Lincoln Electric FLEXCUT 200 CE User manual

Operator’s Manual

www.lincolnelectric.com/register

Authorized Service and Distributor Locator:

www.lincolnelectric.com/locator

IM10485-A | Issue D ate Jul-22

For use with machines having Code Numbers:

12829

Save for future reference

Date Purchased

Code: (ex: 10859)

Serial: (ex: U1060512345)

FlexCut

200 CE

THANK YOU FOR SELECTING

A QUALITY PRODUCT BY

LINCOLN ELECTRIC.

PLEASE EXAMINE CARTON AND EQUIPMENT FOR

DAMAGE IMMEDIATELY

When this equipment is shipped, title passes to the purchaser

upon receipt by the carrier. Consequently, claims for material

damaged in shipment must be made by the purchaser against the

transportation company at the time the shipment is received.

SAFETY DEPENDS ON YOU

Lincoln arc welding and cutting equipment is designed and built

with safety in mind. However, your overall safety can be increased

by proper installation ... and thoughtful operation on your part.

DO NOT INSTALL, OPERATE OR REPAIR THIS EQUIPMENT

WITHOUT READING THIS MANUAL AND THE SAFETY

PRECAUTIONS CONTAINED THROUGHOUT. And, most importantly,

think before you act and be careful.

This statement appears where the information must be followed

exactly to avoid serious personal injury or loss of life.

This statement appears where the information must be followed

to avoid minor personal injury or damage to this equipment.

KEEP YOUR HEAD OUT OF THE FUMES.

DON’T get too close to the arc.

Use corrective lenses if necessary

to stay a reasonable distance

away from the arc.

READ and obey the Safety Data

Sheet (SDS) and the warning label

that appears on all containers of

welding materials.

USE ENOUGH VENTILATION or

exhaust at the arc, or both, to

keep the fumes and gases from

your breathing zone and the general area.

IN A LARGE ROOM OR OUTDOORS, natural ventilation may be

adequate if you keep your head out of the fumes (See below).

USE NATURAL DRAFTS or fans to keep the fumes away

from your face.

If you develop unusual symptoms, see your supervisor.

Perhaps the welding atmosphere and ventilation system

should be checked.

WEAR CORRECT EYE, EAR &

BODY PROTECTION

PROTECT your eyes and face with welding helmet

properly fitted and with proper grade of filter plate

(See ANSI Z49.1).

PROTECT your body from welding spatter and arc

flash with protective clothing including woolen

clothing, flame-proof apron and gloves, leather

leggings, and high boots.

PROTECT others from splatter, flash, and glare

with protective screens or barriers.

IN SOME AREAS, protection from noise may be appropriate.

BE SURE protective equipment is in good condition.

Also, wear safety glasses in work area

AT ALL TIMES.

SPECIAL SITUATIONS

DO NOT WELD OR CUT containers or materials which previously

had been in contact with hazardous substances unless they are

properly cleaned. This is extremely dangerous.

DO NOT WELD OR CUT painted or plated parts unless special

precautions with ventilation have been taken. They can release

highly toxic fumes or gases.

Additional precautionary measures

PROTECT compressed gas cylinders from excessive heat,

mechanical shocks, and arcs; fasten cylinders so they cannot fall.

BE SURE cylinders are never grounded or part of an

electrical circuit.

REMOVE all potential fire hazards from welding area.

ALWAYS HAVE FIRE FIGHTING EQUIPMENT READY FOR

IMMEDIATE USE AND KNOW HOW TO USE IT.

WARNING

CAUTION

Safety 01 of 04 - 10/08/2021

SECTION A:

WARNINGS

CALIFORNIA PROPOSITION 65 WARNINGS

WARNING: Breathing diesel engine exhaust

exposes you to chemicals known to the State

of California to cause cancer and birth defects,

or other reproductive harm.

• Always start and operate the engine in a

well-ventilated area.

• If in an exposed area, vent the exhaust to the outside.

