Linksys WRT3200ACM Owner's manual

HARDWARE INFORMATION

1. What is the Linksys WRT3200ACM AC3200 MU-MIMO Gigabit Wi-Fi Router?

The Linksys WRT3200ACM AC3200 MU-MIMO Gigabit Wi-Fi Router is the latest Wireless-AC

router from Linksys designed with powerful enterprise-grade hardware and flexible software options

for savvy customization. Built with Beamforming and MU-MIMO technology, this Smart Wi-Fi

concurrent dual-band 4 x 4 gigabit router delivers a maximum speed of 600 Mbps on the 2.4 GHz

band and up to 2.6 Gbps on the 5 GHz band. For more information about the product features and

specification of the Linksys WRT3200ACM, click here.

2. What are the parts of the Linksys WRT3200ACM?

The Linksys WRT3200ACM has the following parts:

Ports - Four (4) Ethernet, one (1) Internet, one (1) USB 3.0, one (1) combo USB 2.0

/ eSATA port, and one (1) power connector

LEDs –Power, Internet, 2.4 GHz, 5 GHz, eSATA, USB 1, USB 2 (Primary and Secondary

LEDs), Ethernet 1 - 4 (Primary and Secondary LEDs), and Wi-Fi Protected Setup™ (WPS)

Buttons –Reset, WPS, and Power button

Antennas –Four (4) external dipole adjustable antennas (detachable)

3. What do the LEDs on the Linksys WRT3200ACM indicate?

The LEDs indicate the different status and activities on your router. For a detailed description on the

different Linksys WRT3200ACM LEDs, click here.

4. What is the warranty period of the Linksys WRT3200ACM?

The warranty period is dependent on the country of purchase. For more information about your

device’s warranty, click here.

5. Where can I find the router’s serial number?

The router’s serial number is printed on the sticker located underneath the device. You can also

locate this through the router's web-based setup page by clicking on Troubleshooting > Status >

Report.

6. What USB standards does the Linksys WRT3200ACM support?

The Linksys WRT3200ACM has one (1) USB 2.0 / eSATA port and one (1) USB 3.0 port which is

also backward-compatible with older versions.

7. What is the recommended antenna position for the Linksys WRT3200ACM?

For Single-story homes, the recommended antenna position should be that all external antennas are in

upward position. For Multi-story homes, you can do any of the following:

a. Rear antennas straight-up, side antennas angled outwards (away from the router) 45°.

b. Side antennas straight-up, rear antennas angled outwards (away from each other) 45°.

For more information and image reference, click here.

8. What is the Combo USB 2.0 / eSATA port on my Linksys WRT3200ACM, and how does it

work?

The Combo USB 2.0 / eSATA port on the Linksys WRT3200ACM allows you to connect a USB 2.0

device or an eSATA drive to the network.

NOTE: Only one (1) device can be connected at a time.

9. What is the Network Map feature of my Linksys WRT3200ACM and how can I use it?

The Network Map feature of your Linksys WRT3200ACM allows you to manage and monitor your

devices’ connection to the network. To know more about this and how you can use it, click the links

below:

Overview of the Network Map Tool on your Linksys Smart Wi-Fi Router

Managing devices in the network using the Network Map Tool of the Linksys Smart Wi-Fi

10. Can I wall-mount the Linksys WRT3200ACM?

Yes. For instructions on how to wall-mount the Linksys WRT3200ACM, click here.

11. Is the Linksys WRT3200ACM stackable?

Yes, the Linksys WRT3200ACM is stackable but make sure that it is stacked on top of other

stackable devices. Do not stack any other devices on top of the Linksys WRT3200ACM to prevent

blocking of ventilation of the router.

12. Does Linksys WRT3200ACM support Open Source?

Yes. The Linksys WRT3200ACM is an Open Source Ready router. With this, the Open Source

community's demand for Linksys router source code is met. The base source code is made

available for coders to tweak their own firmware. However, Linksys will only support the official

firmware. Since only the base code is available, the final consumer code would have its own

security encoding, which makes it safe for daily use.

