Lincoln Electric CITOCUT 25i User manual

IM3121

11/2020

REV03

CITOCUT 25i

OPERATOR’S MANUAL

MANUALE OPERATIVO

BEDIENUNGSANLEITUNG

MANUAL DE INSTRUCCIONES

MANUEL D'UTILISATION

BRUKSANVISNING OG DELELISTE

GEBRUIKSAANWIJZING

BRUKSANVISNING

INSTRUKCJA OBSŁUGI

KÄYTTÖOHJE

MANUAL DE INSTRUÇÕES

ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ

Lincoln Electric Bester Sp. z o.o.

ul. Jana III Sobieskiego 19A, 58-260 Bielawa, Poland

IM3121

11/2020

REV03

CITOCUT 25i

OPERATOR’S MANUAL

ENGLISH

Lincoln Electric Bester Sp. z o.o.

ul. Jana III Sobieskiego 19A, 58-260 Bielawa, Poland

English English

12/05

THANKS! For having choosen the QUALITY of the Lincoln Electric products.

Please Examine Package and Equipment for Damage. Claims for material damaged in shipment must be notified

immediately to the dealer.

For future reference record in the table below your equipment identification information. Model Name, Code &

Serial Number can be found on the machine rating plate.

Model Name:

………………...…………………………….…………………………………………………………………………………………..

Code & Serial number:

………………….……………………………………………….. …………………………………………………….……………..

Date & Where Purchased:

…………………………………………………………………... ……………………….…………………………………………..

ENGLISH INDEX

Technical Specifications...................................................................................................................................................... 1

ECO design information ...................................................................................................................................................... 2

Electromagnetic Compatibility (EMC).................................................................................................................................. 4

Safety.................................................................................................................................................................................. 5

Installation and Operator Instructions.................................................................................................................................. 7

WEEE ............................................................................................................................................................................... 13

Spare Parts ....................................................................................................................................................................... 13

REACh .............................................................................................................................................................................. 13

Authorized Service Shops Location .................................................................................................................................. 13

Electrical Schematic.......................................................................................................................................................... 13

English English

Technical Specifications

NAME INDEX

CITOCUT 25i W000404424

INPUT

Input Voltage Input Power at Rated Output EMC Class Frequency

230 V ±10%

Single Phase

2 kW @ 100% Duty Cycle

A 50Hz

2.5 kW @ 60% Duty Cycle

3 kW @ 35% Duty Cycle

RATED OUTPUT AT 40°C

Duty Cycle

(Based on a 10 min. period) Output Current Output Voltage

100% 15 A 86 Vdc

60% 20 A 88 Vdc

35% 25 A 90 Vdc

OUTPUT RANGE

Cutting Current Range Maximum Open Circuit Voltage Pilot Arc Current

10 - 25 A 500 Vdc 12 A

EXTERNAL INLET COMPRESSED AIR

Required Inlet Flow Rate Required Inlet Pressure

80 ±20% l/min @ 5.0bar 6.0bar - 7.5bar

RECOMMENDED INPUT CABLE AND FUSE SIZES

Fuse (delayed) or Circuit Breaker

(“D” characteristic) Size

Type of Plug

(Included with Machine) Input Power Cable

16 A SCHUKO 16A / 250V 3 x 1.5 mm2

PHYSICAL DIMENSIONS

Height Width Length

(case only,without torch) Weight

385 mm 215 mm 480 mm 18 – 18.5 kg

Operating Temperature Storage Temperature

-10°C to +40°C -10°C to +40°C

English English

ECO design information

The equipment has been designed in order to be compliant with the Directive 2009/125/EC and the Regulation

2019/1784/EU.

Efficiency and idle power consumption:

Index Name Efficiency when max power

consumption / Idle power consumption Equivalent model

W000404424 CITOCUT 25i 83,7% / 58W No equivalent model

Idle state occurs under the condition specified in below table:

IDLE STATE

Condition Presence

MIG mode

TIG mode

STICK mode

After 30 minutes of non-working X

Fan off

The value of efficiency and consumption in idle state have been measured by method and conditions defined in the

product standard EN 60974-1:20XX.