• Do not modify or tamper with the exhaust system.

• Do not idle the engine except as necessary.

For more information go to

www.P65 warnings.ca.gov/diesel

WARNING: This product, when usedfor welding or

cutting, produces fumes or gases which contain

chemicals known to the State ofCalifornia to cause

birth defects and, in some cases, cancer.(California

Health & Safety Code § 25249.5 et seq.)

WARNING: Cancer and Reproductive Harm

www.P65warnings.ca.gov

ARC WELDING CAN BE HAZARDOUS. PROTECT

YOURSELF AND OTHERS FROM POSSIBLE SERIOUS

INJURY OR DEATH. KEEP CHILDREN AWAY.

PACEMAKER WEARERS SHOULD CONSULT WITH

THEIR DOCTOR BEFORE OPERATING.

Read and understand the following safety highlights. For

additional safety information, it is strongly recommended

that you purchase a copy of “Safety in Welding & Cutting -

ANSI Standard Z49.1” from the American Welding Society,

P.O. Box 351040, Miami, Florida 33135 or CSA Standard

W117.2. A Free copy of “Arc Welding Safety” booklet E205

is available from the Lincoln Electric Company, 22801

St. Clair Avenue, Cleveland, Ohio 44117-1199.

BE SURE THAT ALL INSTALLATION, OPERATION,

MAINTENANCE AND REPAIR PROCEDURES ARE

PERFORMED ONLY BY QUALIFIED INDIVIDUALS.

FOR ENGINE POWERED

EQUIPMENT.

1.a. Turn the engine off before troubleshooting

and maintenance work unless the

maintenance work requires it to be running.

1.b. Operate engines in open, well-ventilated areas or vent the engine

exhaust fumes outdoors.

arc or when the engine is running. Stop the

engine and allow it to cool before refueling to

prevent spilled fuel from vaporizing on contact

tank. If fuel is spilled, wipe it up and do not start engine until

fumes have been eliminated.

1.d. Keep all equipment safety guards, covers

and devices in position and in good repair.

Keep hands, hair, clothing and tools away

from V-belts, gears, fans and all other

moving parts when starting, operating or

repairing equipment.

1.e. In some cases it may be necessary to remove safety guards to

perform required maintenance. Remove guards only when

necessary and replace them when the maintenance requiring

their removal is complete. Always use the greatest care when

working near moving parts.

1.f. Do not put your hands near the engine fan. Do not attempt to

override the governor or idler by pushing on the throttle control

rods while the engine is running.

1.g. To prevent accidentally starting gasoline engines while turning

the engine or welding generator during maintenance work,

disconnect the spark plug wires, distributor cap or magneto wire

as appropriate.

1.h. To avoid scalding, do not remove the radiator

pressure cap when the engine is hot.

ELECTRIC AND

MAGNETIC FIELDS MAY

BE DANGEROUS

causes localized Electric and Magnetic Fields (EMF).

and welding machines

welders having a pacemaker should consult their physician

before welding.

which are now not known.

2.d. All welders should use the following procedures in order to

2.d.1. Route the electrode and work cables together - Secure

them with tape when possible.

2.d.2. Never coil the electrode lead around your body.

2.d.3. Do not place your body between the electrode and work

cables. If the electrode cable is on your right side, the

work cable should also be on your right side.

2.d.4. Connect the work cable to the workpiece as close as pos-

sible to the area being welded.

2.d.5. Do not work next to welding power source.

SAFETY

Safety 02 of 04 - 10/08/2021

1.c. Do not add the fuel near an open ame welding

with hot engine parts and igniting. Do not spill fuel when lling

2.a. Electric current owing through any conductor

Welding current creates EMF elds around welding cables

2.b. EMF elds may interfere with some pacemakers, and

2.c. Exposure to EMF elds in welding may have other health effects

minimize exposure to EMF elds from the welding circuit:

1.i. Using a generator indoors CAN KILL YOU IN

MINUTES.

