Router function ties it all together and

lets your whole network share a high-speed cable or DSL

Internet connection.

The Wireless-G Broadband Router with SpeedBooster

incorporates the next generation of Wireless-G (802.11g)

networking. SpeedBooster technology is a compatible

add-on to standard Wireless-G, which increases "real-world"

wireless network performance by up to 35%. Unlike other

speed-enhancing technologies, SpeedBooster is fully

Broadband Router

Wireless-G

with SpeedBooster

802.11 compliant, and a "good neighbor" to other wireless

devices and technologies, using a single 2.4GHz channel as

specified by the official wireless standard. And, unlike other

technologies, with SpeedBooster you'll see an overall speed

improvement even when running a mixed network of

SpeedBooster and regular Wireless-G devices.

To protect your data and privacy, the Router can protect all

wireless transmissions with 128-bit encryption. The Router can

serve as a DHCP Server, has a powerful SPI firewall to protect

your PCs against intruders and most known Internet attacks,

and supports VPN pass-through. Configuration is a snap with

the web browser-based configuration utility.

The Router also enables the new Linksys Parental Control

Service,* which makes it easy for you to keep your family safe

on the Internet. First, set individual profiles for time-of-day and

day-of-week access restrictions. Then, choosing from 16

different web content categories, you control what each family

member is allowed to see. E-mail and instant messaging filters

let you decide who can send messages to, and receive

messages from, your family. View on-line individualized activity

reports anytime. A free trial of the Service is included with the

Router.

With the Linksys Wireless-G Broadband Router with

SpeedBooster at the center of your home or office network,

you can share a high-speed Internet connection, files, printers,

and multi-player games with the flexibility, speed, and security

you need!

* Parental Control available to US and Canada customers only.

Wireless-G Broadband Router with SpeedBooster

Model No.

Product Data

Model No.

Linksys

A Division of Cisco Systems, Inc.

18582 Teller Avenue

Irvine, CA 92612 USA

E-mail: [email protected]

[email protected]

Web: http://www.linksys.com

Linksys products are available in more than 50

countries, supported by 12 Linksys Regional Offices

throughout the world. For a complete list of local

Linksys Sales and Technical Support contacts, visit

our Worldwide Web Site at www.linksys.com.

WRT54GS

Package Contents

• Wireless-G Broadband Router with SpeedBooster

• Setup CD-ROM with Symantec Internet Security

•UserGuideonCD-ROM

• Power Adapter

• Ethernet Network Cable

• Quick Installation for Router

• Quick Installation for Parental Control Service

• Parental Control Service Brochure

• Registration Card

Wireless-G

Minimum Requirements

• 200 MHz or faster processor

• 64 MB of RAM

• Internet Explorer 5.5 or Netscape

Navigator 6.1 or higher for web-

based configuration

• Windows 98SE, Me, 2000, or XP

•NetworkAdapter

Specifications

Standards IEEE 802.3, IEEE 802.3u, IEEE 802.11g, IEEE

802.11b

Channels 11 Channels (US, Canada)

13 Channels (Europe)

Ports One 10/100 RJ-45 Port, Four 10/100 RJ-45

Switched Ports

Buttons Power Port, Reset Button

Cabling Type UTP CAT 5

LEDs Power, DMZ, WLAN, LAN (1, 2, 3, 4), Internet

Security Features Stateful Packet Inspection (SPI) Firewall,

Internet Policy, Parental Control

Wireless Security TKIP, AES, 802.1x, WEP, Wireless MAC Filtering

Environmental

Dimensions 7.32" x 1.89" x 7.87"

W x H x D (186 mm x 48 mm x 200 mm)

Unit Weight 17 oz. (0.482 kg)

Power 12V 1A DC

Certifications FCC, IC-03, CE

Operating Temp. 32ºF to 104ºF (0ºC to 40ºC)

Storage Temp. -4ºF to 158ºF (-20ºC to 70ºC)

Operating Humidity 10% to 85% Non-Condensing

Storage Humidity 5% to 90% Non-Condensing

WRT54GS-DS-40225NC-BW

Specifications are subject to change without notice. Linksys is a registered trademark or trademark of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2004

Broadband Router with SpeedBooster

Features

• Complies with 802.11g and

802.11b (2.4GHz) Standards

• SpeedBooster technology

increases wireless perfor-

mance by up to 35%

• Enhanced Internet Security

Management Functions

including Internet Access Poli-

cies with Time Schedules

• All LAN Ports Support Auto-

Crossover (MDI/MDI-X) - No

Need for Crossover Cables

• Free technical support—24

hours a day, 7 days a week,

toll-free US calls

• 3-year limited warranty