Manufacturer’s name, product name, code number, product number, serial number and date of production can be read

from rating plate.

XXXXXXXXXX

Code: XXXXX XXXXXX-X

S/N: P1YYMMXXXXX

P1 YY MM XXXXX

5A5A 5B 5D5C

XXXXXXX

Where:

1- Manufacturer name and address

2- Product name

3- Code number

4- Product number

5- Serial number

5A- country of production

5B- year of production

5C- month of production

5D- progressive number different for each machine

English English

Typical gas usage for MIG/MAG equipment:

Material type

Wire

diameter

[mm]

DC electrode positive Wire Feeding

[m/min] Shielding Gas Gas flow

[l/min]

Current

[A]

Voltage

[V]

Carbon, low

alloy steel 0,9 ÷ 1,1 95 ÷ 200 18 ÷ 22 3,5 – 6,5 Ar 75%, CO225% 12

Aluminium 0,8 ÷ 1,6 90 ÷ 240 18 ÷ 26 5,5 – 9,5 Argon 14 ÷ 19

Austenic

stainless steel 0,8 ÷ 1,6 85 ÷ 300 21 ÷ 28 3 - 7 Ar 98%, O22% /

He 90%, Ar 7,5% CO22,5% 14 ÷ 16

Copper alloy 0,9 ÷ 1,6 175 ÷ 385 23 ÷ 26 6 - 11 Argon 12 ÷ 16

Magnesium 1,6 ÷ 2,4 70 ÷ 335 16 ÷ 26 4 - 15 Argon 24 ÷ 28

Tig Process:

In TIG welding process, gas usage depends on cross-sectional area of the nozzle. For comonnly used torches:

Helium: 14-24 l/min

Argon: 7-16 l/min

Notice: Excessive flow rates causes turbulence in the gas stream which may aspirate atmospheric contamination into

the welding pool.

Notice: A cross wind or draft moving can disrupt the shielding gas coverage, in the interest of saving of protective gas

use screen to block air flow.

End of life

At end of life of product, it has to be disposal for recycling in accordance with Directive 2012/19/EU (WEEE), information

about the dismantling of product and Critical Raw Material (CRM) present in the product, can be found at

https://www.lincolnelectric.com/en-gb/support/Pages/operator-manuals-eu.aspx

English English

Electromagnetic Compatibility (EMC)

01/11

This machine has been designed in accordance with all relevant directives and standards. However, it may still generate

electromagnetic disturbances that can affect other systems like telecommunications (telephone, radio, and television) or

other safety systems. These disturbances can cause safety problems in the affected systems. Read and understand

this section to eliminate or reduce the amount of electromagnetic disturbance generated by this machine.

This machine has been designed to operate in an industrial area. The operator must install and operate this

equipment as described in this manual. If any electromagnetic disturbances are detected the operator must

put in place corrective actions to eliminate these disturbances with, if necessary, assistance from Lincoln

Electric. This machine is not in accordance with IEC 61000-3-12. If it is powered by a low voltage public

distribution network in the connection responsibility of the installer or user of equipment, consultation, if necessary, with

the electricity service distributor.

Before installing the machine, the operator must check the work area for any devices that may malfunction because of

electromagnetic disturbances. Consider the following.

Input and output cables, control cables, and telephone cables that are in or adjacent to the work area and the

machine.

Radio and/or television transmitters and receivers. Computers or computer controlled equipment.

Safety and control equipment for industrial processes. Equipment for calibration and measurement.

Personal medical devices like pacemakers and hearing aids.

Check the electromagnetic immunity for equipment operating in or near the work area. The operator must be sure

that all equipment in the area is compatible. This may require additional protection measures.

The dimensions of the work area to consider will depend on the construction of the area and other activities that are

taking place.

Consider the following guidelines to reduce electromagnetic emissions from the machine.