1.j. Generator exhaust contains carbon monoxide. This is a poison

you cannot see or smell.

1.k. NEVER use inside a home or garage,

EVEN IF doors and windows are open.

1.l. Only use OUTSIDE and far away from

windows, doors and vents.

1.m. Avoid other generator hazards. READ

MANUAL BEFORE USE.

ELECTRIC SHOCK

CAN KILL.

3.a. The electrode and work (or ground) circuits are

electrically “hot” when the welder is on. Do

not touch these “hot” parts with your bare skin or wet clothing.

Wear dry, hole-free gloves to insulate hands.

3.b. Insulate yourself from work and ground using dry insulation.

Make certain the insulation is large enough to cover your full area

of physical contact with work and ground.

In addition to the normal safety precautions, if

welding must be performed under electrically

hazardous conditions (in damp locations or while

wearing wet clothing; on metal structures such as

floors, gratings or scaffolds; when in cramped

positions such as sitting, kneeling or lying, if there

is a high risk of unavoidable or accidental contact

with the workpiece or ground) use the following

equipment:

• Semiautomatic DC Constant Voltage (Wire) Welder.

• DC Manual (Stick) Welder.

• AC Welder with Reduced Voltage Control.

3.c. In semiautomatic or automatic wire welding, the electrode,

electrode reel, welding head, nozzle or semiautomatic welding

gun are also electrically “hot”.

3.d. Always be sure the work cable makes a good electrical

connection with the metal being welded. The connection should

be as close as possible to the area being welded.

3.e. Ground the work or metal to be welded to a good electrical (earth)

ground.

3.f. Maintain the electrode holder, work clamp, welding cable and

welding machine in good, safe operating condition. Replace

damaged insulation.

3.g. Never dip the electrode in water for cooling.

3.h. Never simultaneously touch electrically “hot” parts of electrode

holders connected to two welders because voltage

between the

two can be the total of the open circuit voltage of both

welders.

3.i. When working above floor level, use a safety belt to protect

yourself from a fall should you get a shock.

3.j. Also see Items 6.c. and 8.

ARC RAYS CAN BURN.

4.a. Use a shield with the proper filter and cover plates to protect your

eyes from sparks and the rays of the arc when welding or

observing open arc welding. Headshield and filter lens should

conform to ANSI Z87. I standards.

4.b. Use suitable clothing made from durable flame-resistant material

to protect your skin and that of your helpers from the arc rays.

4.c. Protect other nearby personnel with suitable, non-flammable

screening and/or warn them not to watch the arc nor expose

themselves to the arc rays or to hot spatter or metal.

FUMES AND GASES

CAN BE DANGEROUS.

5.a. Welding may produce fumes and gases

hazardous to health. Avoid breathing these

fumes and gases. When welding, keep your head out of the fume.

Use enough ventilation and/or exhaust at the arc to keep fumes

and gases away from the breathing zone. When welding

hardfacing (see instructions on container or SDS)

or on lead or cadmium plated steel and other

metals or coatings which produce highly toxic

fumes, keep exposure as low as possible and

within applicable OSHA PEL and ACGIH TLV limits

using local exhaust or mechanical ventilation

unless exposure assessments indicate otherwise.

In confined spaces or in some circumstances,

outdoors, a respirator may also be required.

Additional precautions are also required when

welding

on galvanized steel.

5. b. The operation of welding fume control equipment is affected by

various factors including proper use and positioning of the

equipment, maintenance of the equipment and the specific

welding procedure and application involved. Worker exposure

level should be checked upon installation and periodically

thereafter to be certain it is within applicable OSHA PEL and

ACGIH TLV limits.

5.c. Do not weld in locations near chlorinated hydrocarbon vapors

coming from degreasing, cleaning or spraying operations. The

heat and rays of the arc can react with solvent vapors to form

phosgene, a highly toxic gas, and other irritating products.

5.d. Shielding gases used for arc welding can displace air and

cause

injury or death. Always use enough ventilation, especially in

confined areas, to insure breathing air is safe.