SETUP & INSTALLATION

1. What are the product requirements of the Linksys WRT3200ACM?

Browser requirements:

Latest version of Chrome™, Firefox®, Safari® (for Mac® or iPad®), Microsoft Edge or

Internet Explorer® 8 or newer

Latest Adobe Flash® Player

Operating system requirements (for printer utility):

Windows® 10, Windows® 8 / 8.1, Windows® 7, Windows Vista® SP1, Windows® XP SP3

Yosemite 10.10, Mavericks 10.9, Mountain Lion 10.8, Lion 10.7, Snow Leopard 10.6.1 or

later, OS X® Leopard 10.5.8 or later

2. What are the default IP Address and Password of the Linksys WRT3200ACM?

The default IP Address for this router is 192.168.1.1, and admin is the default Password.

3. How do I set up the Linksys WRT3200ACM?

Setting up the Linksys WRT3200ACM is made fast and easy because of its CD-less setup. Now you

can run the setup from a web browser even if the router does not initially have an Internet

connection and is on factory settings. To learn how to set up the Linksys WRT3200ACM, click here.

NOTE: Manual setup of the Linksys WRT3200ACM can be done through the web-based setup

page. On your setup home page, tick the I want to skip Setup and configure my router

manually option and click Next.

4. Will I be able to run the setup on a hardwired computer even though my wireless adapter is

disabled?

Yes, simply connect the router to the computer using an Ethernet cable, open a web browser, and

start the setup process.

5. Can I configure my 5 GHz network during setup?

One wireless network name is configured for both 2.4 GHz and the 5 GHz. When the setup is

complete, you may change the network name of the 5 GHz by logging in to the web-based setup

page. To learn how you can set up the Linksys WRT3200ACM, click here.

6. Can I configure my Linksys WRT3200ACM as a Wireless Bridge or Wireless Repeater?

Yes. The Linksys WRT3200ACM can be configured as a Wireless Bridge or Repeater.

A Wireless Bridge mode uses one (1) of the Linksys WRT3200ACM’s wireless network bands (2.4

GHz or 5 GHz) to connect to your upstream router. The Linksys WRT3200ACM then extends the

upstream router’s signal to the second wireless band and any wired connection. To learn more

about how to configure the Linksys WRT3200ACM as a wireless bridge, click here.

The Wireless Repeater mode uses one (1) of the Linksys WRT3200ACM’s wireless network bands

to connect to your upstream router. That band then splits the bandwidth from the upstream router to

extend the network to both wireless bands and wired connections on the Linksys

WRT3200ACM. You can click here for instructions on how to do this.

7. Can I install external antennas to my Linksys WRT3200ACM to get better wireless range

and coverage?

The Linksys WRT3200ACM alone is a high-performance router that could provide you better

wireless range and coverage. However, you can upgrade its external antennas for enhanced

performance by installing the WRT High Gain Antennas, WRT004ANT. To learn more about it, click

here.

FIRMWARE UPGRADE

1. How do I upgrade the firmware on the Linksys WRT3200ACM?

the Automatic checkbox. This will automatically upgrade the Linksys WRT3200ACM if there is a

new firmware available. You may also click the Check for Updates button to check if there is a new

firmware available.

NOTE: If you wish to upgrade the Linksys WRT3200ACM manually, you can click the Choose

File button. However, you first need to download the appropriate firmware from the Linksys

WRT3200ACM Downloads page.

WIRELESS CONNECTION & SECURITY

1. What wireless security modes does the Linksys WRT3200ACM support?

The Linksys WRT3200ACM supports only WPA2 Personal and WPA2 Enterprise.

2. Which wireless connection standards and frequencies are supported by the Linksys

WRT3200ACM?

The Linksys WRT3200ACM is compatible with 802.11ac, 802.11g, 802.11n and 802.11a. It

supports the 2.4 GHz and 5 GHz frequencies.

3. What Channel Widths does the Linksys WRT3200ACM support?

It supports 20 MHz / 40 MHz / 80 MHz and 160 MHz.

4. What Channel Width should I set on the Linksys WRT3200ACM?

It is recommended to keep the Channel Width to Auto for both bands. The Linksys WRT3200ACM

will automatically select the channel with the least amount of interference if you leave the settings to

Auto.

5. How do I connect a wireless device to the wireless network of the Linksys WRT3200ACM?

To connect your wireless device to the network, follow the steps below:

Step 1:

Go to your device settings or adapter settings if you are using a laptop, and enable Wi-Fi.

Step 2:

Scan through the list of available wireless networks, and select the wireless network name (SSID) of

your router.

