Linksys EtherFast BEFW11P1 User manual

EtherFast®Wireless Access

Point + Cable/DSL Router

w/PrintServer

he EtherFast Wireless Access Point + Cable/DSL

Router w/PrintServer provides the ideal solution for

connecting your wireless network to a high-speed

broadband Internet connection and a 10/100 Fast Ethernet

backbone. Configurable as a DHCP server for your existing

network, the EtherFast Wireless Access Point + Cable/DSL

Router w/PrintServer acts as the only externally recognized

Internet gatewayonyourlocal area network(LAN) andserve

as an Internet firewall against unwanted outside intruders.

The Router can also be configured to filter internal users'

access to the Internet.

The EtherFast Wireless Access Point + Cable/DSL Routers'

high-powered antennas provide an operating range of up to

500 meters, providing seamless roaming throughout your

wireless LAN infrastructure,and its advanced user authenti-

cation feature ensures a high level of network security. The

EtherFast Wireless Access Point + Cable/DSL Router’s easy

to install and easy to use-Windows-based diagnostics and

statistic tools put you in control of your network.

• Interoperable with IEEE 802.11b (DSSS)

2.4GHz-Compliant Equipment

• Provides Roaming, Best Access Point Selection, Load

Balancing, and Network Traffic Filtering

• Long Operating Range Supports 150m (Indoors) and

500m (Outdoors)

• 40-Bit WEP Encryption Protocol

• Compatible with Virtually All Major Operating Systems

• Connects to a Broadband Modem and a 10/100 Ethernet

Backbone

• Configurable Through Your Networked PC's Web

Browser

• Supports IPSec Pass-Thru and PPTP

• Acts as a DHCP Server and a Print Server for Your

Existing Network

• Administrators Can Block Specific Internal Users'

Internet Access with Filtering

• Free Technical Support—24 Hours a Day,

7 Days a Week for North America Only

• 1-Year Limited Warranty

• Fully Compatible with IEEE 802.11b Standard

and Supports a High Data Rate Up to 11 Mbps

• Build a Wireless Broadband Network in Your

Home or Small Office with Just One IP Address

• Create a Firewall to Protect Your PCs From

Outside Intruders

• Auto Fallback Data Rate for Long-Distance

Communication and Noisy Environments

• Free Technical Support—24 Hours a Day,

7 Days a Week for North America Only

• 1-Year Limited Warranty

EEtthheerrFFaasstt®®WWiirreelleessssAAcccceessssPPooiinntt++

CCaabbllee//DDSSLLRRoouutteerrww//PPrriinnttSSeerrvveerr

((BBEEFFWW1111PP11))

ConnectYour Wireless Network to Your

High-Speed Broadband Pipeline

Features

Benefits

BBrrooaaddbbaannddWWiitthhNNoo

CCaabblleessAAttttaacchheedd

Package ContentsSpecifications

Model Number: BEFW11P1

Standards: IEEE 802.3 (10BaseT), IEEE 802.3u

(100BaseTX), IEEE 802.11b (Wireless)

Protocol: CSMA/CD

Ports:

WAN: One 10Base-T RJ-45 Port for Cable/DSL Modem

LAN: One Shared Uplink Port

Printer: One Parallel Port

Cabling Type: UTP Category 5 or better, Standard Printer Cable

Operating Range Indoors: 50M (164 ft.) @ 11 Mbps

(Wireless): 80M (262 ft.) @ 5.5 Mbps

120M (393 ft.) @ 2 Mbps

150M (492 ft.) @ 1 Mbps

Outdoors: 250M (820 ft.) @ 11 Mbps

350M (1148 ft.) @ 5.5 Mbps

400M (1312 ft.) @ 2 Mbps

500M (1640 ft.) @ 1 Mbps

LEDs: Power, Diag,WAN

LAN: 10/100

WLAN,Act

Printer:Err/Act

Environmental

Dimensions: 7.44” x 6.16”X 2.64” (186mm x 154mm x 48mm)

Unit Weight: 17.5 oz. (0.5 Kg)

Power: External, 5V DC, 3A

Certifications: FCC Class B, CE Mark Commercial

Operating Temp: 0ºC to 40ºC (32ºF to 104ºF)

Storage Temp: -20ºC to 70ºC (-4ºF to 158ºF)

Operating Humidity: 10% to 85%, Non-Condensing

Storage Humidity: 5% to 90%, Non-Condensing

EtherFast®Wireless Access Point +

Cable/DSL Router w/PrintServer

• One EtherFast Wireless Access Point +

Cable/DSL Router w/PrintServer

• One AC Power Adapter

• One User Guide and Registration Card

Model Number: BEFW11P1

Linksys

17401 Armstrong Ave.

Irvine, CA 92614 USA

Information (800) 546-5797

Technical Support (800) 326-7114

(949) 261-1288

Fax (949) 261-8868

World Wide Web http://www.linksys.com

Email [email protected]

[email protected]

China

Tech Support (10) 6432 1920

Sales (10) 6432 1923

Fax (10) 6437 6891

Japan

Telephone (03) 5259-5139

Fax (03) 5259-5117

Philippines

Telephone (632) 638 5580

Fax (632) 635 6772

Singapore

Telephone 552-8998

Fax 552-1024

Thailand

Telephone 717-0770

Fax 717-0738

United Kingdom

Tech Support 0870 7393939

Sales 01245 352403

Fax 0870 7393938

01030