5.e. Read and understand the manufacturer’s instructions for this

equipment and the consumables to be used, including the

Safety Data Sheet (SDS) and follow your employer’s safety

practices. SDS forms are available from your welding

distributor or from the manufacturer.

5.f. Also see item 1.b.

SAFETY

Safety 03 of 04 - 10/08/2021

WELDING AND CUTTING

SPARKS CAN CAUSE

FIRE OR EXPLOSION.

6.a. Remove fire hazards from the welding area. If

this is not possible, cover them to prevent the welding sparks

from starting a fire. Remember that welding sparks and hot

materials from welding can easily go through small cracks and

openings to adjacent areas. Avoid welding near hydraulic lines.

Have a fire extinguisher readily available.

6.b. Where compressed gases are to be used at the job site, special

precautions should be used to prevent hazardous situations.

Refer to “Safety in Welding and Cutting” (ANSI Standard Z49.1)

and the operating information for the equipment being used.

6.c. When not welding, make certain no part of the electrode circuit is

touching the work or ground. Accidental contact can cause

overheating and create a fire hazard.

6.d. Do not heat, cut or weld tanks, drums or containers until the

proper steps have been taken to insure that such procedures

will not cause flammable or toxic vapors from substances inside.

They can cause an explosion even though they have been

“cleaned”. For information, purchase “Recommended Safe

Practices for the Preparation for Welding and Cutting of

Containers and Piping That Have Held Hazardous Substances”,

AWS F4.1 from the American Welding Society

(see address above).

6.e. Vent hollow castings or containers before heating, cutting or

welding. They may explode.

6.f. Sparks and spatter are thrown from the welding arc. Wear oil free

protective garments such as leather gloves, heavy shirt, cuffless

trousers, high shoes and a cap over your hair. Wear ear plugs

when welding out of position or in confined places. Always wear

safety glasses with side shields when in a welding area.

6.g. Connect the work cable to the work as close to the welding area

as practical. Work cables connected to the building framework or

other locations away from the welding area increase the

possibility of the welding current passing through lifting chains,

crane cables or other alternate circuits. This can create fire

hazards or overheat lifting chains or cables until they fail.

6.h. Also see item 1.c.

6.I. Read and follow NFPA 51B “Standard for Fire Prevention During

Welding, Cutting and Other Hot Work”, available from NFPA, 1

Batterymarch Park, PO box 9101, Quincy, MA 022690-9101.

6.j. Do not use a welding power source for pipe thawing.

CYLINDER MAY EXPLODE IF

DAMAGED.

7.a. Use only compressed gas cylinders containing

the correct shielding gas for the process used

and properly operating regulators designed for

the gas and pressure used. All hoses, fittings,

etc. should be suitable for the application and

maintained in good condition.

7.b. Always keep cylinders in an upright position securely chained to

an undercarriage or fixed support.

7.c. Cylinders should be located:

• Away from areas where they may be struck or subjected

to physical damage.

• A safe distance from arc welding or cutting operations

and any other source of heat, sparks, or flame.

7.d. Never allow the electrode, electrode holder or any other

electrically “hot” parts to touch a cylinder.

7.e. Keep your head and face away from the cylinder valve outlet

when opening the cylinder valve.

7.f. Valve protection caps should always be in place and hand tight

except when the cylinder is in use or connected for use.

7.g. Read and follow the instructions on compressed gas cylinders,

associated equipment, and CGA publication P-l, “Precautions for

Safe Handling of Compressed Gases in Cylinders,” available from

the Compressed Gas Association, 14501 George Carter Way

Chantilly, VA 20151.

FOR ELECTRICALLY

POWERED EQUIPMENT.

8.a. Turn off input power using the disconnect

switch at the fuse box before working on

the equipment.

8.b. Install equipment in accordance with the U.S. National Electrical

Code, all local codes and the manufacturer’s recommendations.

8.c. Ground the equipment in accordance with the U.S. National

Electrical Code and the manufacturer’s recommendations.