Connect the machine to the input supply according to this manual. If disturbances occur if may be necessary to take

additional precautions such as filtering the input supply.

The output cables should be kept as short as possible and should be positioned together. If possible connect the

work piece to ground in order to reduce the electromagnetic emissions. The operator must check that connecting the

work piece to ground does not cause problems or unsafe operating conditions for personnel and equipment.

Shielding of cables in the work area can reduce electromagnetic emissions. This may be necessary for special

applications.

WARNING

The Class A equipment is not intended for use in residential locations where the electrical power is provided by the public

low-voltage supply system. There can be potential difficulties in ensuring electromagnetic compatibility in those locations,

due to conducted as well as radio-frequency disturbances.

English English

Safety

01/11

WARNING

This equipment must be used by qualified personnel. Be sure that all installation, operation, maintenance and repair

procedures are performed only by qualified person. Read and understand this manual before operating this equipment.

Failure to follow the instructions in this manual could cause serious personal injury, loss of life, or damage to this

equipment. Read and understand the following explanations of the warning symbols. Lincoln Electric is not responsible

for damages caused by improper installation, improper care or abnormal operation.

WARNING: This symbol indicates that instructions must be followed to avoid serious personal injury,

loss of life, or damage to this equipment. Protect yourself and others from possible serious injury or

death.

READ AND UNDERSTAND INSTRUCTIONS: Read and understand this manual before operating this

equipment. Plasma cutting or gouging can be hazardous. Failure to follow the instructions in this

manual could cause serious personal injury, loss of life, or damage to this equipment.

ELECTRIC SHOCK CAN KILL: Welding equipment generates high voltages. Do not touch the

electrode, work clamp, or connected work pieces when this equipment is on. Insulate yourself from the

electrode, work clamp, and connected work pieces.

ELECTRICALLY POWERED EQUIPMENT: Turn off input power using the disconnect switch at the

fuse box before working on this equipment. Ground this equipment in accordance with local electrical

regulations.

ELECTRIC AND MAGNETIC FIELDS MAY BE DANGEROUS: Electric current flowing through any

conductor creates electric and magnetic fields (EMF). EMF fields may interfere with some pacemakers,

and welders having a pacemaker shall consult their physician before operating this equipment.

CE COMPLIANCE: This equipment complies with the European Community Directives.

ARTIFICIAL OPTICAL RADIATION: According with the requirements in 2006/25/EC Directive and

EN 12198 Standard, the equipment is a category 2. It makes mandatory the adoption of Personal

Protective Equipments (PPE) having filter with a protection degree up to a maximum of 15, as required

by EN169 Standard.

WORK MATERIALS CAN BURN: Cutting generates a large amount of heat. Hot surfaces and

materials in work area can cause serious burns. Use gloves and pliers when touching or moving

materials in the work area.

EQUIPMENT WEIGHT OVER 30kg: Move this equipment with care and with the help of another

person. Lifting may be dangerous for your physical health.

CYLINDER MAY EXPLODE IF DAMAGED: Use only compressed gas cylinders containing the correct

shielding gas for the process used and properly operating regulators designed for the gas and pressure

used. Always keep cylinders in an upright position securely chained to a fixed support. Do not move or

transport gas cylinders with the protection cap removed. Do not allow the torch, work clamp or any

other electrically live part to touch a gas cylinder. Gas cylinders must be located away from areas

where they may be subjected to physical damage or the cutting process including sparks and heat

sources.

English English

Cutting sparks can cause explosion or fire. Keep

flammables away from cutting. Do not cut near

flammables. Have a fire extinguisher nearby, and have

a watch person ready to use it. Do not cut on drums or

any closed container.

The plasma arc can cause injury and burns. Keep your

body away from nozzle and plasma arc. Turn off

power before disassembling torch. Do not grip material

near cutting path. Wear complete body protection.

Electric shock from torch or wiring can kill. Wear dry

insulating gloves. Do not wear wet or damaged gloves.