Step 3:

Enter your wireless network password, and select Connect or Join.

6. Where can I see the default wireless network name (SSID) and passphrase of the Linksys

WRT3200ACM?

The default SSID and passphrase can be located at the bottom of the Linksys WRT3200ACM.

7. Can I change the default wireless settings during setup?

Yes, you will have the option to customize the SSID and the passphrase.

8. Does the Linksys WRT3200ACM support simultaneous dual-band (2.4 GHz and 5 GHz)

connection?

Yes.

9. What is 802.11ac, and what kinds of speed does it support?

The 802.11ac technology works on the 5 GHz band. The Linksys WRT3200ACM can have a speed

of up to 2600 Mbps wirelessly when matched with an 802.11ac adapter and when the Channel

Width in the router is set to Auto.

10. Which wireless band should be used to achieve a speed of up to 2600 Mbps?

Connect to the 5 GHz band to achieve a speed of up to 2600 Mbps.

11. How many Guest networks can I set up on my Linksys WRT3200ACM?

The Linksys WRT3200ACM allows you to have two (2) Guest networks both for 2.4 GHz and 5 GHz

bands. With these, your visitors at home can access the Internet but not the local network (e.g.,

shared storage devices, printer access).

NOTE: The router supports up to a total of 50 guests.

12. What is DFS, and does the Linksys WRT3200ACM support it?

Yes. The Dynamic Frequency Selection (DFS) is supported on the 5 GHz band of the Linksys

WRT3200ACM. DFS is a spectrum-sharing mechanism that allows wireless LANs (WLANs) to

coexist with radar systems. It automatically selects a frequency that does not interfere with certain

radar systems while operating in the 5 GHz band.

13. Which channels on the 5 GHz of the Linksys WRT3200ACM support DFS?

Channels 52-64 and as well as channels 100-140 on the 5 GHz band are the DFS channels.

14. Why can't my wireless client detect the 5 GHz network name after I configured the router’s

5 GHz band to use a fixed channel?

If you have configured your router to use a fixed channel other than Auto and your wireless device

does not detect the 5 GHz network name, it’s possible your wireless device does not support DFS

channels. You can contact the manufacturer of your device to confirm if your wireless device

supports DFS. You can also change the channel on the router to use a non-DFS channel or

Auto. Channels 52-64 and Channels 100-140 are DFS channels.

NOTE: In addition, your wireless client must be a Dual-Band client in order to connect to the 5 GHz

band.

15. My wireless clients connected to the 5 GHz network are disconnecting and reconnecting

usually lasting about one (1) minute of disconnect time. Why is this happening?

If you have configured the 5 GHz wireless network to use a fixed wireless channel, other than Auto,

you have selected a DFS channel. When your router is configured to use a fixed DFS channel, the

router needs to adjust to a new channel if a radar system is detected as this can cause interference

with the radar. During this one minute disconnection, the router will scan for the next best channel to

use and the 5 GHz wireless clients will disconnect for one (1) minute and reconnect again once the

router has selected another channel to prevent interference with the radar system. If you want to

change this, simply choose a non-DFS channel or set it to Auto.

NOTE: DFS channels are Channels 52-64 and Channels 100-140, you can use any other channels

beside these.

ADVANCED CONFIGURATION

1. What is a media server, and how does it work?

It allows Digital Living Network Alliance (DLNA®) certified devices including digital media players,

gaming consoles, and digital picture frames to access video, music, and pictures that are stored on a

USB hard drive that is connected to the Linksys WRT3200ACM. Its Storage File System supports

FAT, HFS+ and NTFS.

2. Can I connect a USB hub to the USB port of the Linksys WRT3200ACM to use multiple

devices?

No. You cannot connect a USB hub to the USB port of your Linksys WRT3200ACM.

3. Does the Linksys WRT3200ACM allow VPN tunnels using IPSec, L2TP or PPTP protocols to

pass-through the router?

Yes.

4. Does the Linksys WRT3200ACM support SPI firewall?

Yes. The Linksys WRT3200ACM supports SPI firewall.

5. Does the Linksys WRT3200ACM have a Filter IDENT feature that blocks specific Internet

data types?

Yes, this feature keeps port 113 from being scanned by devices outside of your local network.