Refer to

http://www.lincolnelectric.com/safety

for additional safety information.

SAFETY

Safety 04 of 04 - 10/08/2021

ECO design information 1 ECO design information

ECO design information

The equipment has been designed in order to be compliant with the Directive 2009/125/EC and the Regulation

2019/1784/EU.

Efficiency and idle power consumption:

Name

Efficiency when max power

consumption / Idle power

consumption

Equivalent model

Flexcut 200 CE 92% / 83W (no fan or cooler) No equivalent model

The idle state is defined as the unit is ready to cut, but the output is not enabled. The cool down period after the cut is not

considered the idle state.

The value of efficiency and consumption in idle state have been measured by method and conditions defined in the

product standard EN 60974-1

Manufacturer’s name, product name, code number, product number, serial number and date of production can be read

from rating plate and serial number label.

Typical gas usage for the Flexcut equipment:

The Flexcut 200 CE uses an external Air Compressor, so there are no typical gas flow rates for this product.

ECO design information 2 ECO design information

End of life

At end of life of product, it has to be disposal for recycling in accordance with Directive 2012/19/EU (WEEE), information

about the dismantling of product and Critical Raw Material (CRM) present in the product, can be found at:

www.lincolnelectriceurope.com

Flexcut 200 CE

Item

Component

Material for recovery

CRM

Selective treatment

Enclosure and lamination

Steel

Heat sink

Aluminum

Si, 60 g

Mg, 90 g

Ti, 10 g

Capacitor

Required

External cables – not shown

Copper

Required

Output terminal, 2 total

Brass and copper

PC board, 12 total

Required

Choke

Transformer

Internal cables

Bus bars

Copper

Enclosure,

Mounting Brackets

Aluminum

Si, 16 g

Mg, 177 g

Reference P-1255, code 12829

SAFETY

General Precautions

Whereas plasma cutting has been used safely for years, it does

require certain precautions to ensure the safety of the operator

and other people around the equipment. The following safety

information must be provided to each person who will operate,

observe, perform maintenance, or work in close proximity to this

piece of equipment.

Installation, operation, and repairs made to the system should only

be performed by qualified personnel. The system makes use of

both A.C. and D.C. circuitry for operation. Fatal shock hazard does

exist. Exercise extreme caution while working on the system.

Safety decals On the power supply should not be removed.

ULTRAVIOLET RADIATION

PROTECTION

Plasma cutting produces ultraviolet radiation similar to a welding

arc. This ultraviolet radiation can cause skin and eye burns. For

this reason, it is essential that proper protection be worn. The

eyes are best protected by using safety glasses or a welding

helmet with an AWS No. 12 shade or ISO 4850 No. 13 shade,

which provides protection up to 400 amperes. All exposed skin

areas should be covered with flame-retardant clothing. The

cutting area should also be prepared in such a way that ultraviolet

light does not reflect. Walls and other surfaces should be painted

with dark colors to reduce reflected light. Protective screens or

curtains should be installed to protect additional workers in the

area from ultraviolet radiation.

NOISE PROTECTION

The system generates high noise levels while cutting. Depending

on the size of the cutting area, distance from the cutting torch,

and arc current cutting level, acceptable noise levels may be

exceeded. Proper ear protection should be used as defined by

local or national codes.

TOXIC FUME PREVENTION

Care should be taken to ensure adequate ventilation in the cutting

area. Some materials give off toxic fumes that can be harmful or

fatal to people in the vicinity of the cutting area. Also, some

solvents decompose and form harmful gases when exposed to

ultraviolet radiation. These solvents should be removed from the

area prior to cutting. Galvanized metal can produce harmful gases

during the cutting process. Ensure proper ventilation and use

breathing equipment when cutting these materials.

Certain metals coated with or containing lead, cadmium, zinc,

beryllium, and mercury produce harmful toxins. Do not cut these

metals unless all people subjected to the fumes wear proper air

breathing equipment.