Protect yourself from electric shock by insulating

yourself from work and ground. Disconnect input plug

or power before working on machine.

Breathing cutting fumes can be hazardous to your

health. Keep your head out of the fumes. Use forced

ventilation or local exhaust to remove the fumes. Use

ventilating fan to remove fumes.

Arc rays can burn eyes and injure skin. Wear hat and

safety glasses. Use ear protection and button shirt

collar. Use welding helmet with correct shade of filter.

Wear complete body protection.

Become trained and read the instructions before

working on the machine or cutting.

Do not remove or paint over (cover) the label.

SAFETY MARK: This equipment is suitable for supplying power for cutting operations carried out in an

environment with increased hazard of electric shock.

The manufacturer reserves the right to make changes and/or improvements in design without upgrade at the same time

the operator’s manual.

This manual suits for next models

Table of contents

Languages:

Other Lincoln Electric Welding System manuals

Lincoln Electric

Lincoln Electric SQUARE WAVE IM687 User manual

Lincoln Electric

Lincoln Electric VANTAGE 500 DEUTZ IM805 User manual

Lincoln Electric

Lincoln Electric RANGER IM929 User manual

Lincoln Electric

Lincoln Electric INVERTEC V350-PRO CE User manual

Lincoln Electric

Lincoln Electric RANGER 305LPG User manual

Lincoln Electric

Lincoln Electric 12270 User manual

Lincoln Electric

Lincoln Electric VANTAGE 410 CE User manual

Lincoln Electric

Lincoln Electric K3972-3 User manual

Lincoln Electric

Lincoln Electric BIG RED IM10019 User manual

Lincoln Electric

Lincoln Electric EASY-MIG 180 User manual

Lincoln Electric

Lincoln Electric LINC 405-S User manual

Lincoln Electric

Lincoln Electric MAGNUM 200FM User manual

Lincoln Electric

Lincoln Electric Vantage 435X User manual

Lincoln Electric

Lincoln Electric Prism 13264 User manual

Lincoln Electric

Lincoln Electric 10630 User manual

Lincoln Electric

Lincoln Electric POWER MIG 140 User manual

Lincoln Electric

Lincoln Electric Airgas RED-D-ARC DX500e User manual

Lincoln Electric

Lincoln Electric REDI-MIG 325 Remote User manual

Lincoln Electric

Lincoln Electric RANGER IM612 User manual

Lincoln Electric

Lincoln Electric COOL ARC 35 IM959 User manual

Lincoln Electric

Lincoln Electric INVERTEC V310-T AC/DC User manual

Lincoln Electric

Lincoln Electric Fleet 400 User manual

Lincoln Electric

Lincoln Electric POWER-ARC 4000 SVM103-A User manual

Lincoln Electric

Lincoln Electric INVERTEC V205-T AC/DC TIG User manual

Popular Welding System manuals by other brands

Berner

Berner PLASMACUT 54 instruction manual

Pro Spot

Pro Spot PR-155 Assembly instructions

Forney

Forney 210 operating manual

Thermal Arc

Thermal Arc 400S operating manual

GYS

GYS PROTIG 201 AC/DC Original instructions

TAFA

TAFA 30*8B35 owner's manual

ESAB

ESAB Buddy Arc 145 instruction manual

CIGWELD

CIGWELD 636804 use instructions

Red-D-Arc

Red-D-Arc DC-400 Operator's manual

Hobart Welding Products

Hobart Welding Products Spool Gun DP 3035-10 owner's manual

Elettro

Elettro HI-MIG 3000 SYNERGIC instruction manual

WIA

WIA Weldmatic 270 CP132-2 Operator's manual

Sonics

Sonics H520T instruction manual

Miller

Miller Big Blue 400D owner's manual

NewArc

NewArc RT2000 Operational manual

Hypertherm

Hypertherm powermax1000 Operator's manual

Everlast

Everlast POWER MTS 221STi Operator's manual

Kipor

Kipor KDE180XW Operator's manual