6. What is Demilitarized Zone (DMZ), and what is it used for?

The DMZ screen allows one (1) local user to be exposed to the Internet for a special-purpose

service such as Internet gaming and videoconferencing. DMZ hosting forwards all the ports at the

same time to one (1) computer. Port Forwarding is more secure because it only opens the ports you

want to open.

7. What DDNS providers does the Linksys WRT3200ACM support?

The Linksys WRT3200ACM supports Dyn.com and NO-IP.com providers.

8. What is the Wireless Scheduler feature of my Linksys WRT3200ACM and how can I use it?

The Wireless Scheduler feature of your Linksys WRT3200ACM allows you to turn OFF or ON the

wireless networks, including the Guest networks at your preferred time. To know more about this,

click here.

TROUBLESHOOTING

1. How can I reset the Linksys WRT3200ACM to factory defaults?

There are two (2) ways to reset the Linksys WRT3200ACM to factory defaults:

Hardware Reset –Press and hold the Reset button at the back panel of the Linksys

WRT3200ACM for about 10 seconds then release.

Software Reset –Log in to your Linksys Smart Wi-Fi Account. Under Router Settings,

click Troubleshooting > Diagnostics. Click Reset under Factory reset.

2. I have reset the Linksys WRT3200ACM and now I can’t launch the setup page. What do I

do?

You can try the following troubleshooting steps:

Step 1:

Enter “myrouter.local” or “192.168.1.1” in a web browser.

Step 2:

If your computer has a static IP Address, make sure it has valid DNS numbers. If not, set the

computer to obtain an IP Address automatically.

Step 3:

Try again then, if needed, reassign a static IP Address back to the computer.

3. What should I do if I can't connect to the Internet wirelessly, and my network name is not

listed in the Available Networks?

Try to perform the following steps to resolve the issue:

Verify that your router is ON, and the Power LED is solidly lit.

If you are far from the router, you might try moving closer to make sure that your device is

within the wireless network range.

Using a computer attached to the router via a network cable, open the router's web-based

setup page by entering “myrouter.local” or “http://192.168.1.1”. Go to Wireless > Broadcast

SSID and make sure that it is set to Yes for both the 2.4 GHz and 5 GHz bands.

4. What should I do when my wireless network performance is slow, inconsistent, suffering

from weak signal, or having difficulty maintaining a VPN connection?

Wireless technology uses radio frequency as a medium to connect devices. This means that

connectivity and the throughput performance between devices decreases when the distance

between devices increases.

Other factors that will cause signal degradation are the following:

Obstructions such as walls, fixtures, furniture and metal appliances

Wireless signal interference caused by other wireless networks using the same frequency,

baby monitors, microwave ovens, etc.

NOTE: Connection speed may decrease as you move farther away from the router.

Troubleshooting Tips:

In order to determine if wireless issues are related to distance, it is recommended to

temporarily move the computer within 10 feet from the router if possible.

You may also change the wireless channel of your router. This will resolve issues of

wireless interference to improve the performance and reliability of your network.

5. My Parental Controls feature blocks HTTPS but returns a blank page instead of redirecting

to the Parental Controls screen. Is this a normal behavior?

Yes, for HTTPS this is by design. Website addresses starting with https:// can be blocked, but

because they have encryption, Linksys Smart Wi-Fi cannot redirect you. Instead of a page telling

you the address has been blocked, you will see a browser error page.

Other manuals for WRT3200ACM

Table of contents

Popular Wireless Router manuals by other brands

Milesight

Milesight UG67 user guide

Airlogic

Airlogic AirSync Class 1 Features

Samsung

Samsung WCH730B user manual

TELEFONICA

TELEFONICA USB Adapter quick start guide

NETGEAR

NETGEAR PowerLINE WiFi 1000 Series quick start

Askey

Askey RAC2V1K user manual

Alloy

Alloy WLF2454AP-S user guide

TP-Link

TP-Link TL-WR542G user guide

NETGEAR

NETGEAR WNR2000v4 user manual

Hama

Hama 53120 Operating instruction

Intellinet

Intellinet 524582 user manual

Asus

Asus RT-N10P user guide

D-Link

D-Link DIR-506L Quick installation guide

Sapido

Sapido GR297n user manual

Asus

Asus DSL-N55U user guide

AMTC

AMTC WR7502 user guide

Compaq

Compaq CP-2W - iPAQ Connection Point manual

SMC Networks

SMC Networks WBR14-N2 FICHE user guide