ELECTRIC SHOCK PREVENTION

The system uses high open circuit voltages that can

be fatal. Extreme care should be used when

operating or performing maintenance on the system.

Only qualified personnel should service the system. Observe the

following guidelines to protect against electric shock:

• A wall-mounted disconnect switch should be installed and fused

according to local and national electrical codes. The disconnect

switch should be located as close as possible to the power

supply so it can be turned off in case of an emergency.

• The primary power cord should have a 600 volt minimum rating

in order to protect the operator. In addition, it should be sized

according to local and national electrical codes. Inspect the

primary power cord frequently. Never operate the system if the

power cord is damaged in any way.

• Make sure the primary power ground wire is connected at the

input power ground location on the power supply. Make sure

the connection is securely tightened.

• Make sure the positive output (work ground) of the power

supply is connected to a bare metal area on the cutting table. A

driven ground rod should be placed no further than five feet

from this connection. Make sure this ground point on the cutting

table is used as the star ground point for all other ground

connections.

• Inspect the torch leads frequently. Never use the system if the

leads are damaged in any way.

• Do not stand in wet, damp areas when operating or performing

maintenance on the system.

• Wear insulated gloves and shoes while operating or performing

maintenance on the system.

• Make sure the system is switched off at the wall disconnect

before servicing the power supply or torch.

• Never change torch consumable parts unless main power to the

system is switched off at the power supply or wall disconnect.

• Do not attempt to remove any parts from beneath the torch

when cutting. Remember that the workpiece forms the current

path back to the power supply.

• Never bypass the safety interlock devices.

• Before removing any of the covers, switch the system off at the

wall disconnect. Wait at least five (5) minutes before removing

any cover. This will give the capacitors inside the unit time to

discharge. See Section 5 for additional safety precautions.

• Never operate the system without all of the covers in place. See

Section 5 for additional safety precautions.

• Preventive maintenance should be performed daily to avoid

possible safety hazards.

FlexCut®200 CE SAFETY

FlexCut®200 CE

FIRE PREVENTION

When using the system , it is necessary to exercise good

judgment. While cutting, the arc produces sparks that could cause

a fire if they fall on flammable materials. Make sure that all

flammable materials are a suitable distance away from the cutting

area. All flammable liquids should be at least 40 feet away from

the cutting area, preferably stored in a metal cabinet. Plasma

cutting should never be attempted on containers that contain

flammable materials. Make sure that fire extinguishers are readily

accessible in the cutting area.

EXPLOSION PREVENTION

The system uses compressed gases. Use proper

techniques when handling compressed gas cylinders and other

compressed gas equipment. Observe the following guidelines to

protect against explosion:

• Never operate the system in the presence of explosive gases

or other explosive materials.

• Never cut pressurized cylinders or any closed container.

• When using a water table and cutting aluminum under water

or with water touching the underside at the aluminum plate,

hydrogen gas is produced. This hydrogen gas may collect

under the plate and explode during the cutting process. Make

sure the water table is properly aerated to help prevent the

accumulation of hydrogen gas.

• Handle all gas cylinders in accordance with safety standards

published by the U.S. Compressed Gas Association (CGA),

American Welding Society (AWS), Canadian Standards

Association (CSA), or other local or national codes.

• Compressed gas cylinders should be maintained properly.

Never attempt to use a cylinder that is leaking, cracked, or

has other signs of physical damage.

• All gas cylinders should be secured to a wall or rack to

prevent accidental knock over.

• If a compressed gas cylinder is not being used, replace the

protective valve cover.

• Never attempt to repair compressed gas cylinders.

• Keep compressed gas cylinders away from intense heat,

sparks, or flames.

• Clear the compressed gas cylinder connection point by

opening the valve momentarily prior to installing a regulator.

• Never lubricate compressed gas cylinder valves or pressure

regulators with any type of oil or grease.

• Never use a compressed gas cylinder or pressure regulator

for any purpose other than which it is intended.

• Never use a pressure regulator for any gas other than which it

is intended.

• Never use a pressure regulator that is leaking or has other

signs of physical damage.

• Never use any gas hose that is leaking or has other signs of

physical damage.

HEALTH SUPPORT EQUIPMENT

The system creates electric and magnetic fields

that may interfere with certain types of health

support equipment, such as pacemakers. Any person who uses a

pacemaker or similar item should consult a doctor before

operating, observing, maintaining, or servicing the system.

Observe the following guidelines to minimize exposure to these

electric and magnetic fields:

• Stay as far away from the~power supply, torch, and torch

leads as possible.

• Route the torch leads as close as possible to the work ground

cable.

• Never place your body between the torch leads and work

ground cable. Keep the work ground cable and the torch

leads on the same side of your body.

• Never stand in the center of a coiled up set of torch leads or

work ground cable.

SAFETY

FlexCut®200 CE

Safety Standards Booklet Index

For further information concerning safety practices to be exercised

with plasma arc cutting equipment, please refer to the following

publications:

1. AWS Standard AWN, Arc Welding and Cutting Noise, obtainable

from the American Welding Society, 550 NW LeJeune Road,

Miami, FL 33126.

2. AWS Standard C5.2, Recommended Practices for Plasma Arc

Cutting, obtainable from the American Welding Society, 550 NW

LeJeune Road, Miami, FL 33126.

3. AWS Standard FSW, Fire Safety in Welding and Cutting,

obtainable from the American Welding Society, 550 NW

LeJeune Road, Miami, FL 33126.

4. AWS Standard F4.1, Recommended Safe Practices for

Preparation for Welding and Cutting of Containers and Piping,

obtainable from the American Welding Society, 550 NW

LeJeune Road, Miami, FL 33126.

5. AWS Standard ULR, Ultraviolet Reflectance of Paint, obtainable

from the American Welding Society, 550 NW LeJeune Road,

Miami, FL 33126.

6. AWS I ANSI Standard Z49.1, Safety in Welding, Cutting, and

Allied Processes, obtainable from the American Welding

Society, 550 NW LeJeune Road, Miami, FL 33126.

7. ANSI Standard Z41.1 , Standard For Men's Safety-Toe

Footwear, obtainable from the American National Standards

Institute, 11 West 42nd Street, New York, NY 10036.

8. ANSI Standard Z49.2, Fire Prevention in the Use of Cutting and

Welding Processes, obtainable from the American National

Standards Institute, 11 West 42nd Street, New York, NY 10036.

9. ANSI Standard Z87.1, Safe Practices For Occupation and

Educational Eye and Face Protection, obtainable from the

American National Standards Institute, 11 West 42nd Street,

New York, NY 10036.

10. ANSI Standard Z88.2, Respiratory Protection, obtainable from

the American National Standards Institute, 11 West 42nd

Street, New York, NY 10036.

11. OSHA Standard 29CFR 1910.252, Safety and Health

Standards, obtainable. from the U.S. Government Printing

Office, Washington, D.C. 20402.

12. NFPA Standard 51 , Oxygen - Fuel Gas Systems for Welding,

Cutting, and Allied Processes, obtainable from the National

Fire Protection Association, 1 Batterymarch Park, Quincy, MA

02269.

13. NFPA Standard 51 B, Cutting and Welding Processes,

obtainable from the National Fire Protection Association, 1

Batterymarch Park, Quincy, MA 02269.

14. NFPA Standard 70, National Electrical Code, obtainable from

the National Fire Protection Association, 1 Batterymarch Park,

Quincy, MA 02269.

15. CGA booklet P-1 , Safe Handling of Compressed Gases in

Containers, obtainable from the Compressed Gas Association,

1725 Jefferson Davis Highway, Suite 1004, Arlington, VA

22202.

16. CGA booklet P-14, Accident Prevention in Oxygen-Rich and

Oxygen-Deficient Atmospheres, obtainable from the

Compressed Gas Association, 1725 Jefferson Davis Highway,

Suite 1004, Arlington, VA 22202.

17. CGA booklet TB-3, Hose Line Flashback Arrestors, obtainable

from the Compressed Gas Association, 1725 Jefferson Davis

Highway, Suite 1004, Arlington, VA 22202.

18. CSA Standard W117 .2, Safety in Welding, Cutting, and Allied

Processes, obtainable from Canadian Standards Association,

178 Rexdale Boulevard, Toronto, Ontario M9W IR3, Canada.

19. Canadian Electrical Code Part 1, Safety Standard for Electrical

Installations, obtainable from the Canadian Standards

Association, 178 Rexdale Boulevard, Toronto, Ontario M9W 1

R3, Canada.

SAFETY

Other manuals for FLEXCUT 200 CE

Table of contents

Other Lincoln Electric Welding System manuals

Lincoln Electric

Lincoln Electric VANTAGE 575 CUMMINS User manual

Lincoln Electric

Lincoln Electric RED-D-ARC LN-25 PRO EXTREME User manual

Lincoln Electric

Lincoln Electric POWER WAVE IM808-A User manual

Lincoln Electric

Lincoln Electric Aspect 230 DC User manual

Lincoln Electric

Lincoln Electric Vantage 580 11657 User manual

Lincoln Electric

Lincoln Electric OPTIMARC AC/DC 350-TP User manual

Lincoln Electric

Lincoln Electric LF 52D User manual

Lincoln Electric

Lincoln Electric Idealarc R3R-400 User manual

Lincoln Electric

Lincoln Electric SAE-400 SEVERE DUTY IM727 User manual

Lincoln Electric

Lincoln Electric Red-D-Arc EX350i User manual

Lincoln Electric

Lincoln Electric SVM143-A User manual

Lincoln Electric

Lincoln Electric MIG-PAK 15 User manual

Lincoln Electric

Lincoln Electric FlexCut 125 CCC User manual

Lincoln Electric

Lincoln Electric POWER WAVE SVM173-A User manual

Lincoln Electric

Lincoln Electric PRO-CUT 25 User manual

Lincoln Electric

Lincoln Electric CV-655 User manual

Lincoln Electric

Lincoln Electric POWER WAVE R450 User manual

Lincoln Electric

Lincoln Electric COMMANDER SVM153-A User manual

Lincoln Electric

Lincoln Electric RANGER 250 LPG IM931 User manual

Lincoln Electric

Lincoln Electric outback 185 User manual

Lincoln Electric

Lincoln Electric PIPELINER 200D KUBOTA User manual

Lincoln Electric

Lincoln Electric IDEALARC R3R 600-I User manual

Lincoln Electric

Lincoln Electric CLASSIC SVM194-A User manual

Lincoln Electric

Lincoln Electric SAE-300 HE User manual

Popular Welding System manuals by other brands

Berner

Berner PLASMACUT 54 instruction manual

Pro Spot

Pro Spot PR-155 Assembly instructions

Forney

Forney 210 operating manual

Thermal Arc

Thermal Arc 400S operating manual

GYS

GYS PROTIG 201 AC/DC Original instructions

TAFA

TAFA 30*8B35 owner's manual

ESAB

ESAB Buddy Arc 145 instruction manual

CIGWELD

CIGWELD 636804 use instructions

Red-D-Arc

Red-D-Arc DC-400 Operator's manual

Hobart Welding Products

Hobart Welding Products Spool Gun DP 3035-10 owner's manual

Elettro

Elettro HI-MIG 3000 SYNERGIC instruction manual

WIA

WIA Weldmatic 270 CP132-2 Operator's manual

Sonics

Sonics H520T instruction manual

Miller

Miller Big Blue 400D owner's manual

NewArc

NewArc RT2000 Operational manual

Hypertherm

Hypertherm powermax1000 Operator's manual

Everlast

Everlast POWER MTS 221STi Operator's manual

Kipor

Kipor KDE180XW Operator's manual
